XHG-M600A3G 4G Module

Mobile Broadband module M600A User Manual Sprint Smart View M600A Mobile Broadband Module CONTENTS 1. BEFORE USING M600A......................................................................................4 Introduction...................................................................................................5 System Requirement.......................................................................................5 2. DEVICE ACTIVATION.........................................................................................6 Device Activation Overview..............................................................................7 Activation Wizard Tutorial................................................................................8 3. The Sprint Smart View Interface....................................................................... 11 The Main Window......................................................................................... 12 The Mobile Control Panel............................................................................... 12 The Wi-Fi Control Panel: In Detail................................................................... 13 Automatic vs. Manual Connection.................................................................... 13 The File Menu.............................................................................................. 14 The Tools Menu............................................................................................ 14 The Help Menu............................................................................................. 16 4. ESTABLISHING MOBILE................................................................................... 17 BROADBADN CONNECTIONS............................................................................... 17 Manually Connecting to the Sprint Mobile Broadband Network............................. 19 Automatic Connection Upon Device Attachment................................................ 19 Multiple Broadband Devices........................................................................... 21 Locking and Unlocking Your Sprint Mobile Broadband Device............................... 21 3G Bearer Types........................................................................................... 22 Mobile Info Window...................................................................................... 23 5. THE APPLICATION LAUNCHER.......................................................................... 24 The Application Launch Menu: In Detail........................................................... 25 Configuring Launched Applications.................................................................. 25 Automatically Launching Applications.............................................................. 27 Monitoring Launched Applications................................................................... 29 6. SPRINT SMARTVIEW SETTINGS........................................................................ 31 2 M600A Mobile Broadband Module Accessing the Settings Window....................................................................... 32 Settings: Acceleration................................................................................... 32 Settings: App Launcher................................................................................. 33 Settings: Client............................................................................................ 33 Settings: Hardware....................................................................................... 34 Settings: Location/GPS.................................................................................. 36 Settings: Sounds.......................................................................................... 38 Settings: Updates......................................................................................... 39 Settings: VPN.............................................................................................. 40 7. SUPPORT...................................................................................................... 42 Trouble Shooting.......................................................................................... 43 WARRANTY.................................................................................................. 44 SAFETY INFORMATION.................................................................................. 45 3 M600A Mobile Broadband Module Section 1, 1. BEFORE USING M600A  Introduction  System Requirement 4 M600A Mobile Broadband Module Introduction Welcome to the help pages of the Sprint Smart View software. The Help system is designed to answer users' questions on how to perform specific tasks and to explain the Sprint Smart View's functions. The menu system to the left allows users to browse help topics while the Index and Search tabs provide other mechanisms to access available help topics. System Requirement The system requirements for basic installation and operation of the Sprint Smart View software are shown in the table below. Windows XP Windows Vista Windows 7 Processor 300MHz 800MHz (1GHz recommended) 1GHz RAM 256MB 1GB (2GB recommended) 1GB (2GB recommended) Hard Drive Space 70MB 70MB 70MB Internet Explorer IE 5.5 IE 7 IE 8 OS Service Pack Service Pack 3 Service Pack 2 Additional Requirements:  Windows Vista and Windows 7 operation requires a DirectX 9.0 (or better) graphics accelerator  Internet Connection (if downloading the installer from the Internet)  CD-ROM (if installing from CD) 5 M600A Mobile Broadband Module Section 2, 2. DEVICE ACTIVATION  Device Activation Overview  Activation Wizard Tutorial 6 M600A Mobile Broadband Module Device Activation Overview Some Sprint Mobile Broadband devices may require activation (programming) prior to use. If your device needs such an action, Sprint Smart View will inform you and start the activation process when you c…

Text truncated - open the document above for the full version.

Franklin Technology Inc. 906 JEI Platz, 459-11, Gasan-Dong, Gumcheon-Gu, Seoul, Korea(153-803) Date: April 14, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: XHG-M600A To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Diffon corporation hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Diffon corporation temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 B lock Diagram 2 Op erational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 S chematics 5 E xternal Photos 6 In ternal Photos 7 T est-Setup Photos SHORT-TERM CONFIDENTIAL 8 User ’s Manual The Applicant understands that pursuant to Rule 0.457&0.459, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, ---------------------------------------------- Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Franklin Technology Inc.

