XN6-SV210D08062.1 Soundbar System

Model: SV210D-0806 2.1 Soundbar User Manual Please read this guide before using the product. ENG - iii Accessibility Contact VIZIO for accessibility support at: Email: [email protected] Phone: 1-877-698-4746 Binding Arbitration Agreement and Class Action Waiver This purchase is subject to full VIZIO Terms and Conditions, including Binding Arbitration Agreement and Class Action Waiver, which may be viewed at vizio.com/en/terms/terms-of-service. By using this device, you accept those Terms and Conditions. You have the right to opt out of the Binding Arbitration Agreement and Class Action Waiver within 60 calendar days of your purchase. Please refer to the Limited Warranty section of this User Manual or view the full VIZIO Terms and Conditions for opt-out instructions. ENG - iv IMPORTANT SAFETY INSTRUCTIONS Your Unit is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent your Unit from being damaged, the following rules should be observed for its installation, use, and maintenance. Please read the following safety instructions before operating your Unit. Keep these instructions in a safe place for future reference. • Heed all warnings. • Follow all instructions. • Do not use this Unit near water. • Clean only with a dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other Unit (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at the ends where the plug is located, near convenience receptacles, or where they exit from the Unit. • Only use attachments/accessories specified by the manufacturer. • Use only with the stand, tripod, or bracket specified by the manufacturer, or sold with the Unit. When a cart is used, use caution when moving the cart/Unit combination to avoid injury from tip-over. • Unplug this Unit during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the Unit has been damaged in any way, such as when the power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the Unit, the Unit has been exposed to rain or moisture, does not operate normally, or has been dropped. • To reduce the risk of electric shock or component damage, switch off the power before connecting other components to your Unit. • Unplug the power cord before cleaning your Unit. A damp cloth is sufficient for cleaning. Do not use a liquid or a spray cleaner on your Unit. Do not use abrasive cleaners. • Always use the accessories recommended by the manufacturer to ensure compatibility. • When moving your Unit from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your Unit to avoid causing fire, electric shock, or component damage. • Slots and openings in the back and bottom of the Unit are provided for ventilation. To ensure reliable operation of your Unit and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your Unit in a bookcase or cabinet unless proper ventilation is provided. • Never push any object into the slots and openings on your Unit. Do not place any objects on the top of your Unit. Doing so could short circuit parts causing a fire or electric shock. Never spill liquids on your Unit. • WARNING: Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus (ringing or buzzing in the ears). With continued exposure to loud noises, ears may become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable discomfort. • When connected to a power outlet, power is always flowing into your Unit. To totally disconnect power, unplug the power cord. • Do not overload power strips and extension cords. Overloading can result in fire or electric shock. • The wall socket should be located near your Unit and be easily accessible. • Keep your Unit away from moisture. Do not expose your Unit to rain or moisture. If water penetrates into your Unit, unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock. • Do not use your Unit if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to ENG - v IMPORTANT SAFETY INSTRUCTIONS repair your Unit yourself. • Avoid using dropped or damaged appliances. If your Unit is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your Unit may cause fire or electric shock. • Do not install your Unit in an area with heavy dust or high humidity. Operating your Unit in environments with heavy dust or high humidity may cause fire or electric shock. • Ensure that the power cord and any other cables are unplugged before moving your Unit. • When unplugging your Unit, hold the power plug, not the cord. Pulling on the power cord may damage the wires inside the cord and cause fire or electric shock. When your Unit will not be used for an extended period of time, unplug the power cord. • To reduce risk of electric shock, do not touch the connector with wet hands. • Insert the remote control batteries in accordance with instructions. Incorrect polarity may cause the battery to leak which can damag…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 1 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 2 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 3 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 22 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 HDMI Cable PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 23 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 ______________THE END______________ AC Power Cord

PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 4 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 5 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 6 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 7 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 8 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 9 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 10 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 11 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 12 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 13 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 14 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 15 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 16 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 17 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 18 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 19 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 20 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01 PHOTOGRAPHS OF EUT EP420503 Sporton International Inc. Page No. : 21 of 23 Report Template No.: SE Ver 1.0_EP Issued Date : 01/Apr/2024 Report Version : 01

