UC200T-GL Mini PCIe Hardware Design UMTS/HSPA+ Standard Module Series Rev. UC200T-GL_Mini_PCIe_Hardware_Design_V1.0 Date: 2019-12-12 Status: Released www.quectel.com UMTS/HSPA+ Standard Module Series UC200T-GL Mini PCIe Hardware Design UC200T-GL_Mini_PCIe_Hardware_Design 1 / 51 Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters: Quectel Wireless Solutions Co., Ltd. Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai, China 200233 Tel: +86 21 5108 6236 Email: [email protected] Or our local office. For more information, please visit: http://www.quectel.com/support/sales.htm For technical support, or to report documentation errors, please visit: http://www.quectel.com/support/technical.htm Or email to: [email protected] GENERAL NOTES QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. COPYRIGHT THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN. Copyright © Quectel Wireless Solutions Co., Ltd. 2019. All rights reserved. UMTS/HSPA+ Standard Module Series UC200T-GL Mini PCIe Hardware Design UC200T-GL_Mini_PCIe_Hardware_Design 2 / 51 About the Document History Revision Date Author Description 1.0 2019-12-12 Jouni Yang/ Initial UMTS/HSPA+ Standard Module Series UC200T-GL Mini PCIe Hardware Design UC200T-GL_Mini_PCIe_Hardware_Design 3 / 51 Contents About the Document ................................................................................................................................ 2 Contents .................................................................................................................................................... 3 Table Index ............................................................................................................................................... 5 Figure Index .............................................................................................................................................. 6 1 Introduction ....................................................................................................................................... 7 1.1. Safety Information ................................................................................................................. 10 2 Product Concept ............................................................................................................................. 12 2.1. General Description .............................................................................................................. 12 2.2. Key Features ......................................................................................................................... 12 2.3. Functional Diagram ............................................................................................................... 15 3 Application Interfaces ..................................................................................................................... 16 3.1. Pin Assignment ..................................................................................................................... 16 3.2. Pin Description ...................................................................................................................... 17 3.3. Operating Modes .................................................................................................................. 20 3.4. Power Saving ........................................................................................................................ 20 3.4.1. Sleep Mode.................................................................................................................. 20 3.4.2. Airplane Mode .............................................................................................................. 20 3.5. Power Supply .................................................................................................................. ...... 21 3.6. UART Interfaces .................................................................................................................... 21 3.6.1. Main UART Interface ................................................................................................... 22 3.6.2. COEX UART Interface* .................................................................... 错误！未定义书签。 3.7. USB Interface ........................................................................................................................ 22 3.8. (U)SIM Interface .................................................................................................................... 24 3.9. PCM and I2C Interfaces ........................................................................................................ 25 3.10. Control and Indication Signals .............................................................................................. 28 3.10.1. RI Signal ...................................................................................................................... 28 3.10.2. DTR Signal .........................................................................................................…

Text truncated - open the document above for the full version.

