XTNTP9000ID Card Printer

Cover User’s Manual Page 2 Contents Contents ...................................................... 02 Caution ...................................................... 04 1. Getting Started 1.1 Introduction 1.2 Contents in Package 1.3 Product Features 1.4 Loading Ribbon Cartridge 1.5 Loading Cleaning Rollers 1.6 Card Feeding Hopper 1.7 Card Output Stacker 1.8 Power Device, Power cable, Communication Cable 2. Software Installation 2.1 Installing FTD2xx Direct USB Driver 2.2 Installing Microsoft Windows Application Software / Driver 2.3 Removing FTD2xx Direct USB Driver 2.4 Removing TP-9 000 Application Software / Driver 2.5 Printing with TP-9 000 on Microsoft Windows Application Software 2.6 Printer Settings in Microsoft Windows 2.7 Printer Driver Settings 3. Printer Operating 3.1 Getting Started 3.2 Description on Features 3.3 Designing Card Page 3 Contents 3.4 Tools 3.5 Configuration 3.6 Data Synchronizing 3.7 Card Printing 4. Instructions on Maintenance 4.1 Maintenance of Product 4.2 How to Replace Ribbon Cartridge 4.3 How to Clean the Printer 4.4 How to Replace TPH(Thermal Print Head) and Consumables 4.5 Trouble-shooting 4.6 Technical Specifications Page 4 User should read caution information and keep in mind before using. Different icons remind important information as to safety. TIT Eng is not responsible for physical harm to body or physical damage to the product occurred by user’s careless use. Danger : Warns user of risk of losing life or being seriously injured. Warning : Warns user of risk of being seriously or slightly injured, or damage to product. Caution : Warns you of slight damage to body. Note : Indicates information that supplements detailed information. Page 5 Danger : Warns user of risk of losing life or being seriously injured. POWER  Do not use damaged power cord, plug or socket.  Do not pull plug with power cord line.  Do not touch power plug with wet bare hand.  Do not bend power cord or put heavy things on the power cord.  Unplug during thunder and lightning or storage INSTALLATION  Do not put the printer in wet, dirty place.  Do not put lightings on the printer. Put the printer away from heat source.  Unplug while moving the printer  Put the printer away from flammable source. CLEANING  Clean the wet and dirty plug.  Unplug the printer before cleaning. Do not use water or chemical cleanser. MISCELLANEOUS  Do not put water bowel, medicine, metal on the printer.  In case of abnormal situation in the printer, unplug the printer immediately and contact your dealer.  Make sure that you use adequate power adaptor. Page 6 Caution : Warns you of slight damage to body. INSTALLATION  Do not put the printer on unstable place.  Avoid direct sunlight that may cause trouble. CLEANING  Do not disassemble cover or protection parts.  When you put hand inside the printer, do not operate it  Make sure that you perform cleaning and maintaining according to the instructions. MISCELLANEOUS  Do not disassemble, repair, modify.  Do not put heavy things on the printer. Page 7 1. Getting Started 1.1 Introduction This card printer enables user to create cards easily and shortly in accordance with the card specifications you wish to get. You can get high quality color image with the card printer of dye sublimation printing. In order to meet customers demand, it provides options such as M/S, IC(Contact), RF(Contactless) encoding as well as bar code, diagram, picture printing. It is useful for creating membership card, bonus card and identification card on PET, PVC card. 1.2 Contents in Package TP-9000 , TP-9000 CLEANING ROLLER, POWER ADAPTOR, POWER CABLE, USB PRINTER CABLE, SOFTWARE CD, USER MANUAL, STACKER(not applicable for TP-9000), CLEANING CARD * Please make sure that printer and all the accessories are in good order. If any items are missing, please contact your dealer. Page 8 1.3 Product Features TP-9000 (Manual, Single Printing) Front Rear Side Features Description No Features Description 1 LED Display LED shows the status of printer 2 LCD Display LCD panel displays the status of printer 3 Card Eject Button for ejecting card from the printer 4 Ribbon Load Button for replacing or repositioning ribbon cartridge 5 Mobile Connector Socket for mobile chip 6 Power Button Power on and off (Option) 7 Card Output Stacker Stacker for released output cards 8 Printer Lid Open for replacing ribbons and cleaning rollers 9 Flipper Used for Dual sided printing (Option) 10 USB Socket Used for memory stick or USB connecting 11 USB Communication Port Used for connecting PC and printer with USB cable 12 RS232C Communication Port Used for connecting PC and printer with RS232C 13 Power Socket Used for supplying power 14 External RF Recognize RF Card Page 9 TP-9000 (Auto Continuous Printing) Front Rear Side Features Description No Features Description 1 LED Display LED shows the status of printer 2 LCD Display LCD panel displays the status of printer 3 Card Eject Button for discharging card inside the printer 4 Ribbon Load Button for replacing or relocating ribbon cartridge 5 Mobile Connector Socket for mobile chip 6 Power Button Power on and off (Option) 7 Card Output Stacker Stacker for released output cards 8 Printer Lid Open for replacing ribbons and cleaning rollers 9 Flipper Used for Dual sided printing (Option) 10 USB Socket Used for memory stick or USB connecting 11 USB Communication Port Used for connecting PC and printer with USB cable 12 RS232C Communication Port Used for connecting PC and printer with RS232C 13 Power Socket Used for supplying power 14 External RF Recognize RF Card * Even though we have three different models of TP series, since there is no big difference in operation, user’s manual has been designed for TP-9 000 Dual Sided as main reference. Page 10 TP-9 000 (Dual Sided, Auto Continuous Printing) Front Rear Side Features Description No Features Description 1 LED Display LED shows the status of printer 2 LCD Display LCD panel displays the status of printer 3 …

