XMHQP-350-DU2TWO-WAY RADIO

7120350101 QP-350-DU2 Digital Two-Way Radio USER MANUAL Quantun Electronics, LLC 1 THANK YOU We are grateful for you choice of Quantun production. This Professional Digital two-way radio incorporates the advanced technology and craft. You will be pleased with the quality and features of our product. Please read this manual carefully to ensure you know how to property operate the radio before use. 2 CONTENTS User Safety Information Compliance with RF Energy Exposure Standards Precautions and notices Product Inspection Radio Overview Parts of the Radio The functions of the LEDs and Beeps Table Programmable Auxiliary Functions Radio embedded features Getting Started Battery Antenna Accessory Installation Basic Operations Call VOX Operation Advanced Operations Troubleshooting Care and Cleaning Service 3 User Safety Information READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION BEFORE USING YOUR QUANTUN PORTABLE TWO-WAY RADIO. Compliance with RF Energy Exposure Standards Your Quantun two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environment at duty cycles of up to 50% talk-50% listen and should be used for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. Note: The approved batteries supplied with this radio are rated for a 5-5-90 duty cycle (5% talk-5% listen-90% standby), even though this radio complies with the FCC occupational RF exposure limits at duty cycles of up to 50% talk. Your Quantun two-way radio complies with the following of R F e n e r g y exposure standards and guidelines: z United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J z American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 z Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition z International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 z Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio Frequency Electromagnetic Fields in the Frequency Range from 3KHz to 300GHz, 1999 4 z EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. Please note that the above information is applicable to EU countries only. Precation and Notices z Government law prohibits the operation of unlicensed radio transmitters. Illegal operation is punishable by fine or imprisonment Of both. z To avoid problem caused by electromagnetic interference and electromagnetic compatibility, please turn off the transceiver at the sites where you are required, such as hospital, airplane etc. z In the vehicle equipped with air bag safety, don't put the transceiver within the scope of the air bag inflation. z Please turn off the transceiver before step into the inflammable and explosive places. z Don't transmit for a long time, it may damage the transceiver or it may cause scald. z Don't use the transceiver which antenna is damaged or else when the exposed metal touch the skin, it may cause scald also. z Don't expose the transceiver to long periods of direct sunlight, nor place it close to heating appliances. z If belt the transceiver on with belt clip, please notice that the distance Between body and antenna should be more than 5cm when transmitting. z If an abnormal odor or smoke is detected coming from the transceiver, switch OFF the power immediately and remove the optional battery pack from the transceiver. Contact our dealer nearby. * Industry Canada Compliance: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe B est conforme ¡§¡è la norme NMB-003 Canada. 5 Product Inspection Please carefully take the transceiver out of the box. We recommend that you confirm the items listed in the following table are enclosed before discarding the box. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately. Available Accessories Item Qty. (Pcs.) Antenna 1 Belt Clip 1 Screws(Belt Clip) 2 Battery 1 AC Adapter 1 Nylon Strap 1 User’s Manual 1 6 Radio Overview Parts of the Radio 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 (1) Power Switch (2) Antenna (3) Volume Adjust Keys[+] (4) PTT Key (5) SK(Programmable Side Key) (6) Volume Adjust Keys[-] (7) Microphone (8) Charging Terminal (9) Channel Selector Knob (10) Status Indicator (11) Charge Indicator (12) Charge DC Jack (13)External Earphone Jack (14) External Earphone Jack (15) Speaker (16) Screw(Belt Clip) (17) Belt Clip (18) Rear Cover (19) Battery Latch 7 The functions of the LEDs and beeps Table Power on When the radio is turned on, the power on alert tone sounds and status Indicator flashes green once. When the current channel is a blank channel, the radio sounds beep tone continuously. Power off When the radio is turned off, the power off alert is heard. Low battery alert Status Indicator flashes red, and a Di-Di-Di tone sounds at intervals of 10 seconds. Transmitting Status Indicator glows red when transmitting. When TOT timer expires, the radio sounds beep tone continuously. TOT pre-alert:: A beep is heard. Receiving Status Indicator glows green when carrier is present. Call ended (within the presettime period) LED glows orange Emergency LED flashes orange rapidly Scanning Status Indicator flashes green once every 1 second, while scanning is in process. Scan Start Alert Tone (programmable by your dealer): A beep is heard. When signal is received…

Text truncated - open the document above for the full version.

