P516-098 WIRELESS PORTABLE READER (WPR) INSTRUCTIONS FOR WPR400 Para el idioma español, navegue hacia www.schlage.com/support. Pour la portion française, veuillez consulter le site www.schlage.com/support. 2 WPR-400 Wireless Portable Reader User Guide CONTENTS Overview ............................................................................................................................... ......... 3 Getting Started ............................................................................................................... ............... 3 WPR400 Operation .............................................................................................................. ......... 4 WPR400 Range .................................................................................................................. ...... 4 Connecting a Reader to the WPR400 ....................................................................................... 4Connecting the RF Board to the Main Board ............................................................................ 5Permanently or Temporarily Mounting the WPR400 .................................................................. 5 Handheld Device (HHD) ......................................................................................................... ....... 6 Linking to a PIM400 (Reader mode only) ...................................................................................... 7Re-linking The WPR400 ......................................................................................................... ....... 7 Changing the RF Channel ....................................................................................................... ...... 8 Enabling Dynamic Channel Switching ........................................................................................... 8Resetting To Factory Defaults ................................................................................................. ....... 9 WPR400 LED Reference ............................................................................................................... 9 Link Mode LED Reference ....................................................................................................... .9 Normal Operation LED Reference............................................................................................. 9 Test Mode (No Credential Reader required) ................................................................................ 10 Linking to the PIM400-TD2 in Test Mode ................................................................................ 11Using the WPR400 in Test Mode ............................................................................................. 12WPR400 Test Mode LED Reference ....................................................................................... 12Improving RF Communications ............................................................................................... 12 Batteries ..................................................................................................................... ................. 13 Charging Batteries ................................................................................................................... 13 Installing or Replacing Batteries ............................................................................................. .13 Troubleshooting ............................................................................................................... ............ 14 FCC/IC Statements ............................................................................................................. ........ 15 www.schlage.com/support877.671.7011 3 WPR-400 Wireless Portable Reader User Guide OVERVIEW The WPR400 is a Wireless Access Point Module (WAPM) designed to interface with access control panels through a PIM400. The WPR400: • Communicates with the PIM400 via RF (radio frequency).• May be linked only to a PIM400.• Is powered with rechargeable batteries.• May be used with all credential readers in the AD-Series product line.• When attached to a credential reader, normally operates in on-line (Reader) mode. Information contained in the user credentials is passed to an access control panel (ACP), which controls WPR400 LEDs. The ACP maintains the audit trail. • May be operated in Tester mode, with or without a credential reader. In Tester mode, the WPR400 continually tests the quality of the RF link with a PIM400. LED Indicators Schlage Button On / Off Switch Power Jack GETTING STARTED Follow these steps when setting up a WPR400. 