XHG-RT410Mobile Hotspot

RT410 Mobile Hotspot User Guide 1 Welcome This booklet helps you get started with your new Franklin Wireless RT410 Mobile Hotspot. For more help getting up and running with your new device, please contact T-Mobile. Visit the T-Mobile website for ongoing support and resources. There you'll find user guides, tutorials, and more to help you get the most out of your device. Note: Available applications and services are subject to change at any time. Your RT410 Mobile Hotspot See below for details on everything you will find in the box for your RT410. ü RT410 Mobile Hotspot ü Rechargeable Battery ü Micro-USB C type Charger ü Get Started Guide LCD Screen Micro-USB Charging Port Power/Wake Device Navigation Button 2 Get Started The following topics give you all the information you need to set up your device and wireless service the first time. Parts and Functions Learn your device's primary parts and functions. ● Device Layout The following illustration outlines your device's primary external features and buttons. <TOP> <Bottom> 3 Part Description Display View device status and information SIM card slot Install the SIM card. AC Charging micro USB port Connect the micro USB cable for charging. Battery cover Remove the battery cover to remove or insert the battery or SIM card. Settings Reset button Press to reset your device to its default settings. Power (Menu) button Long press to toggle power on or off. Short press to navigate device information ● SIM Card The SIM card is an IC card containing your device's phone number and other customer information. Note: Your device's SIM card is preinstalled. ● Handling a SIM Card Keep the following in mind when handling a SIM card. • Customer is responsible for any damage caused by inserting the SIM card in another- brand IC card reader, etc. The company is not responsible in such case. • Always keep the IC chip clean. • Wipe clean with a dry, soft cloth. • Avoid applying labels. May damage the SIM card. • See instructions included with the SIM card for handling. • The SIM card is the property of the company. • The SIM card is replaceable (at cost) in case of loss/damage. • Return the SIM card to the company when cancelling subscription. • Returned SIM cards are recycled for environmental purposes. • Note that SIM card specifications and performance may change without notice. • It is recommended that you keep a separate copy of information that is stored on the SIM card. The company is not responsible for damages from stored information that is lost. 4 • Always follow emergency procedures to suspend service if your SIM card or device (SIM card inserted) is lost or stolen. For details, contact Customer Service. • Always power off the mobile broadband device before inserting or removing the SIM card. ● Insert or Remove a SIM Card Follow these instructions to insert or remove a SIM card. Remember to power off your device before inserting or removing a SIM card. Note: Your device's SIM card is preinstalled. These instructions are for reference only. 1. Press and hold the Power key to turn off the device before inserting or removing the SIM card. 2. Remove the battery cover and Insert the SIM card gently with gold IC chip facing downward 5 3. Remove the SIM card by gently pressing down and sliding outwards. 4. Insert the Battery. § Align the contacts of the battery with the contacts in the device. 5. Attach the battery cover. Charge the Battery Follow these instructions to charge your device's battery using the included AC adapter. 6 Battery Charging Cautions Charging Conditions: Under low temperatures charging performance decreases. Charge your device in temperatures between 0°C – 50°C. Do not charge in places where there is high humidity.USB charging may be unavailable depending on Wi-Fi router temperature. Use Supplied Accessories: Always use the supplied AC adapter. Precaution for Extended Use: Your device may become hot when used for a long time or while charging, especially in high temperatures. Prolonged contact with skin may cause low-temperature burn injuries. The RT410 and AC Adapter Becoming Warm or Hot: Your device and the AC adapter may become warm while charging. This is not a malfunction. However, stop using them immediately if they become extremely hot; this could indicate a malfunction. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Mise en garde RISQUE D'EXPLOSION SI LA PILE EST REMPLACÉE PAR UN TYPE INCORRECT. JETER LES PILES USÉES SELON LES INSTRUCTIONS Charge Using the AC Adapter Use the supplied AC adapter. Plug the AC adapter into an electrical outlet. The indicator light on the power button illuminates red when charging starts. The light turns green when the battery is fully charged. Fully charging a battery may take up to three hours. After charging, disconnect the device from the charger. 7 Unplug the AC adapter from the outlet, and remove the micro USB connector from the device. The socket-outlet shall be installed near the equipment and shall be easily accessible. La prise de courant doit être installée à proximité de l'équipement et doit être facilement accessible. Turn Your Device On and Off The instructions below explain how to turn your device on and off, or to restart your device if it cannot be powered on and off using the Power button .. • Turn Your Device On Press and hold the Power button until the device displays "Welcome". • Turn Your Device Off Press and hold the Power button until the device displays "Goodbye" Your device will power off Restart Your Device If your device will not turn on or off using the Power button, remove and re-insert the battery (see the section "Insert the Battery"), then press and hold the power button again. Note: Restarting your device does not reset the device settings. Set Up Your Hotspot ● Insert the Battery Remove the back cover using the thumb catch on the bottom edge of the hotspot. Align the battery's contacts with …

