Introduction to Design Plan of Receiver Receiver USB Charge Port Start Button Receiving Antenna USB Charge Cord Operating Principle • Signal Demodulation ： • Receiving antenna receives high-frequency signal sent by transmitter. The signal will go through capacitive coupling, frequency-selecting circuit to receiving demodulation unit. Finally, the demodulation moduledemodulates the code signal from the radio-frequency signal of transmitter and the code signal will be transited to MCU as control data signal. • MCU （ Microprocessor Control Unit ） • MCU will conduct data analysis, including decoding and identification, on the received code signal, send rele vant command, output corresponding PWM (pulse width modulation signal), so as to control the action and operating mode of vibrator. Logic Block Diagram Receiving antenna Module of radio-frequency receiving and amplification, signal demodulation and processing Power source and filtering Drive circuit Status display Motor Signal gating and receiving circuit Charge and port circuit MCU Master Control Unit Button circuit Rechargeable battery Date signal 6.7458M Quartz crystal resonator Electric Parameters and Properties • Power supply ： Lithium polymer battery --- 3.7V DC • Receiving Sensitivity ： -70DB • Charge time ： 2-3 hours Application Method • Press Start Button on receiver, th e system starts in ready mode; • Long press ON/OFF button of remo te-controller for 3 seconds, and the product begins to work ； • Press 4F button of remote-controller to select operating model of F1- F4 ； • Long press ON/OFF button of remo te-controller for 3 seconds again to turn off the product, then the product stop work. • In case the receiver has not been receiving signal for 1 hour, the product will enter Sleep Mode in wh ich control demand of transmitter will no longer be received, and the normal receiving will only be effective after pressing Start button of receiver. • In the event of excessive low volt age of battery, please recharge the product timely. • FCC Statement • 1. This device complies with Part 15 of the FC C Rules. Operation is su bject to the following • two conditions: • (1) This device may not ca use harmful interference, and • (2) This device must accept any interference received, in cluding interference that may • cause undesired operation. • 2. Changes or modifications not expressly a pproved by the party responsible for compliance • could void the user’s authority to operate the equipment. • Federal Communications Co mmission (FCC) Statement • This equipment has been tested. And it found to comply with the limits for a Clas s B digital device pursuant to Part 15 of the FCC Rules. Th ese limits are designed to provide r easonable protection against harmful interference in a residential installa tion. This equipment ge nerates and uses and ra diates radio frequency energy and, if not installe d and used in accordance with the instru ction, may ca use harmful interference to radio communications. However, ther e is no guarantee that interferenc e will not occur in a particular installation. If this equipment does ca use harmful interference to radio or television recepti on, which can be determined by turning the e quipment off and on, the user is encourag ed to try to correct the interference by one or more of the following measures: • - Reorient or relocate the receiving antenna. • - Increase the separation betwee n the equipment and receiver. • - Connect the equipment into an outlet on a circuit different from th at to which th e receiver is connected • - Consult the dealer or an experien ced radio /TV technician for help. • Warning: A shielded-type power cord is required in order to meet FC C emission limits and also to prevent interference to the nearby radio and te levision reception. It is essential that only the supplied power cord be used.

Logic Block Diagram Receiving antenna Module of radio-frequency receiving and amplification, signal demodulation and processing Power source and filtering Drive circuit Status display Motor Signal gating and receiving circuit Charge and port circuit MCU Master Control Unit Button circuit Rechargeable battery Date signal 6.7458M Quartz crystal resonator

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Revised wording (current) 1.0 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. October 18, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Party in my pants, 31415) We affirm that between SIEMIC and ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. NO. 35 FIRST ROAD, ZHUHAI BAIJAO NEW TECHNOLOGICAL& INDUSTRIAL PARK, ZHUHAI, CHINA

