XHG-S600C3G USB Adapter

1 S600C User Manual 2 FCC Regulations: zThis device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. zThis device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. zThe antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 4RF Exposure Information This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. zThis device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. I. Functions and Usage 3 The S600C development Kit is used to debug the Franklin Wireless M600C series module. It is designed by an auxiliary board with Franklin Wireless M600C series module embedded. When the S600C is used, you can connect the module to a PC through a USB cable. When the module works normally, the debugging functions can be implemented. The S600C provides multiple interfaces, such as the Mini-USB port, DC power jack, RF connectors. The S600C can be used to test the performance of the module. Both the wired connection test (connect the module to the each equipment) and the wireless connection test (connect the module to the antennas) can be implemented. The signal points can also be tested when you maintain and repair the module. II. Structure Figure-1 Structure of the S600C III. Method for Connecting the S600C 1. Diagram of connecting the S600C to the equipment. Figure-2. Configuration for Adjustment and Test of CDMA, PCS mode 4 2. Diagram of connecting the S600C and the antenna Figure-3. Diagram of connecting the module and the antenna Table-1. Port definition of RF connectors Port definition 1 2 S600C CDMA Main CDMA Aux+GPS 5 Figure -4 Port definition of RF connectors IV. Installation of the S600C z Connect the devices and set up the test environment according to Figure-2. Then connect the S600C to the PC through a Micro-USB to Type A USB cable.. z When performing the wired connection test, connect the E5515C to the RF interface of the S600C.. (For the connection method, see Figure-2) z When performing the wireless connection test, connect the antennas to the RF interface of the S600C directly. (For the connection method, see Figure-3.) V. LED indication of the S600C Green: H/W power indication Blue: Indicate the state of the card.(M600C) VI. Material List Model Device USB Y-Cable CDMA Main antenna CDMA Aux/GPS antenna S600C 1 EA 1 EA 1 EA 1 EA

Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 1 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C 1. External Photograph of EUT Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 2 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C 720510 Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 3 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C List of Accessory: Specification of Accessory AC Adapter Brand Name Bestec Model Name EA0121WAA USB Cable Signal Line Type 0.4 meter shielded cable without ferrite core WWAN Module Brand Name Franklin Model Name M600C Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 4 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 5 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C 720510

40*25mm 40 MEID(Hex): XXXXXX XXXXXXXX S/N: MMYYXXXXXX MEID(Dec): XXXXXXXXXXXXXXXXX FCC ID: XHG-S600C Made in Taiwan S600C QUALCOMM 3G CDMA

Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 6 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C 3. Internal Photograph of EUT Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 7 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 8 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C WWAN Module Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 9 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 10 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 11 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 12 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C 720510 WWAN Main Antenna <Tx / Rx> Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 13 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 14 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C WWAN Aux. Antenna <Tx / Rx> Photographs of EUT Report No.: EP131021-02 Brand Name: Franklin / Model Name: S600C SPORTON INTERNATIONAL INC. Page Number : 15 of 15 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C

SPORTON INTERNATIONAL INC. Page Number : 1 of 8 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C RF Exposure Evaluation Report Report No. : FA131021-02 RF Exposure Evaluation Report APPLICANT : Franklin Technology EQUIPMENT : 3G USB adapter BRAND NAME : Franklin MODEL NAME : S600C FCC ID : XHG-S600C FILING TYPE : Certification STANDARD : OET Bulletin 65 Supplement C (Edition 01-01) We, SPORTON INTERNATIONAL INC., would like to declare that the device has been evaluated in accordance with FCC OET Bulletin 65 Supplement C (Edition 01-01), and pass the limit. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Roy Wu / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 8 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C RF Exposure Evaluation Report Report No. : FA131021-02 Table of Contents REVISION HISTORY .......................................................................................................................................... 3 1. RF EXPOSURE INTRODUCTION ............................................................................................................... 4 2. ADMINISTRATION DATA ........................................................................................................................... 6 2.1 Testing Laboratory ............................................................................................................................. 6 2.2 Applicant ............................................................................................................................................ 6 2.3 Manufacturer ...................................................................................................................................... 6 3. GENERAL INFORMATION ......................................................................................................................... 7 3.1 Description of Device Under Test (DUT) ........................................................................................... 7 4. RF EXPOSURE EVALUATION ................................................................................................................... 8 4.1 Radio Frequency Radiation Exposure Evaluation ............................................................................. 8 SPORTON INTERNATIONAL INC. Page Number : 3 of 8 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C RF Exposure Evaluation Report Report No. : FA131021-02 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA131021-02 Rev. 01 Initial issue of report Apr. 12, 2011 SPORTON INTERNATIONAL INC. Page Number : 4 of 8 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C RF Exposure Evaluation Report Report No. : FA131021-02 1. RF Exposure Introduction Requirements Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile and portable and are defined as follows:  Fixed installation: Fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans form the antenna is maintained to at least 2 meters.  Mobile Devices: A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitters’s radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR 2.1091.  Portable Devices: A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC’s Rules (47 CFR 2.1093) SPORTON INTERNATIONAL INC. Page Number : 5 of 8 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C RF Exposure Evaluation Report Report No. : FA131021-02 The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows:  Occupational/controlled Exposure: In general, occupational/controlled exposure limits are applicable to situation in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks.  General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise …

Text truncated - open the document above for the full version.

SPORTON INTERNATIOINAL INC. Page Number : 1 of 23 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 Partial FCC RF Test Report APPLICANT : Franklin Technology EQUIPMENT : 3G USB adapter BRAND NAME : Franklin MODEL NAME : S600C FCC ID : XHG-S600C STANDARD : FCC 47 CFR Part 2, 22(H), 24(E) CLASSIFICATION : PCS Licensed Transmitter (PCB) Tx/Rx FREQUENCY RANGE : CDMA2000 BC0 : 824.70 ~ 848.31 MHz / 869.70 ~ 893.31 MHz CDMA2000 BC1 : 1851.25 ~ 1908.75 MHz / 1931.25 ~ 1988.75 MHz MAX. ERP/EIRP POWER : CDMA2000 BC0 : 0.27 W CDMA2000 BC1 : 0.53 W This is a partial report which is only valid combined with the integrated the 3G Module (Brand Name: Franklin / Model Name: M600C, FCC ID: XHG-M600C) Report. The product was received on Mar. 10, 2011 and completely tested on Apr. 01, 2011. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI / TIA / EIA-603-C-2004 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Roy Wu / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIOINAL INC. Page Number : 2 of 23 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ..................................................................................................................................... 5 1.3 Feature of Equipment Under Test ..................................................................................................... 5 1.4 Testing Site........................................................................................................................................ 6 1.5 Applied Standards ............................................................................................................................. 6 1.6 Ancillary Equipment List .................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Test Mode.......................................................................................................................................... 7 2.2 Connection Diagram of Test System ................................................................................................ 8 3 TEST RESULT ............................................................................................................................................. 9 3.1 Effective Radiated Power and Effective Isotropic Radiated Power Measurement ........................... 9 3.2 Field Strength of Spurious Radiation Measurement ....................................................................... 12 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 22 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 23 APPENDIX A. PHOTOGRAPHS OF EUT APPENDIX B. SETUP PHOTOGRAPHS SPORTON INTERNATIOINAL INC. Page Number : 3 of 23 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FG131021-02 Rev. 01 Initial issue of report Apr. 12, 2011 SPORTON INTERNATIOINAL INC. Page Number : 4 of 23 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 SUMMARY OF TEST RESULT Report Section FCC Rule IC Rule Description Limit Result Remark 3.1 §24.232(c) RSS-133 (6.4) SRSP-510(5.1.2) Equivalent Isotropic Radiated Power < 2 Watts PASS - 3.2 §2.1053 §22.917(a) §24.238(a) RSS-132 (4.5.1) RSS-133 (6.5.1) Field Strength of Spurious Radiation < 43+10log 10 (P[Watts]) PASS Under limit 9.00 dB at 3760 MHz SPORTON INTERNATIOINAL INC. Page Number : 5 of 23 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 1 General Description 1.1 Applicant Franklin Technology 906 JEI Platz, 459-11 Gasan-dong, Guncheon-gu, Seoul, Korea 1.2 Manufacturer U-Media Communications, Inc. 9F, No. 1, Jin-shan 8th St., Hsinchu 300, Taiwan, R.O.C. 1.3 Feature of Equipment Under Test Product Feature & Specification Equipment 3G USB adapter Brand Name Franklin Model Name S600C FCC ID XHG-S600C Integrated Module Brand Name : Franklin Model Name : M600C Tx Frequency CDMA2000 BC0 : 824 MHz ~ 849 MHz CDMA2000 BC1 : 1850 MHz ~1910 MHz Rx Frequency CDMA2000 BC0 : 869 MHz ~ 894 MHz CDMA2000 BC1 : 1930 MHz ~ 1990 MHz Maximum Output Power to Antenna CDMA2000 BC0 : 24.15 dBm CDMA2000 BC1 : 24.15 dBm Maximum ER…

Text truncated - open the document above for the full version.

