XHZU5501HSDPA Module

U5501_Hardware_User_Guide_V2.3 Page 1 of 59 U5501_Hardware_User_Guide _V2.3 U5501_Hardware_User_Guide_V2.3 Page 2 of 59 IMPORTANT NOTICE COPYRIGHT NOTICE Copyright©2010, LongSung Technology (Shanghai) Co., Ltd. All rights reserved. TRADEMARKS LongSung Technology (Shanghai) Co., Ltd’s products are exclusively owned by LongSung Technology (Shanghai) Co., Ltd. References to other companies and their products use trademarks owned by the respective companies and are for reference purpose only. CONFIDENTIALITY The information contained here (including any attachments) is confidential. The recipient here acknowledges the confidentiality of this document, and except for the specific purpose, this document shall not be disclosed to any third party. WARRANTY DISCLAIMER LongSung Technology (Shanghai) Co., Ltd makes no representations or warranties, either express or implied, by or with respect to anything in this document, and shall not be liable for any implied warranties of merchantability or fitness for a particular purpose or for any indirect, special or consequential damages. NO GUARANTEE Our company will not take any responsibility for any damage caused by the customer’s abnormal operation. Please refer to specification and designing reference guide. Our company have right to modify the document according to technical requirement with no announcement to the customer. U5501_Hardware_User_Guide_V2.3 Page 3 of 59 CAUTION: U5501 HSDPA module is an ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 1 K Volts readily accumulate on the human body and test equipment and can discharge without detection. Permanent damage may occur on devices subjected to high-energy electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance degradation or loss of functionality. Warning: The U5501 module is designed to comply with the FCC statements.FCC ID is XHZU5501.The Host system using U5501 should indicated “Contains FCC ID: XHZU5501”. This device complies with part 15B of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authorityto operate the equipment. This equipment complies with FCC/IC radiation exposure limits set forth for an Uncontrolled environment.This equipment should be installed and operated with minimum distance 20cm between the radiator and your body as well as kept minimum 20cm from radio antenna depending on the portable or Mobile status of this module usage. The manual of the host system,which use U5501 must include RF exposure warning statement to advice user should keep minimum 20cm from the radio antenna of U5501 module depending on Mobile status. The U5501 module can not be installed with other radio .such as co-located or operating in conjunction with any other antenna or transmitter. Antenna Type: Connector Antenna Gain: GSM850:1.2dBi;GSM1900:1.2dBi. U5501_Hardware_User_Guide_V2.3 Page 4 of 59 Contents 1. Overview..................................................................................................................................8 1.1. Purpose of the document.......................................................................................8 1.2. Summary......................................................................................................................8 1.3. Correlative documents............................................................................................8 1.4. Document’s history...................................................................................................9 1.5. Abbreviations..............................................................................................................9 2. Introduction........................................................................................................................... 11 2.1. Key features..............................................................................................................13 2.2. Operating modes.....................................................................................................15 2.3. Hardware functional block diagram.................................................................16 3. Application interfaces description.................................................................................18 3.1. 116-pin LGA PAD.....................................................................................................18 3.2. Power supply.............................................................................................................22 3.2.1. Power Supply and reference design.....................................................22 3.2.1.1. VBAT input.........................................................................................22 3.2.1.2. VRTC input.........................................................................................23 3.2.1.3. VOUT voltage output......................................................................24 3.2.1.4. POWER_ON_OFF input..................................................................24 3.2.1.5. RESET_N input.................................................................................25 3.2.2. Power on/off time sequence...................................................................26 3.2.2.1. Power on time sequence..............................................................26 3.2.2.2. Normal power off time seqence.................................................26 3.2.2.3. Low power to power off................................................................27 3.2.3. Reset time sequence..................................................................................27 3.3. USB interface....…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012

SCS-F26 Modular Approval Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (current) 6.0 7.0 Jan-31-2012

Annex B.i. Photograph 1: EUT External Photo Whole Package - Top View EUT - Front View EUT - Rear View

Label and Location Size：28mm*28mm

Annex B.ii. Photograph 2: EUT Internal Photo Uncover Without Shielding - Top View 1 Uncover Without Shielding - Top View 2

