XJ6MT-3003 CH 2.4GHz FHSS Radio System

Channel Output "1": Aileron servo (CH1) "2": Elevator servo (CH2) "3": Throttle servo (CH3) "4": Rudder Gear AUX servo (CH4) "5":(CH5) "6":(CH6) e Antenna Fail Safe Setup , Continue...

Authorization Letter We, (the approval holder) Company name SHANGHAI MERIT TECHNOLOGY CORP. Addresss 1058 TAOGAN RD., SHESHAN TOWN, SONGJIANG DISTRICT, City SHANGHAI Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to BABT TEST-LAB for product certification below Product Description 3CH 2.4GHz FHSS RADIO SYSTEM Type or Model(s) MT-300 Tradename or Brand(s) MERITRC Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2012/5/24 Dongcheng Zheng Artificial Person

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name SHANGHAI MERIT TECHNOLOGY CORP. Addresss 1058 TAOGAN RD., SHESHAN TOWN, SONGJIANG DISTRICT, City SHANGHAI Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: XJ6 MT-300 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2012/5/24 Dongcheng Zheng Artificial Person

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC label 3.8*5cm

Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13

FCC RADIO TEST REPORT FCC ID: XJ6MT-300 Product： 3CH 2.4GHz FHSS RADIO SYSTEM Trade Name： MERITRC Model Name： MT-300 Serial Model： N/A Report No.： NTEK- 2012NT0523980F Prepared for Shanghai Merit Technology Corp. No. 1058 Taogan Road, Sheshan, Songjiang, Shanghai, China Prepared by NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 37 Report No.: NTEK- 2012NT0523980F ` TEST RESULT CERTIFICATION Applicant’s name ................. : Shanghai Merit Technology Corp. Address ................................. : No. 1058 Taogan Road, Sheshan, Songjiang, Shanghai, China Manufacture's Name ............ : Shanghai Merit Technology Corp. Address ................................. : No. 1058 Taogan Road, Sheshan, Songjiang, Shanghai, China Product description Product name ........................... : 3CH 2.4GHz FHSS RADIO SYSTEM Model and/or type reference : MT-300 Serial Model： N/A Rating(s) ................................ : DC 6V(1.5V*4cell “AA” alkaline battery) Standards ............................. : FCC Part15.249 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 15 May 2012 ~22 May 2012 Date of Issue ........................................... : 22 May 2012 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 37 Report No.: NTEK- 2012NT0523980F ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . ANTENNA REQUIREMENT 12 3.1 STANDARD REQUIREMENT 12 3.2 EUT ANTENNA 12 3.3 CONDUCTED EMISSION MEASUREMENT 13 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.3.2 TEST PROCEDURE 14 3.3.3 DEVIATION FROM TEST STANDARD 14 3.3.4 TEST SETUP 14 3.2.5 TEST RESULT 15 3.4 RADIATED EMISSION MEASUREMENT 16 3.4.1 RADIATED EMISSION LIMITS 16 3.4.2 TEST PROCEDURE 17 3.4.3 DEVIATION FROM TEST STANDARD 17 3.4.4 TEST SETUP 18 3.4.5 TEST RESULTS (BLOW 30MHZ) 20 3.4.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 21 3.4.7 TEST RESULTS (ABOVE 1000 MHZ) 23 3.4.8 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 29 4 . BANDWIDTH TEST 33 4.1 TEST PROCEDURE 33 4.2 DEVIATION FROM STANDARD 33 4.3 TEST SETUP 33 4.4 TEST RESULTS 34 5 . EUT TEST PHOTO 37 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 37 Report No.: NTEK- 2012NT0523980F ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.205 Band Edge Emission PASS 15.249 Occupied Bandwidth Pass NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 5 of 37 Report No.: NTEK- 2012NT0523980F ` 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC FRN Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 37 Report No.: NTEK- 2012NT0523980F ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment 3CH 2.4GHz FHSS RADIO SYSTEM Trade Name MERITRC Model Name MT-300 Serial Model N/A Model Difference N/A Product Description The EUT is a 3CH 2.4GHz FHSS RADIO SYSTEM Operation Frequency: 2405~2455 MHz Modulation Type: FHSS Antenna Designation: Built-in Antenna Antenna Gain(Peak) 2.0 dBi EIRP 105.39dbuv/m@3m Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery 1.5V*4cell “AA” alkaline battery Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 7 of 37 Report No.: NTEK- 2012NT0523980F ` 2. Channel Frequency (MHz) 01 2405 02 2406 ...... ...... 26 2430 27 2431 ...... ...... 50 2454 51 2455 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna N/A 2.0 Antenna Page 8 of 37 Report No.: NTEK- 2012NT0523980F ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated r…

Text truncated - open the document above for the full version.

Page 37 of 37 Report No.: NTEK- 2012NT0523980F ` 5. EUT TEST PHOTO Radiated Measurement Photos
