XOQXRS-2LOW FREQUENCY RFID TAG READER WITH BLUETOOTH INTERFACE

Datamars SA

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Oct 17, 2011
Application Purpose: Original Equipment
Date of Application: Oct 17, 2011
Equipment Note: LOW FREQUENCY RFID TAG READER WITH BLUETOOTH INTERFACE
Frequency Range: 0.13420000 - 0.13420000
Company: Datamars SA
Country: Switzerland

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

813557 issue 2, 10/2011 © Tru-Test Limited, 2011 All rights reserved Bluetooth® is a registered trade mark owned by Bluetooth SIG, Inc. This quickstart guide provides basic instructions for setting up and using your XRS Stick Reader. For more detailed instructions, see the comprehensive XRS Stick Reader User Manual available on the CD supplied or at www.tru-test.com. Note: In this document, EID = Electronic Identification and VID = Visual Identification. Before you start Charging the internal battery Note: Before using the stick reader, ensure that the internal battery is fully charged. The battery will be fully charged in approximately 3 hours. When fully charged, the internal battery will allow the stick reader to be used for up to 19 hours 1 . The stick reader may be used while it is on charge. For other battery charging options, see the XRS Stick Reader User Manual. Using EziLink TM EziLink software can be installed from the CD provided with the XRS Stick Reader. EziLink allows information to be transferred to and from the stick reader and a PC. A number of stick reader settings can be adjusted on the stick reader itself, but there are some that must be configured using EziLink. To use EziLink: 1 Install the EziLink software on a PC (see information provided on the EziLink CD). 2 Connect the stick reader to the PC’s USB port using the XRS-Serial cable and the USB-Serial adaptor (see opposite). 3 Launch EziLink by double-clicking on the EziLink icon on the desktop: When connected, the XRS icon in the top right-hand corner of the EziLink screen illuminates and the connection details appear at the bottom of the screen. Note: For troubleshooting information, see the information provided on the EziLink CD. 1 When default settings are used. Parts of the stick reader LEDs The stick reader has two LEDs. One is green and the other is blue or red, depending on the current function of the stick reader. Here are the most common LED display sequences: Blue/Red LED flashes red. The stick reader is in the process of scanning for or reading an EID tag. Green LED flashes. The EID tag has been read successfully. Blue/Red LED is Blue when not flashing red. The stick reader is connected to a Bluetooth® device. Parts of the stick reader LCD Battery indicator Shows the battery charge level. Bluetooth set to auto Indicates that the Bluetooth setting is set to automatically connect to a Bluetooth device. To change this, see ‚Modifying the stick reader settings‛ below. Bluetooth connected The stick reader is connected to a Bluetooth device. Time The current time is displayed. The time and date are recorded against the animal ID during the scanning session. The stick reader’s date and time can be set in EziLink. See the XRS Stick Reader User Manual for information. Count The number of animals scanned during the current scanning session. Status Message display area. Turn on the stick reader Press the Read button. The stick reader beeps and the message ‚READY‛ appears on the LCD: Scanning an EID tag Press and release the Read button while passing the antenna near a tag. The ID tag number appears on the LCD, the green LED flashes once, the hand grip vibrates and the stick reader beeps to indicate that the tag has been read successfully. Tip: If animals are moving quickly through a race or into a pen, you can hold down the Read button continuously. Scanning will stop when the Read button is released 2 . Turning off the stick reader Press and hold the Scroll button. A countdown appears on the LCD (3, 2, 1) then the stick reader beeps and turns off. 2 When Read Button Mode is set to ‚Standard‛ (default). Using a cross-reference file A file containing EIDs and corresponding VIDs (visible tag numbers) can be uploaded into the stick reader prior to the scanning session, using EziLink. If a cross-reference file has been pre-loaded, the animal’s VID will appear in large numerals on the LCD when a tag is scanned. The EID is displayed in small numerals directly above. For information about uploading a cross-reference file, see the XRS Stick Reader User Manual. Modifying the stick reader settings To access stick reader settings: Press and hold both the Read button and the Scroll button. The first three items appear on the LCD with the EXIT option available at the top. To scroll through the menu options, press the Scroll button repeatedly. To select an option, highlight the option and press the Read button. To exit out of the stick reader menu settings, press the Scroll button until EXIT is highlighted, then press the Read button. For an explanation of the stick reader menu settings, see the following page. Other stick reader settings Other stick reader settings can be configured using the EziLink software. Settings include Automatic Power Down, Beeper and Vibration On/Off, Read Button Mode, Date/Time settings etc. See the XRS Stick Reader User Manual for information. Adding custom field information during scanning If you have enabled the Custom Field setting, you can add information about a particular animal during scanning. The stick reader has one preset custom field – Flag (options are 1, 2, 3, 4 or 5). The custom field may also be configured in EziLink (see the XRS Stick Reader User Manual for information). 1 Scan the EID tag as described above. 2 Press the Scroll button to view through the available options. 3 When the appropriate option is displayed, scan the next EID tag. The custom field information for the previously scanned EID tag will then be stored against it. Note: The custom field information will also be stored if the display times out and returns to the READY screen or the XRS is turned off. Receiving alerts during scanning If you have enabled the Alerts setting, you can receive alerts about a particular animal as its tag is read. A file containing EIDs and alert messages can be uploaded into the stick reader prior to the scanning session, using EziLink. 1 Scan the EID tag as described above. If an alert i…