1. Install the PIM400 (PIM-TD2 or PIM-485). Refer to the User Guide that came with the PIM400, or visit www.schlage.com/support, for more information. 2. Make sure PIM400 power is properly connected.3. The WPR400 is shipped with batteries installed and ready for confi guration. If the batteries need charging or replacing, please see Batteries on page 13. Make sure batteries are fully charged before use. 4. Familiarize yourself with the information contained in this user guide. ! Save this user guide for future reference. 4 WPR-400 Wireless Portable Reader User Guide WPR400 OPERATION WPR400 RangeFor optimum performance, the WPR400 should be operated within the following range limits: • Maximum distance between the PIM400 and WPR400 is 200 feet (61 meters) horizontally on the same fl oor in a building with normal construction materials. • For a line-of-sight installation, maximum distance is 1000 feet (305 meters). Connecting a Reader to the WPR400 1. Connect the reader cable to the reader as shown below.2. Secure the reader to the front cover using the screws and washers provided. 1. Reader Reader cable 2. 5 WPR-400 Wireless Portable Reader User Guide Connecting the RF Board to the Main Board 1. While maintaining a proper electrical connection, push the RF board onto the support posts and secure with screws provided. Permanentl…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 1 of 5 Side View Front View EXTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 2 of 5 Back View View with Multi‐tech and Smart Card Reader Removed EXTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 3 of 5 View with Multi‐tech and Smart Card Reader Removed Close‐up Side View of Multi‐tech and Smart Card Reader EXTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 4 of 5 Close‐up Side View of Multi‐tech and Smart Card Reader Close‐up Side View of Multi‐tech and Smart Card Reader EXTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 5 of 5 Close‐up Back View of Multi‐tech and Smart Card Reader

Label and Location

INTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 1 of 5 Open for Inspection‐Backside of RF Section, View #1 Open for Inspection‐Backside of RF Section, View #2 INTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 2 of 5 Close Up of RF Section Close‐Up, Partial RF Section INTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 3 of 5 Internal Photo that contains certified 900MHz RF Module Internal Photo that contains certified 900MHz RF Module INTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 4 of 5 Internal Photo that contains certified 900MHz RF Module removed Backside of non‐RF board INTERNAL PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 5 of 5 Close‐up Backside of non‐RF board

LS Research, LLC Testing Cert. # 1255.01 W66 N220 Commerce Court ● Cedarburg, WI 53012 ● USA Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com ------------------------------------------------------------------------------------------------------------------------- ENGINEERING TEST REPORT # 310090-Multitech PROX LSR Job #: C-864 Compliance Testing of: Multitech with WPR Test Date(s): May 17 th , July 6 th , September 21 st and September 27 th 2010 Prepared For: Ingersoll-Rand Company 11819 N. Pennsylvania St. Carmel, IN 46074. In accordance with: Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.209, 15.109 and 15.107 Industry Canada (IC) RSS 210 Annex 2 and section 2.7 General Operating Requirements for Low-Power License-Exempt Transceivers This Test Report is issued under the Authority of: Thomas T. Smith, Manager EMC Test Services Signature: Date: 10/5/2010 Test Report Reviewed by: Thomas T. Smith, Manager EMC Test Services Signature: Date: 010/5/10 Authorized/Tested by: Khairul Aidi Zainal, Senior EMC Engineer Signature: Date: 09/27/2010 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: Ingersoll-Rand Company Model #: 23536758 LS Research, LLC EUT: Multitech with WPR IC: 8053B-ADMULTI Template: 15.209 - v1 10-22-09 Report #:310090-Multitech PROX FCC ID #: XPB-ADMULTI Page 2 of 34 TABLE OF CONTENTS (page 1 of 2) Description Page EXHIBIT 1: INTRODUCTION 1.1 Scope 4 1.2 Normative References 5 1.3 LS Research, LLC Test Facility 6 1.4 Location of Testing 6 1.5 Test Equipment Utilized 6 EXHIBIT 2: PERFORMANCE ASSESSMENT 2.1 Client Information 7 2.2 Equipment Under Test (EUT) Information 7 2.3 Associated Antenna Description 7 2.4 EUT’s Technical