Design Document QP - 350 - D U2 block diagram

September12,2012 FederalCommunicationsCommission Re:FCCID:XMHQP-350-DU2 Applicant:QuantunElectronics,LLC Subject:justificationletterforexpandedfrequencyrange450–470MHz ToWhomItMayConcern: Youhaveaskedtheapplicantforjustificationtohavethe450–470MHzfreqrangeappear onhefaceoftheFCCGrantofCertificationforaPart90Certification.Thisfrequencyrange containsfrequenciesregardedasusual&customarybyUnitedStatesFederalGovernmentand itsvariousdepartments,userorganizationsandthemilitarytoappearonthefaceofthe equipmentGrantofCertification. (1)TheapplicantplanstoensurethatUSAusers,otherthanthosespecificallyidentifiedin thisletter,notoperatewithinbandswhicharenotallowedbythePart90,ascontrolledbythe users’FCCstationlicense. (2)ThisdevicewillnotbemarketedtoUSAusers,otherthanthoseidentifiedintheletter, namelytheUSGovernmentanditsvariousdepartments&military,foroperationinfrequency rangeoutofPart90. Sincerely, ------------------------------- FranciscoNoyola/CEO Tel:954-598-3500 Fax:954-598-3511

POWER OF ATTORNEY FCC ID: XMHQP- 350-DU2 Sep. 11, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen CTL Electromagnetic Technology Co., Ltd. (MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen CTL Electromagnetic Technology Co., Ltd. (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on Sep. 10, 2013. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Quantun Electronics, LLC are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely yours, ------------------------------- Francisco Noyola / CEO Tel: 954-598-3500 Fax: 954-598-3511

Page1of1 TestLabAttestationLetter DateofTest:FromAugust31,2012toSeptember4,2012. ApplicantName:QuantunElectronics,LLC FCCId:XMHQP-350-DU2 TestedBy: Duruwei Title:SAREngineer EmailAddress:[email protected] PhoneNo.:+86-21-50791141 StatementofCompliance: TATechnology(Shanghai)Co.,Ltd.declaresthatthisUnithas beentestedinaccordancewiththetestmethodidentifiedin thistestreportandthatweobserveditbeingtested.Italso declaresthattheUnitcomplieswiththerelevantlimits.All instrumentationandaccessoriesusedtotestthisunitfor compliancetotheindicatedtestmethodarecalibrated regularlyinaccordancewithISO17025:2005requirementsby laboratoriesaccreditedbyA2LA,NVLAP,orACLASforthe measurementparameters. Themeasurementsweremadeat:TATechnology(Shanghai)Co.,Ltd. No.145,JintangRd,TangzhenIndustryPark,PudongShanghai,China TestLabWitness- ApprovedBy: Yangweizhong TitleofWitness:Manager EmailAddress:[email protected] PhoneNo.:+86-21-50791141

V1.0Page72of77ReportNo.:CTL120824885-W 6.Ex t e rna lan dInt e rn alPh ot osoftheEU T ExternalPhotos V1.0Page73of77ReportNo.:CTL120824885-W

Applicant:QuantunElectronics,LLC FCCID:XMHQP-350-DU2 IC:8502A-QP350DU2 ModelName:QP-350-DU2 QuantunElectronics,LLC ModelName:QP-350-DU2 FCCID:XMHQP-350-DU2 IC:8502A-QP350DU2 TheFCCidentifierismarkedintheproductlabelandtheRFexposurecautionlabelisattachedontherearsideof thecabinet.Theusernoticeandwarningstatementaredescribedintheusermanual.. ProposedLabelLocationonEUT

