XKB-M2600CL4GWPayment terminal

INGENICO

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 24, 2023
Application Purpose: Original Equipment
Date of Application: Jul 24, 2023
Equipment Note: Payment terminal
Frequency Range: 2412.00000000 - 2462.00000000
Company: INGENICO
Country: France

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.ingenico.com 13-17 rue Pagès, 92150 Suresnes – France Banks and Acquirers International Holding SAS / 814 767 216 RCS Nanterre Move/2600 User Guide 2 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve Contents 1. Introduction 2. Presentation 2.1 Content of the box 2.2 Overview on the Move/2600 2.3 Keyboard details and functionality 3. Use of the terminal 3.1 Switching off the terminal 3.2 Reading card 4. Installation 4.1 Recommendations 4.2 Terminal connections 4.2.1 USB 4.3 Opening trap door 4.4 SAMs & SIMs 4.5 Cable connection 4.6 Battery 4.6.1 Main characteristics 4.6.2 Installing the battery 4.6.3 Charging the battery 4.6.4 Changing the battery 4 5 5 6 8 9 9 9 11 11 11 11 12 13 14 15 15 15 16 17 3 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 4.7 Paper roll 4.7.1 Main characteristics of Igenico roll 4.7.2 Installing paper roll 5. Troubleshooting 18 18 18 20 4 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 1. Introduction We hope that you will be fully satisfied with your new terminal Move/2600. Please select by yourself in this documentation items related to your model. Read this guide to understand and make the best use of your terminal. It presents you the necessary information about use, installation, maintenance, safety and security recommendations. WARRANTY / SECURITY Use only the power supply included with the product to ensure best performance and safety. Maintenance should only be provided by Ingenico authorized technician. Failure to comply with these instructions will void the manufacturer’s responsibility. This symbol indicates an important Warning. This symbol indicates a piece of advice. 5 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve ADVICE Keep the packaging. It must be re-used whenever the terminal is shipped. 2. Presentation 2.1 Content of the box Move/2600 terminal unit equipped with a paper roll A battery pack Power Supply Unit (PSU) 6 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 2.2 Overview of the Move/2600 2’’4 LCD Display Smart Card Reader Magnetic Stripe Reader Contactless Card Reader Easy Loading Printer Backlight keyboard with large key 7 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve Compartment where are located: The battery pack The SIM/SAM slots Weight (without paper roll nor battery) 254g Dimensions (L x w x h)167x76x56 mm Electrical mains network 100 - 240VAC / 50-60 Hz or 50/60Hz - Class II equipment Connections on terminalUSB-C connector for PSU 8 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 2.3 Keyboard details and functionality Some keys can have other functions according to the applications that are in the terminal. NAVIGATION keys CANCEL keyCLEAR keyVALIDATION key FEED PAPER 9 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 3. Use of the terminal 3.1 Switching off the terminal If the battery is empty and the terminal in use is removed from its base, the terminal automatically shuts off. It may also be switch by pressing simultaneously and (yellow key) for one second. In order to restart the terminal, press on the keyboard. 3.2 Reading card Magnetic stripe card The card can be read either from left to right or from right to left, with the stripe on top of the terminal (stripe can be seen by user). Use a regular movement to ensure a reliable card reading. Before using the terminal, always check if the paper roll is present and if battery is connected. Without battery pack connected, printer and 4G connectivity won’t be available. 10 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve insert the card horizontally with the chip facing upwards and leave in position throughout the transaction. Smart card Bring the card firmly up to the active zone. Keep the card close to the reader during the transaction. Contactless (Cless) The 4 virtual LEDs are displayed during the transaction. The terminal behavior for the cardholder may depend on: The terminal environment Local usage (language,...) 11 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 4. Installation 4.1 Recommendations Location of the Move/2600 Place the product on flat surface near an electric socket and according to the options close to an Ethernet socket. The terminal should be placed far from any very hot zones, protected from vibrations, dust, damp and electromagnetic radiation (computer screen, anti-theft barrier etc.). Operating conditions Battery charging conditions Storage conditions Ambient temperature Ambient temperature Ambient temperature from +0°C to +50°C from +0°C to +45°C from -20°C to +55°C Max relative humidity Max relative humidity 85% at +40°C 85% at +55°C 4.2 Product connections 4.2.1 Terminal USB A USB type C connector is available behind the battery door of Move/2600. This connector is used to connect PSU or USB type C to USB slave type A cable or USB type C to USB Host connector. This connector can also be used for SW loading. 12 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / / ee ve 4.3 Opening trap door Turn the terminal and unclip the trapdoor by pushing on the clip with as shown with the arrows on the picture Switch off the terminal before opening the trapdoor. CAUTION 13 Move/2600 300040537/855/000/02/9/0521 o /2021/ e o/ // e e o/ o / / …

Text truncated - open the document above for the full version.

