XKB-ICT250RFID Tag Reader

INGENICO – 192 avenue Charles de Gaulle – 92200 Neuilly sur Seine ‐ FRANCE Tél. 33(0)1 46 25 82 00 ‐ Fax 33 (0)1 47 72 56 95 www.ingenico.com Product name : iCT220/iCT250 Range : COUNTER TOP User Guide Product name : iCT220/iCT250 • 2/21 Copyright © 2009 Ingenico 900002734 R11 000 01/1021 296114093 All rights reserved Contents 1. Introduction __________________________________________________3 2. Unpacking ____________________________________________________3 3. Recommendations ____________________________________________ 4 3.1. Security _____________________________________________________________4 3.2. Telephone emergency, hanging up _______________________________________4 3.3. Security of your terminal _______________________________________________5 3.4. Standard compliance marking ___________________________________________5 3.5. FCC compliance _______________________________________________________5 3.6. Main Characteristics ___________________________________________________ 7 4. Installation and connection_____________________________________ 8 4.1. Positioning the terminal ________________________________________________8 4.2. Connections__________________________________________________________8 4.3. Installing the iCT220/iCT250 – Cable fixing__________________________________8 4.3.1. Opening the cable cover_________________________________________________________ 8 4.3.2. Kit Magic Box installation ________________________________________________________ 9 4.3.3. Connect cables _______________________________________________________________ 10 4.3.4. Close cover ___________________________________________________________________ 11 4.4. Installation of the Magic Box ___________________________________________ 11 4.5. Installing SAM (Secure access module) ___________________________________ 12 4.6. Installing MicroSD Card (optional) _______________________________________ 13 5. Installing a paper roll __________________________________________ 14 6. Daily use ____________________________________________________ 15 6.1. Keypad functions ____________________________________________________ 15 6.2. Adjusting the contrast ________________________________________________ 15 6.3. Card insertion _______________________________________________________ 16 6.3.1. Swiping a card ________________________________________________________________ 16 6.3.2. Inserting a chip card ___________________________________________________________ 16 6.3.3. Inserting a chip card in second reader (Optional) ____________________________________ 16 6.3.4. Reading Contactless (Optional) __________________________________________________ 16 7. Maintenance _________________________________________________ 18 7.1. Paper roll ___________________________________________________________ 18 7.2. Cleaning of the terminal _______________________________________________ 19 7.3. Transport and storage ________________________________________________ 19 7.4. Troubleshooting _____________________________________________________ 19 7.5. End of life___________________________________________________________20 Product name : iCT220/iCT250 • 3/21 Copyright © 2009 Ingenico 900002734 R11 000 01/1021 296114093 All rights reserved 1. Introduction Thank you for choosing an Ingenico payment terminal. We recommend you to read carefully this user guide: It gives you the necessary information about safety precautions, unpacking, installation, and maintenance of your terminal. CAUTION To benefit from the guarantee‐related product, and to respect the security, we ask you to use only the power supply delivered in box with the product, entrusting maintenance operations only to an authorized person. Failure to comply with these instructions will void the manufacturer’s responsibility. 2. Unpacking ADVICE Carefully preserve the packaging of the iCT220/iCT250. It must be re‐used whenever the terminal is shipped. According to the model, the following items are included in the iCT220/iCT250 box • The iCT220/iCT250 terminal equipped with its paper roll • Magic box ( mandatory use ) • The main power supply with its cable connection (according to the national needs). • The cable connection for the telephone network • This installation guide CAUTION The power supply unit provided with your equipment is specially designed for Ingenico iCT220/iCT250 terminals. Do not use any other power supply. Wall mounted power supply unit Cable connection for the telephone network iCT220/iCT250 terminal User guide Desktop power supply unit provided (mandatory) with iCT equipped with the following options: • Contactless model Magic box Product name : iCT220/iCT250 • 4/21 Copyright © 2009 Ingenico 900002734 R11 000 01/1021 296114093 All rights reserved 3. Recommendations 3.1. Security Power on/Power down To power on or power down the iCT220/iCT250 connect or disconnect the power supply from the electric outlet. Lithium battery The iCT220/iCT250 is fitted with a lithium battery which is not accessible to the user. Only a qualified technician may be authorized to open the unit and change this component. Electrical power supply network Provide an electrical outlet : ‐ located near the equipment and easily accessible ‐ which meets the standards and regulations in the country of use. Telephone network Provide a phone jack complying with standards and regulations in the country of use. SAM/SIM or SD Memory Card compartment cover Located under the terminal, it must be in place during normal operation of the terminal. Cable compartment cover The cable compartment cover is located under the terminal, it must be in place during normal operation of the terminal. 3.2. Telephone emergency, hanging up You have an urgent call to make, when iCT220/iCT250 hangs on the line. In order to get a dial tone... Place the handset in the hang up position and : press the red key (=cancel) or disconnect the power supply from the mains network or disconnect the iCT220/iCT250 telephone connec…

