XDW5000-0001Card Printer

1 Pronto 100 ID Card Printer User Manual ID Card Printer – User Manual 2 CONTENTS General Information: .......................................................................................................................................... 3 Safety Instructions: ............................................................................................................................................. 3 Caution ............................................................................................................................................................... 3 Printer installation .............................................................................................................................................. 4 Welcome ..................................................................................................................................................... 4 Printer and Dye Film Environmental requirements: ......................................................................................... 5 Printer Key Components ............................................................................................................................... 6 Installing the Dye Film .................................................................................................................................. 7 Connecting the Power Supply ........................................................................................................................ 8 Installing the Driver ............................................................................................................................................ 9 USB Installation .......................................................................................................................................... 11 Ethernet Installation ................................................................................................................................... 14 Accessing the Driver Settings ............................................................................................................................ 18 Printer Front Display Menu Options .................................................................................................................. 19 Maintaining your printer ................................................................................................................................... 23 Caring for your Printer ................................................................................................................................ 23 Cleaning Supplies ....................................................................................................................................... 23 How to Clean your Printer ........................................................................................................................... 24 Using the Cleaning Pen ............................................................................................................................... 25 Choosing the Correct Dye Film .......................................................................................................................... 26 Choosing the correct Cards................................................................................................................................ 27 Card size .................................................................................................................................................... 27 Card thickness ............................................................................................................................................ 27 Card requirements necessary for good quality prints .................................................................................... 27 Printable area of the Card ........................................................................................................................... 27 General Data Protection Regulation (GDPR) ...................................................................................................... 28 FCC Declaration: ......................................................................................................................................... ....- 2 - CE Declaration: ............................................................................................................................................... - 3 - Document: DRAFT Issue 0.99 – 12/01/2021 ID Card Printer – User Manual 3 GENERAL INFORMATION: This document contains proprietary information belonging to Magicard Ltd. and may not be wholly or partially copied, stored in a data retrieval system, or used for any purpose other than that for which it was supplied, without the express written authority of Magicard Ltd. All rights are reserved. Microsoft and Windows Vista and Windows 7, 8 and 10 are trademarks of Microsoft Corporation. Copyright © 2011 Magicard L td. Magicard Ltd. shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance or use of this material. Magicard Ltd. reserves the right to change the content of this document without prior notification. SAFETY INSTRUCTIONS: • To prevent electric shock do not remove covers. • Do not attempt to service the printer yourself. • There are no user serviceable parts inside (either printer or dye film). In the event of malfunction, contact your printer/consumable supplier. • This product is only to be used with the Power Source supplied at point of purchase. • Take care not to spill any liquid on the printer. • When handling the printer a void touching the printing edge of the Thermal Print Head. Any grease and contamination will shorten its life. • Before transporting the printer, remove dye film & card hoppers and pack the printer in its original packaging to reduce the likelihood of damage in transit. Magicard is not…

Text truncated - open the document above for the full version.

Magicard Ltd Waverley House Hampshire Road Weymouth DT4 9XD United Kingdom Tel: +44 (0)1305 470000 https://magicard.com/ Federal Communicaons Commission Authorizaon and Evaluaon Division 7435 Oakland Mills Road Columbia, Maryland 21046 Confidenality Request regarding applicaon for cerficaon of FCC ID: XDW5000-0001 Pursuant to CFR 47; Secons 0.457 and 0.459, we hereby request long-term confidenal treatment of informaon accompanying this applicaon as outlined below:
Schemacs
Block Diagrams
Operaonal Descripons
Parts List These documents contain detailed system and equipment descripon and related informaon about the product which we consider to be proprietary, confidenal, a custom design and ordinarily unavailable to the general public. Since this design is a basis from which the future technological products will evolve, we consider this informaon to be of benefit to its competors, and that the disclosure of the informaon in these documents would give competors an unfair advantage in the market. Yours faithfully Gordon Hague Chief Technical Officer 11 th January 2021

XDW5000-0001 External Photos General view and arrangement including external uni versal PSU Page 1 of 8 XDW5000-0001 External Photos Front Page 2 of 8 XDW5000-0001 External Photos Left side Page 3 of 8 XDW5000-0001 External Photos Right side Page 4 of 8 XDW5000-0001 External Photos Rear Page 5 of 8 XDW5000-0001 External Photos Rear – close-up user ports Page 6 of 8 XDW5000-0001 External Photos Top Page 7 of 8 XDW5000-0001 External Photos Underside – showing position of product label Page 8 of 8

XDW5000-0001 Product Label 18/01/2020Issue: 1.00 Label details (physical) The product label consists of a tear-resistant matt chrome metallic finished polyester film which is dimensionally stable with good chemical resistance and tolerance to temperature range. The information on the label is printed via compatible thermal transfer ribbon using a Zebra ZT410. The adhesive used is S8015, which is suitable for difficult substrates including low surface energy plastics and coatings. The UL file number for the base label is MH27538. Label details (printed information) Page 1 of 2 XDW5000-0001 Product Label 18/01/2020Issue: 1.00 Label details (location on product) The label is applied to the underside of the product enclosure in a slightly recessed location designed to accommodate it. Page 2 of 2

XDW5000-0001 Internal Photos Right side viewed with lid open and front panel con nected Page 1 of 8 XDW5000-0001 Internal Photos Right detail – showing RFID elements Page 2 of 8 XDW5000-0001 Internal Photos Left side with front panel connected (on/off button and LED indicators) Page 3 of 8 XDW5000-0001 Internal Photos Underside – showing Main PCB external connections Page 4 of 8 XDW5000-0001 Internal Photos Underside with Main PCB partially disconnected and turned over to show detail Page 5 of 8 XDW5000-0001 Internal Photos RFID antenna close-up (lifted from mounting positio n and turned to show detail) Page 6 of 8 XDW5000-0001 Internal Photos Main PCB top view - RFID area highlighted within re d line Page 7 of 8 XDW5000-0001 Internal Photos Main PCB underside (RFID circuitry located within a rea bounded by red line) Page 8 of 8