Radio Exposure Evaluation Report Report No. : FA420503 TEL : 886-3-327-3456 Page Number : 1 of 8 FAX : 886-3-327-0973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XN6-SV210D0806 Radio Exposure Evaluation Report FCC ID : XN6-SV210D0806 Equipment : 2.1 Soundbar System Brand Name : VIZIO Model Name : SV210D-0806 Applicant : Zylux Acoustic Corporation 7F, 70, Rui Guang Road, Neihu District, Taipei 114, Taiwan Manufacturer : Zylux Acoustic Corporation 7F, 70, Rui Guang Road, Neihu District, Taipei 114, Taiwan Standard : 47 CFR FCC Part 2 Subpart J, section 2.1091 The product was received on Mar. 08, 2024, and testing was started from Mar. 14, 2024 and completed on Mar. 14, 2024. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in 47 CFR FCC Part 2 Subpart J, section 2.1091 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Radio Exposure Evaluation Report Report No. : FA420503 TEL : 886-3-327-3456 Page Number : 2 of 8 FAX : 886-3-327-0973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XN6-SV210D0806 Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 5 1.3 Testing Location ..................................................................................................................................... 5 2 MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 6 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 6 2.2 RF Exposure Exempt Measurement ...................................................................................................... 6 2.3 Multiple RF Sources Exposure ............................................................................................................... 7 2.4 MPE Calculation Method ........................................................................................................................ 8 2.5 Calculated Result and Limit .................................................................................................................... 8 Photographs of EUT V01 Radio Exposure Evaluation Report Report No. : FA420503 TEL : 886-3-327-3456 Page Number : 3 of 8 FAX : 886-3-327-0973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XN6-SV210D0806 History of this test report Report No. Version Description Issued Date FA420503 01 Initial issue of report Apr. 01, 2024 Radio Exposure Evaluation Report Report No. : FA420503 TEL : 886-3-327-3456 Page Number : 4 of 8 FAX : 886-3-327-0973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XN6-SV210D0806 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: None Reviewed by: Ben Tseng Report Producer: Ann Hou Radio Exposure Evaluation Report Report No. : FA420503 TEL : 886-3-327-3456 Page Number : 5 of 8 FAX : 886-3-327-0973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XN6-SV210D0806 1 General Description 1.1 Information 1.1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type Bluetooth 2400-2483.5 2402-2480 BR / EDR: FHSS (GFSK / π/4-DQPSK / 8DPSK) LE: DSSS (GFSK) 1.1.2 Antenna Information Ant. Port Brand Model Name Antenna Type Connector Gain (dBi) 1 1 WIESON ARY196-4044-003-00 Omni directional MHF 1 2.36 Note 1: The EUT has one antenna. For BT function: For IEEE 802.15.1 Bluetooth mode (1TX/1RX) Ant. 1 (port 1) could transmit/receive. 1.1.3 Accessories Accessories AC Power Cord Signal Line 1.5 meter, Non-Shielded cable, without ferrite core HDMI Cable Signal Line 1.83 meter, Non-Shielded cable, without ferrite core Reminder: Regarding to more detail and other information, please refer to user manual. 1.2 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⬧ 47 CFR FCC Part 2 Subpart J, section 2.1091 ⬧ KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF. ⬧ 47 CFR Part 1.1307 ⬧ 47 CFR Part 1.1310 1.3 Testing Location Test Lab.：Sporton International Inc. Hsinhua Laboratory Hsinhua ADD: No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwa…

Text truncated - open the document above for the full version.

