XMR2021EC25ADLLTE Module

EC25Hardware Design LTE Standard Module Series Rev. EC25_Hardware_Design_V2.3 Date: 2019-11-26 Status: Released www.quectel.com LTE Standard Module Series EC25 Hardware Design EC25_Hardware_Design 1 / 130 Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters: Quectel Wireless Solutions Co., Ltd. Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai, China 200233 Tel: +86 21 5108 6236 Email: [email protected] Or our local office. For more information, please visit: http://www.quectel.com/support/sales.htm For technical support, or to report documentation errors, please visit: http://www.quectel.com/support/technical.htm Or email to: [email protected] GENERAL NOTES QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. COPYRIGHT THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN. Copyright©QuectelWirelessSolutionsCo.,Ltd.2019.Allrightsreserved. LTE Standard Module Series EC25 Hardware Design EC25_Hardware_Design 2 / 130 About the Document Revision History RevisionDateAuthorDescription 1.02016-04-01 Woody WUInitial 1.12016-09-22 Lyndon LIU/ Frank WANG 1. Updated EC25 series frequency bands in Table 1. 2. Updated transmitting power, supported maximum baud rate of main UART/internal protocols/USB drivers of USB interface, firmware upgrade and temperature range in Table 2. 3. Updated timing of turning on module in Figure 12. 4. Updated timing of turning off module in Figure 13. 5. Updated timing of resetting module in Figure 16. 6. Updated supported baud rates of main UART in Chapter 3.11. 7. Added notes for ADC interface in Chapter 3.13. 8. Updated GNSS performance in Table 21. 9. Updated operating frequencies of module in Table 23. 10. Added current consumption in Chapter 6.4. 11. Updated RF output power in Chapter 6.5. 12. Added RF receiving sensitivity in Chapter 6.6. 1.22016-11-04 Lyndon LIU/ Michael ZHANG 1. Added SGMII and WLAN interfaces in Table 2. 2. Updated function diagram in Figure 1. 3. Updated pin assignment (Top View) in Figure 2. 4. Added description of SGMII and WLAN interfaces in Table 4. 5. Added SGMII interface in Chapter 3.17. 6. Added WLAN interface in Chapter 3.18. 7. Added USB_BOOT interface in Chapter 3.19. 8. Added reference design of RF layout in Chapter 5.1.4. 9. Added note about SIMO in Chapter 6.6. LTE Standard Module Series EC25 Hardware Design EC25_Hardware_Design 3 / 130 1.32017-01-24 Lyndon LIU/ Frank WANG 1. Updated function diagram in Figure 1. 2. Updated pin assignment (top view) in Figure 2. 3. Added BT interface in Chapter 3.18.2. 4. Updated GNSS performance in Table 24. 5. Updated reference circuit of wireless connectivity interfaces with FC20 module in Figure 29. 6. Updated current consumption of EC25-E module in Table 33. 7. Updated EC25-A conducted RF receiving sensitivity in Table 38. 8. Added EC25-J conducted RF receiving sensitivity in Table 40. 1.42018-03-05 AnniceZHANG/ Lyndon LIU/ Frank WANG 1. Updated functional diagram in Figure 1. 2. Updated LTE, UMTS and GSM features in Table 2. 3. Updated description of pin 40/136/137/138. 4. Updated PWRKEY pulled down time to 500ms in Chapter 3.7.1 and reference circuit in Figure 10. 5. Updated reference circuit of (U)SIM interface in Figure 17&18. 6. Updated reference circuit of USB interface in Figure 19. 7. Updated PCM mode in Chapter 3.12. 8. Added SD card interface in Chapter 3.13. 9. Updated USB_BOOT reference circuit in Chapter 3.20. 10. Updated module operating frequencies in Table 26. 11. Updated antenna requirements in Table 30. 12. Updated EC25 series module current consumption in Chapter 6.4. 13. Updated EC25 series module conducted RF receiving sensitivity in Chapter 6.6. 14. Added thermal consideration description in Chapter 6.8. 15. Added dimension tolerance information in Chapter 7. 16. Added storage temperature range in Table 2 and Chapter 6.3. 17. Updated RF output power in Table 41. 18. Updated GPRS multi-slot classes in Table 53. 19. Updated storage information in Chapter 8.1. 1.52018-04-20 Kinsey ZHANG 1. Added information of EC25-AF in Table 1. 2. Updated module operating frequencies in Table 27. 3. Added current consumption of EC25-AF module in Table 40. 4. Changed GNSS current consumption of EC25 series LTE Standard Module Series EC25 Hardware Design EC25_Hardware_Design 4 / 130 module into Table 41. 5. Added EC25-AF conducted RF receiving sensitivity in Table 50. 2.02019-04-30 Nathan LIU/ Frank WANG/ Ward WANG/ Ethan SHAN 1. Added new variants EC25-EU/-EC/-EUX/-MX and related information. 2. Updated functional diagram in Figure 1. 3. Updated star structure of the power supply in Figure 8. 4. Updated power-on scenario of module in Figure 12. 5. Updated reference circuit with translator chip in Figure 20. 6. Added timing sequence for entering into emergency download mode of USB_BOOT interface in Figure 32. 7. Updated general description in Table 1. 8. Updated module operating frequencies in Table 27. 9. Updated GNSS frequency in Table 29. 10. Updated antenna requirements in Table 30. 11. Updated EC25-V current consumption in Table 36. 12. Added EC25-EU current consumption in Tabl…