Attestation Statements

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 3, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: XKB-M2600CL4GW INGENICO (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Link: List of Equipment and Services Covered By Section 2 of The Secure Networks Act Sincerely, INGENICO Nicolas JACQUEMONT Signature: Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 3, 2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: XKB-M2600CL4GW INGENICO (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Link: List of Equipment and Services Covered By Section 2 of The Secure Networks Act Sincerely, INGENICO Nicolas JACQUEMONT Signature:

Attestation Statements

U.S. AGENT LETTER OF ATTESTATION Date: March 28, 2023 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attestation Statement according to 2.911(d)(7) TO WHOM IT MAY CONCERN: We, Ingenico designate Ingenico, Inc. to act as U.S. agent for service of process. Ingenico, Inc. with FCC Registration Number (FRN) 0033589185 hereby acknowledges the obligation of the U.S. agent for service of process. Further Ingenico accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Sincerely, Signature Signature Applicant U.S. Agent Contact: Nicolas Jacquemont Contact: Christopher E. Bryant Title: Certification Manager Title: Product Manager Company: Ingenico Company: Ingenico, Inc. Address: 9 Avenue de la gare - Rovaltain TGV BP25156, Valence Cedex 9, 26958 ,France Address: 3025 Winward Parkway Suite 600 Alpharetta, Georgia 30005 - USA Phone: +1 678-456-1200

Cover Letter(s)

COVER LETTER INGENICO – Move/2600 CL/4G/WiFi F CC ID: XKB-M2600CL4GW May 3, 2023 This report concerns: File : Original Grant SubPart: SubPart 15B and 15C Equipment type : Payment terminal Request issue of grant : __ Immediately upon completion of review ___ Defer grant per 47 CFR 0.457(d)(1)(ii) until ____ date _____. Company Name agrees to notify the Commission by _____date_____ of the intended date of announcement of the product so that the grant can be issued on that date. Confidentiality of grant : __ Applicant requests the existence of this grant to be kept confidential until ____date____. The announcement of this product before this date via freedom of information would be detrimental to Company Name, and therefore must be considered a business secret. Public announcement of this product will not be made prior to this date. (Max. 60 days after grant issued). Limits used : (check one) C ISPR 22: ___ ___ Part15: ______ Measurement procedure used is ANSI C63.4-2014 / C63.10-2013 unless another is specified. Other test procedure : ____________________________________________________ Application for verification Prepared by : Maj id MOURZAGH LCIE Sud-Est ZI Centr’Alp – 170, rue de Chatagnon 38430 MOIRANS - France Ph. : 33 4 76 07 36 36 Fax : 33 4 76 55 90 88 e- mail : [email protected] FRN : 0005-0971-18 Applicant for this device Nicolas JACQUEMONT INGENICO 9 Avenue de la gare - Rovaltain TGV BP25156 26958 - VALENCE - FRANCE Ph. : +33 475842123 Fax : +33 - e-mail: [email protected] FRN : 0018912279 Signature : Signature : *Not to be filed with Equipment Authorization Branch of FCC unless requested Report format prepared by the Information Technology Industry Council (ITI) ESC-5 and reviewed by FCC staff in 1994

Cover Letter(s)

Document Version 1.1 2020-10-30 LONG-TERM CONFIDENTIALITY REQUEST for Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT M AY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request Long-Term Confidentiality for the following product: For the product stated above, we request Long-Term Confidentiality for exhibits which contain Block Diagram, Operational Description, Parts List/Tune Up Info, Schematics, SDR Software/Security Info. The above exhibits contain ou r trade secrets and proprietary information that could be of benefit to o ur competitors. This information will not be publicly available. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Company Name: Phone: Company Address: Fax: E-mail: Contact Name: Signature: Signature Date: Check your GC here. Click Grantee Search. FCC I D: Grantee Code Equipment Product Code

Cover Letter(s)