變更履歷表 Change the resume 料号(Part Number)：1029-0A00207 品名（Name）：BT ANTENNA 序號 NO 版次 Edition 變更原因 Change Reasons 发行時間 Issue Date 責任人 Person in Charge 备注 Note 1 A 初版发行 2024/02/20 WAH Customer DrawingCustomer Drawing RoHS Compliant WIESON 供應商名稱 (Supplier Name) 填寫部門 (Fill in the department) 填寫人員 (Fill in the personnel) 填寫日期 (Fill in the date) 公 司電話(The phone company) 公司傳真(fax) E-MALL 產品圖樣 料號 (P/N(Part Number)) 產品名稱 (The name of the Product) 產品重量(g) (Product weight (g)) 零件名稱 Part name Part mass (mg) 零件重量 (組成零件的 均一材料名稱)Homogeneous Material Name 均一材料厂商名稱/生產國 Homogeneous material manufacturer name/country of origin 材質重量 Material mass (mg) 構成之化學成份名稱 substance name CAS 號 (Chemical Abstract System Number) 化學成份 重量百分比 weigh% of substance 備註( Note) Cu 7440-50-8 91.80%Sn 7440-31-5 8%P 7723-14-0 0.20%PBT 30965-26-5 71%Flame retardants NA 15%Glass Fiber 65997-17-3 14%Au 7440-57-5 99%Co 7440-48-4 1%Polyimide film 25038-81-7 20copper foil 7440-50-8 70halogen-free adhesiv e NA 10 Epoxy acrylate oligm e 28064-14-4 46 Fused silica 7631-86-9 13.5Aromatic solvent 64742-94-5 5Methyl dipropylene g l 34590-94-8 5 Carbon black 1333-86-4 4BaSO4 13462-86-7 25Photoinitiator and t h 5495-84-1 1.5 BUTANE 106-97-8 33Naphtha (petroleum), 92045-53-9 15PENTANE 109-66-0 13PROPANE 74-98-6 10Hydrotreated 64742-49-0 15ACRYLATE POLYMER NA 5ACETONE 67-64-1 5Polyterpene resin 31393-98-3 4Cu 7440-50-8 99Sn 7440-31-5 1 NEOFLON FEP DAIKIN FLUORO CHEMICALS 115 FEP 25067-11-2 100Carbon black 1333-86-4 5FEP 25067-11-2 95 QMR-IP40-06-01 WAH 請將圖樣放於指定表格中 審核人員： 職位： 審核人員聯繫電話： E-Mail： 三 聲明 供應商必須保證上述数据真实有效，如果发生变更会将变更后数据及时通知朝陽公司。he supplier shall ensure that the above data is true and valid and, if any changes are made, notify the Zhaoyang company of th e changed data in time. 四、說明：1.該表一個表格對應一個料號，請不要多個料號填寫進一個表格。行數不夠的情況下，請自行添加足夠的行數。1.The table corresponds to a material number. Please don't fill in a form with the numbers.If the number of rows is not enough , please add enough lines yourself. 2.該表填寫的時機為：在我司承認之前，作為承認資料之一進行提供。2.The timing of the form is as follows: prior to our company's recognition, it is provided as one of the acknowledged data. 3.該表從2017年8月9日開始填寫電子檔即可，不用填好后打印簽字蓋章。但是必須得到貴司主管人員確認該表的正確性。3.The table from August 9, 2017 began to fill in the electronic file, you can not fill it, print, signature, seal. However, yo u must have your supervisor confirm the validity of the statement. ARY196-4044-003-00 BT Antenna PBT Yongyifa Plating Au MHF 6015 5 80 C5210 Zijin Shinkong Zhao Yang Elec. (Shenzhen) Co., Ltd Material Composition Declaration 物料成份清單 一 供應商基本信息(Supplier Basic Information) 無線工程 WIESON 二 料件成份信息表(ingredient information table) 2024/2/20 0.69 150 FPC 25 3M 9448HK 30 Tape 140 中國富邦電子 單面基材銅箔 C OLORANT CHROMATICS TRADIN G 鍍錫銅線 FEP Colormasterbatch 10 優利寶業 防焊油墨 240 CABLE 245 75 明星精密線材 *生產設備/Machine *模穴號 重量 Cav.NO. Weight 出線長 FPC板長 PCB板寬 单重/g 150 30 10 0.69 ±3 ±0.3 ±0.3 ±5% 1 151 30.00 10.00 0.69 2 150 30.00 10.00 0.69 3 150 30.00 10.00 0.69 測 4 151 30.00 10.00 0.69 定 5 152 30.00 10.00 0.69 值6 Data 7 89 10 備注 Remark ■ 合格/OK □ 不合格/NG OK Produce place OK 規格/Specification 判定欄/Judgement 公差/Tolerance / (QMR-P14-09.B) *__僅對屬於本廠模具或有指定時方填寫/ *__Only for Zylux'mold need 主管/Approval 檢驗者/Inspector xlin LYQING 外觀記錄/Appearance Record裝配記錄/Assembly Record ／ *模號/Mold NO. *第／次試模/T___ 品名/Part Name 檢查項目/Ins.Item 廠商 Vendor Mold Maker *模具廠商 WIESON 規格/Description MINI COAXIAL1.13 黑色L150mm 環保 / 朝陽電子(深圳)有限公司/Zhaoyang Elec.