XHHBNRV500-AeBook Reader

barnesandnoble.com llc, 76 Ninth Avenue, New York, NY 10011 USA. © 2010-2013 barnesandnoble.com llc. All rights reserved. Free Friday™, GlowLight®, LendMe®, Lifetime Library®, More In Store®, NOOK®, NOOK Book®, NOOK Friends™, NOOK GlowLight™, NOOK Kids®, NOOK News- stand™, NOOK Press™, NOOK Store®, NOOK Study®, Read In Store®, and the NOOK logos are trademarks of barnesandnoble.com llc or its affiliates. Patent Pending. Screenshots and product images are simulated and for in- structional purposes only. They may differ from the actual product and are subject to change without notice. Content shown may vary from actual available content, which may change without notice. Your use of NOOK is subject to the Terms of Service located in the Settings area of your device and here: www.nook.com/support. Contains Reader® Mobile technology by Adobe Systems Incorporated. Adobe®, Reader®, and Reader® Mobile are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Wi-Fi® is a registered trademark of the Wi-Fi Alliance. All trademarks or registered trademarks that are not the property of barnesandnoble.com llc or its affiliates are the property of their respective owners. Model: BNRV500 Version: 1.3.0.D Table of Contents Introduction ....................................................................................................................................................7 Contact Us ........................................................................................................................................................................................7 Getting to Know Your NOOK ........................................................................................................................................................7 Registering Your NOOK ................................................................................................................................................................11 Power and Charging ........................................................................................................................................................................13 Safety and Care ...............................................................................................................................................................................16 Caring for Your NOOK ..................................................................................................................................................................17 Locking and Unlocking Your NOOK .............................................................................................................................................18 Using Gestures to Control Your NOOK ....................................................................................................19 Ta p ...................................................................................................................................................................................................19 Double Tap ......................................................................................................................................................................................19 Press and Hold ...............................................................................................................................................................................20 Swipe ...............................................................................................................................................................................................20 Scroll ................................................................................................................................................................................................21 The Quick Nav Bar ......................................................................................................................................22 The Status Bar .............................................................................................................................................23 The Left Side of the Status Bar .......................................................................................................................................................23 The Right Side of the Status Bar ....................................................................................................................................................23 Swiping Left on the Status Bar ........................................................................................................................................................24 GlowLight ......................................................................................................................................................25 Turning GlowLight On or Off ........................................................................................................................................................25 Adjusting the Brightness of GlowLight ..........................................................................................................................................25 The Home Screen ........................................................................................................................................27 The Reading Now Panel .................................................................................................................................................................27 The NEW ON NOOK Shelf .........................................................................................................................................................27 Reading Books on Your NOOK ...................................................................................................................29 Opening a Book ................................…

Text truncated - open the document above for the full version.

BARNES&NOBLE www.bn.com September 18, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Attestation of Orientations supported for Model BNRV500 FCC ID: XHHBNRV500-A To Whom It May Concern Regarding the model BNRV500, an electronic book reader, we hereby attest that this device can only be used in a lap held, portrait position. No other orientations are supported by this device. Best Regards Vice President, Hardware Engineering Barnes&Noble.com

BARNES&NOBLE www.bn.com August 28, 2013 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; BARNES&NOBLE www.bn.com Cont- e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Barnes&Noble.com

BARNES&NOBLE www.bn.com September 18, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: XHHBNRV500-A To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission's rules (47 CFR §§ 0.457, 0.459), we hereby request that the Commission withhold the attached confidential document from public disclosure indefinitely: o Schematic Diagram o Block Diagram o Theory of Operation The above-mentioned documents contain detailed system and equipment descriptions and are considered proprietary information of Barnes & Noble relating to the operation of the equipment. Public disclosure of above documents might be harmful to our company and would give any of our competitors an unfair advantage in the marketplace. In additional to the above-mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission's policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we hereby request that the BARNES NOBLE www.bn.com commission grant short-term confidentiality request on the following attachments until 90 days after the date of grant. o External Photos o Internal Photos o Test Setup Photos o User Manual It is our understanding that all measurement test reports, FCC ID label formatting and correspondence during the certification review process cannot be granted as confidential documents and that such information will be available for public review once the grant of equipment authorization is issued. Best Regards Vice President, Hardware Engineering Barnes&Noble.com

01 01 02 13/2/18 Change to single color 03 13/5/17 Update ID Numbers Model No: BNRV500 FCC ID: XHHBNRV500-A IC: 8961A-BNRV500A Assembled in China BC