Letter of Agency May 3, 2023 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Timco Engineering, Inc. 849 NW State Road 45 Newberry, Florida 32669 - United States We, the undersigned INGENICO hereby authorizes Majid MOURZAGH, LCIE SUD EST, to act on our behalf in all matters relating to all processes required for FCC certification of our devices. Any and all acts carried out by the above agent on our behalf shall have the same effects as acts of our own. This authorization is valid until: December 30th, 2023 If you have any questions regarding this authorization, let us know please. Sincerely, Nicolas JACQUEMONT Signature:

External Photos

Move/2600 CL/4G/WiFi FCC ID : XKB-M2600CL4GW • • 1ngen1co • • 1ngen1co

ID Label/Location Info

SCALE ECHELLE P.N R. FAB SIZE FORMAT DRAWING NUMBER NUMERO DU DOCUMENT PLM TYPE PLM PART REV. SHEET FEUILLE ALL DIMENSIONS IN MILLIMETERS TOUTES LES DIMENSIONS EN MILLIMETRES TITLE : 1:1 A4900047447 R40000 011/1 TOLERANCE : Voir tableau/See table All components must be certified in compliance with REACH Regulation No 1907/2006 and RoHS Directive - 2011/65/EU No lead exemption allowed 51mm ±0.5mm 23mm ±0.5mm 4 Radius1mm ±0.5mm Color: White RAL9010 Adhesive one side: permanent UL969 certified Material: Vynil or Polyster, thickness 50 to 100μm UL969 certified DOCUMENT INGENICO REPRODUCTION ET DIVULGATION INTERDITES ALL RIGHTS RESERVED. REPRODUCTION AND DISCLOSURE PROHIBITED CAO/CAD : SOLIDWORKS 4 321 ABC D F E D C B 1 A 6 Product: Move/2600 CL/4G/WiFi FCC ID: XKB-M2600CL4GW contains FCC ID: XKB-INGEG91AUX

Internal Photos

Move/2600 CL/4G/WiFi ·------· 1ngen1co ·-------· 1ngen1co WiFi antenna • • 1ngen1co • • 1ngen1co • • 1ngen1co • • 1ngen1co ·--· 1ngen1co • • 1ngen1co • • 1ngen1co • • 1ngen1co

RF Exposure Info

1 (77) Copyright © Verkotan 2023 Document ID: FCC ISED SAR report_Move2600_ID6030c_02062023.docx SAR Compliance Test Report Date of Report 2/06/2023 Client’s Contact person: Stephane Ranchon Number of pages: 77 Responsible Test engineer: Ilari Kinnunen Testing laboratory: Verkotan Oy Elektroniikkatie 17 90590 Oulu Finland Client: Applicant: LCIE BUREAU VERITAS ZI Centr’Alp 170 rue de Chatagnon 38430 Moirans France INGENICO 9 Avenue de la gare - Rovaltain TGV BP25156 VALENCE Cedex 9 FRANCE 26958 Tested device Move/2600 CL/4G/WiFi Related reports: - Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC published RF exposure KDB procedures IEC/IEEE 62209-1528, 2020 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices RSS-102, Issue 5, 2015 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signatures: 02.06.2023 Laboratory Manager 2 (77) Copyright © Verkotan 2023 Document ID: FCC ISED SAR report_Move2600_ID6030c_02062023.docx TABLE OF CONTENTS 1. SUMMARY OF SAR TEST REPORT .......................................................................................................... 4 1.1 TEST DETAILS ........................................................................................................................................................................... 4 1.2 MAXIMUM RESULTS ............................................................................................................................................................. 4 1.2.1 Standalone SAR ................................................................................................................................................................. 5 1.2.2 Simultaneous Transmission SAR ................................................................................................................................. 5 1.2.3 ISED ......................................................................................................................................................................................... 5 1.2.4 Maximum Drift .................................................................................................................................................................... 5 1.2.5 Measurement Uncertainty ............................................................................................................................................ 6 2. DESCRIPTION OF THE DEVICE UNDER TEST (DUT) ............................................................................... 7 2.1 SUPPORTED FREQUENCY BANDS AND OPERATIONAL MODES ........................................................................ 7 2.2 TEST EXEMPTIONS ................................................................................................................................................................. 8 2.2.1 FCC .......................................................................................................................................................................................... 8 2.2.2 ISED ......................................................................................................................................................................................... 9 2.3 SIMULTANEOUS TRANSMISSION ................................................................................................................................... 9 3. OUTPUT POWER ..................................................................................................................................... 10 3.1 MAXIMUM SPECIFIED CONDUCTED OUTPUT POWER ......................................................................................... 10 3.2 TESTED CONDUCTED POWER ........................................................................................................................................ 12 4. TEST EQUIPMENT ................................................................................................................................... 19 4.1 TEST EQUIPMENT LIST ....................................................................................................................................................... 20 4.1.1 Isotropic E-field Probe Type EX3DV4 ...................................................................................................................... 20 4.2 PHANTOMS ............................................................................................................................................................................ 21 4.3 TISSUE SIMULANTS ............................................................................................................................................................. 21 4.4 SYSTEM VALIDATION STATUS ........................................................................................................................................ 21 4.5 SYSTEM CHECK ..................................................................................................................................................................... 22 4.5.1 Tissue Simulant Verification ........................................................................................................................................ 22 5. TEST PROCEDURE ................................................................................................................................... 24 5.1 DEVICE HOLDER ...................…