Text truncated - open the document above for the full version.

June 10 th , 2010 CONFIDENTIALITY REQUEST Curtis-Straus LLC One Distribution Center Circle #1 Littleton, MA 01460 USA Re: Confidentiality request for a Low Power Communication Device FCC ID: XKB-ICT250 Gentlemen, INGENICO requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application. The following document regarding this submission for FCC ID: XKB-ICT250 shall be kept confidential: 1. Schematic Diagram of the ICT250-01T1099C (file: Schematic- XKB-ICT250.pdf) 2. Block Diagram description of the ICT250-01T1099C (file: Block Diagram- XKB-ICT250.pdf) Specifically, these exhibits contain information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that INGENICO does not customarily release to the public and which is otherwise not generally available to the public. Regards, Marc DELORME Quality Manager 1, rue Claude Chappe – BP 346 07503 GUILHERAND GRANGES - France

FCC ID: XKB-ICT250 Page 1/3 EXTERNAL PHOTOS OF TESTED EUT General views FCC ID: XKB-ICT250 Page 2/3 Connectors view Printer view FCC ID: XKB-ICT250 Page 3/3 MagicBox views Power supply views

FCC ID: XKB-ICT250 Page 1/1 PRODUCT LABELING FCC ID / IC number label

FCC ID: XKB-ICT250 Page 1/7 INTERNAL PHOTOS OF TESTED EUT General views FCC ID: XKB-ICT250 Page 2/7 Views without enclosure FCC ID: XKB-ICT250 Page 3/7 Screen detail views Magnetic card reader views Printer view FCC ID: XKB-ICT250 Page 4/7 General PCB views FCC ID: XKB-ICT250 Page 5/7 Detail PCB views FCC ID: XKB-ICT250 Page 6/7 Detail PCB views FCC ID: XKB-ICT250 Page 7/7 Detail RF module views

