Ingenico - 190-192 avenue Charles de Gaulle - 92200 Neuilly-sur-Seine Tél. 33(0)1 46 25 82 00 - Fax 33 (0)1 47 72 56 95 – www.ingenico.com iWL220/250 T e c h n i c a l M a n u a l Technical manual _iWL220/250 ICO_MKP_009_GU_EN_V4 2/60 Copyright © 2010 Ingenico All rights reserved Technical manual _iWL220/250 ICO_MKP_009_GU_EN_V4 3/60 Copyright © 2010 Ingenico All rights reserved Contents 1. Document __________________________________________________ 11 1.1. Document change history______________________________________________ 11 1.2. Document sign off ____________________________________________________ 11 2. Equipment __________________________________________________ 13 2.1. Introduction _________________________________________________________ 13 2.2. General hardware description __________________________________________ 13 2.2.1. Terminal’s description _________________________________________________________ 13 2.2.1.1. Dimensions & weight __________________________________________________________ 13 2.2.1.1.1. With 25 mm paper roll ______________________________________________________ 13 2.2.1.1.2. With 40 mm paper roll _____________________________________________________ 14 2.2.1.2. Functional overview ________________________________________________________ 14 2.2.2. Base description ______________________________________________________________ 16 2.3. Technical hardware characteristics ______________________________________ 16 2.3.1. Processor ____________________________________________________________________ 16 2.3.2. Memory capacity ______________________________________________________________17 2.3.3. Booster ______________________________________________________________________17 2.3.4. Data security __________________________________________________________________17 2.3.4.1. Hardware design ____________________________________________________________17 2.3.4.2. Software design ___________________________________________________________ 18 2.3.4.3. Product activation _________________________________________________________ 18 2.3.5. The isolation mechanism by electronic locking system _______________________________ 18 2.3.5.1. Isolation __________________________________________________________________ 18 2.3.5.2. MMU features _____________________________________________________________ 19 2.3.5.3. Inviolable memory protection ________________________________________________ 19 2.3.5.4. OS is inviolable and protected ________________________________________________ 19 2.3.5.5. The OS ensures the inter-violability of software application ________________________ 19 2.3.6. Card readers _________________________________________________________________ 19 2.3.6.1. Main smart card reader _____________________________________________________ 19 2.3.6.2. 2 nd card reader ____________________________________________________________ 20 Technical manual _iWL220/250 ICO_MKP_009_GU_EN_V4 4/60 Copyright © 2010 Ingenico All rights reserved 2.3.6.3. Magnetic stripe reader _______________________________________________________ 21 2.3.6.4. Contactless reader __________________________________________________________ 21 2.3.6.4.1. Introduction to Contactless _________________________________________________ 22 2.3.6.4.2. What is Contactless card payment? __________________________________________ 23 2.3.6.4.3. The advantages of Contactless technology ____________________________________ 23 2.3.6.5. SAM readers ______________________________________________________________ 23 2.3.7. Keypad , navigation pad ________________________________________________________ 24 2.3.8. Display ______________________________________________________________________ 25 2.3.9. Printer ______________________________________________________________________ 25 2.3.10. Audio _______________________________________________________________________ 26 2.3.11. Battery ______________________________________________________________________ 26 2.3.12. Power supply unit _____________________________________________________________ 27 3. Connectivity ________________________________________________ 29 3.1. On terminal _________________________________________________________ 29 3.1.1. Wired Connectivity: ____________________________________________________________ 29 3.1.1.1. micro USB type A/B ____________________________________________________________ 29 3.1.1.2. Base Interface _____________________________________________________________ 29 3.1.2. Wireless Connectivity __________________________________________________________ 30 3.1.2.1. GPRS ____________________________________________________________________ 30 3.1.2.2. 3G - HSDPA _______________________________________________________________ 30 3.1.2.3. Bluetooth ________________________________________________________________ 31 3.1.2.4. Wifi _____________________________________________________________________ 31 3.2. On base ____________________________________________________________ 31 3.2.1. Base charger _________________________________________________________________ 33 3.2.2. USB ________________________________________________________________________ 33 3.2.3. Bluetooth ___________________________________________________________________ 34 3.2.4. Modem (PSTN) _______________________________________________________________ 34 3.2.5. Ethernet_____________________________________________________________________ 35 4. Standards __________________________________________________ 37 4.1. Immunity characteristics_______________________________________________ 37 4.2. Disturbance produced by the equipment _________________________________ 37 4.3. Operating conditions _________________________________________________ 37 4.4. Storage conditions ___________________________________________________ 37 Technical manual _iWL220/250 ICO_MKP_009_GU_EN_V4 5/60 Copyright © 2010 Ingenico All rights reserved 5. Norms and certifications ____________________________…

