XNAWAM01Pedometer

Pulse Quick Installation Guide 9454 BESOIN D’AIDE | BRAUCHEN SIE HILFE | NECESITAS AYUDA | TI SERVE AIUTO http://support.withings.com/pulse Thank you for choosing the Withings Pulse HELP?! BOX CONTENT Withings Pulse Power Cable Withings Belt Clip FR Câble d’alimentation FR Clip ceinture Sleep Wristband FR Bracelet sommeil EN Hard button EN Touch screen EN Charging only connector Let’s set up your Pulse 1 iPhone, iPad & iPod touch Android 2 Installation requires compatible smartphone / tablet. No installation from computer. 6 Press the top button for 3 seconds Hello! PC/Mac USB port Smartphone charger 2 No « Hello »? Charge your product. 3 Settings / Bluetooth / ON -> Withings Pulse Pulse 27 4 Install the Withings app fom the App Store App already installed? Update it, then: 5 5 Launch the app and follow the instructions Let’s set up your Withings Pulse! 10 Addi%onal informa%on Hello! Press the top button for 3 seconds 6 PC/Mac USB port Smartphone charger No « Hello »? Charge your product. 7 Settings / Bluetooth / ON -> Withings Pulse 3 8 Install the Withings app fom the Play Store 9 Launch the app and follow the instructions 3 s. i Plug your Pulse to computer to charge it not to synchronize your data. Picto synchro How to sync your Pulse? 10 Federal Communications Commission (FCC) Statement FCC ID: XNAWAM01 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION Any changes or modi#cations not expressly approved by the p arty responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation. Safety instruc%ons Please take care not to expose the Withings Pulse to moisture. Store the product in a clean, dry place at 0° to 50° C. Use the product exclusively at temperatures between 10°C and 50°C. Withings Pulse QIG | v 0.11 | May 3rd, 2013 © 2013 Withings. All right reserved. iPad, iPhone and iPod touch are trademarks of Apple inc. Android is a trademark of Google Inc.

ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 1 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 1. 2. ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 2 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 3. 4. ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 3 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 5. 6.

Withings 20, rue Rouget de Lisle, 92130 Issy les Moulineaux, FRANCE FCC ID Label FCC ID: XNAWAM01 ↕2mm →│ 10mm │←

ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 4 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 7. 8. ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 5 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 9. 10. ETC Report No. : 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 6 of 6 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 11.

FCC ID: XNAWAM01 RF Exposure Evaluation of E.U.T. : Withings Pulse FCC ID. : XNAWAM01 MODEL : WAM01 for APPLICANT : Withings ADDRESS : 20, rue Rouget de Lisle, 92130 Issy les Moulineaux, FRANCE Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU, LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 13-04-RBF-047-MPE FCC ID: XNAWAM01 Product Information: Type of EUT: Withings Pulse FCC ID: XNAWAM01 Manufacturer: Withings Model: WAM01 Description: Bluetooth 2.1+EDR Frequency band: 2402MHz~2480MHz Number of channels: 79 channels Channel spacing: 1MHz BLE Frequency band: 2405MHz~2480MHz Number of channels: 16 channels Channel spacing: 5MHz Transmitter antenna source: SMD Ceramic Antenna Maximum conducted output power (measured): (1) Bluetooth 2.1+EDR: 3.67 dBm or 2.328mW (2) BLE: 4.57 dBm or 2.864mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric 1001312 SMD Antenna 1.72 1.49 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: XNAWAM01 Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 6141.63*(100) 6 3-30 ..................... 1842/f4.89/f *(900/f 2 ) 6 30-300 .................. 61.40.1631.0 6 300-1500 ............... ...................... ......................f/300 6 1500-100,000 ......... ...................... ......................5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 6141.63*(100) 30 1.34-30 ............... 824/f2.19/f*(180/f2) 30 30-300 .................. 27.50.0730.2 30 300-1500 ............... ...................... ......................f/1500 30 1500-100,000 ......... ...................... ......................1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: XNAWAM01 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4R 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= PG / 4S) 1/2 For our device P = 2.864mW G = 1.49 R = 20 cm S = (2.864 * 1.49) / (4**20 2 ) = 0.0008 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5).

13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 24 of 51 Sheets Rev. No 2.0 4.6 Photos of Radiation Measuring Setup Test Mode :CHARGE MODE 13-04-RBF-047-02 FCC ID: XNAWAM01 Sheet 25 of 51 Sheets Rev. No 2.0 Test Mode :BLUETOOTH MODE