Text truncated - open the document above for the full version.

Test Report

Move/2600 - WiFi Antenna datasheet sheet 296292834 This Wifi antenna is a metallic frame. The antenna consists in an Inverted F antenna. Electrical Specifications Frequency Range: 2.4Ghz band 5Ghz band Gain: 1 dBi in 2.4Ghz Band 0dBi in 5Ghz Band Material Specifications Radiating Elements: Tin plate CRS / CRS 1008\1010 1.54 μm min. Tin pre plated. Radiation pattern !

Test Report

Move/2600 - Cless Antenna datasheet The 13.56MHz antenna is designed by printed wire. It is a loop antenna type with 2 turns of track. The 13.56MHz resonant frequency is achieved by a RLC tuning circuit. L is the inductance of the loop antenna and R itsresistance. The 13,56MHz RF technology operates by inductive coupling (magnetic field) between two antennas. T he radiated power (Electric field) is very weak because there is not a real radiated element. That’s why the 13.56MHz antenna gain is very low (compared with a dipole antenna at 13,56MHz) and difficult to measure. The gain is very inferior to 1. Material : Brass C2680-H thickness : 0.2 mm

Test Report

WIFI 5GHz Template: Release October 22 nd , 2022 This document shall not be reproduced, except in full, without the written approval of the LCIE. This document contains results related only to the items tested. It does not imply the conformity of the whole production to the items tested. Unless otherwise specified or rule defined by the test method, the decision of conformity doesn’t take into account the uncertainty of measures. This document doesn’t anticipate any certification decision. The COFRAC accreditation attests the technical capability of the testing laboratory for the only tests covered by the accreditation. If some tests mentioned in this report are carried out outside the framework of COFRAC accreditation, they are indicated by the symbol. Accreditation N°1-1633 Scope available on www.cofrac.fr TEST REPORT N°: 18390042-787450-D (FILE#5215959) Version : 01 Subject Radio spectrum matters tests according to standards: 47 CFR Part 15.407 & RSS-Gen Issue 5 (RF Test Only) Issued to INGENICO 9 avenue de la gare – Rovaltain TGV BP25156 VALENCE CEDEX 9 France 26958 Apparatus under test  Product Payment terminal  Trade mark INGENICO  Manufacturer INGENICO  Model under test Move/2600  Serial number 221967317151286025803467 222107317151286026031075  FCC ID XKB-M2600CL4GW  IC / Conclusion See Test Program chapter Test date March 28, 2023 to April 6, 2023 Test location Moirans FCC Test site FR0008 - 197516 ISED Test site / Sample receipt date February 27, 2023 Composition of document 120 pages Document issued on May 22, 2023 Written by : Approved by : Majid MOURZAGH Anthony MERLIN Tests operator Technical manager TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 2/120 PUBLICATION HISTORY Version Date Author Modification 01 May 22, 2023 Majid MOURZAGH Creation of the document Each new edition of this test report replaces and cancels the previous edition. The control of the old editions of report is under responsibility of client. TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 3/120 SUMMARY 1. TEST PROGRAM ............................................................................................................................... 4 2. EQUIPMENT UNDER TEST: CONFIGURATION (DECLARED BY PROVIDER) ................................ 5 3. OCCUPIED BANDWIDTH ................................................................................................................. 