Text truncated - open the document above for the full version.

EC25 Mini PCIe Hardware Design LTE Standard Module Series Rev. EC25_Mini_PCIe_Hardware_Design_V2.4 Date: 2019-12-18 Status: Released www.quectel.com LTE Standard Module Series EC25 Mini PCIe Hardware Design EC25_Mini_PCIe_Hardware_Design 1 / 80 Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters: Quectel Wireless Solutions Co., Ltd. Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai, China 200233 Tel: +86 21 5108 6236 Email: [email protected] Or our local office. For more information, please visit: http://www.quectel.com/support/sales.htm For technical support, or to report documentation errors, please visit: http://www.quectel.com/support/technical.htm Or email to: [email protected] GENERAL NOTES QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. COPYRIGHT THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN. Copyright©QuectelWirelessSolutionsCo.,Ltd.2019.Allrightsreserved. LTE Standard Module Series EC25 Mini PCIe Hardware Design EC25_Mini_PCIe_Hardware_Design 2 / 80 About the Document Revision History RevisionDateAuthorDescription 1.02016-06-07 Mountain ZHOU/ Frank WANG Initial 1.12017-01-24 Lyndon LIU/ Frank WANG 1. Deleted description of EC25-AUT Mini PCIe in Table 1. 2. Added description of EC25-AU and EC25-J Mini PCIe in Table 1. 3. Updated key features of EC25 Mini PCIe in Table 2. 4. Added current consumption in Chapter 4.7. 5. Updated conducted RF receiving sensitivity of EC25-A Mini PCIe in Table 17. 6. Added conducted RF receiving sensitivity of EC25-J Mini PCIe in Table 18. 2.02019-04-30 Nathan LIU/ Frank WANG/ Ward WANG/ Ethan SHAN 1. Added new variants EC25-AF Mini PCIe, EC25-EU Mini PCIe, EC25-EC Mini PCIe, EC25-EUX Mini PCIe, EC25-MX Mini PCIe and their related information. 2. Updated LTE ， UMTS and GSM features, and added storage temperature range in Table 2. 3. Added pin definition and description of pin 3, 5, 44 in Figure 2 and Table 4. 4. Modified the reference circuit of USB interface in Figure 6. 5. Updated the mechanical dimension of EC25 Mini PCIe in Figure 18. 6. Added USIM_PRESENCE in (U)SIM interface and updated the reference circuit in Chapter 3.4. 7. Added COEX UART interface (under development) as UART interface in Chapter LTE Standard Module Series EC25 Mini PCIe Hardware Design EC25_Mini_PCIe_Hardware_Design 3 / 80 3.6. 8. Modified description of W_DISABLE# signal in Chapter 3.8.3. 9. Modified description of LED_WWAN# signal in Chapter 3.8.5. 10. Updated description of antenna connection in Chapter 5. 11. Added thermal consideration in Chapter 6.7. 12. Added operating frequencies in Table 16. 13. Added GNSS frequency in Table 17. 14. Updated antenna requirements in Table 18. 15. Updated EC25 Mini PCIe conducted RF output power in Table 21. 16. Updated conducted RF receiving sensitivity of EC25-A Mini PCIe in Table 22. 17. Added conducted RF receiving sensitivity of EC25-AU Mini PCIe in Table 23. 18. Updated conducted RF receiving sensitivity of EC25-J Mini PCIe in Table 24. 19. Updated conducted RF receiving sensitivity of EC25-E Mini PCIe in Table 25. 20. Updated conducted RF receiving sensitivity of EC25-V Mini PCIe in Table 26. 21. Added conducted RF receiving sensitivity of EC25-AF Mini PCIe in Table 27. 22. Added conducted RF receiving sensitivity of EC25-EU Mini PCIe in Table 28. 23. Added conducted RF receiving sensitivity of EC25-EC Mini PCIe in Table 29. 24. Added conducted RF receiving sensitivity of EC25-EUX Mini PCIe in Table 30. 25. Added current consumption of EC25-AU Mini PCIe in Table 33. 26. Added current consumption of EC25-J Mini PCIe in Table 34. 27. Added current consumption of EC25-AF Mini PCIe in Table 37. 28. Added current consumption of EC25-EC Mini PCIe in Table 38. 29. Added current consumption of EC25-EUX Mini PCIe in Table 39. 2.12019-07-05 Fanny CHEN/ Ethan SHAN 1. Added EC25-AFX/-AUX Mini PCIe and related information. 2. Updated supported protocols and USB serial LTE Standard Module Series EC25 Mini PCIe Hardware Design EC25_Mini_PCIe_Hardware_Design 4 / 80 drivers in Table 2. 3. Added EC25-AFX Mini PCIe conducted RF receiving sensitivity in Table 28. 4. Updated conducted RF receiving sensitivity of EC25-EU Mini PCIe in Table 29. 5. Updated EC25-AF Mini PCIe current consumption in Table 39. 6. Added EC25-AFX Mini PCIe current consumption in Table 42. 7. Added EC25-MX Mini PCIe conducted RF receiving sensitivity in Table 32. 8. Added EC25-MX Mini PCIe current consumption in Table 43. 2.22019-08-19 Ward WANG/ Owen WEI 1. Deleted the information of GNSS supported on EC25-EC Mini PCIe in Table 1. 2. Updated conducted RF receiving sensitivity of EC25-AU Mini PCIe in Table 24. 3. Updated conducted RF receiving sensitivity of EC25-EU Mini PCIe in Table 30. 4. Added conducted RF receiving sensitivity of EC25-AUX Mini PCIe in Table 34. 5. Updated current consumption of EC25-J Mini PCIe in Table 38. 6. Added current consumption of EC25-AUX Mini PCIe in Table 45. 7. Added current consumption of EC25-EU Mini PCIe in Table 46. 8. Deleted current consumption of EC21-EC Mini PCIe, and the data will be updated in the future versio…