FCC Label: FCC ID: XG531415R

FCC Label Location

Report No.: A001P101016001E-1 Shenzhen AOV Testing Technology Co., Ltd. Page 1 of 11 FCC TEST REPORT Under FCC 15 Subpart B For ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD Party in my pants FCC ID : XG531415R Model No. : 31415 Prepared for : ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD NO. 35 FIRST ROAD, ZHUHAI BAIJAO NEW TECHNOLOGICAL & INDUSTRIAL PARK, ZHUHAI CITY, GUANGDONG PROVINCE, CHINA Prepared By : Shenzhen AOV Testing Technology Co., Ltd. 2-6/F, No.5, Yuantou Lane , Tanglang, Taoyuan Street, Nanshan District, Shenzhen ,Guangdong, China Tel : (86) 755-86008000 Fax : (86) 755-86008282 Report No. : A001P101016001E-1 Date of Test : October 18-20, 2010 Date of Rep. : October 20, 2010 Report No.: A001P101016001E-1 Shenzhen AOV Testing Technology Co., Ltd. Page 2 of 11 TABLE OF CONTENTS Description Page Test Report Declaration 1. GENERAL INFORMATION...................................................................................................... 4 1.1. Description of Device (EUT)........................................................................................................... 4 1.2. Test Facility....................................................................................................................................... 5 1.3. Uncertainty........................................................................................................................................ 5 1.4. Description of Test System............................................................................................................ 5 2. POWER LINE CONDUCTED EMISSION TEST................................................................... 6 2.1. Test Equipment................................................................................................................................6 2.2. Block Diagram of Test Setup......................................................................................................... 6 2.3. Power Line Conducted Emission Limit......................................................................................... 6 2.4. EUT Configuration on Test............................................................................................................. 6 2.5. Operating Condition of EUT........................................................................................................... 7 2.6. Test Procedure................................................................................................................................. 7 2.7. Power Line Conducted Emission Test Results........................................................................... 7 3. RADIATED EMISSION TEST.................................................................................................. 8 3.1. Test Equipment................................................................................................................................8 3.2. Block Diagram of Test Setup......................................................................................................... 8 3.3. Radiation Limit.................................................................................................................................. 9 3.4. EUT Configuration on Test............................................................................................................. 9 3.5. Operating Condition of the EUT.................................................................................................... 9 3.6. Test Procedure...............................................................................................................................10 3.7. Radiated Emission Test Result................................................................................................... 10 4. TEST SETUP PHOTOGRAPH.............................................................................................. 11 4.1. Photo of Power Line Conducted Emission Test....................................................................... 11 4.2. Photo of Radiated Emission Test................................................................................................ 11 APPENDIX I ------------ Power Line Conducted Emission Test Data APPENDIX II ----------- Radiated Emission Test Data Report No.: A001P101016001E-1 Shenzhen AOV Testing Technology Co., Ltd. Page 3 of 11 TEST REPORT DECLARATION Applicant : ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD Manufacturer : ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD EUT Description : Party in my pants (A) Model No. :31415 (B) Serial No. :N/A (C) Power Supply :DC 3.7V Test Procedure Used: FCC Rules and Regulations Part 15 Subpart B 2007. The device described above has been tested by Shenzhen AOV Testing Technology Co., Ltd to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B Class B limits both conducted and radiated emissions. The test results are contained in this test report and Shenzhen AOV Testing Technology Co., Ltd is assumed of full responsibility for the accuracy and completeness of these tests. Also, this report shows that the EUT (Equipment Under Test) is complies with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen AOV Testing Technology Co., Ltd. Date of Test: October 18-20, 2010 Prepared by: Project Engineer Approved & Authorized Signer: Project Manager Report No.: A001P101016001E-1 Shenzhen AOV Testing Technology Co., Ltd. Page 4 of 11 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Description : Party in my pants Model Number : 31415 Applicant : ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD Address : NO. 35 FIRST ROAD, ZHUHAI BAIJAO NEW TECHNOLOGICAL & INDUSTRIAL PARK, ZHUHAI CITY, GUANGDONG PROVINCE, CHINA Manufacturer : ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., …