Text truncated - open the document above for the full version.

INGENICO – 28-32 Boulevard de Grenelle – 75015 Paris - FRANCE Tél. 33(0)1 58 01 80 00 www.ingenico.com iWL2xx Wireless Series U s e r G u i d e iWL2xx Wireless Series 2/34 Copyright © 2013 Ingenico 900003061 R11 000 08/1324 All rights reserved Contents 1. Introduction __________________________________________________ 4 2. Presentation __________________________________________________ 5 2.1. Content of the box ____________________________________________________ 5 2.1.1. Terminal _____________________________________________________________________ 5 2.1.2. Base ( optional ) _______________________________________________________________ 5 2.2. Overview of the iWL2XX ________________________________________________ 6 2.3. Keyboard details and functionality _______________________________________ 7 3. Use of the terminal ____________________________________________ 7 3.1. Adjusting contrast (B&W display only) ____________________________________ 7 3.2. Switching off the terminal ______________________________________________ 8 3.3. Reading cards ________________________________________________________ 8 3.4. Installing the terminal on the base________________________________________ 9 4. Installation ___________________________________________________ 10 4.1. Recommendations ___________________________________________________ 10 4.2. Terminal connections _________________________________________________ 10 4.3. Installing Modules ____________________________________________________ 11 4.3.1. SAM1/SAM2/SIM _______________________________________________________________ 11 4.3.2. MicroSD Memory Card __________________________________________________________ 12 4.4. Paper roll ___________________________________________________________ 13 4.4.1. Mains characteristics of INGENICO paper roll _______________________________________ 13 4.4.2. Installing paper roll ____________________________________________________________ 14 4.1. Battery _____________________________________________________________ 15 4.1.1. Main characteristics ___________________________________________________________ 15 4.1.2. Installing the battery __________________________________________________________ 15 4.1.3. Charging the battery ___________________________________________________________ 16 4.1.4. Changing the battery ___________________________________________________________17 5. Base _________________________________________________________ 18 5.1.1. Base rear connections _________________________________________________________ 18 5.1.2. Base downside connections _____________________________________________________ 19 iWL2xx Wireless Series 3/34 Copyright © 2013 Ingenico 900003061 R11 000 08/1324 All rights reserved 5.1.3. Fasten your base on desk _______________________________________________________ 20 6. Recommendations _____________________________________________ 21 6.1. Safety ______________________________________________________________ 21 6.2. Security of your terminal ______________________________________________ 22 6.3. Telephone call _______________________________________________________ 22 7. Standards ___________________________________________________ 23 8. Troubleshooting ______________________________________________ 31 9. Annex ______________________________________________________ 32 iWL2xx Wireless Series 4/34 Copyright © 2013 Ingenico 900003061 R11 000 08/1324 All rights reserved 1. Introduction We hope that you will be fully satisfied with your new terminal iWL2XX. This terminal is available in different models. Please select by yourself in this documentation items related to your model. Read this guide to understand and make the best use of your terminal. It presents you the necessary information about use, installation, maintenance, safety and security recommendations. WARRANTY / SECURITY Use only the power supply included with the product to ensure best performance and safety. Maintenance should only be provided by Ingenico authorized technician. Failure to comply with these instructions will void the manufacturer’s responsibility. This symbol indicates an important Warning. This symbol indicates a piece of advice. iWL2xx Wireless Series 5/34 Copyright © 2013 Ingenico 900003061 R11 000 08/1324 All rights reserved 2. Presentation 2.1. Content of the box 2.1.1. Terminal 2.1.2. Base ( optional ) WARNING The power supply unit provided with your equipment is specially designed for Ingenico terminals. Do not use any other power supply. The use of a power supply with apparently similar voltage/current characteristics may damage your terminal. ADVICE Keep the packaging. It must be re-used whenever the terminal is shipped. IWL2XX terminal unit equipped with a paper roll Base A power supply unit that connect the base to the mains network A battery pack disconnected A telephone cable (with base modem) Power supply unit (PSU) (charging from the micro-USB port of the terminal ) When the terminal is delivered with a base, this PSU is replaced by a base PSU A user’s guide iWL2xx Wireless Series 6/34 Copyright © 2013 Ingenico 900003061 R11 000 08/1324 All rights reserved 2.2. Overview of the iWL2XX Base Weight About 150g Dimensions (L x w x h) 140,7x87,7x45 mm Power supply unit Weight About 100g 2pole sockets 1A (terminal power supply) or 1 A (base power supply) Power supply units are specially fitted for INGENICO terminals. Weight (without paper roll nor battery) 285g for the R25 model and 300g for the R40 model Dimensions (L x w x h) 150x76x44mmfor the R25 model and 164,5x76x53,5mm for the R40 model Mains network 100-240VAC / 50-60 Hz - Class II equipment Connections on terminal Micro USB AB serial link Backlit keyboard Smart card reader Easy loading printer Large graphic display Magnetic card reader Compartment where are located : the battery pack the SAM1/SAM2/SIM connector the module microSD the 2 nd Smart card reader Terminal unit Base unit External links External links iWL2xx Wireless Seri…

