X6I-KW9177TTHERMO SENSOR

KW9075RFwithoutdoorcableprobe  WWVB 1.Features: RadiocontrolledclockwithWWVBsignal. 433MHzRFreceivingfrequency. PerpetualCalendarUptoYear2099. 12/24Hourtimedisplayselectable. Dailysnoozealarmfunction IndoorTemperaturemeasurement:range32F~122F OutdoorTemperaturemeasurement:range58F~+158F  2.MainUnitAppearance:  PARTA: A1:RadioControlledTime. A2:RadioControlledIcon A3:AlarmIcon A4:Second A5:IndoorTemperature A6:Date&DayofWeek A7:OutdoorTemperature  PARTB: B1:“SNOOZE”Button B2:“+/12/24”Button B3:“MODE/SET”Button B4:“/C/F/  “Button B5:“RESET”Button B6:“ALON/OFF”Button B7:“ALERT”Button B8:“SEARCH”Button PARTC  433.92MHz RF receiving frequency. C1:WallMountHole  C2:BatteryCompartmentCover  C3:Stand 3.OutdoorSensorAppearance.   D1:TransmissionIndicationLED D2:OutdoorTemperature D3:BatteryCompartment D4:WallMountHole D5:“RESET”button  D6:°C/°F”button  D7:Stand D8:Cableprobe  4.GettingStarted: 4.1MainUnit: Openmainunitbatterycompartmentcover[C2] Insert3xCsizebatteriesobservingpolarity[“+”and“–“marks] Replacemainunitbatterycompartmentcover[C2] UseapintopresstheRESET[B5]buttonontherearofthemainunit,themain unitisnowreadyforuse  4.2OutdoorThermoSensor Battery compartment (D3) of thermo sensor is locating behind the backcover, unscrewsthebatteriescovertoopen. Insert2xAAAbatteriesobservingpolarity[“+”and“–“marks]   5.Installation 5.1MainUnit Themainunitcanbeplacedontoanyflatsurface(C3),orwallmountedbythe hanginghole(C1)atthebackoftheunit.   5.2OutdoorThermosensor Theremotesensorshouldbesecurelymountedontoahorizontalsurface.  Note:Transmissionsbetweenreceiverandtransmittercanreachupto100min openarea.  OpenArea:therearenointerferingobstaclessuchasbuildings, trees,vehicles,highvoltagelines,etc.   6.RFTransmission The main unit automatically starts receiving transmission from outdoor thermo sensorforoutdoortemperatureafterbatteriesinserted.RFicon“”flasheson theLCD. The thermo sensor unit will automatically transmit temperature signal to the mainunitafterbatteriesinserted.  Ifmainunitfailedtoreceivetransmissionfromoutdoorthermosensorinfirst3 minutesafterthebatteriesinserted,“.–”displayontheLCD. Hold“SEARCH”button(B8)for3secondstoreceivetransmissionmanually.  Press “C/F” button (D5) on thermo sensor unit to select temperature to be displayedinCelsiusmodeorFahrenheitmode.  7.TimeandAlarmSetting 7.1RadioControlledClock: After batteries inserted and main unit finishes receiving the transmission from outdoor thermo sensor, the clock automatically starts to scan the WWVB time signal.RadioControlIcon“ ”flashesontheLCD. flashes, Indicatingnowisreceiving WWVBsignal turnson, Indicatingsignalreceived successfully  disappear, Indicatingsignalreception failed The clock automatically scans the time signal at 2.00 a.m. every day tomaintain accurate timing. If reception fail, scanning stops (“ ” on LCD disappear) and repeatsagainat3.00a.m.,4.00a.m.and5.00am. Theclockcanbesettoscanthetimesignalmanuallybyholding“ ”button(B4) for 3 seconds. Each reception takes around several minutes. If receptions fail, scanningstops.(“ ”onLCDdisappear)andrepeatsagainonnextfullhour.E.g. scanningfailedat8:20a.m.Itwillscanagainat9:00a.m. Stopscanningbyholding“”button(B4)for3seconds.  7.2ManualTimeSetting: In time display mode, hold “MODE” button (B3) for 3 seconds to enter Clock/CalendarsettingMode. Press “+” (B2) or “” (B4) button to adjust the setting and press “MODE” button (B3)toconfirmeachsetting. (Bykeepingthe“ +”(B2)or“”(B4)buttonpressed,couldacceleratetheprocess andreachthedesiredvaluemorequickly) Thesettingsequenceisshownasfollow:Hour,Minute,Second,Year,Month/Day sequence,Month,Date,DST Note:  (1) All Setting mode will automatically exit in around 15 seconds without any adjustment (2) ForTimeZone:thedefaultsettingiszone“E”.Byholding“+”(B2)buttonfor3 secondstoadjusttootherzones“P”“M”or“C”. (3) DST:WhenDSTfunctionisactivated,andit’sinDaylightSavingMode(RCCsignal withDST)“DST”wouldbeshownontheLCD.  