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Franklin Technology Inc. Address 906 JEI Platz, 186, Gasan digital 1-ro, Gumcheon-Gu, Seoul, South Korea, 08502 Grantee Code XHG FCC ID XHG-RT410 Authorized Contact Name James Lee Contact Email [email protected] Contact Phone 82-70-8228-6445 I, the under signed, certify that I am an authorized signatory for the Applicant and therefore declare; a)in ac cordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and beli ef. b)in ac cepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made i n thi s application, the Applicant is responsible for: (1 ) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)i f the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensur e that pr oduction units of this equipment will continue to comply with the FCC’s technical requirements. d)in ac cordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsibl e par ty and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in ac cordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements . (1 ) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CF R 1.2002(b) for the definition of a “party” for these purposes. g)t he Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions . Li nk to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: November 3, 2020 Print Name: James Lee Title: R&D HW team Leader *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Date: November 3, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: XHG-RT410 To whom it may concern: We, the undersigned, hereby authorize SGS Korea Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC Certification above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Franklin Technology Inc. This authorization is valid until further written notice from the applicant. Name (Printed): James Lee Title: R&D HW team Leader Signature: On behalf of Company: Franklin Technology Inc. Telephone: 82-70-8228-6445

To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Franklin Technology Inc. 906 JEI Platz, 186, Gasan digital 1-ro, Gumcheon-Gu, Seoul, South Korea, 08502 Regarding: Confidentiality Request regarding application for FCC ID: XHG-RT410 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. - Schematic(s) - Block Diagrams - Operational Descriptions - Tune Up Procedure The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. - External Photos - Internal Photos - Test Setup Photos - User manual(s) Sincerely, James Lee R&D HW team Leader Franklin Technology Inc.

Photographs of EUT Front View of EUT Rear View of EUT Inside of EUT Front View of Main Board Rear View of Main Board Front View of Battery Rear View of Battery View of Travel Adapter

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

RT410 Device Label Artwork RT410 T10 Device Label Location

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB View of Module WLAN Module WWAN Module View of Antenna WLAN Antenna WWAN Antenna