Text truncated - open the document above for the full version.

Ingenico – S.A. au capital de 53 069 625 € - 28-32 boulevard de Grenelle – 75015 Paris Tél. +33 (0)1 58 01 80 00 – Fax +33 (0)1 58 01 91 35 - www.ingenico.com 317 218 758 RCS Paris Date : 2014-01-10 Telecommunication Certification Body Emitech Z.A. de l’Observatoire 3, rue des coudriers 78180 Montigny-Le-Bretonneux France To whom it may concern Agency letter This is to certify that Ingenico authorizes Emitech to act on our behalf for the application of the iWL Wifi Handheld FCC ID : XKB-IWL2XXWBCL to Emitech Telecommunication Certification Body. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5001 of the Anti-Drug Abuse Act of 1988, 21 .U.S.C &862 because of conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purpose. Kind regards, Company Official: INGENICO Name : Marc DELORME FRN 0018-9122-79 Title: Quality Manager Contact Information: Ph. : 33 4 75 60 22 85 Fax : 33 4 75 81 41 57 e-mail:[email protected] Signature

Ingenico – S.A. au capital de 53 069 625 € - 28-32 boulevard de Grenelle – 75015 Paris Tél. +33 (0)1 58 01 80 00 – Fax +33 (0)1 58 01 91 35 - www.ingenico.com 317 218 758 RCS Paris Date : 2014-01-10 To whom it may concern Attestation We attest that the Bluetooth circuitery and Contact less circuitery of the FCC ID : XKB- IWL2XXWBCL is totally identical to the FCC ID : XKB-IWL2XXBCL and XKBIWL2XXBPOS (schematics, bill of material, placement, layout, pcb and antennas). The only difference between FCC ID : XKB-IWL2XXWBCL and the FCC ID : XKB- IWL2XXBCL is the addition of a wifi module and a wifi antenna. So we declare that the test report for FCC ID: XKB-IWL2XXBCL and FCC ID: XKBIWL2XXBPOS can be used for FCC ID: XKB-IWL2XXWBCL concerning Bluetooth and contact less compliancy. Kind regards, Company Official: INGENICO Name : Marc DELORME FRN 0018-9122-79 Title: Quality Manager Contact Information: Ph. : 33 4 75 60 22 85 Fax : 33 4 75 81 41 57 e-mail:[email protected] Signature