Text truncated - open the document above for the full version.

Quectel Wireless Solutions Company Limited Declaration of the Modular Approval Applicant/Grantee Quectel Wireless Solutions Company Limited FCCID: XMR2021EC25ADL Model: EC25-ADL, EC25-ADL MINIPCIE The single module transmitter has been evaluated then tested meeting the requirements under Part 15C Section 212 as below: Modular approval requirementEUT ConditionCom ply (a) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio elements of the modular transmitter have their own shielding. YES (b) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. The modular has buffered data inputs, it is integrated in chip. Please see schematic.pdf YES (c)The modular transmitter must have its own powersupply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to the EC25-ADL, EC25-ADL MINIPCIE. Please see schematic.pdf YES Quectel Wireless Solutions Company Limited (d) The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. A permanently attached antenna or unique antenna connector is not a requirement for licensed modules. YES (e)The modular transmitter must be tested in a stand-alone configuration,i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i))mustnotbeinsideanotherdeviceduringtesting. The EC25-ADL, EC25-ADL MINIPCIEwas tested in a stand ‐ alone configuration via a PCMCIA extender. Please see spurious set ‐ up YES (f)The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. The label position of EC25-ADL, EC25- ADL MINIPCIEis clearly indicated. If the FCC ID of the module cannot be seen when it is installed, then the host label must include the text: Contains FCC ID: XMR2021EC25ADL . Please see the label.pdf YES (g) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any suchrequirements. A copy of these instructions must be included in the application for equipmentauthorizationrequirements,whicharebasedonthei ntendeduse/configurations. The EC25-ADL, EC25-ADL MINIPCIE is compliant with all applicable FCC rules. Detail instructions are given in the User Manual. YES (h)The modular transmitter must comply with any applicable RF exposure requirements in its final The EC25-ADL, EC25-ADL MINIPCIE is approved to comply with the applicable RF YES Quectel Wireless Solutions Company Limited configuration.exposure requirement, please see the MPE evaluation with 20cm as the distance restriction. Dated 2022/01/07 By: Jean Hu SignaturePrinted Title: ProjectManager