UC Ha UMTS Rev. Date: 20 Statu C20 rd w S/HSPA+ UC200T- 19-10-14 s: Releas 0T- war + Module -GL_Hard 4 sed -GL re D e Series dware_De L Des esign_V1 sign 1.0 n wwww.quectel.com UC200T-GL Our aim assistan c Quectel W Building 5, Shanghai, C Tel: +86 21 Email:info @ Or our lo c http://www.q For techn http://www.q Or Email to GENERAL QUECTEL PROVIDE D TO ENSUR MAKE ANY ANY LIABIL RELIANCE CHANGE W COPYRI G THE INFO QUECTEL W AND EDIT FORBIDDE DAMAGES REGISTR A Copyrigh L_Hardware is to prov ce, please Wireless S Shanghai China 20023 5108 6236 @quectel.com cal office. quectel.com nical suppo quectel.com : support@q L NOTES OFFERS TH D IS BASED RE THE QUA Y WARRANT LITY FOR A UPON TH WITHOUT P GHT ORMATION WIRELESS TING OF T EN WITHOU . ALL RIG ATION OF A t © Quecte e_Design1 / vide custo contact o Solutions C Business P 33 m For more m/support/sa ort, or to r m/support/tec quectel.com HE INFORM D UPON CU ALITY OF T TY AS TO TH ANY INJURY E INFORMA RIOR NOTI CONTAIN E SOLUTION THIS DOCU UT PERMIS GHTS ARE UTILITY MO el Wireles / 84 omers wit our compa Co., Ltd. Park Phase informati les.htm report doc chnical.htm MATION AS STOMERS ’ THE INFOR HE INFORM Y, LOSS O ATION. ALL CE. ED HERE NS CO., LTD UMENT AS SSION. OFF E RESERV ODEL OR D ss Solution th timely any headq e III (Area ion, please cumentati A SERVICE ’ REQUIRE RMATION IT MATION CO R DAMAG E L INFORMA IS PROP D. TRANSM S WELL A FENDERS W VED IN TH DESIGN. ns Co., Ltd and com uarters: B), No.101 e visit: on errors, E TO ITS C MENTS. QU T MAKES AV NTAINED H E OF ANY K ATION SUP RIETARY MITTING, RE AS UTILIZA WILL BE H HE EVENT d. 2019. A UMTS/H UC200T prehensiv 6 Tianlin R , please v CUSTOMER UECTEL MA VAILABLE. HEREIN, AN KIND INCUR PPLIED HER TECHNICA EPRODUCT ATION OF ELD LIAB L T OF A P All rights re HSPA+ Mod T-GLHardw ve service Road, Minha isit: S. THE INF AKES EVER QUECTEL ND DOES NO RRED BY U REIN IS SU AL INFORM TION, DISSE THE CON LE FOR PA PATENT G eserved. dule Series ware Design e. For any ang District FORMATION RY EFFORT DOES NOT OT ACCEPT USE OF OR UBJECT TO MATION OF EMINATION TENT ARE AYMENT OF GRANT OR s n y t, N T T T R O F N E F R UC200T-GL Abou History Revision 1.0 L_Hardware ut the y Date 2019-1 e_Design2 / e Doc A 0-14 J o A / 84 cume Author ouni YANG/ Andrea ZHAN nt Des NG Init i scription ial UMTS/H UC200T HSPA+ Mod T-GLHardw dule Series ware Design s n UC200T-GL Contents About the D Contents ... Table Index Figure Inde 1 Introdu 1.1. 2 Produ c 2.1. 2.2. 2.3. 2.4. 3 Applic 3.1. 3.2. 3.3. 3.4. 3.5. 3. 5 3.5 3.6. 3. 6 3.6 3.6 3.7. 3. 7 3.7 3.7 3.8. 3.9. 3.10. 3.11. 3.12. 3.13. 3.14. L_Hardware s Document . ................... x ................ ex ............... uction ........ Safety Info ct Concept General D e Key Featur Functional Evaluation ation Inter f General De Pin Assignm Pin Descrip Operating M Power Sav 5.1. Sleep 3.5.1.1. 3.5.1.2. 3.5.1.3. 3.5.1.4. 5.2. Airpla Power Sup 6.1. Powe 6.2. Decre 6.3. Refer Power-on/o 7.1. Turn 7.2. Turn 3.7.2.1. 3.7.2.2. 7.3. Rese (U)SIM Inte USB Interfa UART Inter PCM and I2 SD Card In ADC Interfa Network St e_Design3 / .................. .................. .................. .................. .................. rmation ...... .................. escription ... res .............. Diagram .... Board ........ faces .......... escription ... ment .......... ption ........... Modes ....... ving ............. p Mode....... UART Ap p USB Appli USB Appli USB Appli ane Mode ... pply ............. er Supply Pi ease Voltag rence Desig off/Reset Sc on the Mod off the Mod Turn off th Turn off M et the Module erface ......... ace ............. rfaces ......... 2C Interface nterface* ..... aces ........... tatus Indicat / 84 ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... plication ....... cation with U cation with U cation witho ................... ................... ns ............... e Drop ........ gn for Power cenarios ...... ule Using th ule .............. e Module Us odule Using e ................. ................... ................... ................... es ................ ................... ................... tion ............. ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... USB Remot USB Suspen out USB Sus ................... ................... ................... ................... r Supply ...... ................... he PWRKEY ................... sing the PW g AT Comma ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... ................... .................. ................... .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. .................. .................. e Wakeup F nd/Resume spend Funct .................. .................. .................. .................. .................. .................. Y ................. .................. WRKEY Pin . and ............. .................. .................. .................. .................. .................. .................. .................. .................. UMTS/ H UC200T ................... ................... ................... ..............…

Text truncated - open the document above for the full version.

