XM2-EP7P8PEnhanced Power Public Safety Remote Unit for Optical system

Teko Telecom Srl

Click to zoom

Application Details

Equipment Class: B9B - Part 90 Class B Industrial Booster (non-SMR)
Date of Grant: Jul 16, 2014
Application Purpose: Original Equipment
Date of Application: May 13, 2014
Equipment Note: Enhanced Power Public Safety Remote Unit for Optical system
Frequency Range: 851.00000000 - 862.00000000
Company: Teko Telecom Srl
Country: Italy

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 P.IVA/VAT IT 03272231204– Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 10.000,00 i.v. Società con Sistema di Qualità ed Ambiente certificato – ISO 9001:2008, ISO 14001:2004 Equipment Autorisation Division Federal Communications Commission FCC ID: XM2-EP7P8P Product Name: TRU7P8PWE/AC-WS Nonroutine Long-Term Confidentiality Request To Whom it may concerns, Pursuant to Sections 0.457 and 0.459 of the Commission’s rule, we hereby request that nonroutine confidential treatment of information accompanying this application as outlined below: User’s manual Internal photos The EUT is part of our product portfolio consisting exclusively of professional communication devices and periphery designed for and delivered to mobile network operators. These devices are generally installed by well-trained professional installers under the control of the network operators at locations, where the general public has no access; such as mounted at masts, on building roofs or locked inside telecommunication shelters/rooms serviceable only by the licensee or designated technicians. The highly technical installation guides are only handed-out with the ordered devices to the network operator/professional installer. There is an NDA (Non-Disclosure Agreement) between us and our customer that assures that these instructions will never be made available to third parties. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 P.IVA/VAT IT 03272231204– Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 10.000,00 i.v. Società con Sistema di Qualità ed Ambiente certificato – ISO 9001:2008, ISO 14001:2004 Dated 24 March 2014 By: ALESSANDRO BRUNELLI Signature Printed Title: CERTIFICATION ENGINEER On behalf of : TEKO TELECOM Telephone: +39 051 6946811

Cover Letter(s)

P.IVA/VAT IT 03272231204 – Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 750.000,00 i.v. – PEC [email protected] Società con Sistema di Gestione per la Qualità e l’Ambiente certificato - ISO 9001:2008, ISO 14001:2004 www.jmawireless.com JMA Wireless • Teko Systems Group Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 Castel San Pietro Terme, 02 March 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XM2- EP7P8P Product Name: TRU7F8PWE/AC-WS Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Operational Descriptions  User’s manual (non-consumer device – highly technical) These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. P.IVA/VAT IT 03272231204 – Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 750.000,00 i.v. – PEC [email protected] Società con Sistema di Gestione per la Qualità e l’Ambiente certificato - ISO 9001:2008, ISO 14001:2004 www.jmawireless.com JMA Wireless • Teko Systems Group Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 Nonroutine Long-Term Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s rule, we hereby request that nonroutine confidential treatment of information accompanying this application as outlined below:  User’s manual The EUT is part of our product portfolio consisting exclusively of professional communication devices and periphery designed for and delivered to mobile network operators. These devices are generally installed by well-trained professional installers under the control of the network operators at locations, where the general public has no access; such as mounted at masts, on building roofs or locked inside telecommunication shelters/rooms serviceable only by the licensee or designated technicians. Besides, the internal part of the equipment is protected by warranty seals, to avoid unauthorized access. Only Teko Telecom’s technical personnel is authorized to open the seals to access the equipment. The highly technical installation guides are only handed-out with the ordered devices to the network operator/professional installer. There is an NDA (Non-Disclosure Agreement) between us and our customer that assures that these instructions will never be made available to third parties. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. P.IVA/VAT IT 03272231204 – Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 750.000,00 i.v. – PEC [email protected] Società con Sistema di Gestione per la Qualità e l’Ambiente certificato - ISO 9001:2008, ISO 14001:2004 www.jmawireless.com JMA Wireless • Teko Systems Group Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 Dated 02 March 2015 By: ALESSANDRO BRUNELLI Signature Printed Title: CERTIFICATION ENGINEER On behalf of : TEKO TELECOM Telephone: +39 051 6946811 P.IVA/VAT IT 03272231204 – Reg. Imprese di Bologna n. 03272231204 Capitale sociale Euro 750.000,00 i.v. – PEC [email protected] Società con Sistema di Gestione per la Qualità e l’Ambiente certificato - ISO 9001:2008, ISO 14001:2004 www.jmawireless.com JMA Wireless • Teko Systems Group Teko Telecom S.r.l. a Socio Unico Via Meucci, 24/A 40024 Castel S. Pietro Terme (BO) – Italy Tel +39 051 69 46 811 – Fax +39 051 94 84 73 MUTUAL NON-DISCLOSURE AGREEMENT THIS AGREEMENT, made effective as of the [Text] day of [Text], 2014, by and between [Text], having a place of business at [Text] (hereinafter “[Text]”) and John Mezzalingua Associates, LLC d/b/a JMA, having a place of business at 7645 Henry Clay Blvd., Liverpool, NY USA 13088 (hereinafter “JMA”). [Text] and JMA may be both Discloser and Recipient during the exchange of information under this Agreement. This Agreement shall apply to the both party’s Affiliates and subsidiaries. When used herein, the term “Affiliate” shall mean a business entity now or hereafter controlled by, controlling or under common control with JMA or [Text]. Control exists when any entity owns or controls at least 50% of the voting power of the entity. For the avoidance of doubt, “JMA” shall mean John Mezzalingua Associates, LLC and its Affiliates, including, but not limited to Teko Telecom S.r.l., having a place of business at via Meucci, 24/A, Castel San Pietro Terme (BO), Italy (hereinafter “Teko”), and CSS Antenna, Inc., having a place of business at 2206 Lakeside Blvd., Edgewood, MD USA 21040 (hereinafter “CSS”). The parties have a mutual interest in discussing and/or evaluating a potential business relationship (the “Purpose”) at which time the Discloser will disclose proprietary or CONFIDENTIAL INFORMATION to Recipient in the course of discussing or implementing such Purpose. For instance, the Purpose of such disclosure generally may relate to [Text]. In order to facilitate the Purpose and induce the parties to disclose and accept such information, the parties agree as follows: 1. “CONFIDENTIAL INFORMATION” means any information, technical data or know-how relating to the business, services or products of the Discloser and its Affiliates an…