Text truncated - open the document above for the full version.

TIT ENG Co.,Ltd. 7 Floor, Shin-do B/D. 10, Garak-dong, Songpa-Gu, Seoul, 138-160 South Korea TEL: +82-2-3431-2370, FAX: +82-2-3431-5279 www.titeng.co.kr November 16, 2010 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 RE: LETTER OF AGENT AUTHORIZATION We, the undersigned, hereby authorize SK TECH Co., Ltd.(Mr. Jongsoo, Yoon) to act on our behalf in all matters relating to application for equipment authorization. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). APPLICANT/AGENT CERTIFICATION AND AGREEMENT: All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization issued by the TCB, under the authority of the FCC, as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. Authorizing an agent to sign this application, is done solely at the applicant’s discretion; however, the applicant remains responsible for all statements in this application. Sincerely, Sang Joong Lee/ Senior Engineer

TIT ENG Co.,Ltd. 7 Floor, Shin-do B/D. 10, Garak-dong, Songpa-Gu, Seoul, 138-160 South Korea TEL: +82-2-3431-2370, FAX: +82-2-3431-5279 www.titeng.co.kr November 16, 2010 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 RE: LETTER OF AGENT AUTHORIZATION TO WHOM IT MAY CONCERN ATTESTATION: We, the undersigned, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. FCC ID Number Product Product description (Model) XTNTP9000 ID Card Printer(TP-9000, Javelin J200i) Sincerely, Sang Joong Lee/ Senior Engineer

TIT ENG Co.,Ltd. 7 Floor, Shin-do B/D. 10, Garak-dong, Songpa-Gu, Seoul, 138-160 South Korea TEL: +82-2-3431-2370, FAX: +82-2-3431-5279 www.titeng.co.kr November 16, 2010 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, TIT ENG Co.,Ltd. requests confidentiality for the following products: FCC ID Number Product Description (Model) XTNTP9000 ID Card Printer(TP-9000, Javelin J200i) The requested Permanent and Short-Term Confidential exhibits art listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics PERMANENT 4 Part List No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain TIT ENG Co.,Ltd. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Sang Joong Lee/ Senior Engineer

SK TECH CO., LTD. Page 1 of 5 SKTRFC-101118-013 FCC ID: XTNTP9000 External Photographs of EUT <Photograph 1: Front View> <Photograph 2: Rear View> SK TECH CO., LTD. Page 2 of 5 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 3: Left-side View> <Photograph 4: Right-side View> SK TECH CO., LTD. Page 3 of 5 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 5: Top View> <Photograph 6: Bottom View> SK TECH CO., LTD. Page 4 of 5 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 7: AC/DC Adaptor supplied/tested with the EUT> SK TECH CO., LTD. Page 5 of 5 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 8: RFID tag tested with the EUT> Front view (A type) Rear view (A type) Front view (B type) Rear view (B type) Front view (Mifare) Rear view (Mifare)