Quectel Wireless Solutions Co., Ltd Request for Confidentiality Date: _2020/8/3_ Subject: Confidentiality Request for: _____ FCC ID: XMR202007UC200TGL ______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ______ FCC ID: XMR202007UC200TGL_____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TCB in the event information regarding the product or the product is made available to the public. TCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Jean Hu (Signature/Title 2 ) (Print name)

Quectel Wireless Solutions Company Limited Declaration of the Modular Approval A pplicant / Grantee Quectel Wireless Solutions Co., Ltd FCC ID: XMR202007UC200TGL Model: UC200T‐GL, UC200T‐GL MINIPCIE The single module transmitter has been evaluated then tested meeting the requirements under Part 15C Section 212 as below: Modular approval requirement EUT Condition Comply (a) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio elements of the modular transmitter have their own shielding. YES (b) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. The modular has buffered data inputs, it is integrated in chip. Please see schematic.pdf YES (c)The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to UC200T-GL, UC200T-GL MINIPCIE. Please see schematic.pdf YES (d) The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. A permanently attached antenna or unique antenna connector is not a requirement for licensed modules. YES (e)The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted UC200T-GL, UC200T-GL MINIPCIE was tested in a stand ‐alone configuration via a PCMCIA extender. Please see spurious set‐up YES Quectel Wireless Solutions Company Limited requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)) must not be in side another device during testing. (f)The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. The label position of EC25-AFX; EC25-AFX MINIPCIE is clearly indicated. If the FCC ID of the module cannot be seen when it is installed, then the host label must include the text: Contains FCC ID: XMR201909EC25AFX. Please see the label.pdf YES (g) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any suchrequirements. A copy of these instructions must be included in the application for equipmentauthorizationrequirements,whicharebas edon theintendeduse/configurations. UC200T-GL, UC200T-GL MINIPCIE is compliant with all applicable FCC rules. Detail instructions are given in the User Manual. YES (h)The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. UC200T-GL, UC200T-GL MINIPCIE is approved to comply with the applicable RF exposure requirement, please see the MPE evaluation with 20cm as the distance restriction. YES Quect Dated By: Title: On be h Teleph tel Wirele Project M half of : one: ess Solutio 2020/8 Sig n Manager Quectel +86-2 ons Comp 8/03 nature Wireless S 21-51086236 pany Limi olutions Co 6 ext 6511 ited Jea ompany Lim n Hu Pri mited rinted

Quectel Wireless Solutions Co., Ltd POWER OF ATTORNEY DATE:August 3, 2020 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize TA Technology (Shanghai) Co., Ltd. /Jinnan Han on our behalf, to apply to FCC on our equipment for FCC ID: XMR202007UC200TGL. Any and all acts carried out by TA Technology (Shanghai) Co., Ltd. / Jinnan Han on our behalf shall have the same effect as acts of our own. Sincerely, Signature: Print name: Jean Hu Company: Quectel Wireless Solutions Company Limited

E TA Techno This report sh EUT Ap EUT Appearanc ology (Shang hall not be repr ppearanc ce ghai) Co., L roduced except ce td. tin full, without t the written ap pproval of TA Te Re echnology (Shan eport No.: R200 Pa nghai) Co., Ltd. 07A0437 age 1 of 2 E TA Techno This report sh EUT Appearanc ology (Shang hall not be repr ce ghai) Co., L roduced except td. tin full, without Picture 1: t the written ap a: EUT : Constituen pproval of TA Te ts of EUT Re echnology (Shan eport No.: R200 Pa nghai) Co., Ltd. 07A0437 age 2 of 2