Text truncated - open the document above for the full version.

External Photos

ID Label/Location Info

RF Exposure Info

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:31.11(dBm) Maximum peak output power at antenna input terminal:1291(mW) Antenna gain(maximum):7.89(dBi) EIRP7.94W ERP 4.85W Maximum antenna gain:6.15(numeric) Time Averaging:100(%) Prediction distance:50(cm) Prediction frequency:769(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.513(mW/cm^2) Power density at prediction frequency:0.253(mW/cm^2) Margin of compliance:-3.1(dB) This equates to:2.53W/m^2 2 4R PG S π =

Test Report

www.nemko.com Report number: 254061-1TRFWL Equipment Under Test: TRU7P8PWE/ACWS Applicant: TEKO Telecom Srl Via Meucci, 24/a I40024 Castel S. Pietro Terme (BO) FCC ID: XM2EP7P8P Test specification: Title 47Telecommunication Chapter I Federal Communications Commission Subchapter D – Safety and special radio services Part 90 Subpart R – Private land mobile services − Subpart I – General technical standards Reviewed by: 2014/03/27 Signature Date P. Barbieri, Wireless/EMC Specialist Reviewed by: 2014/03/27 Signature Date G. Curioni, Wireless/EMC Specialist Nemko S.p.A. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko S.p.A. accepts no responsibility for damages, if any suffered by any third party as a result of decisions made or actions based on this report. This report shall not be reproduced except in full without the written approval of the testing laboratory. . Report Number: 254061-1 Specification: FCC 90 Page 2 of 33 Table of contents Section 1: Report summary ................................................................................................................... 3 Section 2: Equipment under test .......................................................................................................... 4 2.1 Identification of equipment under test (EUT) ............................................................................ 4 2.2 Accessories and support equipment ......................................................................................... 5 2.3 EUT description ........................................................................................................................ 6 2.4 Technical specifications of the EUT .......................................................................................... 6 2.5 EUT setup diagram................................................................................................................... 7 2.6 Operation of the EUT during testing ......................................................................................... 8 2.7 Modifications incorporated in the EUT ...................................................................................... 8 Section 3: Test conditions .................................................................................................................... 9 3.1 Deviations from laboratory tests procedures ............................................................................. 9 3.2 Test conditions, power source and ambient temperatures ........................................................ 9 3.3 Measurement uncertainty ......................................................................................................... 9 3.4 Test equipment ....................................................................................................................... 10 Section 4: Result summary ................................................................................................................. 11 4.1 FCC Part 90: Test results ....................................................................................................... 11 Appendix A: Test results ..................................................................................................................... 12 Clause 90.205, 90.219(e)(1) Output power ...................................................................................... 12 Clause 90.209, 90.219(e)(4) Occupied bandwidth............................................................................ 14 Clause 90.543(c), 90.219(e)(3) Spurious emissions at the antenna terminal ................................... 15 Clause 90.543(c), 90.219(e)(3) Field strength of spurious radiation ................................................. 17 Clause 90.543(f) Radiated spurious emissions within 15591610 MHz band .................................... 21 Clause 90.213 Frequency stability .................................................................................................... 23 Clause 90.219(e)(2) Noise Figure .................................................................................................... 25 Clause 935210 D02v02 (D.3)(i) Intermodulation .............................................................................. 26 Clause 935219 D02v02 (D.3)(l) Filter frequency response ............................................................... 27 Appendix B: Block diagrams of test set-ups ..................................................................................... 28 Appendix C: Photo of set-ups ............................................................................................................. 29 Section 1: Report summary Report Number: 254061-1 Specification: FCC 90 Page 3 of 33 Section 1: Report summary This report contains an assessment of apparatus against specifications based upon tests carried out on samples submitted at Nemko Italy SpA. Test specification: FCC Part 90 Private land mobile services Subpart I – General technical standards Compliance status: Complies Exclusions: None Noncompliances: None Report release history: Original release Test location: Nemko Italy S.p.A. Via Carroccio, 4 I20853 Biassono (Italy) Registration number: 481407 (10 m Semi anechoic chamber) Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Italy’s ISO/IEC 17025 accreditation. Nemko Italy SpA. authorizes the applicant to reproduce this report provided it is reproduced in its entirety a…

Text truncated - open the document above for the full version.