(Shen Zhen)Co.,Ltd. 原材(物)料檢驗表/Material Inspect Sheet BT Antenna / 1029-0A00207 料號/Part NO. 0.69 生產產地 溫/濕度/Temperature/Humidity / 東莞 Check Date 檢驗日期 2023/11/1 WIESON TECHNOLOGIES CO., LTD. SPECIFICATION LIST TYPE OF PRODUCT RF ANTENNA ITEM INDEX PAGE 1. THE SPECIFICATION LIST ................................................................................................... 1 2. BOM........................................................................................................... 2 3. TEST REPORT........................................................................................... 3-14 4. WIESON ISO APPROVAL............................................................................. 15 Approvals Rev Date Description Edited by Prepared : WAH 01 2024/02/20 ISSUE WAH Checked : FOUNTAIN Approved : ROX Issued No : 01 Sheet : 1 OF 15 No part of the information shown of this document may be used in any way without office stamp or written consent of WIESON TECHNOLOGIES CO., LTD. WIESON TECHNOLOGIES CO.,LTD BILL OF MATERIAL APPROVED BY: ROX CHECKD BY: FOUNTAIN DESIGNED BY: WAH Cust. TITLE BT Antenna Cust.P/N 1029-0A00207 WIESON P/N ARY196-4044-003-00 NO. DESCRIPTION SUPPLIER SUPPLIER PART NO . UL NO. AVL QUANTITY REMARK 1 Size: 30 x 10 mm PCS 2 1.13mm Normal Coaxial Ca ble , FEP Black Jacket MM 3 MHF I Plug For 1.13mm Cable , Gold Plated PCS 4 3M9448HK , Size: 30 x 10mm PCS 5 6 7 8 喬暘AIO Engineer : Betty Report date : 2023/12/06 REV.06 2 www.wieson.com Executive Summary •Revision History •Antenna Specification •Antenna Photo •Antenna MeasurementVector Network Analyzer –VSWR •The Antenna Anechoic Chamber Measurement –Antenna Measurement Photo –Antenna Measurement •3D Gain 、3D Radiation Efficiency、Peak Gain •2D/3D Antenna Radiation Pattern 3 www.wieson.com Revision History RevisionDateEngineerDescription 012023/06/14BenNew Release 022023/07/04BettyAntenna Placement Changed and Update 3D Model 032023/08/25BettyAntenna Changed andCable Length Adjustment 042023/10/02BettyAntenna MeasurementofEVT Machine 052023/11/13TingAdd Ant2 062023/12/06BettyAntenna Verification 4 www.wieson.com Antenna Specification ItemSpecification Operating Frequency(MHz) 2400-2480 Bandwidth80 MHz (Min.) Return Loss10 dB (Min.) PolarizationLinear Azimuth BandwidthOmni-directional Peak Gain2.36dBi (Max.) Impedance50Ω MaterialFPC ConnectorMHF1 Cable typeO.D. 1.13 Maximum Power1W V.S.W.R2 : 1 RadiationOmni directional Efficiency48%(Max.) Operating Temperature -10~60°C Storage temp-10~70°C Cable Type Normal 1.13 Cable:170mm 5 www.wieson.com Antenna Photo Ant Ant 6 www.wieson.com…

