Wi-Drive Installation Manual © Dension Audio Systems 1(26) Installation Manual Document version: 1.03 Rev 3. March 2010 Dension Wi-Drive Version: WID11GEN (Firmware 1.03) The installation procedure of Wi-Drive is a relatively simple process, however the end result is strongly depends on the details. So please read carefully and follow the instructions of this document. Wi-Drive Installation Manual © Dension Audio Systems 2(26) Contents Contents ............................................................................................................................... 2 1 Introduction................................................................................................................. 3 1.1 About Dension Wi-Drive......................................................................................... 3 1.2 Block diagram ........................................................................................................ 4 1.3 Device connections and indicators ......................................................................... 4 1.4 Wi-Drive Utility Software ........................................................................................ 5 2 Physical Installation of the device into the car......................................................... 5 2.1 POWER CONNECTION FOR TEMPORARY INSTALLATION............................... 5 2.2 POWER CONNECTION FOR PERMANENT INSTALLATION............................... 6 2.3 WI-FI ANTENNA CONNECTION AND PLACEMENT ............................................ 6 2.4 Test your physical Installation - Part1: Wi-Fi connection ........................................ 8 2.5 USB CONNECTION (MP3 playback) ..................................................................... 9 2.6 Test your physical Installation – Part2: MP3 playback............................................ 9 3 In-vehicle Internet Access Point Application, 3G configuration.............................. 9 3.1 OPTION1: 3G USB dongle setup......................................................................... 10 3.2 OPTION2 A: 3G Phone connected with USB cable setup .................................... 13 3.3 OPTION2 B: 3G Phone connected via Bluetooth PAN setup ............................... 13 3.4 OPTION2 C: 3G Phone connected via Bluetooth DUN setup............................... 15 4 Wireless Content Synchronisation Setup and Configuration................................ 16 4.1 USB Mass Storage Synchronisation with Wi-Drive Utility ..................................... 16 4.2 USB Mass Storage Synchronisation from shared folders (Samba) ...................... 21 5 Internet Radio Application and Configuration ........................................................ 22 6 Quick reference guide .............................................................................................. 24 Wi-Drive Installation Manual © Dension Audio Systems 3(26) 1 Introduction 1.1 About Dension Wi-Drive A secure mobile HotSpot By plugging in a 3G USB dongle, or via your Bluetooth 3G Phone, your car can become a secure Access Point, giving Internet access to any Wi-Fi device (iPod, iPhone, laptop, etc.) in the vehicle. Passengers can check their email, kids can surf the net; you can make Skype calls, the world is literally at your fingertips. Wireless content synchronisation Dension Wi-Drive allows a vehicle to become part of your home or office wireless network. When the vehicle is parked within your WLAN's coverage area, Wi-Drive can be set to regularly connect with your home computer, and automatically and wirelessly synchronize your car's device (USB disk, Pendrive, iPod 1 ) with the multimedia content on your home PC. Internet Radio By using the 3G connection, Wi-Drive can make your original car stereo to play Internet radio stations. Open Platform Based on the Dension Wi-Drive platform new software applications can offer more and more interesting applications, such as Internet radio, e-mail access, and many more. Visit www.dension.com/widrive in order to get the latest news and feature improvements on Dension Wi-Drive. 1 Requires separate software. Wi-Drive Installation Manual © Dension Audio Systems 4(26) 1.2 Block diagram 1. Figure: Block diagram 1.3 Device connections and indicators 2. Figure: Device connections and indicators Front Push button: Change operating mode, reboot the device (see chapter 6.) Status LED: indicate status of the device (see chapter 6.) Signal LED: indicate signal level in Station mode (see chapter 6.) USB Extension: USB ports for 3G and Bluetooth modems, Internet radio configuration pendrive USB Storage: USB port for hard disk, pendrive Note, the slide switch is not used Wi-Drive Installation Manual © Dension Audio Systems 5(26) Rear Antenna 1,2: Wi-Fi antenna connections Power: 12 Volts power connection Car USB: USB connection to the car 1.4 Wi-Drive Utility Software Wi-Drive Utility (WDU) is a software tool which runs on your home or office computer to set Wi-Drive connection parameters and manage downloads. Normally WDU runs in the background, and it automatically detects, when Wi-Drive is connecting. WDU informs you with a popup message, and it performs automatic synchronization with specified folders, or you can perform manual downloads to Wi-Drive as a Network Attached Storage or via FTP. Of course your computer must be able to establish Wi-Fi connection with Wi-Drive. Your options are: • Use a Wi-Fi router - Wi-Drive should be set as a Station (like a notebook) • Directly with your Wi-Fi laptop/PC - Wi-Drive should be set as an Access Point (AP, like a Wi-Fi Router). 2 Physical Installation of the device into the car Wi-Drive is usually installed in the glove box or in the armrest compartment. Use the provided fastening tapes to fix your device. Make sure that you have sufficient space on the front and on the back for the USB devices (Flash drive, 3G modem, etc.) and for the Wi-Fi antenna. With professional installation you can hide away th…

Text truncated - open the document above for the full version.