Ingenico – S.A. au capital de 53 069 625 € - 28-32 boulevard de Grenelle – 75015 Paris Tél. +33 (0)1 58 01 80 00 – Fax +33 (0)1 58 01 91 35 - www.ingenico.com 317 218 758 RCS Paris INGENICO Marc Delorme 28-32, boulevard de Grenelle 75015 Paris FRN 0018-9122-79 Federal Communications Commission Authorization and Evaluation Division REF. ICO-FCC-IWL2xx-WIFI0AB Merignac, 10 January 2014 SUBJECT Confidentiality Request regarding application for certification of FCC ID XKB-IWL2XXWBCL Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Block Diagram Schematics Operational Description Part list File Name XKB-IWL2XXWBCL_BlockDiagram.pdf XKB-IWL2XXWBCL_Schematics.pdf XKB-IWL2XXWBCL_OpDescription.pdf XKB-IWL2XXWBCL_PartList.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Yours faithfully, Marc Delorme Quality manager

XKB-IWL2XXWBCL External photos

XKB-IWL2XXWBCL Stickers Marking

1 40 20 1 40 20 Ft:A4 Ech: Red: A B 4 1 Dat: Ver: Verif: A BC D 1 2 3 4 DC 04/2013 LV PL EQUIP CIE EXT WiFi Y07 900013137 R44 00 001 1/2 Area for protective kapton if MX2200 mounted J2200 Q2101 Q2103 C2100 C2101 C2109 C2110 C2113 C2114 C2115 C2117 C2129 C2130 C2631 D2100 D2101 L2101 Q2100 Q2105 R2 R2100 R2101R2102 R2104 R2105 R2107 R2108 R2109 R2113 R2115 R2116 R2117 C2111 R2200 R2201 C2103 C2116 C2118 C2119 J2000 L2100 MA2102 MA2103 MX2200 ABC 12 ABC 12 ABC 12 ABC 12 MXT 1 12345 ABCDE MXT 1 MXT 1 Ft:A4 Ech: Red: A B 4 1 Dat: Ver: Verif: A BC D 1 2 3 4 DC PL EQUIP CIE EXT WiFi Y07 900013137 R44 000 01 2/2 LV 04/2013 please ignore the coding for J2400 and J2401 J2400 J2201 J2401 J2500 J2600 MX2600 C2107 C2190 C2191 C2192 C2312 C2320 C2321 C2322 C2323 C2325 C2326 C2327 C2328 C2331 C2334 C2348 C2739 C2743 C2744 C2745C2746 C2747 C2755 C2758 C2759 C2760 C2764 C2792 C2793 L2305 L2306 L2308 MA2190 MX2302 Q2102 R2007 R2009 R2012 R2015 R2018 R2019 R2114 R2300 R2301 R2302 R2311 R2314 R2709 R2711 R2714 R2718 R2719 R2725 R2764 R2796 R2797 Y2300 C2122 C2200 C2201 C2202 C2212 C2213 C2404 C2406 C2407 C2605 C2608 C2609C2610 C2611 C2612C2613 C2615 C2616 C2617C2618 C2619 C2633 C2635 C2636 C2637 C2639 C2640 D2401 J2001 J2002 L2602 L2604 R2014 R2217 R2218 R2310 R2605 R2611 S2605 R2309 R2106C2108 C2300 C2301C2302 C2303 C2304 C2306 C2307 C2308 C2309 C2310 C2311 C2313 C2314 C2315 C2316 C2317 C2318 C2319 C2329 C2330 C2332 C2333 C2335 C2336C2337 C2600 C2628 C2752 C2753 C2754 C2761 L2300 L2302 L2301 L2303 L2304 L2307 MA2300 MA2302 MA2303 MX2301 MX2300 R2005 R2006 C2763 R2020 R2303 R2304 R2305 R2306 R2308 R2312 R2313 R2602 R2618 R2708 R2713 R2717 R2751 R2794 R2795 L2730 S2600S2602 R2752 C2112 C2120 C2121 C2123 C2124 C2203 C2205 C2211 C2214 C2215 C2405 C2409 C2410 C2411 C2500 C2501 C2502 C2601 C2602 C2603 C2606 C2607 C2614 C2620 C2621 C2622 C2625 C2626 C2627 C2629 C2630 C2632 C2634 D2200 D2400 R2610 R2609 R2608 R2607 L2102 L2601 L2605 L2606 L2607 MA2104 MA2601 Q2200 Q2600 Q2601 R2008 R2011 R2016 R2017 R2021 R2053 R2110 R2111 R2112 R2202 R2203 R2204 R2205 R2206 R2207 R2208 R2215 R2216 R2219 R2402 R2403 R2405 R2406 R2407 R2408 R2409 R2410 R2501 R2600 R2601 R2603 R2612R2613 R2619 R2620 R2621 R2622 R2626 R2627 C2043 R2811 R2812 R2813 R2814 S2601 S2603 S2604 R2411 Q2400 L2600 C2604 C2305 C2324 C2408 C2623 C2624 R2307 J2705 L2603 MA2301 MN2704 MN2706 MN2709 MN2710 MX2201 U2000 U2707 U2713 Y2600 U2712

