XHT8038-T49MTOY-R/C TRANS ROBOT CAR
Guangdong Yinrun Industry Co., LTD.
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Nov 10, 2010
- Application Purpose
- Original Equipment
- Date of Application
- Nov 10, 2010
- Equipment Note
- TOY-R/C TRANS ROBOT CAR
- Frequency Range
- 49.86000000 - 49.86000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
User manual Fcc statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
Block Diagram
Block Diagram Filter RF IC Oscillator 49 MHz Control key 49MHz
Cover Letter(s)
ζ·±ε³εΈεζ η΅εη§ζζιε ¬εΈ Bontek Compliance Testing Laboratory Ltd DATE:November 3,2010. Dear TCB Section of Timco Engineering, Inc., Thank you for cooperation. I would like to submit FCC application of Guangdong Yinrun Industry CO., LTD. . FCC ID: XHT8038-T49M by your TCB Approval today. Best Regards, Bontek Compliance Testing Laboratory Ltd. Tony Wu/General Manager
Cover Letter(s)
Guangdong Yinrun Industry CO., LTD. FCC ID: XHT8038-T49M POWER OF ATTORNEY November 3, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Bontek Compliance Testing Laboratory Ltd.(Tony Wu) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Bontek Compliance Testing Laboratory Ltd. (Tony Wu) on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act.We, Guangdong Yinrun Industry CO., LTD.are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuantto that section. Sincerely, Guangdong Yinrun Industry CO., LTD. Cyrus Yang (General Manager)
External Photos
External Photographs EUT βTop View EUT βRear View
ID Label/Location Info
FCC ID Label Sample for FCC ID:XHT8038-T49M FCC ID:XHT8038-T49M Model: 8038 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
ID Label/Location Info
FCC ID Location FCC ID Location
Internal Photos
Internal Photographs EUT βPCB View
Operational Description
65.4 87.8 98.8 76.7 53.6 42 30 18
Operational Description
PRODUCT PRODUCT PRODUCT PRODUCTDESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION Theequipmentundertestis TOY-R/C TRANS ROBOT CAR operationat 49Mhz.TheEUT RX issuppliedsourcebyone new 9V battery.Thetransmitterisa2buttonstransmitter.TheEUT continues totransmitwhilebuttonisbeingpressed,ModulationbyIC. Theantennaconsisisofa 80cmlongthinwire.Whentheantenna receiveselectromagneticwavesofdifferentfrequenciesintotheair aftertheprincipleofelectromagneticinductionthroughinternally generatedintheantennastrengthofdifferentcurrents,andtheninto thehigh-frequencydetectorcircuitforselectivefrequency amplification,amplifiedhighfrequencysignalthroughthelow-pass filteredbythefiltercircuitfeetintotheIC,modulatedbythe decoderICfromICweaksignaloutputpin,intothedrive circuit,amplificationandthendrivenbythemotordrivecircuit rotation,inordertoachieveasharkcarandbackupeachfunction.
