XQWPPEPR692Wireless Microphone

ENGLISH - PAGES . . . . . . . . . . . 6-7 ESPAÑOL - PAGINAS . . . . . . . . 8-9 FRANÇAIS - PAGES . . . . . . . . . . 10-11 ITALIANO - PAGINE . . . . . . . . . 12-13 DEUTSCH - SEITEN . . . . . . . . . . 14-15 PORTUGUÊS - PAGINA. . . . . . . 16-17 . . . . . . . . . . . . . 18-19 IMPORTANT SAFET Y INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suf ficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point where they exit from the apparatus. 11) Only use attachments/accessories specified by the manufacturer. 12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip- over. 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15) To completely disconnect this apparatus from the AC mains, disconnect the power supply cord plug from the AC receptacle. 16) The mains plug of the power supply cord shall remain readily operable. 17) WARNING – To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. 18) Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the equipment. 19) Maintain at least 6 inches (15.25 cm) of unobstructed air space behind the unit to allow for proper ventilation and cooling of the unit. 20) CAUTION – For rack mounted power amplifiers, keep all wiring and materials away from the sides of the unit and allow the unit to cool down for 2 minutes before pulling from a rack enclosure. 21) Amplifiers and loudspeaker systems are capable of producing very high sound pressure levels which may cause temporary or permanent hearing damage. Use care when setting and adjusting volume levels during use. 22) FCC Part 15 Compliance Statement (for digital products, as applicable) - Part 15.21: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. 23) WARNING – To maintain product safety, products with internal or external (battery pack) batteries: •Batteries and/or the product in which they are installed, shall not be exposed to excessive heat such as sunshine, fire or the like. •There may be a danger of explosion if the battery is incorrectly connected/replaced. Replace only with the same or equivalent type battery specified in the instructions or on the product. 24) CAUTION – Unplug unit and allow it to cool before touching/ replacing vacuum tubes. CONSIGNES DE SÉCURITÉ IMPORTANTES Ce symbole avertit l'utilisateur de la présence d’une tension dangereuse non isolée dans le boîtier du produit, qui peut être suffisamment importante pour constituer un risque d'électrocution. Le symbole du point d’exclamation dans un triangle équilatéral avertit l’utilisateur de la présence d’instructions importantes relatives au fonctionnement et à l'entretien dans la documentation qui accompagne le produit. 1) Lisez ces instructions. 2) Conservez ces instructions. 3) Respectez toutes les mises en garde. 4) Suivez toutes les instructions. 5) N’utilisez pas cet appareil à proximité d’un point d’eau. 6) Nettoyez-le uniquement avec un chiffon sec. 7) Ne bloquez pas les ouvertures de ventilation. Installez l'appareil en suivant les instructions du fabricant. 8) Ne l’installez pas à proximité d’une source de chaleur, comme un radiateur, un four ou tout autre appareil (incluant les amplificateurs) produisant de la chaleur. 9) Ne modifiez pas la fiche polarisée (Canada) ou la mise à la terre. Les fiches polarisées possèdent deux lames, dont l’une est plus large que l’autre. Les fiches avec mise à la terre possèdent deux broches plus une broche de terre. La lame plus large et la terre sont des éléments de sécurité. Si la fiche ne correspond pas à votre prise secteur, contactez un électricien pour la faire remplacer. 10) Évitez de marcher sur le cordon secteur ou de le pincer, en particulier au niveau des fiches, des prises secteur et de l'embase de l’appareil. 11) Utilisez uniquement les pièces/accessoi…

Text truncated - open the document above for the full version.