Test Report

www.nemko.com Report number: 254061-2TRFWL Equipment Under Test: TRU7P8PWE/ACWS Applicant: TEKO Telecom Srl Via Meucci, 24/a I40024 Castel S. Pietro Terme (BO) FCC ID: XM2EP7P8P Test specification: Title 47Telecommunication Chapter I Federal Communications Commission Subchapter D – Safety and special radio services Part 90, Subpart S – Private land mobile services − Subpart I – General technical standards Reviewed by: 2014/03/27 Signature Date P. Barbieri, Wireless/EMC Specialist Reviewed by: 2014/03/27 Signature Date G. Curioni, Wireless/EMC Specialist Nemko S.p.A. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko S.p.A. accepts no responsibility for damages, if any suffered by any third party as a result of decisions made or actions based on this report. This report shall not be reproduced except in full without the written approval of the testing laboratory. . Report Number: 254061-2 Specification: FCC 90 Page 2 of 36 Table of contents Section 1: Report summary ................................................................................................................... 3 Section 2: Equipment under test .......................................................................................................... 4 2.1 Identification of equipment under test (EUT) ............................................................................ 4 2.2 Accessories and support equipment ......................................................................................... 5 2.3 EUT description ........................................................................................................................ 6 2.4 Technical specifications of the EUT .......................................................................................... 6 2.5 EUT setup diagram................................................................................................................... 7 2.6 Operation of the EUT during testing ......................................................................................... 8 2.7 Modifications incorporated in the EUT ...................................................................................... 8 Section 3: Test conditions .................................................................................................................... 9 3.1 Deviations from laboratory tests procedures ............................................................................. 9 3.2 Test conditions, power source and ambient temperatures ........................................................ 9 3.3 Measurement uncertainty ......................................................................................................... 9 3.4 Test equipment ....................................................................................................................... 10 Section 4: Result summary ................................................................................................................. 11 4.1 FCC Part 90: Test results ....................................................................................................... 11 Appendix A: Test results ..................................................................................................................... 12 Clause 90.205, 90.219(e)(1) Output power ...................................................................................... 12 Clause 90.209, 90.210(g), 90.210(h), 90.691, 90.219(e)(4) Occupied bandwidth ............................ 14 Clause 90.209, 90.210(g), 90.210(h), 90.691, 90.219(e)(3) Spurious emissions at the antenna terminal ............................................................................................................................................ 16 Clause 90.219(e)(3) Field strength of spurious radiation .................................................................. 19 Clause 90.213 Frequency stability .................................................................................................... 24 Clause 90.214 Transient Frequency behaviour ................................................................................ 26 Clause 90.219(e)(2) Noise Figure .................................................................................................... 27 Clause 935210 D02v02 (D.3)(i) Intermodulation .............................................................................. 28 Clause 935219 D02v02 (D.3)(l) Filter frequency response ............................................................... 30 Appendix B: Block diagrams of test set-ups ..................................................................................... 31 Appendix C: Photo of set-ups ............................................................................................................. 32 Section 1: Report summary Report Number: 254061-2 Specification: FCC 90 Page 3 of 36 Section 1: Report summary This report contains an assessment of apparatus against specifications based upon tests carried out on samples submitted at Nemko Italy SpA. Test specification: FCC Part 90 Private land mobile services Subpart I – General technical standards Compliance status: Complies Exclusions: None Noncompliances: None Report release history: Original release Test location: Nemko Italy S.p.A. Via Carroccio, 4 I20853 Biassono (Italy) Registration number: 481407 (10 m Semi anechoic chamber) Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Italy’s …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Alessandro Brunelli(Certification Engineer)

[email protected]+39 051 6946811Fax: +39 051 948473

Technical Contact

Teko TelecomMassimo Notargiacomo

[email protected]

Via Meucci 24/A · Castel San Pietro Terme · Italy

Non-Technical Contact

Teko TelecomMarco Della Mora

[email protected]

Test Firm

Nemko SpARalph Spanevello

[email protected]39-0392201201Fax: 39-0392201221

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	9	851 MHz - 862 MHz	1.25 W	F3E	Amp

Confidentiality

Long Term

Grant Notes

Power output listed is the composite for multi-channel operation. This transmitter operates as a remote unit as part of a system along with master unit components as described in this filing and excluding any other devices connected to the (downlink) output terminal of the master unit. This application covers only the system configuration with master unit connected to a base station in the downlink path; operations if any with master unit connected to antenna or amplifier in the downlink require separate equipment authorization. Antennas installed for each remote unit must provide a minimum 50 cm separation distance from all persons as described in this filing. The antenna(s) used for this transmitter must be fixed-mounted on (outdoor/indoor) permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3).