SPORTON INTERNATIONAL INC. Page Number : 1 of 29 TEL : 886-3-327-3456 Report Issued Date : Oct. 08, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHHBNRV500-A FCC SAR Test Report Report No. : FA362842-01 FCC SAR Test Report APPLICANT : Barnes&Noble.com EQUIPMENT : eBook BRAND NAME : Nook MODEL NAME : BNRV500 FCC ID : XHHBNRV500-A STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 The product was completely tested on Sep. 29, 2013. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. Page Number : 2 of 29 TEL : 886-3-327-3456 Report Issued Date : Oct. 08, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHHBNRV500-A FCC SAR Test Report Report No. : FA362842-01 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 4 2.1 Testing Laboratory .................................................................................................................................................. 4 2.2 Applicant ................................................................................................................................................................ 4 2.3 Manufacturer .......................................................................................................................................................... 4 2.4 Application Details .................................................................................................................................................. 4 3. General Information ...................................................................................................................................................... 5 3.1 Description of Equipment Under Test (EUT) .......................................................................................................... 5 3.2 Maximum RF output power among production units .............................................................................................. 5 3.3 Applied Standard .................................................................................................................................................... 6 3.4 Device Category and SAR Limits ........................................................................................................................... 6 3.5 Test Conditions ....................................................................................................................................................... 6 4. Specific Absorption Rate (SAR) ................................................................................................................................... 7 4.1 Introduction ............................................................................................................................................................ 7 4.2 SAR Definition ........................................................................................................................................................ 7 5. SAR Measurement System ........................................................................................................................................... 8 5.1 E-Field Probe ......................................................................................................................................................... 9 5.2 Data Acquisition Electronics (DAE) ........................................................................................................................ 9 5.3 Robot ....................................................................................................................................................................10 5.4 Measurement Server .............................................................................................................................................10 5.5 Phantom ................................................................................................................................................................ 11 5.6 Device Holder........................................................................................................................................................12 5.7 Data Storage and Evaluation ................................................................................................................................13 5.8 Test Equipment List ...............................................................................................................................................15 6. Tissue Simulating Liquids ...........................................................................................................................................16 7. System Verification Procedures .................................................................................................................................18 7.1 Purpose of System Performance check ................................................................................................................18 7.2 System Setup .......................................................................................................................…

Text truncated - open the document above for the full version.

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013/9/29 #01_WLAN2.4GHz_802.11b 1Mbps_Front Face_0.5cm_Ch11 Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium: MSL_2450_130929 Medium parameters used: f = 2462 MHz; σ = 1.991 mho/m; ε r = 52.33; ρ = 1000 kg/m 3 DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(4.02, 4.02, 4.02); Calibrated: 2013/6/18; - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2013/1/28 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1029 - Measurement SW: DASY52, Version 52.8 (3);SEMCAD X Version 14.6.5 (6469) Configuration/Ch11/Area Scan (121x51x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.497 mW/g Configuration/Ch11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5m m Reference Value = 17.008 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 0.895 mW/g SAR(1 g) = 0.422 mW/g; SAR(10 g) = 0.209 mW/g Maximum value of SAR (measured) = 0.544 mW/g 0 dB = 0.544 mW/g = -5.29 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013/9/29 #02_WLAN2.4GHz_802.11b 1Mbps_Bottom Face_0.5cm_Ch11 Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium: MSL_2450_130929 Medium parameters used: f = 2462 MHz; σ = 1.991 mho/m; ε r = 52.33; ρ = 1000 kg/m 3 DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(4.02, 4.02, 4.02); Calibrated: 2013/6/18; - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2013/1/28 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1029 - Measurement SW: DASY52, Version 52.8 (3);SEMCAD X Version 14.6.5 (6469) Configuration/Ch11/Area Scan (121x51x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.720 mW/g Configuration/Ch11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5m m Reference Value = 20.516 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 1.323 mW/g SAR(1 g) = 0.586 mW/g; SAR(10 g) = 0.271 mW/g Maximum value of SAR (measured) = 0.785 mW/g 0 dB = 0.785 mW/g = -2.10 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013/9/29 #03_WLAN2.4GHz_802.11b 1Mbps_Edge 3_0.5cm_Ch11 Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium: MSL_2450_130929 Medium parameters used: f = 2462 MHz; σ = 1.991 mho/m; ε r = 52.33; ρ = 1000 kg/m 3 DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(4.02, 4.02, 4.02); Calibrated: 2013/6/18; - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2013/1/28 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1029 - Measurement SW: DASY52, Version 52.8 (3);SEMCAD X Version 14.6.5 (6469) Configuration/Ch11/Area Scan (41x121x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.581 mW/g Configuration/Ch11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5m m Reference Value = 17.080 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.844 mW/g SAR(1 g) = 0.420 mW/g; SAR(10 g) = 0.202 mW/g Maximum value of SAR (measured) = 0.537 mW/g 0 dB = 0.537 mW/g = -5.40 dB mW/g