Magicard Ltd Hampshire Road Weymouth Dorset. DT49XD United Kingdom Tel: +44 (0)1305 470000 Ref. FCC ID XDW5000-0001 Tune-up procedure: Statement: There is no tune-up procedure because there is no adjustable circuitry within XDW5000-0001: all oscillators within the product are of a quartz crystal fixed-frequency design and all reac*ve components are of a fixed value. The RFID IC is programmed with a set of fixed digital parameters for the implementa*on of XDW5000-0001 at boot *me. These parameters cannot be accessed or modified by the user.

Eurofins Hursley Trafalgar House Trafalgar Close Chandlers Ford, Eastleigh Hampshire. UK. SO53 4BW EMC TEST REPORT No. 1920b FR Issue#1: 12 th January 2021 UKAS Accredited FCC Registered KC Lab ID: EU0184 Tel. +44 (0) 23 8027 1111 e mail. [email protected] www.eurofins.co.uk/hursley FCC Part 15C, Industry Canada Certification Report for Pronto 100 Card Printer FCC ID: XDW5000-0001 Project Engineer: R. Pennell Approval Signatory Approved signatories: D. Tiroke  A. Coombes  The above named are authorised Eurofins Hursley sigantories. EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 2 of 26 Contents 1.0 DECLARATION ................................................................................................................................................ 3 1.1 FCC PART 15C STATEMENT AND INDUSTRY CANADA (IC) STATEMENT .............................................................. 3 1.2 RELATED SUBMITTAL(S) GRANTS ......................................................................................................................... 3 1.3 EUT MANUFACTURER .......................................................................................................................................... 3 2.0 EUT DESCRIPTION ......................................................................................................................................... 4 2.1 PRODUCT INFORMATION ....................................................................................................................................... 4 2.2 PRODUCT OPERATION ........................................................................................................................................... 4 2.3 SUPPORT EQUIPMENT ............................................................................................................................................ 5 2.4 EXERCISER PROGRAM ........................................................................................................................................... 5 3.0 MEASUREMENT PROCEDURE AND INSTRUMENTATION ................................................................. 5 3.1 EMI SITE ADDRESS & TEST DATE ........................................................................................................................ 5 3.2 GENERAL OPERATING CONDITIONS ...................................................................................................................... 5 3.3 UNCERTAINTY ....................................................................................................................................................... 6 3.4 ENVIRONMENTAL AMBIENT .................................................................................................................................. 6 3.5 CONDUCTED EMISSIONS ........................................................................................................................................ 7 3.6 RADIATED EMISSIONS ........................................................................................................................................... 8 3.7 H FIELD EMISSIONS ............................................................................................................................................... 9 4.0 TEST DATA ..................................................................................................................................................... 10 4.1 POWER LINE CONDUCTED EMISSIONS; 0.15 TO 30.0 MHZ .................................................................................. 10 4.2 RADIATED EMISSIONS 30MHZ TO 1GHZ ............................................................................................................. 13 4.3 RADIATED EMISSIONS 1 TO 8 GHZ ...................................................................................................................... 15 4.4 FCC PT15.225 ..................................................................................................................................................... 17 4.5 FCC PT15.225 A, B, C, D & F. FIELD STRENGTH OF EMISSIONS 9KHZ TO 30MHZ ................................................ 21 5.0 PHOTO LOG.................................................................................................................................................... 24 EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 3 of 26 1.0 DECLARATION 1.1 FCC Part 15C Statement and Industry Canada (IC) Statement The Equipment Under Test (EUT), as described and reported within this document, complies with ISED RSS-Gen Issue 5 March 2019 and IC RSS-210 Issue 10 December 2019 and the parts 15.207, 15.209, 15.225 of the CFR 47:2015 FCC rules. The EUT operates at frequencies of 13.56 MHz and complies with part 15C emission requirements. For emissions outside the 13.110 – 14.010MHz band the EUT, as described and reported within this document, complies with the parts 15.207 and 15.209 of the CFR 47 FCC rules in accordance with ANSI C63.10:2013 and ANSI C63.4:2014. 1.2 Related Submittal(s) Grants This is an application for certification of a Pronto 100 (transmitting at 13.56 MHz), described in this report. The sections of FCC Part 15 that apply to the EUT are: 15.207 Conducted emissions intentional radiator 15.209 Radiated emissions intentional radiator 15.225 Operation within the band 13.110 to 14.010 MHz 1.3 EUT Manufacturer Trade name: Magicard Ltd Company name: Magicard Ltd Company address: Magicard Ltd Waverley House Hampshire Road Weymouth Dorset DT4 9XD Manufacturing address: As above. Company representative: Timothy Last Tel: +44 (0) 1305 470 263 EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 4 of 26 2.0 EUT DESCRIPTION 2.1 Product Information EUT: Model Number: Pronto 100 3100-0001 Serial numbers: 98778910 Sample build: Production EUT PSU: Model Number: Sunpo…

Text truncated - open the document above for the full version.

EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 24 of 26 5.0 PHOTO LOG Emissions: Radiated emissions 9kHz to 30MHz 30MHz to 1GHz EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 25 of 26 Photo Log (continued) Radiated emissions 1 to 8GHz EMC TEST REPORT 1920b FR FCC Part 15C Certification Report Issue#1: 12 th January 2021 Page 26 of 26 Photo Log (continued) Conducted Measurements 15.225 temperature extreme Measurements End of Document
