XDW3652-0001Printer with RFID

Ultra Electronics Manufacturing & Card Systems Waverley House Hampshire Road Granby Estate, Weymouth Dorset DT4 9XD England Telephone 0'1305 767'100 Fax 01305 777904 27-9-11 Telecom m unication Certification Body RFI Global Services Ltd Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England Subject: Certification Appl ication FCC lD: XDW3652-0001 It is requested that the following information is to be held confidential on behalf of Ultra Electronics Card systems. FCC Rules Part 0.459 and 0.457 refers. Schematic Diagrams Block Diagram Part List (BOM) Operational Description The information listed above is confidential information relating to the integrity of the electronic design and to the methods employed to produce ldentity Cards. This information is company confidential and includes our lP regarding certain methods and techniques associated with printing and encoding of cards. lt has only previously been disclosed to UL, CCC. Yoysinyetv - t'4r'"Zo Andy Loveless Senior Mechanical Engineer

MAGICARD RIO PRO EXTERNAL PHOTOGRAPHS Fig 1 - Rio Pro Top View Fig 2 - Rio Pro Bottom View Fig 3 - Right Hand View Fig 4 - Left Hand View Fig 5 - Front view Fig 6 - Rear view

Fig 2 - Rio Pro Bottom View

MAGICARD RIO PRO PHOTOGRAPHS Fig 1 - Main PCB top view – with magnetic encoding pcb fitted. Fig 2 - Main PCB top view – with magnetic encoding pcb removed Fig 3 - Main PCB – Bottom view Fig 4 - Magnetic Encoding PCB – Bottom View Fig 5 - RFID PCB – Top View Fig 6 - RFID PCB - IC Fig 7 - RFID PCB – Bottom Fig 8 - OmniKey View
