REGULATORY INFORMATION Withings Body Pro Public ©2021 Withings -3 Regulatory information INTENDED USE The Withings Body Pro is a connected scale intended to measure body weight and to calculate the Body Mass Index (BMI). It is intended to be used in a home environment by individuals 18 years of age or older. IMPORTANT NOTICE This product should not be used to diagnose or treat any medical condition. WARRANTY Your Body Pro scale is guaranteed to be free of material and workmanship defects for a period of two (2) years from the date of receipt. This warranty does not apply to the cellular data transmission that requires a data plan subscribed by the entity that has provided you with this scale. Withings hereby declares that the device Withings Body Pro is in conformity with the essential requirements and other relevant requirements of Directive 2014/53/EU. The declaration of conformity can be found at: withings.com/compliance TECHNICAL INFORMATION Measurement range (min-max): 11 lbs - 440 lbs 5 kg - 200 kg 1 st lb - 31 st lb Resolution: Precision: 100 g (3.5 oz) Battery life: Approximately 12 months Physical size: Length: 326.5 mm (12.9’’) Width: 326.5 mm (12.9’’) Depth: 23 mm (0.90’’) 33 mm (1.3‘‘) Power source: 4x 1.5V AAA alkaline batteries (included) Units: lb, kg, st lb Working environment: Temperature: 5°C to 35°C (41°F and 95°F) Humidity: 30% RH to 80% RH Atmospheric pressure: 80kPa to 105kPa SYMBOLSDESCRIPTION Complies with FCC regulations Upper and lower limits of relative humidity Upper and lower limits of pressure Temperature range RCM marking Do not dispose of this product as unsorted municipal waste; take it to electronic recycling Follow instructions for use 2 Public ©2021 Withings Regulatory information CLASSIFICATION Power by: Internally powered Applied Part level: Type BF (Body Floating) IP Protection level: IP22 Mode of operation: Continuous Operation DISCONNECT DEVICE Remove the battery to fully power off the device. CAUTION Potential allergic reaction may occur due to skin irritation. Battery may be swallowed by children or pets and result in choking hazard, keep replacement batteries away from them. Keep away from children, pets, and pests after each use. When in need of assistance, setting up, using, or maintaining or to report unexpected operation or events please contact the manufacturer. WARNING: No modification of this equipment allowed. Activate the device at least once every three months to avoid battery leakage. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. SYMBOLSDESCRIPTION Direct current The CE logo certifies that the product complies with the essen- tial requirements of Directive 2014/53/EU. Scale button for unit change and menu access -5 Regulatory information IMPORTANT NOTE: RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US/CANADA. Contains FCC ID: 2AAGMGM02SA INDUSTRY CANADA STATEMENT: IC: 11411A-WBS09 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference (2) This device must accept any interference, including interference that may cause undesired operation of the device 2006/8/16 v1.0 L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage;(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Contains: IC: 12732A-GM02SA Radiation Exposure Statement: This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Déclaration d’exposition aux radiations: Cet équipement est conforme Canada limites d’exposition aux radi…

Text truncated - open the document above for the full version.

Date: 2021/3/29 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: XNAWBS09 Product name: Withings Body Pro To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model WBS09 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. -------------------------------------------------------------------------------------- Withings SA 2 rue Maurice Hartmann 92130 Issy-Les-Moulineaux France Xavier Debreuil / Product Director [email protected] +33608979794

Date: April 16, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: XNAWBS09 To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180 days from the day of the grant. ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. -------------------------------------------------------------------------------------- Withings SA 2 rue Maurice Hartmann 92130 Issy-Les-Moulineaux France Xavier Debreuil / Product Director [email protected] +33608979794

LETTER HEAD Date: March 29, 2021 Subject: Ad Hoc Mode Function Declaration FCC ID: XNAWBS09 To Whom it may concern, We, Withings SA declare that the device does not support any non-US channels and country code selection and Channel 12 and 13 in 2.4 GHz band in all the operational mode(s). Regards, -------------------------------------------------------------------------------------- Withings SA 2 rue Maurice Hartmann 92130 Issy-Les-Moulineaux France Xavier Debreuil / Product Director [email protected] +33608979794

