XTJ920691ABroadcast Reception Amplifier

User manual 920691A Abt. Erz.-Bezeichnung Erz.-NummerBlatt PDH 1 This document is our property. Any duplication, utilization, communication or disclosure to third parties without our prior consent is prohibited. Infringements require compensation. All rights reserved in the event of granting a patent, registered design or design patent. Type of Product: Amplifier for Antenna Signals for Broadcast Reception Manufacturer: Hirschmann Car Communication GmbH The product is mounted in a vehicle. It’s purpose is to improve the reception of broadcast signals with a wire antennas that are integrated in the backscreen of the vehicle. The product is neither visible nor operable by the user of the car. It is used and controlled by the telematic system of the vehicle. It is also not user servicable. Therefore safety consideration is adjusted to trained installation personnel. DC supply is done by onboard supply through Headunit 8V power system. Signal input comes from the reception antenna, signal output is being applied to the signal input of a receiver. Frequency ranges are: Supply 8V DC vehicle on-board supply AM: 150 ... 1602kHz through headunit. FM: 87.5 ... 108MHz Gain: 6...10dB DAB: 174 ... 240MHz Size: 11x6x2cm, weight: 43gr Working temperature: -40...85°C Declaration of Conformity Hereby, Hirschmann Car Communication GmbH declares that the radio equipment herein mentioned is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.te.com/hirschmann-mobility/red FCC NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 sRL 19.03.2020 Dear Sir or Madam, We, Hirschmann Car Communication GmbH, Stuttgafter Str. 45 - 51, 72654 Neckartenzlingen, hereby au- thorize Mr. Thomas Ring, Sonja Sachs, Benjamin Puls, Stefan Breu and Manuel SedlmairTÜV SÜD Prcduct Service GmbH, Aussere Fruehlingstrasse 45, 94315 Staubing, Germany, to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on Dec 31, 241 contact Name: Joachim Nebel Homologations Hif3chmann Car COmmUnication GmbH I Stuttsarter Stra8e 45 - 51 I 72654 N*kartending€n I Tel.ton +49 7L27 l+O I Tel€fax +19 7127 L+'iO6O www.hiehmann-6r.@m Title: Gesdläftsführer: Jörg Mann Harold G. Barksdale Dr. Dirk Wendt Thomas Falz USt-ldNr. DE 814 272 629 Amtsgericht Stuttgart HRB 225926 EUR: Clübank Frankturt SWIFT: CITIDEFF USD: Oübank London SWIFT: CITIGB2L Sincerely, signed by FCC / lC listed IBAN; DE92 5021 0900 0217 8960 02 IBAN: GB06 Cm 1850 0818 9898 93

TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 sRL Gonft dentiality Request 19.04.2020 USt-ldNr. DE 814 212 629 EUR: Citibank Frankturt USD: Ciübank London Amtsgericht Stuttgart SWIFT: CITIDEFF SWIFT: CmGB2L HRB 225926 IBAN: DE92 5021 0900 0217 8960 02 IBAN: GBO6 Cm 1850 0818 9898 93 FCC lDs: XTJ920642A and XTJ920691A Pursuant to Sections 0.457(dXlXii) and 0.459 of the Commission's Rules, Hfischmann Car Communbation GmbH hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematrbs Bill of Materials/Pafts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmfulto the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(dXlXii), disclosure of this Application and all accom- panying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Joachim Nebel FCC listed Grantee contact Title: Homologations HircChmann Car CommuniCation GmbH I stuttgarter straBe 45 - 51 I 72654 N*kartenzlingen lTelefon +49 7127 14-o lTelefax +49 7127 14-1060 www.hißchmann-6r.@m Geschäftsführer: Jörg l'lann Harold G. Barksdale Dr. Dlrk wenft Thomas Falz

TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 sRL Short-Term Confidentiality Request FCC lD: XTJ920642A and XTJ920691A USt-ldNr. OE 814 ztZ 629 Amtsgericht Stuttgart HRB 225926 EUR: Citibank Frankfurt SWIFT: CITIDEFF 19.04.2020 USD: Citibank London SWIFT: CITIGB2L Pursuant to Sections 0.457(dxlXii) and 0.459 of the Commission's Rules, Hrischmann Car Communications GmbH hereby requests short-term confidential treatment of information accompanying this application as outlined below: User Manual External Photos lnternalPhotos Iesf Sef-up Photos The above materials contain trade secrets and proprietary information not customarily released to the public before September 30,2020 The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(dXlXii), disclosure of this Application and all accom- panying materials will not be made before the date of the Grant for this Application. Sincerely, Name: Joachim Nebel Title: Homologations HircChmann Caf COmmUnlCatiOn GmbH I Stutqarter Straße 45 - 51 172654 N*kartendingen lTeleion +49 7127 14-O lTelefax +49 7127 1+1060 www.hiffihmann-car.com Geschäftsführer: Jörg Mann Harold G. garksdale Dr, Dirk Wendt Thomas FalzIBAN: DE92 5021 0900 0217 8960 02 IBAN: Gg06 Cm 1850 0818 9898 93

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuv-sud.co.uk TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Andy Lawson Senior Engineer Authorised Signatory 29 April 2020 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15B and ICES-003. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing William Mayo 29 April 2020 Supervision Martin Perry 29 April 2020 FCC Accreditation 217472 Bearley Test Laboratory ISED Accreditation 12669A Bearley Test Laboratory EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15B: 2019 and ICES-003: 2016 for the tests detailed in section 1.3. FCC and ISED Test Report Hirschmann Car Communication GmbH Broadcast Reception Amplifier, Model: 920691A In accordance with FCC 47 CFR Part 15B and ICES-003 Prepared for: Hirschmann Car Communication GmbH Stuttgarter Straße 45 – 51 72654 Neckartenzlingen Germany FCC ID: XTJ920691A IC: 8653A-920691A COMMERCIAL-IN-CONFIDENCE Document 75948575-07 Issue 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2020 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75948575-07 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 49 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Application Form ...........................................................................................................................4 1.5 Product Information .......................................................................................................................8 1.6 Deviations from the Standard ..................................................................................................... 11 1.7 EUT Modification Record ........................................................................................................... 12 1.8 Test Location .............................................................................................................................. 12 2 Test Details ............................................................................................................................... 13 2.1 Radiated Disturbance ................................................................................................................. 13 3 Test Equipment Information ................................................................................................... 47 3.1 General Test Equipment Used ................................................................................................... 47 4 Incident Reports ....................................................................................................................... 48 5 Measurement Uncertainty ....................................................................................................... 49 Document 75948575-07 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 49 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 29 April 2020 Table 1 1.2 Introduction Applicant Hirschmann Car Communication GmbH Manufacturer Hirschmann Car Communication GmbH Model Number(s) All Samples - 920691A Serial Number(s) Sample 1 - 40347272-00020-14 – Variant A (AM FM1 DAB1) Sample 2 - 40347270-00017-14 – Variant B (AM FM1) Hardware Version(s) V1.0 Software Version(s) Not applicable Number of Samples Tested 1 of each variant Test Specification/Issue/Date FCC 47 CFR Part 15B: 2019 ICES-003: 2016 Order Number Date 1000433208 10-March-2020 Date of Receipt of EUT 20-March-2020 Start of Test 03-April-2020 Finish of Test 16-April-2020 Name of Engineer(s) William Mayo (Supervised by Martin Perry) Related Document(s) ANSI C63.4: 2014 Document 75948575-07 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 49 1.3 Brief Summary of Results A brief summary of the tests carried out in accordance with FCC 47 CFR Part 15B and ICES-003 is shown below. Section Specification Clause Test Description Result Comments/Base Standard Part 15B ICES-003 Configuration and Mode: Sample 1 (Variant A, AM, FM1 and DAB1) DC Powered - AM 2.1 15.109 6.2 Radiated Disturbance Pass ANSI C63.4: 2014 Configuration and Mode: Sample 1 (Variant A, AM, …

Text truncated - open the document above for the full version.

Document 75948575-07 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 45 of 49 Figure 36 - Test Setup - 30 MHz to 1 GHz Figure 37 - Test Setup - 1 GHz to 2 GHz