Schematics
123456 A B C D 6 54321 D C B A Title NumberRevisionSize B Date:9-Nov-2010 Sheet of File:C:\Documen ts an d Set tin gs\ Ad mini strato r\My Do cu ment s\YY-05 8T3. DDBDrawn By : 1 87 6 5 4 3 2 14 13 12 11 10 9 IC 1 ε·¦εε³εε³ε ι³δΉιζ© ι³δΉεΌε ³ ε·¦εδΈεδΈιζΌη€Ί Q1 1815/Y Q2 1815/Y L2 1.0uH L1 2.2uH R10 100K R8 100R R6 100R C5 33P X1 49 M C6 22P C4 103 C7 501P C9 102P L3 1.5uH ANT C8 471 R11 10K VDD R5 10K VCC K4 B+ LED1 R7 330R C3 104 VDD C2 100uF D1 3.9V/0.5W R9 330R VCC R2 10K R3 10K VCC C1 104 VCC VDD Schematic Diagram
Test Report
Test Report of FCC Part 15 C for FCC Certificate On Behalf of Guangdong Yinrun Industry Co., LTD. FCC ID: XHT8038-T49M Product Description: TOY-R/C TRANS ROBOT CAR Model No.: 8038 Prepared for: Guangdong Yinrun Industry CO., LTD. Yinrun Ind. Garden, Laimei Zone, Chenghai, Shantou City, Guangdong, China Prepared by: Bontek Compliance Testing Laboratory Ltd 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Tel: 86-755-86337020 Fax: 86-755-86337028 Report No.: BCT10JR-1755E Issue Date: November 03, 2010 Test Date: October 01 ~ November 03, 2010 Test by: Reviewed By: Kendy Wang Tony Wu Report No.: BCT10JR-1755E Page 2 of 18 FCC ID:XHT8038-T49M TABLE OF CONTENTS 1- GENERAL INFORMATION ................................................................................................................. 3 1.1 Product Description for Equipment Under Test (EUT)..............................................................3 1.2 Related Submittal(s) / Grant (s).................................................................................................3 1.3 Test Methodology ......................................................................................................................3 1.4 Test Facility................................................................................................................................4 2- SYSTEM TEST CONFIGURATION..................................................................................................... 5 2.1 EUT Configuration .....................................................................................................................5 2.2 EUT Exercise .............................................................................................................................5 2.3 General Test Procedures ..........................................................................................................5 2.4 List of Measuring Equipments Used .........................................................................................6 3- SUMMARY OF TEST RESULTS ........................................................................................................ 8 4- TEST OF CONDUCTED EMISSION ...................................................................................................9 4.1 Applicable Standard...................................................................................................................9 4.2 Test Setup Diagram...................................................................................................................9 5- RADIATED EMISSIONS.................................................................................................................... 10 5.1 Limit of Radiated Emissions ..................................................................................................10 5.2 Test Equipment Used ..............................................................................................................10 5.3 EUT Setup ...............................................................................................................................11 5.4 Test Procedure ........................................................................................................................11 5.5 Test Result ...............................................................................................................................12 6- OCCUPIED BANDWIDTH ................................................................................................................. 17 6.1 Limit of Occupied Bandwidth ...................................................................................................17 6.2 Test Equipment Used ..............................................................................................................17 6.3 Test Procedure ........................................................................................................................17 6.4 Occupied Bandwidth Test Result ............................................................................................17 Report No.: BCT10JR-1755E Page 3 of 18 FCC ID:XHT8038-T49M 1- GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Applicant: Guangdong Yinrun Industry CO., LTD. Address of applicant: Yinrun Ind, Garden, Laimei Zone, Chenghai, Shantou City, Guangdong, China Manufacturer: Guangdong Yinrun Industry CO., LTD. Address of manufacturer: Yinrun Ind, Garden, Laimei Zone, Chenghai, Shantou City, Guangdong, China EUT Description: TOY-R/C TRANS ROBOT CAR Trade Name: N/A Test Model: 8038 Rated Voltage DC 9V laminated battery for transmitter Frequency range 49.862MHz Number of channels 1 Channel Separation None Product Class: Low Power Communication Device Transmitter Measurement Procedure ANSI C63.4-2003 Remark: * The test data gathered are from the production sample provided by the manufacturer. 1.2 Related Submittal(s) / Grant (s) This submittal(s) is a test report based on the Electromagnetic Interference (EMI) tests performed on the EUT. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4 - 2003. The tests were performed in order to determine compliance with FCC Part 15, Subpart C, section 15.235 rules. 1.3 Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4 - 2003, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. Radiated testing was performed at an antenna to EUT distance 3 meters. Report No.: BCT10JR-1755E Page 4 of 18 FCC ID:XHT8038-T49M 1.4 Test Facility All measurement required was performed at laboratory of Bontek Compliance Testing Laboratory Ltd at 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China. The test facility is recognized, certified, or accreditβ¦
Text truncated - open the document above for the full version.
Test Setup Photos
TEST SETUP PHOTOGRAPHS Radiated Emission
Contact Information
Applicant
Cyrus Yang(General Manager)
Test Firm
Bontek Compliance Testing Laboratory LtdTony Wu
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 49.86 MHz - 49.86 MHz | - |
