XKB-IST150RFID Tag Reader

INGENICO

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Mar 17, 2011
Application Purpose: Original Equipment
Date of Application: Mar 17, 2011
Equipment Note: RFID Tag Reader
Frequency Range: 13.56000000 - 13.56000000
Company: INGENICO
Country: France

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

iST150 INSTALLATION GUIDE 90000346 R11 000 01/4710 Copyright © 2010 Ingenico INGENICO – 192 avenue Charles de Gaulle 92200 Neuilly sur Seine – France All rights reserved Safety instruction Power supply network: To switch off the iST150, disconnect first the link to the host and then the power adapter (if there is one) from the power supply network For Pluggable Equipment Type A, the protection in the installation is assumed to be 20A. Only power adapter supplied by Ingenico must be used. Installation Push the two buttons on each side at the same time and adjust the angle. Reading card Contactless Keep the card firmly up to the active area. Keep the card motionless to the target during the transaction. Installing SAM and cable Before starting, switch off the terminal by (see safety instruction). In order to access the SAM card you must first remove the cover located at the back: Press the clip of the cover and lift the cover Hang on the connector Insert the SAM into the slot market (1), (2). Take care to ensure that the SAM Card is inserted in the correct manner. The cut corner must be positioned as indicated on the picture. To position the cable put it in the slot then proceed in reverse order. Your contactless terminal has a row of four status lights that are visible from the front and back side. Graphic display Contactless active area Contactless lights on both side Angle position buttons iST150 INSTALLATION GUIDE 90000346 R11 000 01/4710 Copyright © 2010 Ingenico INGENICO – 192 avenue Charles de Gaulle 92200 Neuilly sur Seine – France All rights reserved Physical characteristics: Weight (without cable) About 150g Dimensions 83x 27 x124 mm (lxWxH) Removable cable Operating conditions : Temperature +5°C to +40°C Maximum relative humidity 85% RH at +40°C Storage conditions: Temperature -20°C to +55°C Maximum relative humidity 85% RH at +55°C Maximum consumption : 400mA at +5V, 300mA at +8V to +12V Power Supply Voltage is a SELV circuits (Safety Extra Low Voltage, according to safety standard IEC 60950-1). The power supply has to be in compliance with §2.5 (Limited power source) of the standard IEC 60950-1 iST150 INSTALLATION GUIDE 90000346 R11 000 01/4710 Copyright © 2010 Ingenico INGENICO – 192 avenue Charles de Gaulle 92200 Neuilly sur Seine – France All rights reserved FCC Statement FCC standard compliance marking certifies that the product stipulated below: iST150-00TXXXXX conforms to the following harmonized standards : – part 15 subpart B of the FCC rules This class (B) digital apparatus complies with Canadian ICES-003. FCC: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help CAUTION: The user is cautioned that any changes or modifications not approved by INGENICO could void user’s authority to operate the equipment RSS-Gen Clause 7.1.2 statement "Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication." "Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé iST150 INSTALLATION GUIDE 90000346 R11 000 01/4710 Copyright © 2010 Ingenico INGENICO – 192 avenue Charles de Gaulle 92200 Neuilly sur Seine – France All rights reserved pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante." RSS-Gen Clause 7.1.3 statement "This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." "Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement." End-of-life The product belongs to the family of electrical and electronic equipment. Therefore, it is subjected to the WEEE directive which requires the collection and the recycling at the end of life product. The Ingenico products present the symbol for the marking of electrical and electronic equipment as required by the WEEE Directive. The crossed-out wheeled b…

Text truncated - open the document above for the full version.

Cover Letter(s)

February 10 th , 2011 CONFIDENTIALITY REQUEST Curtis-Straus LLC One Distribution Center Circle #1 Littleton, MA 01460 USA Re: Confidentiality request for a Low Power Communication Device FCC ID: XKB-IST150 Gentlemen, INGENICO requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application. The following document regarding this submission for FCC ID: XKB-IST150 shall be kept confidential: 1. Schematic Diagram of the IST150-00T1418A (file: Schematic-XKB-IST150.pdf) 2. Block Diagram description of the IST150-00T1428A (file: Block Diagram- XKB-IST150.pdf) Specifically, these exhibits contain information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that INGENICO does not customarily release to the public and which is otherwise not generally available to the public. Regards, Marc DELORME Quality Manager 1, rue Claude Chappe – BP 346 07503 GUILHERAND GRANGES - France