FCC ID: XKB-ICT250 Page 1/4 OPERATIONAL DESCRIPTION 1.1. EUT description FCC ID: XKB-ICT250 Page 2/4 FCC ID: XKB-ICT250 Page 3/4 1.2. Related Submittal(s) / Grant(s) All host equipment used in the test configuration are FCC granted, when relevant. 1.3. Tested System Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: ICT250-01T1099C Serial number: 10034CT70064099 FCC ID: XKB-ICT250 Power Supply: DELTA ELECTRONICS TADP-24AB A, input 100-240V 50/60Hz, output 8VDC 3A. Sn: ABET1016000496 MagicBox: 2961105416 • Inputs/outputs : - 1x DC power input (8Vdc) - 1x Serial link (RS232C can’t be longer than 3m) - 1x Ethernet line (may be longer than 3m) - 1x Dial-up Modem line IN (may be longer than 3m) - 1 x USB host, not used and without cable - 1 x USB slave, not used and without cable - 2 x SAMs - 1 x CAM0 - 1 x MicroSD, not used. • Cables: - 1x Magic Box extension cord with I/O connectors, spiraled: 1m - 1x AC power cord, 2 wires, unshielded: 2m - 1x DC power supply cable (fixed on mains power unit), unshielded: 1.75m - 1x Ethernet cable, Cat 5e, unshielded: 2m - 1x RS232 Com cable, RJ11, unshielded, 1.5m - 1x Line In cable, RJ11, unshielded, 1.5m • Auxiliaries equipment used during test: - 1x Smartcard (Bank credit card) Sn: none - 2x SAM cards Sn: none - 1 x Contactless card RFID reader Sn: None - 1x Laptop PC TOSHIBA SATELITE S1410-704 (PS141E-04YCM-3V) Sn: 13594938G with its power supply unit (PA3201U-1ACA SEB100P2-15.0) - 1x TELTON Telephone line simulator TLS-5B-01 Sn: 014184 Configuration 1 Configuration 2 The EUT is connected to a laptop PC with its Ethernet link. (Ping function activated). The inboard software (TEST CEM) performed the followings tests and activates the followings functions: - Printer ON, - Modem is online - Smartcards reading: CAM0, SAM1 and 2 (power ON and reading) - Backlight and display are ON. The EUT is connected to a laptop PC with its Ethernet link. (Ping function activated). The inboard software (TEST CEM) performed the followings tests and activates the followings functions: - Printer ON, - Contact less is activated - Smartcards reading: CAM0, SAM1 and 2 (power ON and reading) - Backlight and display are ON. FCC ID: XKB-ICT250 Page 4/4 1.4. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4-2003, FCC Part 15 Subpart B. Radiated testing was performed at an antenna to EUT distance of 10 meters. During testing, all equipment’s and cables were moved relative to each other in order to identify the worst case set-up. 1.5. Test facility Tests have been performed on May 17th, 2010. This test facility has been fully described in a report and accepted by FCC as compliant with the radiated and AC line conducted test site criteria in ANSI C63.4-2003 in a letter dated March 25 th , 2008 (registration number 94821). This test facility has also been accredited by COFRAC (French accreditation authority for European Union test lab accreditation organization) according to NF EN ISO/IEC 17025, accreditation number 1-1633 as compliant with test site criteria and competence in 47 CFR Part 15/ANSI C63.4 and EN55022/CISPR22 norms for 89/336/EEC European EMC Directive application. All pertinent data for this test facility remains unchanged.