21 5. 26DB EMISSION BANDWIDTH ........................................................................................................ 29 6. 6DB EMISSION BANDWIDTH .......................................................................................................... 37 7. DUTY CYCLE ................................................................................................................................... 42 8. MAXIMUM CONDUCTED OUTPUT POWER, MAXIMUM POWER SPECTRAL DENSITY, MAXIMUM EIRP, MAXIMUM EIRP SPECTRAL DENSITY ............................................................................................. 45 9. UNWANTED EMISSIONS & UNDESIRABLE EMISSION ................................................................. 61 TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 4/120 1. TEST PROGRAM References ➢ 47 CFR Part 15.407 ➢ RSS Gen Issue 5 ➢ KDB 789033 D02 General U-NII Tests Procedures New Rules v02r01 ➢ KDB 662911 D01 Multiple Transmitter Output v02r01 ➢ ANSI C63.10-2013 Radio requirement: Clause (47CFR Part 15.407 & RSS-247 Issue 2 & RSS-Gen Issue 5) Test Description Test result - Comments Occupied Bandwidth  PASS  FAIL  NA  NP(1) 26dB Bandwidth  PASS  FAIL  NA(2)  NP(1) 6dB Bandwidth  PASS  FAIL  NA(3)  NP(1) Duty Cycle  PASS  FAIL  NA  NP(1) EIRP  PASS  FAIL  NA  NP(1) Maximum Conducted Output Power  PASS  FAIL  NA  NP(1) Power Spectral Density  PASS  FAIL  NA  NP(1) Transmit Power Control  PASS  FAIL  NA(4)  NP(1) Unwanted Emissions & Undesirable Emission  PASS  FAIL  NA  NP(1) Frequency Stability  PASS  FAIL  NA  NP(6) This table is a summary of test report, see conclusion of each clause of this test report for detail. (1): Limited program (2): EUT only operates outside the 5725MHz-5850MHz band (3): EUT only operates inside the 5725MHz-5850MHz band (4): EIRP below 27dBm or EUT only operates inside 5150MHz-5250MHz or/and 5725MHz-5850MHz bands (5): EUT not directly or indirectly connected to the AC Power Public Network (6): The Manufacturer declares the EUT emission is maintained within the band of operation under all conditions of normal operation as specified in the user manual TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 5/120 2. EQUIPMENT UNDER TEST: CONFIGURATION (DECLARED BY PROVIDER) 2.1. HARDWARE IDENTIFICATION (EUT AND AUXILIARIES): Equipment under test (EUT): INGENICO Move/2600 Serial Number:221967317151286025803467 Equipment Under Test TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 6/120 Power supply: All tests are performed with Supply 3 and battery worst case Name Type Rating Reference / Sn Comments Supply1 AC 100-240VAC 0.2A 50-60Hz OUTPUT 5V 1A 5W PHIHONG AM05R-050CK / Supply2 AC 100-240VAC 0.2A 50-60Hz OUTPUT 5V 1A 5W PHIHONG AM05x-050D / Supply3 AC 100-240VAC 50/60Hz 0.2A OUTPUT 5V 1A 5W Ktec KSA-5L-050100D5 / Supply4 Battery 3.6V 2.25Ah 8.1Wh F12433224 / TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 7/120 Voltage table used (for Power Line Conducted Emissions): Type Measurement performed:  AC  120VAC/60Hz  240VAC/50Hz  DC  +12VDC  -....VDC  Battery  +3.6VDC  -....VDC  USB (Laptop auxiliary)  120VAC/60Hz (Laptop auxiliary)  240VAC/50Hz(Laptop auxiliary) Inputs/outputs - Cable: Access Type Length used (m) Declared <3m Shielded Comments Supply1 AC/DC adapter 1.2 Yes No / Supply2 AC/DC adapter 1.2 Yes No / Supply2 AC/DC adapter 1.2 Yes No / Auxiliary equipment used during test: Type Reference Sn Comments LAPTOP DELL E4750 / Use …

Text truncated - open the document above for the full version.