MPE TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd FCC ID XMR202007UC200TGL Product UMTS/HSPA+ Module Brand Quectel Model UC200T-GL, UC200T-GL MINIPCIE Marketing Quectel UC200T-GL, Quectel UC200T-GL MINIPCIE Report No. R2007A0437-M1 Issue Date July 22, 2020 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC 47 CFR Part 1 1.1310. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Yu Wang Approved by: Guangchang Fan TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE Test Report Report No.: R2007A0437-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 2 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ............................................................................................................................... 3 1.1 Notes of the Test Report ......................................................................................................... 3 1.2. Test facility .............................................................................................................................. 3 1.3 Testing Location ...................................................................................................................... 3 1.4 Laboratory Environment .......................................................................................................... 3 2 Description of Equipment under Test .............................................................................................. 5 3 Maximum conducted output power (measured) and antenna Gain ................................................ 6 4 Test Result ..................................................................................................................................... 7 MPE Test Report Report No.: R2007A0437-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 3 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd.The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. 1.3 Testing Location Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China City: Shanghai Post code: 201201 Country: P. R. China Contact: Fan Guangchang Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] 1.4 Laboratory Environment Temperature Min. = 18C, Max. = 25 C Relative humidity Min. = 30%, Max. = 70% MPE Test Report Report No.: R2007A0437-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 4 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Ground system resistance < 0.5  Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. MPE Test Report Report No.: R2007A0437-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 5 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2 Description of Equipment under Test Client Information Applicant Quectel Wireless Solutions Co., Ltd Applicant address Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai 200233, China Manufacturer Quectel Wireless Solutions Co., Ltd Manufacturer address Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai 200233, China General Technologies Model UC200T-GL, UC200T-GL MINIPCIE SN 868817040005702 Hardware Version R1.0 Software Version UC200TGLAAR02A04M16 Date of Testing: July 7, 2020~ July 19, 2020 Note: 1. The EUT is sent from the applicant to TA and the information of the EUT is declared by the applicant. 2. All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. MPE Test Report Report No.: R2007A0437-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 6 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 3 Maximum conducted output power (measured) and antenna Gain The numeric gain (G) of the antenna with a gain specified in dB is determined by Numeric gain (G)=10^(antenna gain/10) Band Burst Turn up Power(dBm) Division Factors (dB) Time-Averaged Tune up Power (dBm) GSM 900 GSM 32.66 -9.03 23.63 GPRS 1 Txslot 32.65 -9.03 23.62 2 Txslots 32.54 -6.02 26.52 3 Txslots 31.04 -4.26 26.78 4 Txslots 29.11 -3.01 26.10 GSM 1800 GSM 29.16 -9.03 20.13 GPRS 1 Txslot 29.38 -9.03 20.35 2 Txslots 29.25 -6.02 23.23 3 Txslots 27.90 -4.26 23.64 4 Txslots 25.75 -3.01 22.74…

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd FCC ID XMR202007UC200TGL Product UMTS/HSPA+ Module Brand Quectel Model UC200T-GL, UC200T-GL MINIPCIE Marketing Quectel UC200T-GL, Quectel UC200T-GL MINIPCIE Report No. R2007A0437-R1 Issue Date July 22, 2020 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2019)/ FCC CFR 47 Part 22H (2019). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 RF Test Report Report No.: R2007A0437-R1 TA Technology (Shanghai) Co., Ltd. TA-MB-05-001R Page 2 of 33 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ...................................................................................................................................... 4 1.1. Notes of the Test Report ............................................................................................................... 4 1.2. Testing Location ............................................................................................................................ 4 2. General Description of Equipment under Test ....................................................................................... 5 2.1. Applicant and Manufacturer Information ....................................................................................... 5 2.2. General Information ....................................................................................................................... 5 3. Applied Standards .................................................................................................................................. 6 4. Test Configuration .................................................................................................................................. 7 5. Test Case Results .................................................................................................................................. 8 5.1. RF Power Output and Effective Radiated Power .......................................................................... 8 5.2. Occupied Bandwidth ................................................................................................................... 11 5.3. Band Edge Compliance ............................................................................................................... 15 5.4. Peak-to-Average Power Ratio (PAPR) ....................................................................................... 18 5.5. Frequency Stability ...................................................................................................................... 20 5.6. Spurious Emissions at Antenna Terminals ................................................................................. 24 5.7. Radiates Spurious Emission ....................................................................................................... 29 6. Main Test Instruments ......................................................................................................................... 33 RF Test Report Report No.: R2007A0437-R1 TA Technology (Shanghai) Co., Ltd. TA-MB-05-001R Page 3 of 33 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results No. Test Case Clause in FCC rules Verdict 1 RF Power Output and Effective Radiated Power 2.1046 22.913(a)(5) PASS 2 Occupied Bandwidth 2.1049 PASS 3 Band Edge Compliance 2.1051 / 22.917(a) PASS 4 Peak-to-Average Power Ratio 22.913(d)/ KDB 971168 D01(5.7) PASS 5 Frequency Stability 2.1055 / 22.355 PASS 6 Spurious Emissions at Antenna Terminals 2.1051 / 22.917(a) PASS 7 Radiates Spurious Emission 2.1053 / 22.917 (a) PASS Date of Testing: July 7, 2020~ July 19, 2020 Note: All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., …