Test Report No. : F690501-RF-EMG000359-1 Page : 2 of 11 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) Contents 1. General Information ................................................................................................... 4 1.1 Client Information ................................................................................................ 4 1.2 Test Laboratory ................................................................................................... 4 1.3 General Information of E.U.T. ............................................................................. 4 1.4 Operating Modes and Conditions ........................................................................ 5 1.5 Auxiliary Equipments .......................................................................................... 5 1.6 Cable List ............................................................................................................ 5 1.7 System Configurations ........................................................................................ 5 1.8 Test System Layout ............................................................................................ 5 1.9 Modifications ....................................................................................................... 5 1.10 Applicable Standards for Testing ...................................................................... 5 1.11 Summary of Test Results .................................................................................. 5 2. Emission Test ............................................................................................................ 6 2.1 Test Results ........................................................................................................ 6 2.2 Test Method and Limits ....................................................................................... 6 2.2.1 Test Method ............................................................................................... 6 2.2.2 Test Limits ................................................................................................. 6 2.3 Conducted Emission ........................................................................................... 7 2.3.1 Test Equipments ........................................................................................ 7 2.3.2 Test Site .................................................................................................... 7 2.3.3 Environment Conditions and data .............................................................. 7 2.4 Radiated Emission .............................................................................................. 8 2.4.1 Test Equipments ........................................................................................ 8 2.4.2 Test Site .................................................................................................... 8 2.4.3 Environment Conditions and data .............................................................. 8 Appendix A : Conducted Emission at AC Mains Port .................................................. 10 Appendix B : Radiated Emission ................................................................................. 11 Test Report No. : F690501-RF-EMG000359-1 Page : 3 of 11 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) Revision History Revision Report Number Description 0 F690501-RF-EMG000359 Initial 1 F690501-RF-EMG000359-1 Added information in clause1.3 and 1.4. 2 Test Report No. : F690501-RF-EMG000359-1 Page : 4 of 11 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) 1. General Information 1.1 Client Information Applicant : Franklin Technology Inc. - Address of Applicant : 906(Gasan-Dong, JEI Platz), 186, Gasan digital 1-ro, Geumcheon-gu, Seoul, Republic of Korea.(08502) Manufacturer : Franklin Technology Inc. - Address of Manufacturer : 906(Gasan-Dong, JEI Platz), 186, Gasan digital 1-ro, Geumcheon-gu, Seoul, Republic of Korea.(08502) 1.2 Test Laboratory Name and Address : SGS Korea Co., Ltd. - Giheung 1 Laboratory : 35, Giheungdanji-ro 121beon-gil, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea - Giheung 2 Laboratory : 23, Giheungdanji-ro 24beon-gil, Giheung-gu,Yongin-si, Gyeonggi-do, Republic of Korea - Gunpo Laboratory : 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 15807, Republic of Korea. FCC Registration No. : KR0150 IC Registration No. : 7837B Phone : + 82 31 428 5700 Fax : + 82 31 427 2370 e-mail : [email protected] 1.3 General Information of E.U.T. Classification Description Product Name Mobile Hotspot Model Name RT410 Serial No. None EMI Classification Class B Test Voltage 120 V~, 60 ㎐ Rated Voltage 3.8 Vd.c.