External Photos

FCC ID: XKB-IST150 Page 1/5 EXTERNAL PHOTOS OF TESTED EUT iST150-00T1428A FCC ID: XKB-IST150 Page 2/5 FCC ID: XKB-IST150 Page 3/5 Cable Ref : 296116774 (Configuration n°1) Cable Ref : 296119720 Cable Ref : 296120004 (Configuration n°2) FCC ID: XKB-IST150 Page 4/5 Power supply SAGEM AD5632 (Configuration n°2) , “Used to emulate a 8Vdc power source” FCC ID: XKB-IST150 Page 5/5 Configuration 1 : Communication access : - USB Power supply : - (5Vdc) Provided by Laptop THOSHIBA (Auxilliary Equipment) Option Cable: - Ref: 296116774 Configuration 2 : Communication access : - RJ11 Power supply : - Power through AC/DC power supply type Option Cable: - Ref: 296120004 Remark : 2 x externals power supplies are used in this configuration permits to emulate 8-12Vdc power supply source (1) : Power supply adapter (SAGEM AD5632) is used for Conducted Emission (8Vdc). (2) : A laboratory power supply (TDK-Lambda 30V- 50A) is also used in order to performed following tension from 4.25Vdc to 13.8Vdc (Extreme condition Test, and 12Vdc rating for Radiated emission : Configuration 2)

ID Label/Location Info

FCC ID: XKB-IST150 IC : 2586D-IST150 Page 1/3 PRODUCT LABELING FCC ID / IC number label FCC ID: XKB-IST150 IC : 2586D-IST150 Page 2/3 LABELING EXPLICATION Family models: • IST150-00T1428A : IST150 8+16 T UR G SD 2 STD GC S (Contact less) Label : FCC ID: XKB-IST150 IC : 2586D-IST150 Page 3/3 Level 3 refererences Family = IST : Satellite Range = 150 : color background display Security = Always 00 Item = T : Terminal P : Product ID Level 3 = Unique ID given by B.Maurice (in 4 digits) Version = A : version identifier The final letter is the index, starting at "A" that evolves when an important chan ge occurs. This final letter is useful to ensure traceability of the evolution(s) of the device. Level 3 commercial description Family = IST : Satellite Range = 150 : color background display Memory RAM+Flash = Memory / Flash + Ram (in Ko) Item = T : Terminal P : Product COMs = 1st digit : U = USB To ICT 2nd digit : R =RS232 Family = 1st digit : G = Green leds 2nd digit : R =Rainbow leds Software = SD : Standard software by default PL : Pre loaded software that could be personalised a posteriori CU : When the product includes the customer (end user) software SAMs & SD = No SAMs do not fill up Colour = See Addendum - color table Country = See addendum - country table Customised = C : if the internal device has been customised by a logo, colour, software or something else that prevent selling i t to a different customer than the one defined at t he creation step. S : if it is standard and doesn’t have any customiza tion.

Internal Photos

FCC ID: XKB-IST150 Page 1/4 INTERNAL PHOTOS OF TESTED EUT iST150-00T1428A Enclosure detail Views FCC ID: XKB-IST150 Page 2/4 General view with antenna Antenna FCC ID: XKB-IST150 Page 3/4 Screen Display Front Plastic piece FCC ID: XKB-IST150 Page 4/4 General view of PCB