FCC Project no.: 132075 FCC ID: - Page 1 of 1 Nemko AS, N-2007 Kjeller EXTERNAL PHOTOS OF EUT Passport Executive – Front view Passport Executive – rear view Passport Executive – Right side view Passport Executive – Left side view

FCC Project no.: 132075 FCC ID: - Page 1 of 1 Nemko AS, N-2007 Kjeller INTERNAL PHOTOS OF EUT Passport Executive – View of PCB Display side Passport Executive – View of PCB RF side Passport Executive – View of PCB RF side (shields removed)

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Comlab Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 132075 - 5 Item tested : Passport Executive TX Type of equipment : 672–696 MHz Wireless Microphone Client : Fender Musical Instrument Corporation FCC Part 74H.861 Licensed wireless microphone 26 November 2009 Authorized by : ............................................. Frode Sveinsen Technical Verificator TEST REPORT FCC parts 74H.861 Project no.: 132075-5 Nemko AS, N-2027 Kjeller Page 2 (29) CONTENTS 1 GENERAL INFORMATION ...................................................................................................... 3 1.1 Testhouse Info .......................................................................................................................... 3 1.2 Client Information ...................................................................................................................... 3 1.3 Manufacturer ( if other than client) ............................................................................................ 3 2 Test Information ...................................................................................................................... 4 2.1 Test Item ................................................................................................................................... 4 2.2 Test Environment ...................................................................................................................... 5 2.2.1 Normal test condition ................................................................................................................ 5 2.3 Test Period................................................................................................................................ 5 3 TEST REPORT SUMMARY ..................................................................................................... 6 3.1 General ..................................................................................................................................... 6 3.2 Test Summary ........................................................................................................................... 7 3.3 Description of modification for Modification Filing ..................................................................... 7 3.4 Comments ................................................................................................................................ 7 3.5 Family List Rationale ................................................................................................................ 7 4 TEST RESULTS ....................................................................................................................... 8 4.1 RF Output Power, Conducted ................................................................................................... 8 4.2 Modulation Characteristics........................................................................................................ 9 4.2.1 Audio Frequency Response...................................................................................................... 9 4.2.2 Modulation Limiting ................................................................................................................. 11 4.3 Occupied Bandwidth ............................................................................................................... 12 4.4 Spurious Emissions at the Antenna Terminal, Swept Frequency ........................................... 16 4.5 Spurious Emissions at the Antenna Terminal, Emission Masks ............................................. 18 4.6 Radiated Spurious Radiations ................................................................................................ 22 4.7 Frequency Stability ................................................................................................................. 27 5 LIST OF TEST EQUIPMENT .................................................................................................. 28 6 TEST SETUP .......................................................................................................................... 29 6.1 Test Site Radiated Emissions ................................................................................................. 29 TEST REPORT FCC parts 74H.861 Project no.: 132075-5 Nemko AS, N-2027 Kjeller Page 3 (29) 1 GENERAL INFORMATION 1.1 Testhouse Info Name : Nemko AS Address : Nemko Kjeller Instituttveien 6, Box 96 N-2027 Kjeller, NORWAY Telephone : +47 64 84 57 00 Fax : +47 64 84 57 05 E-mail: [email protected] FCC test firm registration # : 994405 IC OATS registration # : 2140D-1 Total Number of Pages: 29 1.2 Client Information Name : Fender Musical Instrument Corporation Address : 8860 E, Chaparral Road Suite 100, Scottsdale, AZ 85250-2610 USA Telephone : - Fax : - Contact: Name : Larry Clauss Telephone : +4803675203 E-mail : [email protected] 1.3 Manufacturer ( if other than client) -“- TEST REPORT FCC parts 74H.861 Project no.: 132075-5 Nemko AS, N-2027 Kjeller Page 4 (29) 2 Test Information 2.1 Test Item Name : Passport Executive TX Model/version : PR692 Serial number : / Hardware identity and/or version: MPR Software identity and/or version : / Operating frequency: Ch1 – Ch16 Switching range: 672.000 – 696.00MHz Allowed band : 614.000 – 806.000MHz Emission designator : 150KF3E Tuneable Bands : None Number of Channels : 16 Operating Modes : Transmitter Channel bandwidth: 200kHz TX data rate: / Type of Modulation : FM (analogue) User Frequency Adjustment : None Rated Output Power : 20mW Threshold audio input level: 150mV Type of Power Supply : Battery 3.0 V DC Antenna Connector : Integral Antenna Diversity Supported : None Theory of Operation The passport Executive is an analogue wireless tr…

Text truncated - open the document above for the full version.