LetterforLabelProposal FCCID:XMHQP-350-DU2September11,2012 EquipmentAuthorizationDivision OfficeofEngineeringandTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 DearSirs: QuantunElectronics,LLC.requestsacceptanceofthelabelingproposaldescribed belowfortransceiversbearingFCCidentifierXMHQP-350-DU2. Thesubjecttransceiversarecompacthandheldmodelsasshowninfigure1, authorizedunder47CFRPart90forLandservices. Figure1. Becausethemajorityofthetransceiverhousingiscomposedofdisplay,speaker, operatingcontrols,andaremovablebatterypack,thereisextremelylimited spaceavailabletoattachtherequiredlabelcarryingtheFCCidentifier. Attachingthelabeltothebatterypackisnotacceptablebecausethebattery packisaremovableitem.Forthisreason,Quantunproposesplacingthelabel carryingtheFCCidentifierinsidethebatterycompartmentasshowninfigure2. ProposedLabelLocationonEUT Figure2. Theconsumerpackagingforthesemodelsincludesthebatterypackasaseparate item,NOTinstalledontheradio.Assuch,theFCCidentifierwillbereadily visibletotheuserbeforethebatterypackisinstalledandwheneverthe batterypackisremovedorreplaced.Inthislocation,thelabelwillalsobe protectedfromphysicalabuseandremainreadablefortheanticipatedlifeof thedevice. Theconsumerpackagingforthesemodelsisa"giftbox"whichdoesnotallowthe transceivertobeseenattimeofpurchase.Inordertomeettherequirements of47CFRPart2.925(d),QuantunwilladdtheFCCidentifier"XMHQP-350-DU2"to theoutsideoftheconsumer"giftbox"packaging. Sincerelyyours, ------------------------------- FranciscoNoyola/CEO Tel:954-598-3500 Fax:954-598-3511

InternalPhotosofEUT

Design Document Theory of transmitter for QP-350 -DU2 Figure 1-1 shows QP-350-DU2 Digital two-way radio block diagram. Tx Baseband Processing The microphone signals are amplified by the VGA (variable gain amplifier) of the codec, and converted into digital form by the external codec and store in the left input channel buffer of U801. The following steps are applied to the digitized signals: 1. VENC, the voice encoder, which compress the voice signals into 2400 bps encoded signals 2. ENCRYPT, optional encryption block with configurable key 3. FEC, channel coding block, which adds 1200 bps to form 3600 bps signals for protecting of bit error 4. PACKET, which adds header and control information to form 4800 bps signals 5. 4FSK modulator 6. DIGI_MOD_GAIN, a gain block with linear 16 bit gain, for adjusting the modulation index. The resulting signals are split into left channel and right channel signal for two point modulation. RF Power Amplifier The modulated carrier signal output from VCO goes to the front-stage amplifier Q401, Design Document driver-stage amplifier Q402 and final-stage amplifier Q403 respectively. Afterwards, the amplified RF signal enters the low-pass filter (LPF) circuit through diode D401, and then is transmitted via the antenna after ultroharmonics are removed.D402 and D501 COMPOSE THE Rx-TX switch circuit.