Test Report

TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 61/120 9. UNWANTED EMISSIONS & UNDESIRABLE EMISSION 9.1. TEST CONDITIONS Test performed by : Akram HAKKARI / Majid MOURZAGH Date of test : March 28, 2023 to April 3, 2023 Ambient temperature : 20 °C – 22°C Relative humidity : 32 % - 38% 9.2. TEST SETUP The product has been tested according to ANSI C63.10 (2013) and FCC part15 subpart C. Test is performed in parallel, perpendicular and ground parallel axis with a loop antenna below 30MHz. Measurement bandwidth was 200Hz below 150kHz and 9kHz between 150kHz & 30MHz. The level has been maximised by the turntable rotation of 360 degrees range on all axis of EUT used in normal configuration. Antenna height was 1m. The EUT is placed in a full anechoic chamber. Distance between measuring antenna and the EUT is 3m. Test is performed in horizontal (H) and vertical (V) polarization with bilog between 30MHz & 1GHz and with a horn antenna above 1GHz. Measurement bandwidth was 120kHz below 1GHz and 1MHz above 1GHz. The level has been maximised by the turntable rotation of 360 degrees range on all axis of EUT used in normal configuration. The EUT is place at 1.5m high above 1GHz and at 0.8m high under 1GHz. The EUT is placed in a full anechoic chamber above 1GHz and on an open area test site from 30MHz to 1GHz. Distance between measuring antenna and the EUT is 3m. The height antenna is varied from 1m to 4m from 30MHz to 1GHz and above 1GHz is:  On mast, varied from 1m to 4m  Fixed and centered on the EUT (EUT smaller than the beamwidth of the measurement antenna, ANSI C63.10 §6.6.5) Frequency list has been created with anechoic chamber pre-scan results. The product has been tested according to the FCC KDB 789033 D02 General UNII Test Procedures New Rules v02r01. The following factor is applied to convert E[dBμV/m] to EIRP[dBm]. EIRP[dBm]= E[dBμV/m] + 20 log (d[meters]) -104.77 Absorber Plastic table Ground plane Turntable Absorber turntable EUT 80cm Antenna 3m 1 to 4m Bundle cable at 40cm of the ground plane Measuring receiver Absorber if measurements above 1GHz TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 62/120 Test set up of Unwanted Emissions in Restricted Frequency Bands in semi anechoic chamber Test Set up for radiated measurement in open area test site Absorber Plastic table Ground plane Turntable Absorber turntable EUT 10cm Antenna 3m 1 to 4m Measuring receiver Absorber if measurements above 1GHz Plastic table Ground plane Turntable turntable EUT 80cm Antenna 10m 1 to 4m Bundle cable at 40cm of the ground plane Measuring receiver Plastic table Ground plane Turntable turntable EUT 10cm Antenna 10m 1 to 4m Measuring receiver TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 63/120 Photo Setup : anechoic chamber (XY axis) Photo Setup : anechoic chamber (Z axis) Photograph for Unwanted Emissions & Undesirable Emission limits TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 64/120 Photograph for Unwanted Emissions & Undesirable Emission limits TEST REPORT N° 18390042-787450-D (FILE#5215959) Version : 01 Page 65/120 9.3. LIMIT Measure at 300m Frequency range Level Detector 9kHz-490kHz 67.6dBμV/m /F(kHz) QPeak Measure at 30m Frequency range Level Detector 490kHz-1.705MHz 87.6dBμV/m /F(kHz) QPeak 1.705MHz-30MHz 29.5dBμV/m QPeak Measure at 10m Frequency range Level Detector 30MHz to 88MHz 29.5dBμV/m QPeak 88MHz to 216MHz 33dBμV/m QPeak 216MHz to 960MHz 35.5BμV/m QPeak 960MHz to 1000MHz 43.5dBμV/m QPeak Above 1000MHz 63.5dBμV/m Peak 43.5dBμV/m Average Measure at 3m Frequency range Level Detector 30MHz to 88MHz 40dBμV/m QPeak 88MHz to 216MHz 43.5dBμV/m QPeak 216MHz to 960MHz 46BμV/m QPeak 960MHz to 1000MHz 54dBμV/m QPeak Above 1000MHz 74dBμV/m Peak 54dBμV/m Average Limit (dBm): 5150MHz-5250MHz: Shall not exceed EIRP of -27dBm/MHz outside of the band 5250MHz-5350MHz: Shall not exceed EIRP of -27dBm/MHz outside of the band 5470MHz-5725MHz: Shall not exceed EIRP of-27dBm/MHz outside of the band FCC 15.407 5725MHz-5850MHz: Shall not exceed EIRP of-27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Nicolas Jacquemont(Certification Manager)

[email protected]+330475842123Fax: +33475842350

Test Firm

LCIE Etablissement Sud EstAnthony MERLIN

[email protected]0033 4 76 07 36 35

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	5.70 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is the maximum conducted output power. This devicemust not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing. This device supports 20 and 40 MHz modes. Device contains Radio module FCC ID: XKB-INGEG91AUX Max Extremity SAR is 0.90W/Kg, Max Simultaneous Extremity SAR 3.79W/Kg
