XKB-DX8AM

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	824.2 MHz - 848.8 MHz	2.4491 W	247KGXW	2.5ppm
2	22H	824.2 MHz - 848.8 MHz	445.70 mW	244KG7W	2.5ppm
3	24E	1.85 GHz - 1.91 GHz	1.4454 W	251KGXW	2.5ppm
4	24E	1.85 GHz - 1.91 GHz	417.80 mW	251KG7W	2.5ppm
5	24E	1.85 GHz - 1.91 GHz	302.00 mW	4M15F9W	2.5ppm
6	27	1.71 GHz - 1.75 GHz	254.10 mW	4M17F9W	2.5ppm
7	22H	826.4 MHz - 846.6 MHz	257.00 mW	4M21F9W	2.5ppm
8	24E	1.85 GHz - 1.91 GHz	269.20 mW	18M0G7D	2.5ppm
9	24E	1.85 GHz - 1.91 GHz	237.70 mW	18M0W7D	2.5ppm
1	24E	1.85 GHz - 1.91 GHz	287.10 mW	9M02G7D	2.5ppm
11	24E	1.85 GHz - 1.91 GHz	285.80 mW	9M05W7D	2.5ppm
12	27	1.71 GHz - 1.75 GHz	229.60 mW	18M1G7D	2.5ppm
13	27	1.71 GHz - 1.75 GHz	227.50 mW	18M1W7D	2.5ppm
14	27	1.71 GHz - 1.75 GHz	242.10 mW	9M05G7D	2.5ppm
15	22H	824 MHz - 849 MHz	258.80 mW	9M04G7D	2.5ppm
16	22H	824 MHz - 849 MHz	222.80 mW	9M01W7D	2.5ppm
17	22H	824 MHz - 849 MHz	233.90 mW	1M11W7D	2.5ppm
18	27	2.50 GHz - 2.57 GHz	257.60 mW	18M0G7D	2.5ppm
19	27	2.50 GHz - 2.57 GHz	255.30 mW	18M1W7D	2.5ppm
2	27	2.50 GHz - 2.57 GHz	266.70 mW	9M05G7D	2.5ppm
21	27	699 MHz - 716 MHz	276.10 mW	9M02G7D	2.5ppm
22	27	699 MHz - 716 MHz	235.50 mW	9M04W7D	2.5ppm
23	27	699 MHz - 716 MHz	279.90 mW	1M12G7D	2.5ppm
24	27	777 MHz - 787 MHz	266.70 mW	9M04G7D	2.5ppm
25	27	777 MHz - 787 MHz	240.40 mW	9M02W7D	2.5ppm
26	27	704 MHz - 716 MHz	265.50 mW	9M08G7D	2.5ppm
27	27	704 MHz - 716 MHz	241.50 mW	9M05W7D	2.5ppm
28	27	1.85 GHz - 1.92 GHz	259.40 mW	18M0G7D	2.5ppm
29	27	1.85 GHz - 1.92 GHz	258.80 mW	18M0W7D	2.5ppm
3	27	1.85 GHz - 1.92 GHz	267.30 mW	1M11G7D	2.5ppm
31	9	814 MHz - 824 MHz	266.70 mW	9M03G7D	2.5ppm
32	9	814 MHz - 824 MHz	224.40 mW	9M05W7D	2.5ppm
33	9	814 MHz - 824 MHz	291.10 mW	2M75G7D	2.5ppm
34	9	814 MHz - 824 MHz	239.90 mW	1M11W7D	2.5ppm
35	22H	824 MHz - 849 MHz	264.20 mW	13M5G7D	2.5ppm
36	22H	824 MHz - 849 MHz	276.10 mW	13M5W7D	2.5ppm
37	22H	824 MHz - 849 MHz	282.50 mW	9M00G7D	2.5ppm
38	27	2.50 GHz - 2.69 GHz	273.50 mW	18M1G7D	2.5ppm
39	27	2.50 GHz - 2.69 GHz	240.40 mW	18M0W7D	2.5ppm
4	27	1.71 GHz - 1.78 GHz	261.20 mW	17M9G7D	2.5ppm
41	27	1.71 GHz - 1.78 GHz	248.30 mW	18M0W7D	2.5ppm
42	27	1.71 GHz - 1.78 GHz	300.60 mW	2M74G7D	2.5ppm
43	27	1.71 GHz - 1.78 GHz	255.90 mW	2M74W7D	2.5ppm
44	27	663 MHz - 697 MHz	257.60 mW	17M9G7D	2.5ppm
45	27	663 MHz - 697 MHz	254.10 mW	18M0W7D	2.5ppm
46	27	663 MHz - 697 MHz	263.60 mW	9M01G7D	2.5ppm

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. This device supports LTE of 1.4/3/5/10/15/20 MHz bandwidth modes for LTE Band 2/4/25/66; LTE of 1.4/3/5/10 MHz bandwidth modes for LTE Band 5/12; LTE of 5/10/15/20MHz bandwidth modes for LTE Band 7/41/71; LTE of 5/10MHz bandwidth modes for LTE Band 13/17; LTE of 1.4/3/5/10/15MHz bandwidth modes for LTE Band 26. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. For body worn operation, this device has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the device a minimum of 10mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Highest reported SAR for Body-worn accessory, product specific, simultaneous transmissions and extremity (hand) exposure conditions are 1.46 W/kg, 1.51 W/kg, 1.51 W/kg and 2.81 W/kg respectively. This device contains functions that are not operational in U.S. Territories; this filing is only applicable for U.S. operations.