Operational Description © Dension Audio Systems 4(4) Power connector: to connect 12V power supply. 64Mbit Flash: memory 256Mbit SDRAM: memory Power management: measures power levels and operate LED, Pushbutton. Backup power supply: backup power supply Main power supply: to supply +5V, +3.3V and +1.3V for operation Microprocessor: main controller PCI USB controller: USB controller for USB hosts PCI WiFi card: wireless card USB device connector: connector for USB storage device USB host connector: connector for USB hosts WiFi antenna: WiFi antenna connection. Manufacturer: 2J Type: 2J510F Gain: 2.14dBi The device does not have ground system.

Labeling Information © Dension Audio Systems 1(2) Labeling Information Document version: 1. Rev 1 February 2010 Dension Wi-Drive Version: WID11GEN Labeling Information © Dension Audio Systems 2(2) 1 Label information and location Image shows bottom of the device. Device size: 12,4 x 9,2 cm Label size: 4,8 x 2,4 cm FCC ID: X6LWID11GEN IC: 8791A-WID11GEN This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received,including interference that may cause undesired operation. 12,4 cm 9,2 cm

MPE Calculations For RF Exposure Requirements Wi-Drive Model: WID11GEN Page 1 of 1 MAXIMUM PERMISSIBLE EXPOSURE FOR SUBPART C 2.4 GHz BAND Calculations Power density at the specific separation: S = PG/(4R 2 π) S = (67.92 * 1.64) / (4 * 20 2 * π) S = 0.022160098 mW/cm 2 (at 20 cm) Limit = 1 mW/cm 2 where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) – 18.32 dBm G = Numeric power gain of the antenna R = distance to the center of the radiation of the antenna (20 cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 1 cm does not exceed the 1 mW/cm 2 . Therefore, the exposure condition is compliant with FCC rules. The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (2.14 dBi/10) G = 1.64

Report Number: B00125D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Wi-Drive Model: WID11GEN Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 23 FCC PART 15, SUBPART B and C TEST REPORT for WI-DRIVE MODEL: WID11GEN Prepared for DENSION AUDIO SYSTEMS SZTREGOVA u. 1. BUDAPEST, HUNGARY, H-1116 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: FEBRUARY 11, 2010 REPORT APPENDICES TOTAL BODY A B C D E PAGES 23 2 2 2 13 44 86 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B00125D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Wi-Drive Model: WID11GEN Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 23 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 5.3 EMI Test Equipment (Continued) 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Channel Number and Frequencies 15 7.2 Antenna Gain 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 17 8.2 6 dB Bandwidth 19 8.3 Peak Output Power 20 8.4 RF Antenna Conducted Test 20 8.5 RF Band Edges 21 8.6 Spectral Density Test 22 9. CONCLUSIONS 23 Report Number: B00125D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Wi-Drive Model: WID11GEN Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 23 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site – 3 Meters Report Number: B00125D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Wi-Drive Model: WID11GEN Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 23 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: Wi-Drive Model: WID11GEN S/N: N/A Product Description: See Expository Statement. Modifications: There were no modifications made to the EUT during the testing. Manufacturer: Dension Audio Systems Sztregova u. 1. Budapest, Hungary, H-1116 Test Dates: January 25, 26, 28; and February 8 and 17, 2010 Test Specifications : EMI requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.247 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B00125D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Wi-Drive Model: WID11GEN Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 23 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz The EUT does not directly or indirectly connect to the AC mains, thus this test was not performed. 2 Spurious Radiated RF Emissions, 10 kHz – 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and CFR Title 47, Part 15, Subpart C, section 15.247(d) Highest reading in relation to spec limit: 42.58 dBuV @ 192.239 MHz (*U = 4.22 dB) 3 Fundamental and Emissions produced by the intentional radiator in non-restricted bands, 10 kHz – 25000 MHz Complies with the relevant requirements of CFR Title 47, Part 15, Subpart C, section 15.247(d) 4 Emissions produced by the intentional radiator in restricted bands, 10 kHz – 25000 GHz Complies wit…