Applicant/Grantee Franklin Technology Inc. FCC ID: XHG-M600A Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Refer to external photos. Shield is over the radio circuit module. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Refer to schematics. Y 3 The modular transmitter must have its own power supply regulation. Internal 3.3V power regulator.Refer to schematics Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Module contatins a hirose connector. The module will go inside final product where the antenna(s) will be integral to the end product, which can be considered permanently attached. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Module was tested outside. Refer to test setup photos in test report Y equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. Refer to label provided. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to manual. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Refer to MPE calculation in the Test report. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 3 EXTERNAL PHOTOGRAPHS FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 3 ■ EXTERNAL PHOTO FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 3 ■ EXTERNAL PHOTO

27.77 38.46 XHG-M600A Note: The FCC Label will be visible at the time of purchase.

FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 3 INTERNAL PHOTOGRAPHS FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 3 ■ INTERNAL PHOTO FCC ID: XHG-M600A HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 3 ■ INTERNAL PHOTO

FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 1 of 3 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 2 of 3 2-1. CDMA BAND Max Peak output Power at antenna input terminal (dBm) 24.300 Max Peak output Power at antenna input terminal (mW) 269.153 Prediction distance (cm) 20.000 Prediction frequency (MHz) 836.000 Antenna Gain(typical) (dBi) 1.700 Antenna Gain(numeric) 1.479 Power density at prediction frequency (mW/cm²) 0.07920 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 0.557 2-2.PCS BAND Max Peak output Power at antenna input terminal (dBm) 24.06000 Max Peak output Power at antenna input terminal (mW) 254.68303 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 1880.00 Antenna Gain(typical) (dBi) 3.500 Antenna Gain(numeric) 2.23872 Power density at prediction frequency (mW/cm²) 0.11343 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 3 of 3 3. RESULTS The power density level at 20 cm is 0.07920 mW/cm², which is below the uncontrolled exposure limit of 0.557 mW/cm² at 836.00 MHz for CDMA band. The power density level at 20 cm is 0.11343 mW/cm², which is below the uncontrolled exposure limit of 1.0 mW/cm² at 1880.00 MHz for PCS band.

FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 1 of 3 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 2 of 3 2-1. 5 MHz Bandwidth Max Peak output Power at antenna input terminal (dBm) 23.42 Max Peak output Power at antenna input terminal (mW) 219.78599 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2500.00 Antenna Gain(typical) (dBi) 2.900 Antenna Gain(numeric) 1.94984 Power density at prediction frequency (mW/cm²) 0.08526 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 2-2. 10 MHz Bandwidth Max Peak output Power at antenna input terminal (dBm) 22.90 Max Peak output Power at antenna input terminal (mW) 194.98446 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2500.0000 Antenna Gain(typical) (dBi) 2.900 Antenna Gain(numeric) 1.94984 Power density at prediction frequency (mW/cm²) 0.07564 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 FCC ID:XHG-M600A HCT CO., LTD 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 4601 www.hct.co.kr 3 of 3 3. RESULTS The power density level at 20 cm is 0.08526mW/cm², which is below the uncontrolled exposure limit of 1.0 mW/cm² at 2500.0 MHz for 5 MHz Bandwidth. The power density level at 20 cm is 0.07564 mW/cm², which is below the uncontrolled exposure limit of 1.0 mW/cm² at 2500.0 MHz for 10 MHz Bandwidth