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: IWL252-01T1535A FCC ID: XKB-IWL2XXBCL IC Certification Number: 2586D-IWL2BCL To: FCC Part 15.225: 2010 Subpart C, RSS-210 Issue 8 December 2010 & RSS-Gen Issue 3 December 2010 Test Report Serial No: RFI-RPT-RP82173JD01A V3.0 Version 3.0 supersedes all previous versions This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: Ian Watch Signature: Date of Issue: 20 September 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 Page 2 of 23 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 RFI Global Services Ltd Page 3 of 23 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) ....................................................................................................... 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 8 4. Operation and Monitoring of the EUT during Testing ............................................................... 9 4.1. Operating Modes 9 4.2. Configuration and Peripherals 9 5. Measurements, Examinations and Derived Results ................................................................ 10 5.1. General Comments 10 5.2. Test Results 11 5.2.1. Receiver/Idle Mode Radiated Spurious Emissions 11 5.2.2. Transmitter AC Conducted Spurious Emissions 13 5.2.3. Transmitter Fundamental Field Strength 16 5.2.4. Transmitter Radiated Spurious Emissions 17 5.2.5. Transmitter Band Edge Radiated Emissions 19 5.2.6. Transmitter 20 dB Bandwidth 20 5.2.7. Transmitter Frequency Stability (Temperature & Voltage Variation) 21 6. Measurement Uncertainty .......................................................................................................... 22 Appendix 1. Test Equipment Used ................................................................................................ 23 TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 Page 4 of 23 RFI Global Services Ltd 1. Customer Information Company Name: Ingenico SA Address: 1, rue Claude Chappe – BP 346 Guilherand-Granges 7503 France TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 RFI Global Services Ltd Page 5 of 23 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.225 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart C (Radio Frequency Devices) - Section 15.225 Specification Reference: 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart B (Radio Frequency Devices) – Section 15.109 Specification Reference: 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart C (Intentional Radiators) - Section 15.209 Specification Reference: RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Specification Reference: RSS-210 Issue 8 December 2010 Specification Title: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment. Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 05 August 2011 to 18 September 2011 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.109 - Receiver/Idle Mode Radiated Spurious Emissions Part 15.207 RSS-Gen 7.2.2 Transmitter AC Conducted Emissions Part 15.225(a)(b)(c)(d) RSS-Gen 4.8 RSS-210 A2.6 Transmitter Fundamental Field Strength Part 15.209(a)/ 15.225(d) RSS-Gen 4.9 RSS-210 A2.6 Transmitter Radiated Emissions Part 15.209(a)/ 15.225(c)(d) RSS-Gen 4.9 RSS-210 A2.6 Transmitter Band Edge Radiated Emissions Part 2.1049 RSS-Gen 4.6.1/4.6.3 Transmitter 20 dB Bandwidth Part 15.225(e) RSS-Gen 4.7 RSS-210 A2.6 Transmitter Frequency Stability (Temperature & Voltage Variation) Key to Results = Complied = Did not comply TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 Page 6 of 23 RFI Global Services Ltd 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP82173JD01A V3.0 VERSION 3.0 ISSUE DATE: 20 SEPTEMBER 2011 RFI Global Services Ltd Page 7 of 23 3. Equipment Under Test (EUT) 3.1. Identification o…