(Min : 3.40 Vd.c., Max : 4.35 Vd.c.), Max. DC Current : 2.450 A Highest Internal Frequenc y 5 825㎒ Device Capabilities * WCDMA B2/4/5 * LTE B2/4/5/12/25/26/41/66/71 * WLAN 2.4GHz, 5GHz H/W Version P1 S/W Version RT410F21.FR.1609 Operating temperature (-)10 °C~ 55 °C Test Report No. : F690501-RF-EMG000359-1 Page : 5 of 11 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) 1.4 Operating Modes and Conditions Operating Mode Operating Condition 1) Charging + LTE Band 2 Idle Charging status and connect to LTE Band 2 Idle status Note : For all supported bands, LTE Band 2 showed the most worst case as a result of measurement 1.5 Auxiliary Equipments Description Model Serial No. Manufacturer FCC ID Wideband Radio Communication Tester CMW 500 - - - 1.6 Cable List Start END Cable Spec. Used core Name I/O Port Name I/O Port Length Shield AC Power Source AC OUT Travel Adapter AC IN - - - Wideband Radio Communication Tester - - - Travel Adapter DC OUT EUT DC IN 1.0 Unshield No. EUT - Wideband Radio Communication Tester - - - - 1.7 System Configurations Description Model Serial No. Manufacturer Main Board RT410 P1 2020.08.11. - - Battery - - - Travel Adapter - - - 1.8 Test System Layout 1.9 Modifications There was no modified item during the test. 1.10 Applicable Standards for Testing Standards Status Deviation FCC P…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 2 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents Page 1. General Information ---------------------------------------------------------------------------------------- 3 2. RF Radiated Output Power & Spurious Radiated Emission ------------------------------------- 9 3. Occupied Bandwidth ---------------------------------------------------------- ----------------------------- 50 4. Peak-Average Ratio --------- ------------------------------------------------------------------------------ 65 5. Spurious Emissions at Antenna Terminal -------- ---------------------------------------------------- 84 6. Band Edge ------------------------------ ---------------------------------------------------------------------- 115 7. Frequency Stability ----------------------------------------------------------------------------------------- 146 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 3 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : Franklin Technology Inc. Address : 906 JEI Platz, 186, Gasan digital 1-ro, Gumcheon-Gu, Seoul, South Korea, 08502 Contact Person : Lee, James Phone No. : +82 70 8228 6445 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Mobile Hotspot Model Name R717V Power Supply DC 3.8 V Rated Power LTE Band 2, 5: 22 ㏈m LTE Band 4, 66: 21.5 ㏈m LTE Band 12, 41: 23.5 ㏈m LTE Band 25: 22.2 ㏈m LTE Band 26: 23 ㏈m LTE Band 71: 23.3 ㏈m Frequency Range LTE Band 2: 1 850 ㎒ ~ 1 910 ㎒ LTE Band 4: 1 710 ㎒ ~ 1 755 ㎒ LTE Band 5: 824 ㎒ ~ 849 ㎒ LTE Band 12: 699 ㎒ ~ 716 ㎒ LTE Band 25: 1 850 ㎒ ~ 1 915 ㎒ LTE Band 26: 824 ㎒ ~ 849 ㎒ LTE Band 41: 2 496 ㎒ ~ 2 690 ㎒ LTE Band 66: 1 710 ㎒ ~ 1 780 ㎒ LTE Band 71: 663 ㎒ ~ 698 ㎒ Modulation Technique QPSK, 16QAM Antenna Type FPCB type antenna Antenna Gain 699 ㎒ ~ 716 ㎒: -0.59 ㏈i 1 850 ㎒ ~ 1 915 ㎒: 3.01 ㏈i 824 ㎒ ~ 849 ㎒: 2.89 ㏈i 2 496 ㎒ ~ 2 690 ㎒: 3.62 ㏈i 1 710 ㎒ ~ 1 780 ㎒: 4.16 ㏈i 663 ㎒ ~ 698 ㎒: -1.94 ㏈i SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 4 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator Agilent E8257D MY51501169 Nov. 11, 2019 Annual Nov. 11, 2020 Spectrum Analyzer R&S FSV30 103455 Dec. 22, 2019 Annual Dec. 22, 2020 Mobile Test Unit R&S CMW500 144034 Feb. 28, 2020 Annual Feb. 28, 2021 Power Meter Anritsu ML2495A 1223004 Jun. 01, 2020 Annual Jun. 01, 2021 Power Sensor Anritsu MA2411B 1207272 Jun. 01, 2020 Annual Jun. 01, 2021 Temperature Chamber ESPEC CORP. PL-1J 15000793 Jun. 02, 2020 Annual Jun. 02, 2021 High Pass Filter Wainwright Instrument GmbH WHKX10-900-1000-18000 -40SS 7 Mar. 04, 2020 Annual Mar. 04, 2021 High Pass Filter Wainwright Instrument GmbH WHKX1.5/15G-6SS 4 Jun. 11, 2020 Annual Jun. 11, 2021 High Pass Filter Wainwright Instrument GmbH WHKX2.2/12.75G-10SS 8 Mar. 04, 2020 Annual Mar. 04, 2021 High Pass Filter Wainwright Instrument GmbH WHK3.0/18G-10SS 344 May 18, 2020 Annual May 18, 2021 High Pass Filter Wainwright Instrument GmbH WHK7.5/26.5G-6SS 15 Jun. 05, 2020 Annual Jun. 05, 2021 Directional Coupler KRYTAR 152613 122660 Jun. 11, 2020 Annual Jun. 11, 2021 DC Power Supply Agilent U8002A MY49030063 Feb. 03, 2020 Annual Feb. 03, 2021 Preamplifier H . P. 8447F 2944A03909 Aug. 06, 2020 Annual Aug. 06, 2021 Signal Conditioning Unit R&S SCU 18 10117 Jun. 10, 2020 Annual Jun. 10, 2021 Preamplifier MITEQ Inc. JS44-18004000-35-8P 1546891 May 08, 2020 Annual May 08, 2021 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 22, 2019 Biennial Aug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB9163 396 Mar. 21, 2019 Biennial Mar. 21, 2021 Horn Antenna R&S HF906 100326 Feb. 14, 2020 Annual Feb. 14, 2021 Horn Antenna Schwarzbeck Mess-Elektronik BBHA9170 9170-540 Jul. 24, 2019 Biennial Jul. 24, 2021 Antenna Master Innco systems GmbH MM4000 N/A N.C.R. N/A N.C.R. Turn Table Innco systems GmbH DS 1200S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/383 30516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.4 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE SFX086-NMNM-5M (5m) 20200323001 Aug. 10, 2020 Semi- annual Feb. 10, 2021 Coaxial Cable RFONE PL520-NMNM-10M (10 m) 20200324001 Aug. 10, 2020 