Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 8 th June 2011 SUBJECT: FCC Application for XOQXRP-1 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, Tim Otley Chief Technology Officer Tru-Test Limited

EMC Technologies NZ Ltd PO Box 68307 Newton Auckland NEW ZEALAND 8th June 2011 SUBJECT: Authorisation to Act. To whom it may concern I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd, to act on our behalf with regard to the FCC Certification of the XOQXRP-1 Transceiver. Yours sincerely, Tim Otley Chief Technology Officer Tru-Test Limited

Federal Communications Commission Equipment Authorisation Branch 7435 Oakland Mills Road Columbia, MD 21046 United States of America 8th June 2011 To whom it may concern CONFIDENTIALITY REQUEST Reference rule sections 0.457 (d) (ii) and pursuant to rule section 0.459 (a) confidentiality is requested as follows. Specific Information: Schematic diagrams, Part lists, Block Diagram, Operational Description This information contains trade secret information which is not routinely made available to the public or to our competitors. Disclosure of this information could result in an unfair advantage to our competitors. It should be treated as confidential for the duration of the Grant of Equipment Authorisation. Yours sincerely, Tim Otley Chief Technology Officer Tru-Test Limited

____________________________________________________________________________________________________________________________________________________________________________ Page 20 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. 9. PHOTOTGRAPHS EID Reader ____________________________________________________________________________________________________________________________________________________________________________ Page 21 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. ____________________________________________________________________________________________________________________________________________________________________________ Page 22 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Cattle Antenna – Large Antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 23 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. ____________________________________________________________________________________________________________________________________________________________________________ Page 24 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Sheep Antenna – Small Antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 25 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full.

I t e m S p e c i f i c a t i o n LABEL XRP COMPLIANCE 8 1 8 6 4 5 MASTER > F:\Share\Forms\Item specification.doc 11/09 1 / 1 Issue E.C.N.No. Edited Checked Date Approved Date 1 M Keating S McDonald 21.04.11 T Otley 21.04.11 2 ECN 11/042C M Keating S Dooley 18.05.11 T Otley 18.05.11 Environment
Subject to acid and alkaline detergents, water, direct sunlight (UV) and ambient temperatures of –10 to +40 ºC. Dimensions
17 x 70mm with 1mm corner radius Material
Clear PVC. Printing
1 colour white. Adhesive
Permanent self-adhesive on the underside. Finish
Protective overgloss after printing. Supply
Dispenser pack. Data

Adobe Illustrator EPS with PDF colour proof. Die line supplied in file for reference but must be removed for printing. Notes

FCC & WEEE directives require that the artwork on this label be displayed visibly, legibly and indelibly. The label material, adhesive, printing method and printing ink should be suitable to meet these requirements. Any variations from this specification are subject to approval by Tru-Test. Not shown at 100%

____________________________________________________________________________________________________________________________________________________________________________ Page 26 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Internal Photos ____________________________________________________________________________________________________________________________________________________________________________ Page 27 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. ____________________________________________________________________________________________________________________________________________________________________________ Page 28 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. ____________________________________________________________________________________________________________________________________________________________________________ Page 29 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full.