Text truncated - open the document above for the full version.

Cover Letter(s)

EMC Technologies NZ Ltd PO Box 68307 Newton Auckland NEW ZEALAND 27th September 2011 SUBJECT: Authorisation to Act. To whom it may concern I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd, to act on our behalf with regard to the FCC Certification of the XOQXRS-2 Transceiver. Yours sincerely, Tim Otley Chief Technology Officer Tru-Test Limited

Cover Letter(s)

Federal Communications Commission Equipment Authorisation Branch 7435 Oakland Mills Road Columbia, MD 21046 United States of America 27th September 2011 To whom it may concern CONFIDENTIALITY REQUEST Reference rule sections 0.457 (d) (ii) and pursuant to rule section 0.459 (a) confidentiality is requested as follows. Specific Information: Schematic diagrams, Part lists, Block Diagram, Operational Description This information contains trade secret information which is not routinely made available to the public or to our competitors. Disclosure of this information could result in an unfair advantage to our competitors. It should be treated as confidential for the duration of the Grant of Equipment Authorisation. Yours sincerely, Tim Otley Chief Technology Officer Tru-Test Limited

Cover Letter(s)

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 27 th September 2011 SUBJECT: FCC Application for XOQXRS-2 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, Tim Otley Chief Technology Officer Tru-Test Limited

Cover Letter(s)

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 14 th October 2011 SUBJECT: FCC Application for XOQXRS-2 To Whom It May Concern: We, the undersigned, attest that: (i) the product to which this application pertains contains a Bluetooth ® radio module, FCC ID: POOWML-C40, that is electrically identical to the original filing, and (ii) no modifications have been made to the module. Sincerely, Tim Otley Chief Technology Officer Tru-Test Limited

External Photos

ID Label/Location Info

ITEM SPECIFICATION PART NUMBER LABEL TRU XRS WAND ID 814829 MASTER > F:\Share\Forms\Item specification.doc 11/09 1 / 1 Issue C.N.No. Edited Checked Date Approved Date 1 11/018C K McKinley Mark Tunnicliffe 26/07/11 Shane Dooley 26/07/11 2 11/088C M.Tunnicliffe M. Keating 14/10/11 T. Otley 14/10/11 Environment  Outdoor, all-weather farm use –15 to +50 ºC. Subject to acid and alkaline detergents and water spray. Compliance  This product must comply with requirements of the European ‘RoHS’ Directive 2002/95/EC. Dimensions  59.8mm wide x 19.8mm high with 1mm corner radius on three corners. Material  White polyester TT permanent – (supplier’s internal code WPSG5) Printing   1 colour black. Serial numbers and bar codes to be added in black. These shall be sequential and matching as specified on the purchase order. Barcode to be interleaved 2 of 5 format, 6 digit plus checkdigit. Issue 2 starting from 501001. Adhesive  Permanent self-adhesive on the underside. Finish (Laminate)  PP Matt Transp\RP37 – (supplier’s internal code CPPM5) after serial number applied. Supply  Dispenser pack. Label is applied by hand. Data    Adobe Illustrator EPS with PDF colour proof. Die line supplied in file for reference but must be removed for printing. Barcode and pink text/numbers supplied in file for reference but must be removed for printing. Notes  Any variations from this specification are subject to approval by Tru-Test. < Matching serial number < Sequential bar code Not shown at full size Z913 MODEL: XRS-2 VOLTAGE: 12-13V FCC ID: XOQXRS-2 IC: 8521A-XRS2 MADE IN NEW ZEALAND SERIAL NO. . Contains FCC ID: POOWML-C40 . Contains IC: 4250A-WMLC40 000000 Serial number barcode ____________________________________________________________________________________________________________________________________________________________________________ Page 18 of 26 Test Report No 110803.6 LF 23 August 2011 This report may not be reproduced except in full. 9. PHOTOGRAPHS External photos of the sample tested showing old label