Text truncated - open the document above for the full version.

FCC Radio Test Report Report No. : FR420503AD TEL : 886-3-3273456 Page Number. : 1 of 21 FAX : 886-3-3270973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-C9 Ver4.3 Report Version : 01 FCC ID: XN6-SV210D0806 FCC Radio Test Report FCC ID : XN6-SV210D0806 Equipment : 2.1 Soundbar System Brand Name : VIZIO Model Name : SV210D-0806 Applicant : Zylux Acoustic Corporation 7F, 70, Rui Guang Road, Neihu District, Taipei 114, Taiwan Manufacturer : Zylux Acoustic Corporation 7F, 70, Rui Guang Road, Neihu District, Taipei 114, Taiwan Standard : 47 CFR FCC Part 15.247 The product was received on Mar. 08, 2024, and testing was started from Mar. 14, 2024 and completed on Mar. 19, 2024. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2013 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) FCC Radio Test Report Report No. : FR420503AD TEL : 886-3-3273456 Page Number. : 2 of 21 FAX : 886-3-3270973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-C9 Ver4.3 Report Version : 01 FCC ID: XN6-SV210D0806 Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information ............................................................................................................................................. 5 1.2 Testing Applied Standards .................................................................................................................... 6 1.3 Testing Location Information ................................................................................................................. 6 1.4 Measurement Uncertainty ..................................................................................................................... 6 2 TEST CONFIGURATION OF EUT......................................................................................................... 7 2.1 Test Channel Mode ............................................................................................................................... 7 2.2 The Worst Case Measurement Configuration ....................................................................................... 8 2.3 Accessories ........................................................................................................................................... 9 2.4 Support Equipment ................................................................................................................................ 9 2.5 Test Setup Diagram ............................................................................................................................. 10 3 TRANSMITTER TEST RESULT .......................................................................................................... 11 3.1 AC Power-line Conducted Emissions .................................................................................................. 11 3.2 20dB Bandwidth and Carrier Frequency Separation ........................................................................... 13 3.3 Maximum Conducted Output Power .................................................................................................... 14 3.4 Number of Hopping Frequencies and Hopping Bandedge ................................................................. 15 3.5 Time of Occupancy (Dwell Time) ........................................................................................................ 16 3.6 Emissions in Non-restricted Frequency Bands ................................................................................... 17 3.7 Emissions in Restricted Frequency Bands .......................................................................................... 18 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 21 APPENDIX A. TEST RESULTS OF AC POWER-LINE CONDUCTED EMISSIONS APPENDIX B. TEST RESULTS OF 20DB BANDWIDTH AND CARRIER FREQUENCY SEPARATION APPENDIX C. TEST RESULTS OF MAXIMUM CONDUCTED OUTPUT POWER APPENDIX D. TEST RESULTS OF NUMBER OF HOPPING FREQUENCIES AND HOPPING BANDEDGE APPENDIX E. TEST RESULTS OF TIME OF OCCUPANCY (DWELL TIME) APPENDIX F. TEST RESULTS OF EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS APPENDIX G. TEST RESULTS OF EMISSIONS IN RESTRICTED FREQUENCY BANDS APPENDIX H. TEST PHOTOS PHOTOGRAPHS OF EUT V01 FCC Radio Test Report Report No. : FR420503AD TEL : 886-3-3273456 Page Number. : 3 of 21 FAX : 886-3-3270973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-C9 Ver4.3 Report Version : 01 FCC ID: XN6-SV210D0806 History of this test report Report No. Version Description Issued Date FR420503AD 01 Initial issue of report Apr. 01, 2024 FCC Radio Test Report Report No. : FR420503AD TEL : 886-3-3273456 Page Number. : 4 of 21 FAX : 886-3-3270973 Issued Date : Apr. 01, 2024 Report Template No.: HE1-C9 Ver4.3 Report Version : 01 FCC ID: XN6-SV210D0806 Summary of Test Result Report Clause Ref. Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PASS - 3.1 15.207 AC Power-line Conducted Emissions …

Text truncated - open the document above for the full version.

Test Photos Appendix H Sporton International Inc. Page No. : H1 of H4 1. Photographs of Conducted Emissions Test Configuration Front view Side view Report No. : FR420503AD Test Photos Appendix H Sporton International Inc. Page No. : H2 of H4 Under table view Report No. : FR420503AD Test Photos Appendix H Sporton International Inc. Page No. : H3 of H4 2. Photographs of Radiated Emissions Test Configuration For radiated emissions 30MHz~1GHz Front view Rear view Report No. : FR420503AD Test Photos Appendix H Sporton International Inc. Page No. : H4 of H4 For radiated emissions above 1GHz Front view Rear view ─────THE END───── Report No. : FR420503AD