Rapport d’essai / Test report N° 201005-6240C-R1-E JDE : 99043 DELIVRE A / ISSUED TO : INGENICO 1, Rue Claude Chappe BP 348 07503 GUILHERAND-GRANGES - France Objet / Subject : Essais de compatibilité électromagnétique conformément aux normes FCC CFR 47 Part 15, Subpart B et C. Electromagnetic compatibility tests according to the standards FCC CFR 47 Part 15, Subpart B and C Matériel testé / Apparatus under test : • Produit / Product : Lecteur carte bancaire / Credit Card Reader • Marque / Trade mark : INGENICO • Constructeur / Manufacturer : INGENICO • Type / Model : ICT250-01T1099C • N° de série / serial number : 10034CT70064099 • FCC ID : XKB-ICT250 Date des essais / Test date : Du 15 Avril au 17 Mai 2010 / From April 15 th to May 17 th , 2010 Lieu d’essai / Test location : BUREAU VERITAS LCIE SUD-EST ZI Centr’Alp – 170 rue de Chatagnon 38430 MOIRANS - France Test réalisé par / Test performed by : Anthony MERLIN Ce document comporte /Composition of document : 29 pages. M OIRANS, LE 28 MAI 2010 / MAY 28TH, 2010 Ecrit par / Written by, Approuvé par / Approved by, Anthony MERLIN Jacques LORQUIN La reproduction de ce document n'est autorisée que sous sa forme intégrale. Toute reproduction partielle ou toute insertion de résultats dans un texte d'accompagnement en vue de leur diffusion doit recevoir un accord préalable et formel du LCIE. Ce document résulte d’essais effectués sur un spécimen, un échantillon ou une éprouvette. Il ne préjuge pas de la conformité de l’ensemble des produits fabriqués à l’objet essayé. Sauf indication contraire, la décision de conformité prend en compte l’incertitude de mesures. Il ne préjuge en aucun cas d’une décision de certification. This document shall not be reproduced, except in full, without t he written approval of the LCIE. This document contains results related only to the item tested. It does not imply the conformity of the whole production to the item tested .Unless otherwise specified; the decision of conformity takes into account the uncertainty of measures. This document does not anticipate any certification decision. RAPPORT D'ESSAI / TEST REPORT N° 201005-6240C-R1-E Page : 2 / 29 SUMMARY 1. TEST PROGRAM ................................................................................................................................... 3 2. SYSTEM TEST CONFIGURATION ........................................................................................................ 4 3. RADIATED EMISSION DATA ................................................................................................................. 6 4. FUNDAMENTAL FREQUENCY TOLERANCE (15.225E) ..................................................................... 11 5. BAND-EDGE COMPLIANCE §15.209................................................................................................. 12 6. CONDUCTED EMISSION DATA .......................................................................................................... 13 7. ANNEX 1 (GRAPHS) ............................................................................................................................ 16 TEST EQUIPMENT LIST (MOIRANS SITE) ................................................................................................. 27 8. UNCERTAINTIES CHART .................................................................................................................... 29 RAPPORT D'ESSAI / TEST REPORT N° 201005-6240C-R1-E Page : 3 / 29 1. TEST PROGRAM Standard: - FCC Part 15, Subpart B (Digital Devices) - ANSI C63.4 (2003) EMISSION TEST LIMITS RESULTS (Comments) Frequency Quasi-peak value (dBμV) Average value (dBμV) 150-500kHz 66 to 56 56 to 46 0.5-5MHz 56 46 Limits for conducted disturbance at mains ports 150kHz-30MHz 5-30MHz 60 50 PASS Radiated emissions 30MHz-12.5GHz Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m PASS Standard: - FCC Part 15, Subpart C - ANSI C63.4 (2003) EMISSION TEST LIMITS RESULTS (Comments) Frequency Quasi-peak value (dBμV) Average value (dBμV) 150-500kHz 66 to 56 56 to 46 0.5-5MHz 56 46 Limits for conducted disturbance at mains ports 150kHz-30MHz 5-30MHz 60 50 PASS Radiated emissions 9kHz-30MHz Measure at 300m 9kHz-490kHz : 67.6dBμV/m /F(kHz) Measure at 30m 490kHz-1.705MHz : 87.6dBμV/m /F(kHz) 1.705MHz-30MHz : 29.5 dBμV/m PASS Radiated emissions 30MHz-12.5GHz* Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m PASS Fundamental frequency tolerance Operation within the band 13.110-14.010 MHz §15.225 PASS Bandedge compliance Operation within the band 13.110-14.010 MHz §15.225 PASS *§15.33: The highest internal source of a testing device is defined like more the highest frequency generated or used in the testing device or on which the testing device works or agrees. - If the highest frequency of the internal sources of the testing device is lower than 108 MHz, measurement must be only performed until 1GHz. - If the highest frequency of the internal sources of the testing device ranges between 108 MHz and 500 MHz, measurement must be only performed until 2GHz. - If the highest frequency of the internal sources of the testing device ranges between 500 MHz and 1 GHz, measurement must be only performed until 5GHz. If the highest frequency of the internal sources of the testing device is above 1 GHz, measurement must be only performed until 5 times the highest frequency or 40 GHz, while taking smallest of both. RAPPORT D'ESSAI / TEST REPORT N° 201005-6240C-R1-E Page : 4 / 29 2. SYSTEM TEST CONFIGURATION 2.1. JUSTIFICATION The system was configured for testing in a typical fashion (as a customer would normally use it). 2.2. HARDWARE IDENTIFICATION • Equipment under test (EUT): ICT250-01T1099C Serial number: 10034CT70064099 FCC ID: XKB-ICT250 Power Supply: DELTA ELECTRONICS TADP-24AB A, input 100-240V 50/60Hz, output 8VDC 3A. Sn: ABET1016000496 MagicBox: 296…

Text truncated - open the document above for the full version.

FCC ID: XKB-ICT250 Page 1/2 CONDUCTED AND RADIATED MEASUREMENT PHOTO 1.1 Conducted emission FCC ID: XKB-ICT250 Page 2/2 1.2 Radiated emissions Radiated emission test setup