Semi- annual Feb. 10, 2021 Coaxial Cable Rosenberger LA1-C006-1500 131014 01/20 Aug. 21, 2020 Semi- annual Feb. 21, 2021 Coaxial Cable Rosenberger LA1-C006-1500 131014 05/20 Aug. 21, 2020 Semi- annual Feb. 21, 2021 Coaxial Cable Rosenberger LA1-C006-1500 131014 10/20 Aug. 21, 2020 Semi- annual Feb. 21, 2021 ▶ Support Equipment Description Manufacturer Model Serial Number N/A - - - SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 5 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.6. Summary of Test Results The EUT has been tested according to the following spe…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 59 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 41 5 ㎒ QPSK Middle Channel - Full RB 5 ㎒ 16QAM Middle Channel - Full RB 10 ㎒ QPSK Middle Channel - Full RB 10 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 60 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 41 15 ㎒ QPSK Middle Channel - Full RB 15 ㎒ 16QAM Middle Channel - Full RB 20 ㎒ QPSK Middle Channel - Full RB 20 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 61 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 66/4 1.4 ㎒ QPSK Middle Channel - Full RB 1.4 ㎒ 16QAM Middle Channel - Full RB 3 ㎒ QPSK Middle Channel - Full RB 3 ㎒ 16QAM Middle Channel - Full RB 5 ㎒ QPSK Middle Channel - Full RB 5 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 62 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 66/4 10 ㎒ QPSK Middle Channel - Full RB 10 ㎒ 16QAM Middle Channel - Full RB 15 ㎒ QPSK Middle Channel - Full RB 15 ㎒ 16QAM Middle Channel - Full RB 20 ㎒ QPSK Middle Channel - Full RB 20 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 63 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 71 5 ㎒ QPSK Middle Channel - Full RB 5 ㎒ 16QAM Middle Channel - Full RB 10 ㎒ QPSK Middle Channel - Full RB 10 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 64 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) LTE band 71 15 ㎒ QPSK Middle Channel - Full RB 15 ㎒ 16QAM Middle Channel - Full RB 20 ㎒ QPSK Middle Channel - Full RB 20 ㎒ 16QAM Middle Channel - Full RB SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 65 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 4. Peak-Average Ratio 4.1. Limit - §22.913(d), Measurement of the ERP of Cellular base transmitters and repeaters must be made using an average power measurement technique. The peak-to-average ratio (PAR) of the transmission must not exceed 13 ㏈. - §24.232(d), Power measurements for transmissions by stations authorized under this section may be made either in accordance with a Commission-approved average power technique or in compliance with paragraph (e) of this section. In both instances, equipment employed must be authorized in accordance with the provisions of §24.51. In measuring transmissions in this band using an average power technique, the peak-to-average ratio (PAR) of the transmission may not exceed 13 ㏈. - §27.50(d)(5), Power measurements for transmissions by stations authorized under this section may be made either in accordance with a Commission-approved average power technique or in compliance with paragraph (d)(6) of this section. In measuring transmissions in this band using an average power technique, the peak-to-average ratio (PAR) of the transmission may not exceed 13 ㏈. 4.2. Test Procedure The test follows section 5.2.3.4 of ANSI C63.26-2015. See instrumentation-specific application literature for further guidance regarding use of the CCDF capability. The following guidelines are offered for performing a CCDF measurement. a. Set resolution/measurement bandwidth ≥ OBW or specified reference bandwidth. b. Set the number of counts to a value that stabilizes the measured CCDF curve. c. Set the measurement interval as follows: 1) For continuous transmissions, set to greater of [10 x (number of points in sweep) x (transmission symbol period)] or 1 ㎳. 2) For burst transmissions, employ an external trigger that is synchronized with the EUT burst timing sequence, or use the internal burst trigger with a trigger level that allows the burst to stabilize. Set the measurement interval to a time that is less than or equal to the burst duration. 3) If there are several carriers in a single antenna port, the peak power shall be determined for each individual carrier (by disabling the other carriers while measuring the required carrier) and the total peak power calculated from the sum of the individual carrier peak powers. d. Record the maximum PAPR level associated with a probability of 0.1 %. e. The peak power level is calculated form the sum of the PAPR value from step d) to the measured average power. EUT Directional Coupler Mobile Test Unit Spectrum Analyzer SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001275-2 Page: 66 of 152 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 4.3 Test Results Ambient temperature : (23 ± 1) °C Relative humidity : 47 % R.H. Band Bandwidth (㎒) Mode Frequency (㎒) PAR (㏈) 12 1.4 QPSK 699.7 4.84 707.5 4.93 715.3 …

Text truncated - open the document above for the full version.
