Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 86 | 27 | 3.75 GHz - 3.93 GHz | 328.10 mW | 96M5G7D | 0.0103
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesPower out is conducted at the antenna terminal. Single Modular Approval.
This device is certified for mobile and fixed applications. Co-location of this module with other transmitters would require the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. OEM integrators must insure that the end user has no manual instructions to remove or install this module. For mobile operating configurations the antenna gain, including cable loss, must not exceed the gains documented in this filing for satisfying RF exposure compliance, as defined in 2.1091. Under no conditions may an antenna gain be used that would exceed the ERP and/or EIRP power limits as specified in Parts 22/24/27/90. The Grantee is responsible for providing the documentation required for modular use.
This device has 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth modes for LTE Bands 2/4/25/66; 1.4 MHz, 3 MHz, 5 MHz, 10 MHz and 15MHz bandwidth modes for LTE Band 26; 1.4 MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Bands 5/12; 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth modes for LTE Bands 7/38/41/71; 5 MHz and 10 MHz bandwidth modes for LTE Bands 13/14/17/30.
This device also has 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth modes for 5GNR Bands n2/n5/n7/n25/n66/n71; 5 MHz, 10 MHz and 15 MHz bandwidth modes for 5GNR band n12; 20 MHz, 30 MHz, 40 MHz, 50 MHz, 60 MHz, 80 MHz and 100MHz bandwidth modes for 5GNR band n41; 100 MHZ bandwidth mode for 5GNR band n77.
This device supports LTE CA Uplink and SA/NSA features for 5GNR Bands and it also contains LTE Band 48 (CBRS) transmitter.
This device supports mmW bands but it is not able to be used directly due to the lack of some components, as documented in this filing.