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1104FR12 Test Dates: April 14, 2011 EUT Type: 3G 4G Module FCC ID: XHG-M600A Page ２ of 40 Version TEST REPORT NO. DATE DESCRIPTION HCTR1104FR12 April 14, 2011 First Approval Report FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1104FR12 Test Dates: April 14, 2011 EUT Type: 3G 4G Module FCC ID: XHG-M600A Page ３ of 40 Table of Contents 1. GENERAL INFORMATION ..........................................................................................................................４ 2. INTRODUCTION ..........................................................................................................................................５ 2.1. EUT DESCRIPTION...........................................................................................................................５ 2.2. MEASURING INSTRUMENT CALIBRATION ...................................................................................５ 2.3. TEST FACILITY .................................................................................................................................５ 3. DESCRIPTION OF TESTS ..........................................................................................................................６ 3.1 EFFECTIVE RADIATED POWER/EQUIVALENT ISOTROPIC RADIATED POWER.......................６ 3.2 PEAK- TO- AVERAGE RATIO ...........................................................................................................７ 3.3 OCCUPIED BANDWIDTH..................................................................................................................８ 3.4 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL...........................................９ 3.5 RADIATED SPURIOUS AND HARMONIC EMISSIONS ...............................................................１０ 3.6 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................１１ 4. LIST OF TEST EQUIPMENT ...................................................................................................................１２ 5. SUMMARY OF TEST RESULTS .............................................................................................................１３ 6. SAMPLE CALCULATION ........................................................................................................................１４ 7. TEST DATA ..............................................................................................................................................１５ 7.1 CONDUCTED OUTPUT POWER ...................................................................................................１５ 7.2 OCCUPIED BANDWIDTH ..............................................................................................................１６ 7.3 CONDUCTED SPURIOUS EMISSIONS ........................................................................................１６ 7.3.1 BAND EDGE.........................................................................................................................１６ 7.4 RADIATED SPURIOUS EMISSIONS .............................................................................................１７ 7.4.1 RADIATED SPURIOUS EMISSIONS(CDMA MODE) .........................................................１７ 7.4.2 RADIATED SPURIOUS EMISSIONS(PCS CDMA MODE) .................................................１８ 7.5 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................１９ 7.5.1 FREQUENCY STABILITY (CDMA)......................................................................................１９ 7.5.2 FREQUENCY STABILITY (PCS CDMA) .............................................................................２０ 8. TEST PLOTS............................................................................................................................................２１ FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1104FR12 Test Dates: April 14, 2011 EUT Type: 3G 4G Module FCC ID: XHG-M600A Page ４ of 40 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: Franklin Technology Inc. Address: 1505 Digital Tower Aston, 505-15 Gasan-dong, Gumcheon-gu, Seoul, Korea Contact Person: Name: Joong Il Hwang Phone #: TEL :+82-70-8228-3457 / FAX : +82-2-862-8923 FCC ID: XHG-M600A Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §22, §24, §2 EUT Type: 3G 4G Module Model(s): M600A Tx Frequency: 824.70 — 848.31 MHz (CDMA) 1 851.25 — 1 908.75 MHz (PCS CDMA) Rx Frequency: 869.70 — 893.31 MHz (CDMA) 1 931.25 — 1 988.75 MHz (PCS CDMA) Max. Conducted Power: 0.269 W CDMA (24.30 dBm) / 0.255 W PCS CDMA (24.06 dBm)/ 0.254 W CDMA EVDO (24.04 dBm) / 0.248 W PCS EVDO (23.95 dBm) Emission Designator(s): 1M28F9W (CDMA) / 1M29F9W (PCS CDMA) 1M28F9W (CDMA EVDO), 1M30F9W (PCS CDMA EVDO) Date(s) of Tests: April 07, 2011 ~ April 14, 2011 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1104FR12 Test Dates: April 14, 2011 EUT Type: 3G 4G Module FCC ID: XHG-M600A Page ５ of 40 2. INTRODUCTION 2.1. EUT DESCRIPTION The M600A 3G 4G Module consists of Cellular CDMA, PCS CDMA, EVDO Rev.0, A. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.3. TEST FACILITY The SAC(Semi-Anechoic Chamber) and conducted measurement facility used to collect the radiated data are located at the 105-1, Jangam-ri , Majang-Myeon, Icheon-si, 467-811, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated September 03, 2010 (Registration Number: 90661) FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1104FR12 Test Dates: April 14, 2011 EUT Type: 3…