Withings 2 rue Maurice Hartmann 92130 Issy-les-Moulineaux 92130 France To Whom It May Concern: This letter is to certify that the following Withings product: Brand name and model type of the specified radio equipment: Withings / WBS09 FCC ID: XNAWBS09 IC: 11411A-WBS09 Product name: Withings Body Pro Exhibits the following behaviors: - The scale connects to webservice server through Wi-Fi one time everyday. - Wi-Fi and Bluetooth communication never occurs while weight is being measured. - Wi-Fi or Bluetooth communication is started after user was weighted. The device contains a certified WWAN module as below FCC ID IC ID 2AAGMGM02SA 12732A-GM02SA - The scale connects to web service server through Wi-Fi one time every day. - WWAN communication never occurs while weight is being measured. - WWAN communication is started after user was weighted Applicant : Withings SA Address : 2 rue Maurice Hartmann 92130 Issy-les-Moulineaux 92130 France Signature : _________________________________ Name and Job Title. : Xavier Debreuil / Product Director E-mail : [email protected] Tel. : +33608979794

Project No.: EP132501 Page No. : 1 of 12 Photographs of EUT Project No.: EP132501 Page No. : 2 of 12 Project No.: EP132501 Page No. : 3 of 12 Project No.: EP132501 Page No. : 4 of 12

Withings Body Pro Model: WBS09 - Designed in France by Withings FCC ID: XNAWBS09 contains FCC ID: 2AAGMGM02SA IC: 11411A-WBS09 contains IC: 12732A-GM02SA DC6V500mAMade in China Withings 2 rue Maurice Hartmann 91130 Issy-Les-Moulineaux, France 37mm 29mm FCC ID: XNAWBS09 IC: 11411A-WBS09

Project No.: EP132501 Page No. : 5 of 12 Project No.: EP132501 Page No. : 6 of 12 Project No.: EP132501 Page No. : 7 of 12 Project No.: EP132501 Page No. : 8 of 12 Project No.: EP132501 Page No. : 9 of 12 Project No.: EP132501 Page No. : 10 of 12 Project No.: EP132501 Page No. : 11 of 12 Project No.: EP132501 Page No. : 12 of 12

Report No.: FA132501 Page : 1 of 7 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : XNAWBS09 Equipment : Withings Body Pro Model No. : WBS09 Brand Name : Withings Applicant : Withings SA Address : 2 rue Maurice Hartmann 92130 Issy-Les-Moulineaux France Standard : 47 CFR FCC Part 2.1091 Received Date : Feb. 04, 2021 Tested Date : Mar. 09 ~ Apr. 08, 2021 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA132501 Page : 2 of 7 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 4 1.1 Information .............................................................................................................................................. 4 2 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 5 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 5 2.2 MPE EVALUATION FORMULA ............................................................................................................. 5 2.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 2.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 2.5 MPE EVALUATION RESULTS .............................................................................................................. 6 2.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 6 3 TEST LABORATORY INFORMATION ................................................................................................. 7 Report No.: FA132501 Page : 3 of 7 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA132501 Rev. 01 Initial issue Apr. 26, 2021 Report No.: FA132501 Page : 4 of 7 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Test Sample Information MAC Number of Test Sample Antenna Port Conducted: 00:24:E4:C7:25:2D Report No.: FA132501 Page : 5 of 7 Report Version: Rev. 01 2 MPE EVALUATION OF MOBILE DEVICES 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 2.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 2.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 2.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA132501 Page : 6 of 7 Report Version: Rev. 01 2.5 MPE EVALUATION RESULTS BT & WiFI Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412~2462 (Wi-Fi) 14.77 15 2.8 20 0.012 1 0.012 Pass 2402-2480 (BT EDR) -3.48 -3 2.8 20 0.0002 1 0.0002 Pass 2402-2480 (BT LE) 3.57 4 2.8 20 0.001 1 0.001 Pass *Ratio = Power density / Limit. LTE The device contains a certified module, FCC ID: 2AAGMGM02SA Frequency Range (MHz) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 1850~1910 LTE Band 2 25 3.1 20 0.128 1 0.128 Pass 1710~1755 LTE Band 4 25 3.1 20 0.128 1 0.128 Pass 699 ~ 716 LTE Band 12 25 1.6 20 0.091 0.466 0.195 Pass *Ratio = Power density / Limit. 2.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Mode Max Ratio of Each Mode BT 0.001 LTE 0.195 Sum 0.196 Limit 1 Pass / Fail Pass Report No.: FA132501 Page : 7 of 7 Report Version: Rev. 01 3 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corporation (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No.30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan (R.O.C.) No.3-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 33381, Taiwan (R.O.C.) No.14-1, Lane 19, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 333, Taiwan (R.O.C.) If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318…