7.3DailyAlarmFunction: Press “MODE” button (B3) to select to view alarm Time, “AL” shown on the display WhenviewingtheAlarmTime,hold“MODE”button(B3)for3secondstoenter Alarm Time setting. Press “+” (B2) or “” (B4) button to adjust the alarm time. Press“MODE”button(B3)toconfirmthesetting.  7.4SnoozeAlarmFunction: Press“ALON/OFF”Button(B6)toactivateordeactivatethealarm.Ifthealarmis on,alarmicon" "appearsonthedisplay. Whenalarmalerts,except“SNOOZE”button,pressanybuttontostopthealarm. Otherwise, the alarm signal sounds for about2 minutes, then stops automatically. Press “SNOOZE” (B1) button when alarm alerts. The alarm snoozes for around 5 minutes, then it alerts again. “ ” flashes on the LCD during the snooze time. Thisprocesscanberepeated7times.   7.5  12/24HourDisplaymode: Press“12/24”(B2)buttontoselect12or24hoursmode.   8.Thermometer 8.1Temperaturedisplay Press “°C/°F” (B4) button to select Temperature in Celsius mode/ Fahrenheit mode. If the temperature is out of…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTSE14070133301 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover PageFCC REPORT Applicant: CARRIN ELECTRONICS COMPANY LIMITED Address of Applicant: UNIT 2105-2106, TOWER A, REGENT CENTRE, 63 WO YI H HONG KONG Equipment Under Test (EUT) Product Name: THERMO SENSOR Model No.: KW9177T FCC ID: X6I-KW9177T Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231:2013 Date of sample receipt: July 30, 2014 Date of Test: July 30-August 04, 2014 Date of report issue: August 04, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE14070133301 Global United Technology Services Co., Ltd. Project No.: GTSE140701333RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 27 2 Version Version No. Date Description 00 August 04, 2014 Original Prepared by: Date: August 04, 2014 Project Engineer Reviewed by: Date: August 04, 2014 Reviewer Report No.: GTSE14070133301 Global United Technology Services Co., Ltd. Project No.: GTSE140701333RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 27 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION .......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE ........................................................................................................................................ 5 5.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.5 TEST FACILITY .................................................................................................................................... 6 5.6 TEST LOCATION .................................................................................................................................. 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 8 7.1 ANTENNA REQUIREMENT: .................................................................................................................... 8 7.2 RADIATED EMISSION ........................................................................................................................... 9 7.2.1 Field Strength Of The Fundamental Signal ............................................................................... 11 7.2.2 Spurious Emissions ................................................................................................................... 13 7.3 20DB BANDWIDTH ............................................................................................................................ 16 7.4 DWELL TIME ..................................................................................................................................... 17 7.5 SILENT PERIOD ................................................................................................................................. 18 8 TEST SETUP PHOTO ............................................................................................................................ 19 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 20 Report No.: GTSE14070133301 Global United Technology Services Co., Ltd. Project No.: GTSE140701333RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 …

Text truncated - open the document above for the full version.

Radiated Emission