____________________________________________________________________________________________________________________________________________________________________________ Page 1 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd PO Box 68-307 Newton, Auckland Phone 09 360 0862 Fax 09 360 0861 E-Mail Address: [email protected] Web Site: www.emctech.com.au TEST REPORT TRU-TEST XRP-1S Synchronisable EID Reader tested to 47 Code of Federal Regulations Part 15 - Radio Frequency Devices Subpart C – Intentional Radiators for Tru-Test Ltd This Test Report is issued with the authority of: ______________________________ Andrew Cutler - General Manager ____________________________________________________________________________________________________________________________________________________________________________ Page 2 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Table of Contents 1. STATEMENT OF COMPLIANCE 3 2. RESULTS SUMMARY 3 3. INTRODUCTION 4 4. CLIENT INFORMATION 4 5. DESCRIPTION OF TEST SAMPLE 5 6. RESULTS 6 7. TEST EQUIPMENT USED 19 8. ACCREDITATIONS 19 9. PHOTOGRAPH (S) 20 ____________________________________________________________________________________________________________________________________________________________________________ Page 3 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. 1. STATEMENT OF COMPLIANCE The TRU-TEST XRP-1S Synchronisable EID Reader complies with FCC Part 15 Subpart C as an Intentional Radiator when the methods as described in ANSI C63.4 - 2003 are applied. 2. RESULTS SUMMARY Clause Parameter Result 15.201 Equipment authorisation requirement Certification required. 15.203 Antenna requirement Complies. Antenna connects externally to the device and has a unique non standard fitting. A cattle and sheep antenna were tested with this device 15.204 External PA and antenna modifications Noted. 15.205 Restricted bands of operation Complies. Device transmits on 134.2 kHz. 15.207 Conducted limits Complies with a 4.9 dB margin at 3.944 MHz (Average). 15.209 Radiated emission limits - Fundamental Complies with a 3.5 dB margin (average) at 134.2 kHz when the Cattle Antenna is used. 15.209 Radiated emission limits - Spurious emissions <30 MHz Complies with a 24.3 dB margin at 402.600 kHz (average) when the Cattle Antenna is used. 15.209 Radiated emission limits – Spurious emissions >30 MHz Complies with a 7.4 dB margin at 154.598 MHz (Vertical) when the Sheep Antenna is used. ____________________________________________________________________________________________________________________________________________________________________________ Page 4 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. 3. INTRODUCTION This report describes the tests and measurements performed for the purpose of determining compliance with the specification. The client selected the test sample. This report relates only to the sample tested. This report contains no corrections or erasures. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. NB: This report replaces report number 110120.1a to show the FCC ID number and 110120.1b to show additional model information. 4. CLIENT INFORMATION Company Name Tru-Test Ltd Address PO Box 51078 Pakuranga City Auckland 2140 Country New Zealand Contact Mr Jason Crozier ____________________________________________________________________________________________________________________________________________________________________________ Page 5 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. 5. DESCRIPTION OF TEST SYSTEM Brand Name TRU-TEST Product Low Frequency Electronic ID (RFID) Reader System Model Number XRP-1S Synchronisable EID Reader Serial Number 300102 Antenna 1 Cattle EID Antenna Serial Number 100101 Antenna 2 Sheep EID Antenna Serial Number 100102 Manufacturer Tru-Test Ltd Country of Origin New Zealand Power Supply Cincon Electronics Co Ltd Model TRG36A12 21E11 Serial Number 36120-0010712 FCC ID XOQXRP-1 The XRP Synchronisable EID Reader is an AC mains and battery operated RFID Reader that operates on 134.2 kHz. The system comes with two antennas that are suitable for operating with sheep (small antenna) and with cattle (large antenna). When a tag is successfully read a green LED is illuminated on the EID reader along with an audible beep. The tag details are then output to a PC using a serial port link using Hyperterminal. Model variant: TRU-TEST XRP-1 Standard EID Reader This report can also be used to show compliance with the TRU-TEST XRP-1 Standard EID Reader which is a scaled down version of the XRP-1S which has been tested. The XRP-1 version has no external SYNC connectors and the internal wire loom to the PCB is not connected. In all other respects the samples are electrically identical. ____________________________________________________________________________________________________________________________________________________________________________ Page 6 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. 6. RESULTS Standard The sample was tested in accordance with 47 CFR Part 15 Subpart C. Methods and Procedures The measurement methods and procedures as described in ANSI C63.4 - 2003 were used. Section 15.201: Equipment authorisation requirement Certification as detailed in Subpart J of Part 2 is required for this device. Section 15.203: Antenna requirement This device operates with an external antenna using a unique custom connector that can be seen in the photographs at the rear of this report. Two antennas were supplied and tested with this devi…

Text truncated - open the document above for the full version.

____________________________________________________________________________________________________________________________________________________________________________ Page 30 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Radiated emissions test set up – Low Frequency test set up ____________________________________________________________________________________________________________________________________________________________________________ Page 31 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Radiated emissions – Metallic ground plane general set up ____________________________________________________________________________________________________________________________________________________________________________ Page 32 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Large antenna set up ____________________________________________________________________________________________________________________________________________________________________________ Page 33 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. ____________________________________________________________________________________________________________________________________________________________________________ Page 34 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full. Small antenna ____________________________________________________________________________________________________________________________________________________________________________ Page 35 of 35 Test Report No 110120.1c 12 March 2011 This report may not be reproduced except in full.