Quectel Wireless Solutions Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Subject; Request for Long Term Confidentiality FCC ID: XMR2021EC25ADL To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune up procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Printname:JeanHu Company:Quectel Wireless Solutions Co., Ltd

Quectel Wireless Solutions Co., Ltd POWER OF ATTORNEY DATE: January 6, 2022 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize TA Technology (Shanghai) Co., Ltd. /Jinnan Han on our behalf, to apply to FCC on our equipment for FCC ID: XMR2021EC25ADL. Any and all acts carried out by TA Technology (Shanghai) Co., Ltd. / Jinnan Han on our behalf shall have the same effect as acts of our own. Sincerely, Signature: Printname:JeanHu Company:Quectel Wireless Solutions Co., Ltd

EUT Appearance Report No.: R2110A0927 TA Technology (Shanghai) Co., Ltd. Page 1 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. EUT Appearance EC25-ADL EUT Appearance Report No.: R2110A0927 TA Technology (Shanghai) Co., Ltd. Page 2 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. EC25-ADL MINIPCIE a: EUT Picture 1: Constituents of EUT

Internal photo Report No.: R2110A0927 TA Technology (Shanghai) Co., Ltd. Page 1 of 1 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo

MPE TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd FCC ID XMR2021EC25ADL Product LTE Module Brand Quectel Model EC25-ADL, EC25-ADL MINIPCIE Report No. R2110A0927-M1 Issue Date January 10, 2022 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC 47 CFR Part 1 1.1310. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Prepared by: Fangying Wei Approved by: Guangchang Fan TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 2 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ............................................................................................................................... 3 1.1 Notes of the Test Report ......................................................................................................... 3 1.2. Test facility ............................................................................................................................ 3 1.3 Testing Location ...................................................................................................................... 3 1.4 Laboratory Environment .......................................................................................................... 4 2 Description of Equipment under Test .............................................................................................. 5 3 Maximum tune-up tolerance(dBm) and antenna Gain .................................................................... 6 4 Test Result ..................................................................................................................................... 7 ANNEX A: The EUT Appearance ......................................................................................................... 10 MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 3 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd.The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. 1.3 Testing Location Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China City: Shanghai Post code: 201201 Country: P. R. China Contact: Fan Guangchang Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 4 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1.4 Laboratory Environment Temperature Min. = 18C, Max. = 25 C Relative humidity Min. = 30%, Max. = 70% Ground system resistance < 0.5  Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 5 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2 Description of Equipment under Test Client Information Applicant Quectel Wireless Solutions Co., Ltd Applicant address Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai, China 200233 Manufacturer Quectel Wireless Solutions Co., Ltd Manufacturer address Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai, China 200233 General Technologies Model EC25-ADL, EC25-ADL MINIPCIE SN 861107037143642 Hardware Version R1.0 Software Version EC25ADLFAR07A01M4G Date of Testing: May 24, 2018~ May 28, 2018 Note: 1. The EUT is sent from the applicant to TA and the information of the EUT is declared by the applicant. 2. All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. 3. The series model number is: EC25-ADL, EC25-ADL MINIPCIE. The difference of these models are have different marketing requirement. MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S Page 6 of 10 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 3 Maximum tune-up tolerance(dBm) and antenna Gain The numeric gain (G) of the antenna with a gain specified in dB is determined by Numeric gain (G)=10^(antenna gain/10) Band Maximum Tune up Power (dBm) (mW) LTE Band 2 23.5 223.872 LTE Band 4 23.5 223.872 LTE Band 12 23.5 223.872 MPE Test Report Report No.: R2110A0927-M1 TA Technology (Shanghai) Co., Ltd. TA-MB-01-013S P…