Operational Description

FCC ID: XKB-IST150 Page 1/6 OPERATIONAL DESCRIPTION 1.1. EUT description FCC ID: XKB-IST150 Page 2/6 FCC ID: XKB-IST150 Page 3/6 1.2. Related Submittal(s) / Grant(s) All host equipment used in the test configuration are FCC granted, when relevant. 1.3. Tested System Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: • Equipment under test (EUT): E.U.T. : iST150-00T1428A Serial number: 10347CL40045131 Power supply interface : 1: 5Vdc 2: 8-12Vdc - - Highest internal frequency: 96.768 MHz • Input/output: - 1 x Power supply “Type HDMI” • Auxiliaries used for testing: - 1 x Laptop TOSHIBA SATELLITE PS141E-04YC (Configuration n°1) sn : 13594938G - 1 x AC/DC Power supply adapter (LAPTOP) TOSHIBA API4AD19 (Configuration n°1) sn : None - 1 x AC/DC Power supply adapter SAGEM AD5632 (Configuration n°2) sn : None - 1 x Power supply TDK-LAMBDA (30V-50A) - 2 x Sam Cards - 1 x Contact Less Card 3M Oberthur Technologies FCC ID: XKB-IST150 Page 4/6 • I/O cables used for testing: - Configuration 1: 1 x USB cable (2m) shielded, Ref: 296116774 - Configuration 2: 1 x RS232 cable (2m),Type RJ11 unshielded, Ref: 296120004 1.4. Running Mode Sequence n°1 : Sequence n°2: A reading process are performed on contactless Card Sequence n°1 + serial communication on COM0 A continuous writing/reading process is performed on SAM Card RX and TX is connected each other in order to performed a continuous communication Configuration Running mode 1 2 Sequence n°1 x Sequence n°2 x 1.5. Equipment modifications None 1.6. Test Methodology OS : 8200360833 Test software : TEST CAM0107 FCC ID: XKB-IST150 Page 5/6 1.7. EUT Configuration Configuration 1 : Communication access : - USB Power supply : - (5Vdc) Provided by Laptop THOSHIBA (Auxilliary Equipment) Option Cable: - Ref: 296116774 Configuration 2 : Communication access : - RJ11 Power supply : - Power through AC/DC power supply type Option Cable: - Ref: 296120004 Remark : 2 x externals power supplies are used in this configuration permits to emulate 8-12Vdc power supply source (1) : Power supply adapter (SAGEM AD5632) is used for Conducted Emission (8Vdc). (2) : A laboratory power supply (TDK-Lambda 30V- 50A) is also used in order to performed following tension from 4.25Vdc to 13.8Vdc (Extreme condition Test, and 12Vdc rating for Radiated emission : Configuration 2) FCC ID: XKB-IST150 Page 6/6 1.8. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4-2003, FCC Part 15 Subpart B and C. Radiated testing was performed at an antenna to EUT distance of 10 meters. During testing, all equipment’s and cables were moved relative to each other in order to identify the worst case set-up. 1.9. Test facility Tests have been performed from September 7 th to November 23 rd , 2010. This test facility has been fully described in a report and accepted by FCC as compliant with the radiated and AC line conducted test site criteria in ANSI C63.4-2003 in a letter dated March 25 th , 2008 (registration number 94821). This test facility has also been accredited by COFRAC (French accreditation authority for European Union test lab accreditation organization) according to NF EN ISO/IEC 17025, accreditation number 1-1633 as compliant with test site criteria and competence in 47 CFR Part 15/ANSI C63.4 and EN55022/CISPR22 norms for 89/336/EEC European EMC Directive application. All pertinent data for this test facility remains unchanged.