longsung Technology （Shanghai）Co .,Ltd HSDPA Module Main Model:U5501 September 06, 2012 Report No.: 12050061-FCC-R2 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Chris Bi Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 2 of 8 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 3 of 8 www.siemic.com.cn This page has been left blank intentionally. Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 4 of 8 www.siemic.com.cn CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION...........................................................................................5 2. TECHNICAL DETAILS ..........................................................................................................................................6 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) ..................................................................................................7 FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE)...................................................................................7 Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 5 of 8 www.siemic.com.cn 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programmed was to demonstrate compliance of the longsung Technology （Shanghai）Co .,Ltd HSDPA Module and model: U5501 against the current Stipulated Standards. The HSDPA Module has demonstrated compliance with the FCC 2.1091: 2012. EUT Information EUT Description : HSDPA Module Main Model : U5501 Antenna Gain : GSM850: 1.2dBi PCS1900: 1.2dBi Input Power : DC 3.3~4.2V Maximum Conducted Peak Power to Antenna : GSM850: 32.65 dBm PCS1900: 28.70 dBm Maximum Radiated ERP/EIRP : GSM850: 28.39 dBm / ERP PCS1900: 27.02 dBm / EIRP Classification Per Stipulated Test Standard : FCC 2.1091: 2012 Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 6 of 8 www.siemic.com.cn 2. TECHNICAL DETAILS Purpose Compliance testing of HSDPA Module with stipulated standard Applicant / Client longsung Technology （Shanghai）Co .,Ltd Bldg.5,299 BiSheng Rd, Zhangjiang Hi-Tech Park, Pudong, Shanghai, P.R. China Manufacturer longsung Technology （Shanghai）Co .,Ltd Bldg. 5, Lane 299, Bisheng Rd., Zhangjiang Hi-Tech Park, Pudong District, Shanghai, P.R. China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 12050061-FCC-R2 Date EUT received August 13, 2012 Standard applied FCC 2.1091: 2012 Dates of test August 15, 2012 to August 23, 2012 No of Units #1 Equipment Category PCE Trade Name Longsung RF Operating Frequency (ies) GSM850 TX : 824.2 ~ 848.8 MHz; RX : 869.2 ~ 893.8 MHz PCS1900 TX : 1850.2 ~ 1909.8 MHz; RX : 1930.2 ~ 1989.8 MHz Number of Channels 299CH (PCS1900) and 124CH (GSM850) Modulation GSM / GPRS: GMSK EDGE: 8PSK GPRS Multi-slot class 8/10/12 FCC ID XHZU5501 Title: RF Exposure Report for HSDPA Module Main Model: U5501 To: FCC 2.1091: 2012 Report No: 12050061-FCC-R2 Issue Date: September 06, 2012 Page: 7 of 8 www.siemic.com.cn 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500…

Text truncated - open the document above for the full version.

longsung Technology （Shanghai）Co .,Ltd HSDPA Module Main Model: U5501 Serial Model: N/A August 24, 2012 Report No.: 12050061-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Chris Bi Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for HSDPA Module Main Model: U5501 Serial Model: N/A To: FCC Part 22(H) & FCC Part 24(E): 2012, ANSI/TIA-603-C-2004 Report No: 12050061-FCC-R1 Issue Date: August 24, 2012 Page: 2 of 58 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Test Report for HSDPA Module Main Model: U5501 Serial Model: N/A To: FCC Part 22(H) & FCC Part 24(E): 2012, ANSI/TIA-603-C-2004 Report No: 12050061-FCC-R1 Issue Date: August 24, 2012 Page: 3 of 58 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for HSDPA Module Main Model: U5501 Serial Model: N/A To: FCC Part 22(H) & FCC Part 24(E): 2012, ANSI/TIA-603-C-2004 Report No: 12050061-FCC-R1 Issue Date: August 24, 2012 Page: 4 of 58 www.siemic.com.cn CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION...........................................................................................5 2. TECHNICAL DETAILS ..........................................................................................................................................6 3. MODIFICATION .....................................................................................................................................................7 4. TEST SUMMARY ....................................................................................................................................................8 5. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ...................................................................9 FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE)...................................................................................9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................50 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ...........................................................................................53 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT................................................................................54 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................57 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................58 Title: RF Test Report for HSDPA Module Main Model: U5501 Serial Model: N/A To: FCC Part 22(H) & FCC Part 24(E): 2012, ANSI/TIA-603-C-2004 Report No: 12050061-FCC-R1 Issue Date: August 24, 2012 Page: 5 of 58 www.siemic.com.cn 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programmed was to demonstrate compliance of the longsung Technology （Shanghai）Co .,Ltd HSDPA Module and model: U5501 against the current Stipulated Standards. The HSDPA Module has demonstrated compliance with the FCC Part 22(H) & FCC Part 24(E): 2012. EUT Information EUT Description : HSDPA Module Main Model : U5501 Serial Model : N/A Antenna Gain : GSM850: 1.2dBi; PCS1900: 1.2dBi; Input Power : DC 3.3~4.2V Maximum Conducted Peak Power to Antenna : GSM850: 32.65 dBm PCS1900: 28.70 dBm Maximum Radiated ERP/EIRP : GSM850: 28.39 dBm / ERP PCS1900: 27.02 dBm / EIRP Classification Per Stipulated Test Standard : FCC Part 22(H) & FCC Part 24(E): 2012 ANSI/TIA-603-C-2004 Title: RF Test Report for HSDPA Module Main Model: U5501 Serial Model: N/A To: FCC Part 22(H) & FCC Part 24(E): 2012, ANSI/TIA-603-C-2004 Report No: 12050061-FCC-R1 Issue Date: August 24, 2012 Page: 6 of 58 www.siemic.com.cn 2. TECHNICAL DETAILS Purpose Compliance testing of HSDPA Module with stipulated standard Applicant / Client longsung Technology （Shanghai）Co .,Ltd Bldg.5, 299 BiSheng Rd, Zhangjiang Hi-Tech Park, Pudong, Shanghai, P.R. China Manufacturer longsung Technology （Shanghai）Co .,Ltd Bldg. 5, Lane 299, Bisheng Rd., Zhangjiang Hi-Tech Park, Pudong District, Shanghai, P.R. China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 12050061-FCC-R1 Date EUT received …

Text truncated - open the document above for the full version.

Annex B. Test Setup Photo Radiated Spurious Emissions Test Setup Below 1GHz - Front View Radiated Spurious Emissions Test Setup Above 1GHz - Front View