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013/9/29 System Check_Body_2450MHz_130929 DUT: D2450V2-SN:736 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_130929 Medium parameters used: f = 2450 MHz; σ = 1.975 mho/m; ε r = 52.379; ρ = 1000 kg/m 3 DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(4.02, 4.02, 4.02); Calibrated: 2013/6/18; - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2013/1/28 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1029 - Measurement SW: DASY52, Version 52.8 (3);SEMCAD X Version 14.6.5 (6469) Configuration/Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 18.3 mW/g Configuration/Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5m m Reference Value = 94.064 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 26.031 mW/g SAR(1 g) = 12.9 mW/g; SAR(10 g) = 6.07 mW/g Maximum value of SAR (measured) = 16.7 mW/g 0 dB = 16.7 mW/g = 24.45 dB mW/g

FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : 1 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 lFCC Test Report Equipment : eBook Brand Name : Nook Model No. : BNRV500 FCC ID : XHHBNRV500-A Standard : 47 CFR FCC Part 15.247 Operating Band : 2400 MHz – 2483.5 MHz Equipment Class : DTS Applicant : Barnes&Noble.com 76 Ninth Avenue, 9th Floor, New York, NY 10011 Manufacturer : Maintek Computer (Suzhou) Co,, Ltd. NO .233, Jin Feng Road, Suzhou New District, Jiang Su Province, P.R.C. The product sample received on Sep. 11, 2013 and completely tested on Sep. 27, 2013. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : 2 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Accessories and Support Equipment ..................................................................................................... 7 1.3 Testing Applied Standards ..................................................................................................................... 8 1.4 Testing Location Information .................................................................................................................. 8 1.5 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION OF EUT ...................................................................................................... 10 2.1 The Worst Case Modulation Configuration .......................................................................................... 10 2.2 The Worst Case Power Setting Parameter .......................................................................................... 10 2.3 The Worst Case Measurement Configuration ...................................................................................... 11 2.4 Test Setup Diagram ............................................................................................................................. 13 3 TRANSMITTER TEST RESULT .......................................................................................................... 14 3.1 AC Power-line Conducted Emissions .................................................................................................. 14 3.2 6dB Bandwidth ..................................................................................................................................... 17 3.3 RF Output Power .................................................................................................................................. 19 3.4 Power Spectral Density ........................................................................................................................ 23 3.5 Transmitter Radiated Bandedge Emissions ......................................................................................... 25 3.6 Transmitter Radiated Unwanted Emissions ......................................................................................... 28 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 51 APPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : 3 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.3 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]: 0.1556680MHz 54.42 (Margin 11.27dB) - QP 46.60 (Margin 9.09dB) - AV FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth Unit [MHz] 20M: 7.06 ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm]: 19.32 Power [dBm]:30 Complied 3.4 15.247(e) Power Spectral Density PSD [dBm/100kHz]: -10.18 PSD [dBm/3kHz]:8 Complied 3.5 15.247(d) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 2400.00 MHz: 30.41dB Restricted Bands [dBuV/m at 3m]: 2390.00MHz 65.26 (Margin 8.74 dB) - PK 49.89 (Margin 4.11 dB) - AV Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied 3.6 15.247(d) Transmitter Radiated Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 59.100 MHz 38.52 (Margin 1.48 dB) - QP Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : 4 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR362842 Rev. 01 Initial issue of report Sep. 02, 2013 FR362842-01 Rev. 01 Change to new version of WiFi ModuleOct. 14, 2013 2500-2690 FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : 5 of 52 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 Feature of Equipment under Test Component type SKU A SKU B Battery McNair / MLP305787 Lico / S11ND018A eMMC Samsung 4GB AC Adaptor BARNES&NOBLE / BNRP5-850-1 USB Cable 1 Foxlink / NA USB Cable 2 MEC /…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : D1 of D1 TEL : 886-3-327-3456 Report Issued Date : Oct. 08, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : XHHBNRV500-A FCC SAR Test Report Report No. : FA362842-01 Appendix D. SAR Test Setup Photos Bottom Face, Test Separation 0.5 cm Front Face, Test Separation 0.5 cm Edge3, Test Separation 0.5 cm

FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A1 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Appendix A. Test Photos FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A2 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Photographs of Conducted Emissions Test Configuration Mode 4 FRONT VIEW REAR VIEW FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A3 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 SIDE VIEW FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A4 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A5 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions 30MHz~1GHz Mode 2 FRONT VIEW REAR VIEW FCC Test Report Report No. : FR362842-01 SPORTON INTERNATIONAL INC. Page No. : A6 of A6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions above 1GHz Mode 2 FRONT VIEW REAR VIEW