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1010FFR12-2 Test Dates: November 02, 2010 EUT Type: 3G Module FCC ID: XHG-M600C Page ２ of 40 Version TEST REPORT NO. DATE DESCRIPTION HCTR1010FR12 October 19, 2010 First Approval Report HCTR1010FR12-1 October 29, 2010 Change the test site description HCTR1010FR12-2 November 02, 2010 Delete ERP/ EIRP Test FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1010FFR12-2 Test Dates: November 02, 2010 EUT Type: 3G Module FCC ID: XHG-M600C Page ３ of 40 Table of Contents 1. GENERAL INFORMATION ..........................................................................................................................４ 2. INTRODUCTION ..........................................................................................................................................５ 2.1. EUT DESCRIPTION...........................................................................................................................５ 2.2. MEASURING INSTRUMENT CALIBRATION ...................................................................................５ 2.3. TEST FACILITY .................................................................................................................................５ 3. DESCRIPTION OF TESTS ..........................................................................................................................６ 3.1 EFFECTIVE RADIATED POWER/EQUIVALENT ISOTROPIC RADIATED POWER.......................６ 3.2 PEAK- TO- AVERAGE RATIO ...........................................................................................................７ 3.3 OCCUPIED BANDWIDTH..................................................................................................................８ 3.4 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL...........................................９ 3.5 RADIATED SPURIOUS AND HARMONIC EMISSIONS ...............................................................１０ 3.6 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................１１ 4. LIST OF TEST EQUIPMENT ...................................................................................................................１２ 5. SUMMARY OF TEST RESULTS .............................................................................................................１３ 6. SAMPLE CALCULATION ........................................................................................................................１４ 7. TEST DATA ..............................................................................................................................................１５ 7.1 CONDUCTED OUTPUT POWER ...................................................................................................１５ 7.2 OCCUPIED BANDWIDTH ..............................................................................................................１６ 7.3 CONDUCTED SPURIOUS EMISSIONS ........................................................................................１６ 7.3.1 BAND EDGE.........................................................................................................................１６ 7.4 RADIATED SPURIOUS EMISSIONS .............................................................................................１７ 7.4.1 RADIATED SPURIOUS EMISSIONS(CDMA MODE) .........................................................１７ 7.4.2 RADIATED SPURIOUS EMISSIONS(PCS CDMA MODE) .................................................１８ 7.5 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................１９ 7.5.1 FREQUENCY STABILITY (CDMA)......................................................................................１９ 7.5.2 FREQUENCY STABILITY (PCS CDMA) .............................................................................２０ 8. TEST PLOTS............................................................................................................................................２１ FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1010FFR12-2 Test Dates: November 02, 2010 EUT Type: 3G Module FCC ID: XHG-M600C Page ４ of 40 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: Franklin Technology Inc. Address: 1505 Digital Tower Aston, 505-15 Gasan-dong, Gumcheon-gu, Seoul, Korea Contact Person: Name: Michael Chun Phone #: TEL :+82-70-8260-343 / FAX : +82-2-2082-822 FCC ID: XHG-M600C Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §22, §24, §2 EUT Type: 3G Module Model(s): M600C Tx Frequency: 824.70 — 848.31 MHz (CDMA) 1 851.25 — 1 908.75 MHz (PCS CDMA) Rx Frequency: 869.70 — 893.31 MHz (CDMA) 1 931.25 — 1 988.75 MHz (PCS CDMA) Max. Conducted Power: 0.254 W CDMA (24.05 dBm) / 0.248 W PCS CDMA (23.96 dBm)/ 0.255 W CDMA EVDO (24.08 dBm) / 0.254 W PCS EVDO (24.06 dBm) Emission Designator(s): 1M28F9W (CDMA) / 1M28F9W (PCS CDMA) 1M27F9W (CDMA EVDO), 1M28/F9W (PCS CDMA EVDO) Date(s) of Tests: October 05, 2010 ~ October 15, 2010 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1010FFR12-2 Test Dates: November 02, 2010 EUT Type: 3G Module FCC ID: XHG-M600C Page ５ of 40 2. INTRODUCTION 2.1. EUT DESCRIPTION The M600C 3G Module consists of Cellular CDMA, PCS CDMA, EVDO Rev.0 and EVDO Rev.A. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.3. TEST FACILITY The SAC(Semi-Anechoic Chamber) and conducted measurement facility used to collect the radiated data are located at the 105-1, Jangam-ri , Majang-Myeon, Icheon-si, 467-811, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated June 10, 200…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : B1 of B1 TEL : 886-3-327-3456 Report Issued Date : Apr. 12, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHG-S600C FCC RF Test Report Report No. : FG131021-02 Appendix B. Setup Photographs <Radiated Emission>