Internal Photos

Test Report

____________________________________________________________________________________________________________________________________________________________________________ Page 1 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd PO Box 68-307 Newton, Auckland Phone 09 360 0862 Fax 09 360 0861 E-Mail Address: [email protected] Web Site: www.emctech.com.au TEST REPORT TRU-TEST XRS-2 Portable Low Frequency ID (EID) Reader tested to 47 Code of Federal Regulations Part 15 - Radio Frequency Devices Subpart C – Intentional Radiators for Tru-Test Ltd This Test Report is issued with the authority of: ______________________________ Andrew Cutler - General Manager ____________________________________________________________________________________________________________________________________________________________________________ Page 2 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. Table of Contents 1. STATEMENT OF COMPLIANCE 3 2. RESULTS SUMMARY 3 3. INTRODUCTION 4 4. CLIENT INFORMATION 4 5. DESCRIPTION OF TEST SYSTEM 5 6. RESULTS 6 7. TEST EQUIPMENT USED 15 8. ACCREDITATIONS 15 9. PHOTOGRAPHS 16 ____________________________________________________________________________________________________________________________________________________________________________ Page 3 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. 1. STATEMENT OF COMPLIANCE The TRU TEST XRS-2 Portable Low Frequency Electronic ID (EID) Reader complies with FCC Part 15 Subpart C as an Intentional Radiator when the methods as described in ANSI C63.4 - 2003 are applied. 2. RESULTS SUMMARY Clause Parameter Result 15.201 Equipment authorisation requirement Certification required. 15.203 Antenna requirement Complies. Antenna is integral to the device. 15.204 External PA and antenna modifications Noted. 15.205 Restricted bands of operation Complies. Device transmits on 134.2 kHz. 15.207 Conducted limits Complies with a 14.5 dB margin at 0.198 MHz (Average). 15.209 Radiated emission limits - Fundamental Complies with a 4.7 dB margin (average) at 134.2 kHz. 15.209 Radiated emission limits - Spurious emissions <30 MHz Complies. 15.209 Radiated emission limits – Spurious emissions >30 MHz Complies with a 9.6 dB margin at 250.000 MHz (Horizontal). ____________________________________________________________________________________________________________________________________________________________________________ Page 4 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. 3. INTRODUCTION This report describes the tests and measurements performed for the purpose of determining compliance with the specification. The client selected the test sample. This report relates only to the sample tested. This report contains no corrections or erasures. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. This report replace report number 110803.1a to address a number of issues raised by the TCB during the certification process 4. CLIENT INFORMATION Company Name Tru-Test Ltd Address PO Box 51078 Pakuranga City Auckland 2140 Country New Zealand Contact Mr Tim Otley ____________________________________________________________________________________________________________________________________________________________________________ Page 5 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. 5. DESCRIPTION OF TEST SYSTEM Brand Name Tru-Test Product Description Portable (Handheld) Low Frequency Electronic ID (EID) Reader Manufacturer Tru Test Ltd Country of Origin New Zealand Model Number XRS-2 Accessories Franmar International Inc Model FRA030E-S15-I AC Power Supply Serial number 500000 FCC ID XOQXRS-2 BT Module FCC ID POOWML-C40 This system is a portable (handheld) low frequency electronic ID (EID) device this is used to read animal identification tags. The system operates on 134.2 kHz and comprises of an EID reader that is battery powered. An AC adaptor can be used to re-charge the internal battery but it is not possible to operate the device from the external power source without the battery pack installed. Data from the reader is either down loaded to a PC using the supplied 2 metre long serial cable or by establishing a Bluetooth link. An FCC approved Bluetooth module has been used. The module that has been used is a Mistsumi WML-C40# Bluetooth Module which has the following FCC ID: POOWML-C40. ____________________________________________________________________________________________________________________________________________________________________________ Page 6 of 24 Test Report No 110803.1b 23 August 2011 This report may not be reproduced except in full. 6. RESULTS Standard The sample was tested in accordance with 47 CFR Part 15 Subpart C. Methods and Procedures The measurement methods and procedures as described in ANSI C63.4 - 2003 were used. Section 15.201: Equipment authorisation requirement Certification as detailed in Subpart J of Part 2 is required for this device. Section 15.203: Antenna requirement The antenna for this device is integral. Result: Complies. Section 15.204: External radio frequency power amplifiers and antenna modifications It is not possible to attach an external power amplifier to this transmitter. Result: Complies. Section 15.205: Restricted bands of operation The device tested transmits as follows: - On 134.2 kHz which falls between the restricted bands of 90 –110 kHz and 495 – 505 kHz. Result: Complies. ____________________________________________________________________________________________________________________________________________________________________________ Page 7 o…

Text truncated - open the document above for the full version.

Test Setup Photos
