XPB-OEM200-90MTEmbedded Multitech Reader Module

Schlage Lock Company
Embedded Multitech Reader Module - FCC ID XPB-OEM200-90MT - Schlage Lock Company
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Jun 23, 2020
Application Purpose
Original Equipment
Date of Application
Jun 14, 2020
Equipment Note
Embedded Multitech Reader Module
Frequency Range
0.12500000 - 0.12500000
Company
Schlage Lock Company
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

OEM 200 Developer guide 2 • Schlage • OEM 200 Developer guide Contents iv FCC Statements v IC Statements vi Contact information vi Warnings and cautions 7 Introduction 7 General Description 8 Specifications 15 Operational Behavior 15 Powering Up the OEM 200 15 Communication 15 RF Field 16 Diagnostic LEDs 17 General Output 18 Reader Configuration 19 Design Considerations 19 Cable 20 Mounting Consideration 22 Environmental 22 Electrostatic Discharge (ESD) Precautionary Statement 22 EMI Design Consideration 23 Troubleshooting 25 Appendix A: Terms and Abbreviations 27 Appendix B: OSDP Communication 29 Appendix C: System Performance Requirements 29 Measurements Required per Integration Agreement iv • Schlage • OEM 200 Developer guide Contents | FCC Statements FCC Statements FCC Compliance Statements • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications not expressly approved by Schlage Lock Company could void the user's authority to operate the equipment. • This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help FCC Labeling Requirements • Exterior of product must include “Contains Transmitter Module FCC ID: XPB-OEM 200-XXXX”where XXXX is the model included in the installation OEM 200 ModelFCC Certification Number 80mm Multi-TechXPB-OEM 200-80MT 80mm Smart OnlyXPB-OEM 200-80SM 90mm Multi-TechXPB-OEM 200-90MT 90mm Smart OnlyXPB-OEM 200-90SM FCC Integration Requirements 1. The FCC/IC Statements contained in this guide must also be included in the final product’s documentation. 2. Applicable standards are 15.225, 15.209, and RSS-210. 3. For the purposes of compliance testing, it may be necessary to put the OEM 200 Module into a ‘constant read’ mode. In order to achieve this, present an Anti-Passback configuration card within the first minute of the module being powered. If performed correctly, the module will reboot and presenting a credential will result in constant reading and rereading of a credential as long as it remains in the operating volume of the antenna. This differs from normal operation in that when a credential is polled for a second time under normal operation the credential data is not output as it is seen as redundant. 4. Take care to NOT to place the OEM 200 antenna boards near other wireless antennas as they may cause interference with each other and result in the need for additional RF testing. Preferred distance is three (3) inches from other wireless transceivers. 5. The OEM 200 is only FCC authorized for the specific rule parts listed on the grant (the applicable standards from note #2). The host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Contents | IC Statements Schlage • OEM 200 Developer guide • v IC Statements IC Compliance Statements • This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 6. This device may not cause interference. 7. This device must accept any interference, including interference that may cause undesired operation of the device. • L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 8. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement IC Labelling Requirements • The host product shall be properly labelled to identify the modules within the host product. The ISED certification label of a module shall be clearly visible at all times when installed in the host product; otherwise, the host product must be labelled to display the ISED certification number for the module, preceded by the word "contains" or similar wording expressing the same meaning, as follows: Contains IC: XXXXXX-YYYYYYYYYYY Where XXXXX-YYYYYYYYYY is one of the ISED certification numbers form the following table OEM 200 ModelISED Certification Number 80mm Multi-Tech8053B-OEM 20080MT 80mm Smart Only8053B-OEM 20080SM 90mm Multi-Tech8053B-OEM 20090MT 90mm Smart Only8053B-OEM 20090SM vi • Schlage • OEM 200 Developer guide Contents | Contact information Contact information Should a system design engineer or developer need assistance, they should contact technical support at: Phone: 1-877-671-7011 www.allegion.com/us MIFARE® and DESFire™ are registered trademarks of NXP B.V. Warnings and cautions WARNING Warnings indicate potentially hazardou…