Test Report

RAPPORT D'ESSAI / TEST REPORT N° 69196CR-R1-E Page : 2 / 33 SUMMARY 1. TEST PROGRAM ................................................................................................................................... 3 2. SYSTEM TEST CONFIGURATION ........................................................................................................ 4 3. RADIATED EMISSION DATA ................................................................................................................. 7 4. FUNDAMENTAL FREQUENCY TOLERANCE (15.225E) ..................................................................... 12 5. BAND-EDGE COMPLIANCE §15.209................................................................................................. 14 6. CONDUCTED EMISSION DATA .......................................................................................................... 15 7. TEST EQUIPMENT LIST (MOIRANS SITE) ......................................................................................... 19 8. UNCERTAINTIES CHART .................................................................................................................... 21 9. ANNEX 1 (GRAPHS) ............................................................................................................................ 22 RAPPORT D'ESSAI / TEST REPORT N° 69196CR-R1-E Page : 3 / 33 1. TEST PROGRAM Standard: - FCC Part 15, Subpart B (Digital Devices) - ANSI C63.4 (2003) EMISSION TEST LIMITS RESULTS (Comments) Frequency Quasi-peak value (dBμV) Average value (dBμV) 150-500kHz 66 to 56 56 to 46 0.5-5MHz 56 46 Limits for conducted disturbance at mains ports 150kHz-30MHz 5-30MHz 60 50 COMPLY Radiated emissions 30MHz-12.5GHz Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m COMPLY Standard: - FCC Part 15, Subpart C - ANSI C63.4 (2003) EMISSION TEST LIMITS RESULTS (Comments) Frequency Quasi-peak value (dBμV) Average value (dBμV) 150-500kHz 66 to 56 56 to 46 0.5-5MHz 56 46 Limits for conducted disturbance at mains ports 150kHz-30MHz 5-30MHz 60 50 COMPLY Radiated emissions 9kHz-30MHz Measure at 300m 9kHz-490kHz : 67.6dBμV/m /F(kHz) Measure at 30m 490kHz-1.705MHz : 87.6dBμV/m /F(kHz) 1.705MHz-30MHz : 29.5 dBμV/m COMPLY Radiated emissions 30MHz-12.5GHz* Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m COMPLY Fundamental frequency tolerance Operation within the band 13.110-14.010 MHz §15.225 COMPLY Bandedge compliance Operation within the band 13.110-14.010 MHz §15.225 COMPLY *§15.33: The highest internal source of a testing device is defined like more the highest frequency generated or used in the testing device or on which the testing device works or agrees. - If the highest frequency of the internal sources of the testing device is lower than 108 MHz, measurement must be only performed until 1GHz. - If the highest frequency of the internal sources of the testing device ranges between 108 MHz and 500 MHz, measurement must be only performed until 2GHz. - If the highest frequency of the internal sources of the testing device ranges between 500 MHz and 1 GHz, measurement must be only performed until 5GHz. If the highest frequency of the internal sources of the testing device is above 1 GHz, measurement must be only performed until 5 times the highest frequency or 40 GHz, while taking smallest of both. RAPPORT D'ESSAI / TEST REPORT N° 69196CR-R1-E Page : 4 / 33 2. SYSTEM TEST CONFIGURATION 2.1. JUSTIFICATION The system was configured for testing in a typical fashion (as a customer would normally use it) see §2.6: The apparatus IST150 is a product with full option, IST150 can be sell with three kind of cable : USB cables: (2m) shielded, Ref: 296116774 (2m) shielded, Ref: 296119720 Remark : the difference between these two kind of USB cable is only the design of USB port , all test was performed with the reference 296116774 RS232 cable: (2m),Type RJ11 unshielded, Ref: 296120004 2.2. HARDWARE IDENTIFICATION Equipment under test (EUT): E.U.T. : IST150-00T1428A Serial number: 10347CL40045131 Power supply interface : 1: 5Vdc 2: 8-12Vdc Highest internal frequency: 96.768 MHz 296116774 296119720 RAPPORT D'ESSAI / TEST REPORT N° 69196CR-R1-E Page : 5 / 33 Input/output: - 1 x Power supply “Type HDMI” Auxiliaries used for testing: - 1 x Laptop TOSHIBA SATELLITE PS141E-04YC (Configuration n°1) sn : 13594938G - 1 x AC/DC Power supply adapter (LAPTOP) TOSHIBA API4AD19 (Configuration n°1) sn : None - 1 x AC/DC Power supply adapter SAGEM AD5632 (Configuration n°2) sn : None - 1 x Power supply TDK-LAMBDA (30V-50A) - 2 x Sam Cards - 1 x Contact Less Card 3M Oberthur Technologies I/O cables used for testing: - Configuration 1: 1 x USB cable (2m) shielded, Ref: 296116774 - Configuration 2: 1 x RS232 cable (2m),Type RJ11 unshielded, Ref: 296120004 2.3. RUNNING MODE Sequence n°1: Sequence n°2: A reading process are performed on contactless Card Sequence n°1 + serial communication on COM0 A continuous writing/reading process is performed on SAM Card RX and TX is connected each other in order to performed a continuous communication Configuration Running mode 1 2 Sequence n°1 x Sequence n°2 x 2.4. EQUIPMENT MODIFICATIONS None 2.5. EUT EXERCISE SOFTWARE OS : 8200360833 Test software : TESTCAM0107 RAPPORT D'ESSAI / TEST REPORT N° 69196CR-R1-E Page : 6 / 33 2.6. EUT CONFIGURATION Configuration 1 : Communication access : - USB Power supply : - (5Vdc) Provided by Laptop THOSHIBA (Auxilliary Equipment) Option Cable: - Ref: 296116774 Configuration 2 : Communication access : - RJ11 Power supply : - Power through AC/DC power supply type Option Cable: - Ref: 296120004 Remark : 2 x externals power supplies are used in this configuration permits to emulate 8-12Vdc power supply source (1) : Power supply adapter (SAGEM AD5632) is used for Conducted Emission (8Vdc). (2) : A laboratory power supply (TDK-Lambda 30V- 50A) is also used in order t…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: XKB-IST150 Page 1/3 CONDUCTED AND RADIATED MEASUREMENT PHOTO 1.1 Conducted emission Configuration n°1 FCC ID: XKB-IST150 Page 2/3 Configuration n°2 FCC ID: XKB-IST150 Page 3/3 1.2 Radiated emission Configuration n°1 Configuration n°2