Specifications 8 2.5 Product Description 9 EXHIBIT 3: EUT OPERATING CONDITIONS & CONFIGURATIONS DURING TESTS 3.1 Climate Test Conditions 10 3.2 Applicability & Summary of EMC Emission Test Results 10 3.3 Modifications Incorporated in the EUT for Compliance Purposes 10 3.4 Deviations & Exclusions from Test Specifications 10 EXHIBIT 4: DECLARATION OF CONFORMITY 11 EXHIBIT 5: RADIATED EMISSIONS TESTING 5.1 Test Setup 12 5.2 Test Procedure 12 5.3 Test Equipment Utilized 13 5.4 Test Results 13 5.5 Calculation of Radiated Emissions Limits 14 5.6 Radiated Emissions Test Data Chart 15 5.7 Test Setup Photo(s) – Radiated Emissions Test 18 5.8 Screen Captures – Radiated Emissions Test 20 EXHIBIT 6: CONDUCTED EMISSIONS TEST, AC POWER LINE 6.1 Test Setup 24 6.2 Test Procedure 24 6.3 Test Equipment Utilized 24 6.4 Test Results 25 6.5 FCC Limits of Conducted Emissions at the AC Mains Ports 25 6.6 Conducted Emissions Test Data Chart 26 6.7 Test Setup Photo(s) – Conducted Emissions Test 27 6.8 Screen Captures – Conducted Emissions Test 28 Prepared For: Ingersoll-Rand Company Model #: 23536758 LS Research, LLC EUT: Multitech with WPR IC: 8053B-ADMULTI Template: 15.209 - v1 10-22-09 Report #:310090-Multitech PROX FCC ID #: XPB-ADMULTI Page 3 of 34 TABLE OF CONTENTS (Page 2 of 2) Description Page EXHIBIT 7: OCCUPIED BANDWIDTH 7.1 Limits 29 7.2 Method of Measurements 29 7.3 Test Data 29 7.4 Screen Captures – Occupied Bandwidth 30 EXHIBIT 8: BAND-EDGE MEASUREMENT 8.1 Test Criterion 31 8.2 Screen Captures 31 APPENDICES APPENDIX A: TEST EQUIPMENT LIST 32 APPENDIX B: TEST STANDARDS – RADIO 33 APPENDIX C: UNCERTAINTY STATEMENT 34 Prepared For: Ingersoll-Rand Company Model #: 23536758 LS Research, LLC EUT: Multitech with WPR IC: 8053B-ADMULTI Template: 15.209 - v1 10-22-09 Report #:310090-Multitech PROX FCC ID #: XPB-ADMULTI Page 4 of 34 EXHIBIT 1. INTRODUCTION 1.1 SCOPE References: FCC Part 15, Subpart C, Section 15.209 Title: Telecommunication – Code of Federal Regulations, CFR 47, Part 15 Purpose of Test: To gain FCC Certification Authorization for Low-Power License-Exempt Transmitters. References: RSS 210 Annex 2 Title: Low-power License-exempt Radiocommunication Devices (All Frequency Bands): Category I equipment. Purpose of Test: To gain IC Certification Authorization for Low-Power License-Exempt Transmitters. References: RSS GEN Title: General requirements and Information for the Certification of Radiocommunication Equipment. Purpose of Test: To gain IC Certification Authorization for Low-Power License-Exempt Transmitters. Test Procedures: Both conducted and radiated emissions measurements were conducted in accordance with American National Standards Institute ANSI C63.4 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. Environmental Classification: • Commercial, Industrial or Business • Residential Prepared For: Ingersoll-Rand Company Model #: 23536758 LS Research, LLC EUT: Multitech with WPR IC: 8053B-ADMULTI Template: 15.209 - v1 10-22-09 Report #:310090-Multitech PROX FCC ID #: XPB-ADMULTI Page 5 of 34 1.2 NORMATIVE REFERENCES Publication Year Title 47 CFR, Parts 0-15 (FCC) 2009 Code of Federal Regulations - Telecommunications RSS 210 Annex 2 2007 Low-power License-exempt Radiocommunication Devices (All Frequency Bands): Category I equipment. RSS GEN 2007 General requirements and information for the certification of Radiocommunication Equipment. ANSI C63.4 2009 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. CISPR 16-1-1 2006-03 A1: 2006-09 A2: 2007-07 Specification for radio disturbance and immunity measuring apparatus and methods. Part 1-1: Measuring Apparatus. CISPR 16-2-1 2003 A1: 2004-04 A2: 2007-07 Specification for radio disturbance and immunity measuring apparatus and methods. Part 201: Conducted disturbance measurement. Prepared For: Ingersoll-Rand Company Model #: 23536758 LS Research, LLC EUT: Multitech with WPR IC: 8053B-ADMULTI Template: 15.209 - v1 10-22-09 Report #:310090-Multitech PROX FCC ID #: XPB-ADMULTI Page 6 of 34 1.3 LS Resear…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 1 of 3 A. Emissions testing setup. Side (S) orientation Vertical (V) orientation Flat (F) orientation Rear view of EUT TEST SETUP PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 2 of 3 B. WPR charging mode emissions testing setup. Vertical (V) orientation Side (S) orientation Flat (F) orientation Rear view of EUT TEST SETUP PHOTOS Company Name Ingersoll Rand Model # 23536758 FCC ID # XPB‐ADMULTI IC # 8053B‐ADMULTI Page 3 of 3 C. Conducted Emissions Testing
