Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 1 | 27 | 2.31 GHz - 2.31 GHz | 161.10 mW | 8M96W7D | 0.021
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesPower output listed is conducted at the antenna terminal. Single Modular Approval. This device is certified for mobile and fixed applications. Co-location of this module with other transmitters would require the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. OEM integrators must ensure that the end user has no manual instructions to remove or install this module. For mobile operating configurations the antenna gain, including cable loss, must not exceed the gains documented in this filing for satisfying RF exposure compliance, as defined in 2.1091. Under no conditions may an antenna gain be used that would exceed the ERP and/or EIRP power limits as specified in Parts 22/24/27/90. The Grantee is responsible for providing the documentation required for modular use. This device contains LTE/5G NR functions that are not operational in US Territories. This filing is only applicable for US operations.
This device has 1.4/3/5/10/15MHz/20 MHz bandwidth modes for LTE Bands 2/4/25/66; 1.4/3/5/10/15MHz bandwidth modes for LTE Band 26; 1.4/3/5/10 MHz bandwidth modes for LTE Bands 5/12; 5/10/15/20 MHz bandwidth modes for LTE Bands 7/38/41/71; 5/10 MHz bandwidth modes for LTE Bands 13/14/17/30.
This device also has 5/10 MHz bandwidth modes for 5G NR band n13/n14/n30; 5/10/15 MHz bandwidth modes for 5G NR band n12; 5/10/15/20 MHz bandwidth modes for 5G NR Bands n2/n5/n26/n71; 5/10/15/20/25/30/40 MHz bandwidth modes for 5G NR Bands n66; 5/10/15/20/25/30/40 MHz bandwidth modes for 5G NR Bands n7/n25; 10/15/20/30/40 MHz bandwidth modes for 5G NR Bands n38; 10/15/20/30/40/50/60/70/80/90/100 MHz bandwidth modes for 5G NR band n41; 10/15/20/25/30/40/50/60/70/80/90/100 MHz bandwidth modes for 5G NR band n77/n78.
This device supports both SA and NSA modes for 5G NR technology.
This device supports LTE intra-band Uplink CA in the LTE Bands 2/5/7/38/41/66 and SA UL MIMO in the 5G NR bands n38/n41/n77/n78.
This device suports HPUE in the LTE bands 38/41 and 5G NR bands n38/n41/n77/n78.
Certification for 3GPP 5G NR bands n77/n78 operations is limited to the 3.7GHz segment under §27.5(m) and 3.45GHz segment under §27.5(o).
It also contains LTE Band 48 and 5G NR band n48 (CBRS) transmitter.