Design Document QP-350-DU2 Tune up Procedure 1 Required Test Instrument Radio Communication Test Set 1 set Scanner 1 set 1A/5V Power Supply 1 set Digital Voltmeter 1 set 3A Ammeter 1 set 2 Adjustment process VCO Measurement Adjustment Item Condition Test Instrument TerminalParts Method Specification/ Remarks 1. Setting Power supply voltage 1. CH: TX high adjustment 2.Transmit VCO lock voltage 2. CH:TX Low Check 1. CH: RX high 3.Receive VCO lock voltage 2. RX low Digital Voltmeter CV TC301 TC302 Check Transmitter Item Condition Test InstrumentMethod Purpose Adjust a channel Enter the adjust mode; Turn to CH1; TX mode. Radio Communication Test Set; TX Test Adjust VR1 Frequency Error≤ 100Hz Group 1 1. TX power Low Enter the adjust mode. Turn to CH1. Adjust at 5 point (wideband). PTT key (increase) SK1 key (decrease) Adjust power to: 0.5W±0.1W Design Document 2. CDCSS balance Enter the adjust mode. Turn to CH3. Adjust at 3 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. PTT key (increase) SK1 key (decrease) 3. CDCSS deviation Enter the adjust mode. Turn to CH3. Adjust at 3 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. PTT key (increase) SK1 key (decrease) 4. CTCSS (67.0Hz) deviation Low Enter the adjust mode. Turn to CH4. Adjust at 3 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. PTT key (increase) SK1 key (decrease) 5. CTCSS (136.5Hz) deviation Center Enter the adjust mode. Turn to CH5. Adjust at 3 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. PTT key (increase) SK1 key (decrease) 6. CTCSS (254.1Hz) deviation High Enter the adjust mode. Turn to CH6. Adjust at 3 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. Radio Communication Test Set TX TEST HPF：20HZ LPF：300HZ PTT key (increase) SK1 key (decrease) Adjust deviation to 750Hz (wideband), 600Hz (medium band) and 400Hz (narrowband) respectively. Design Document 7. Transmit Audio Deviation Enter the adjust mode. Turn to CH7. Adjust at 3 point (wideband), 1 point (medium band), 1 point (narrow band). Radio Communication Test Set HPF: 20Hz LPF: 15KHz 1KHz 120mV PTT key (increase) SK1 key (decrease) Adjust deviation to 4KHz (wideband), 3.2KHz (medium band) and 2KHz (narrowband) respectively. 8. 2 Tone deviation Enter the adjust mode. Turn to CH8. Adjust at 1 point (wideband), 1 point (medium band), 1 point (narrow band). PTT key (increase) SK1 key (decrease) Adjust deviation to 3.2KHz (wideband), 2.5KHz (medium band) and 1.8KHz (narrowband) respectively. 9. DTMF deviati on Enter the adjust mode. Turn to CH9. Adjust at 1 point (wideband), 1 point (medium band), and 1 point (narrow band). PTT key (increase) SK1 key (decrease) Adjust deviation to 3.2KHz (wideband), 2.5KHz (medium band) and 1.8KHz (narrowband) respectively. 10. MSK deviati on Enter the adjust mode. Turn to CH10. Adjust at 3 point (wideband), 1 point (medium band), 1 point (narrow band). Radio Communication Test Set TX Test HPF: 20Hz LPF: 15KHz No modulation signal. PTT key (increase) SK1 key (decrease) Adjust deviation to 3.2KHz (wideband), 2.5KHz (medium band) and 1.8KHz (narrowband) respectively. 11. VOX GAIN1 Enter the adjust mode. Turn to CH11. Adjust at 1 point (wideband). Save Modulation signal: 1KHz, 45mv Press PTT to save; 12. VOX GAIN5 Enter the adjust mode. Turn to CH12. Adjust at 1 point (wideband). Radio Communication Test Set TX TEST HPF: 20HZ LPF: 15KHZ Save Modulation signal: 1KHz, 15mv Press PTT to save; 13. TX power HIGH Enter the adjust mode. Turn to CH13. Adjust at 5 point (wideband). Radio Communication Test Set TX TEST PTT key (increase) SK1 key (decrease) Adjust power to 2±0.1W VHF: 2W, UHF: 2W Design Document 14. TX voltage Low Enter the adjust mode. Turn to CH14. Adjust at 1 point (wideband). Save Adjust voltage to 3.0V,press PTT to save Receiver Item Condition Test Instrument Method Purpose 1. RX sensitivity Enter the adjust mode. Turn to CH1. Adjust at 5 point (wideband). PTT key SK1 key Adjust level to 119dBm. SINAD≥12dB 2. RX volume Enter the adjust mode. Turn to CH2. Adjust 1 point at wideband, medium band and narrowband respectively. PTT key (Increase) SK1 key (Decrease When Max. volume is set, adjust AC level to 1W (16Ω), single input 2.5V, dual input 5V 3. Squelch Level 3 (OPEN) Enter the adjust mode. Turn to CH3. Adjust at 5 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. Save Adjust level to -123dBm，press PTT to save 4. Squelch Level 3 (SQUELCH) Enter the adjust mode. Turn to CH4. Adjust at 5 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. Save Adjust level to -125dBm，press PTT to save Group 2 5. Squelch Level 9 (OPEN) Enter the adjust mode. Turn to CH5. Adjust at 5 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. Radio Communication Test Set RX TEST HPF：300HZ LPF：3KHZ Save Adjust level to -117dBm，press PTT to save Design Document 6. Squelch Level 9 (SQUELCH) Enter the adjust mode. Turn to CH6. Adjust at 5 point (wideband), 1 point (medium band) and 1 point (narrowband) respectively. Save Adjust level to -119dBm，press PTT to save 7. RX voltage Low Enter the adjust mode. Turn to CH7. Adjust at 1 point (wideband). Save Adjust power supply voltage to 3.1V, press PTT to save Note: AF deviation of the receiver is 3KHz (wideband)，2.5KHz(medium band) and 1.5KHz (narrowband)

TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 52 of 68 ANNEX E: D450V3 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 53 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 54 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 55 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 56 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 57 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 58 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 59 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 60 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 61 of 68 ANNEX F: DAE4 Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 62 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 63 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 64 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 65 of 68 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 66 of 68 ANNEX G: The EUT Appearances and Test Configuration Front Back Left Side TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 67 of 68 Right Side Picture 3-1: EUT Picture 3-2: Battery Picture 3: Constituents of the sample TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 68 of 68 Picture 4: Face-held, the front of the EUT towards phantom, the distance from EUT Antenna to the bottom of the Phantom is 35mm Picture 5: Body-worn, the front of the EUT towards ground, the distance from the EUT Antenna to the bottom of the Phantom is 16mm 25mm 35mm 10mm 16m

TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 1 of 68 TESTING No. L2264 OET 65 TEST REPORT Product Name Two-way Radio Model QP-350-DU2 FCC ID XMHQP-350-DU2 Client Quantun Electronics, LLC TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01R1 Page 2 of 68 GENERAL SUMMARY Product Name Two-way Radio Model QP-350-DU2 FCC ID XMHQP-350-DU2 Report No. RXA1208-0754SAR01R1 Client Quantun Electronics, LLC Manufacturer Shenzhen Surwave Technologies Co.,LTD Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438 June 19, 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. KDB 643646 D01 SAR Test for PTT Radios v01: SAR Test Reduction Considerations for Occupational PTT Radios KDB 447498 D01 Mobile Portable RF Exposure v04: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: September 5 th , 2012 Comment The test result only responds to the measured sample. Approved by Yang weizhong Director Revised by Ling minbao SAR Manager Performed by Du ruwei SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1208-0754SAR01 Page 3 of 68 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT................................................................................................................ 7 1.6. The Maximum SAR 1g Values ................................................................................................ 8 1.7. Test Date .............................................................................................................................. 8 2. SAR Measurements System Configuration .................................................................................. 9 2.1. SAR Measurement Set-up .................................................................................................... 9 2.2. DASY5 E-field Probe System ............................................................................................. 10 2.2.1. ES3DV3 Probe Specification ....................................................................................... 10 2.2.2. E-field Probe Calibration .............................................................................................. 11 2.3. Other Test Equipment ......................................................................................................... 11 2.3.1. Device Holder for Transmitters .................................................................................... 11 2.3.2. Phantom...................................................................................................................... 12 2.4. Scanning Procedure........................................................................................................... 12 2.5. Data Storage and Evaluation .............................................................................................. 14 2.5.1. Data Storage................................................................................................................ 14 2.5.2. Data Evaluation by SEMCAD ...................................................................................... 14 3. Laboratory Environment............................................................................................................. 16 4. Tissue-equivalent Liquid ............................................................................................................ 17 4.1. Tissue-equivalent Liquid Ingredients................................................................................... 17 4.2. Tissue-equivalent Liquid Properties .................................................................................... 18 5. System Check ............................................................................................................................ 19 5.1. Description of System Check .............................................................................................. 19 5.2. System Check Results ........................................................................................................ 21 6. Operational Conditions during Test ............................................................................................ 22 6.1. General Description of Test Procedures............................................................................. 22 6.2. Test Configuration ......................................................…
