Page 19 of 109 QOMO HiteVision, LLC. QClick FCC ID: XQGQRF600-RE QOMO HiteVision,LLC. User’s Manual Part 1. QRF600 ARS Overview The QRF600 Audience Response System (ARS) is an easy-to-use RF response system that obtains immediate feedback from each participant (up to 400 persons) synchronously. Working completely out of Power Point, the QClick software is both easy to learn and use. The system is also organized for instructors to use any no-Power Point formats of document exam files or hardcopy exam paper to start an exam, or with free style of system setting, an instructor can start a quiz even without considering a quiz file or a quiz paper ahead before starting a quiz. The instance captured quiz questions and answers can be easily saved to the system after a quiz is finished. The system is composed of hardware (instructor remote keypad, participants’ remote keypads, RF main receiver, and extended USB cable, etc) and PC software. The instructor keypad is equipped with a remote mouse and PC keypad functions making it easy to control any formats of showing slice and the system functions in a far distance. The QRF600 LCD display and no volatile memory in student and instructor keypads make it possible that remote control can be used in any classes with the features of virtually log into a class which is located by automatic RF channel searching. The beauty of RF communication makes it easy for a student to raise a question by directly communicating to an instructor with one single key press, but not interrupting other people. At the same time, an instructor can view each student’s exam performances and the exam statistical data on the remote LCD display without sharing the private student exam info with others. The no volatile memory in the student remote keypad can hold as much as a whole semester’s homework and exam answers for later review. Students can use the keypads to receive the homework assignment, do the homework from home, and then turn in the assignment in the class with just a simple key press. Each student keypad keeps one unique Student ID which can be easily set and reset by a manager or by a user. If a student keypad is lost or damaged, it can be replaced with any new keypad by just resetting its Student ID. The QRF600 ARS encourages participation and elicits individual response through the following no free style activities: Normal Quiz, Paper Quiz, Homework, Rush Quiz, Elimination, Survey, Vote, and Roll Call and free style activities : Normal Quiz, Rush Quiz and Elimination. The QRF600 displays the instant results in the form of a histogram and score board after each question is finished in a quiz. Page 20 of 109 QOMO HiteVision, LLC. QClick FCC ID: XQGQRF600-RE QOMO HiteVision,LLC. Part 2. Hardware & System Installation Illustration 1. Student keypad 1.1 Specifications Dimensions (l w h): 130mm x 52mm x18.5mm Keys: 21 Power required: 2 AAA Batteries RF transmission distance: ~200 feet Battery life: 6 months to 1 year dependent on the usage Function: Transmit response signals Frequency band : 2404.1-2480.0 MHz ISM/SRD band systems The working frequency of QRF 600 system 1. Adopting the 2404.1-2480.0 MHz ISM/SRD band systems 2. The specific value of 50 carrier wave frequency points are as follows: 0 2404.1 2424.0 2444.0 2464.0 1 2405.6 2425.6 2445.6 2465.6 2 2407.2 2427.2 2447.2 2467.2 3 2408.8 2428.8 2448.8 2468.8 4 2410.4 2430.4 2450.4 2470.4 5 2412.0 2432.0 2452.0 2472.0 6 2413.6 2433.6 2453.6 2472.6 7 2415.2 2435.2 2455.2 2474.5 8 2416.7 2436.8 2456.8 2476.2 9 2418.4 2438.4 2458.4 2478.8 10 2412.0 2440.0 2460.0 2480.0 11 2421.6 2441.6 2461.6 12 2423.2 2443.2 2463.2 Page 21 of 109 QOMO HiteVision, LLC. QClick FCC ID: XQGQRF600-RE QOMO HiteVision,LLC. 1. 2. Illustration 1.2.1 Student Keypad Layout: 1- LCD 2- Power Key: Press and hold for at least 0.5 seconds to turn on or off the keypad. 3- Up Key: To scroll the screen display up when pressed. 4- Return Key: To return menu to one level up. Special function is used to enter a function selection menu when a user exits from the answer screen in homework or paper quiz mode (see 1.2.2 section 6). 5- Alpha-Numeric Key: To toggle between alpha and numeric key functions. 6- Enter key: To confirm a selection or to enter the main menu when pressed. 7- Del key: To back space or to delete an exam under Paper Quiz or Home Work. 8- T/Y Key: To respond to Yes/No or True/False prompt for T (TRUE) or Y (YES). 9- Down Key: To scroll the screen display down when pressed. A special function is used for auto registration. 10- F/N Key: To respond to Yes/No or True/False prompt for F (FALSE) or N (NO). 11- Choice Keys: Labeled “A1” to “J0” for alpha numeric inputs. 12- Operation +/- Key: For”＋” “－” sign enter. 13- Operation /. Key: For the division “/” and the decimal point “.” sign enter. Page 22 of 109 QOMO HiteVision, LLC. QClick FCC ID: XQGQRF600-RE QOMO HiteVision,LLC. 1.2.2 Student Keypad Instruction: 1- NoHost Screen: The following information is displayed: 1) RF Signal strength is displayed on the upper left corner of LCD. 2) Battery remaining sign is displayed on the upper right corner of LCD. 3) Student ID. 4) The class name registered last time. The following functions can be performed under this display: 1) To enter main menu by pressing the “Enter Key”. 2) To auto register by pressing “Down Key”. 3) To search class by pressing “F/N Key”. 2- Menu Screens: Use “Up Key” or “Down Key” to scroll selection of the menu item. The item selected will be highlighted. Press “Enter Key” to select the menu item. The shortcut to select a menu item is by directly pressing “Choice Keys” number corresponding to the submenu items number shown at front of each item. Page 23 of 109 QOMO HiteVision, LLC. QClick FCC ID: XQGQRF600-RE QOMO HiteVision,LLC. 3- Input Screens: The shown cursor prompts a user to input characters or numeric numbers. The user can press “Choice Keys” or press its combination of “Alpha-Numeric Key” to enter desired characters. …