ID Label Location & Sample LABEL LOCATION: Label will be attached to the Rear of the product LABEL Drawing: 65 mm 54 mm

SK TECH CO., LTD. Page 1 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 Internal Photographs <Photograph 1: Cover removed - Top view> <Photograph 2: Cover removed - Right -side view> External antenna Ribbon RFID SK TECH CO., LTD. Page 2 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 3: Cover removed - Bottom view> <Photograph 4: Main Board & Ethernet Board- Front view> Ethernet Board Internal antenna SK TECH CO., LTD. Page 3 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 5: Main Board - Rear view > <Photograph 6: Ethernet Board- Front view> SK TECH CO., LTD. Page 4 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 7: Card RFID Board - Front view> <Photograph 8: Card RFID Board - Rear view > SK TECH CO., LTD. Page 5 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 9: External antenna - Front view> <Photograph 10: External antenna - Rear view > SK TECH CO., LTD. Page 6 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 11: Internal antenna - Front view> <Photograph 12: Internal antenna - Rear view > SK TECH CO., LTD. Page 7 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 13: Ribbon RFID - Front view> <Photograph 14: Ribbon RFID - Rear view > SK TECH CO., LTD. Page 8 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 15: MSRW Board - Front view> <Photograph 16: MSRW Board - Rear view > SK TECH CO., LTD. Page 9 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 17: LCD Board - Front view> <Photograph 18: LCD Board - Rear view > SK TECH CO., LTD. Page 10 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 19: External Interface Board - Front view> <Photograph 20: External Interface Board - Rear view > SK TECH CO., LTD. Page 11 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 21: IFM Board - Front view> <Photograph 22: IFM Board - Rear view > SK TECH CO., LTD. Page 12 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 23: IFM mobile Board - Front view> <Photograph 24: IFM mobile Board - Rear view > SK TECH CO., LTD. Page 13 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 25: SAM Board - Front view> <Photograph 26: SAM, mobile Board - Rear view > SK TECH CO., LTD. Page 14 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 27: Ribbon sensor Board - Front view> <Photograph 28: Ribbon sensor Board - Rear view > SK TECH CO., LTD. Page 15 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 29: Switch Board - Front view> <Photograph 30: Switch Board - Rear view > SK TECH CO., LTD. Page 16 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 31: Power switch Board - Front view> <Photograph 32: Power switch Board - Rear view > SK TECH CO., LTD. Page 17 of 17 SKTRFC-101118-013 FCC ID: XTNTP9000 <Photograph 33: LED Board - Front view> <Photograph 34: LED Board - Rear view >

SK TECH CO., LTD. Page 2 of 23 SKTRFC-101118-013 FCC ID: XTNTP9000 >> CONTENTS << 1. GENERAL ···························································································3 2. TEST SITE ···························································································3 2.1 Location ·························································································3 2.2 List of Test and Measurement Instruments ·················································4 2.3 Test Date ·························································································4 2.4 Test Environment ···············································································4 3. DESCRIPTION OF The EQUIPMENT UNDER TEST ····································5 3.1 Rating and Physical Characteristics ·························································5 3.2 Submitted Documents ·········································································5 3.3 Equipment Modifications ·····································································5 4. MEASUREMENT CONDITIONS ······························································6 4.1 Description of test configuration ·····························································6 4.2 List of Peripherals ··············································································6 4.3 Type of Used Cables ············································································6 4.4 Uncertainty ······················································································6 5. TEST AND MEASUREMENTS ·································································7 5.1 ANTENNA REQUIREMENT ······························································7 5.1.1 Regulation ··················································································7 5.1.2 Result ·······················································································7 5.2 RADIATED EMISSIONS ···································································8 5.2.1 Regulation ··················································································8 5.2.2 Measurement Procedure ·································································9 5.2.3 Calculation of the filed strength limits below 30 MHz ···························· 10 5.2.4 Test Results ·············································································· 11 Table 1: Field strength below 30 MHz ·········································································· 11 Table 2: Field strength above 30 MHz ·········································································· 12 Figure 1: Plot of the Band edge ················································································· 13 Figure 2: Plot of the 20 dB bandwidth ········································································· 14 5.3 FREQUENCY TOLERANCE OF CARRIER SIGNAL ···························· 15 5.3.1 Regulation ················································································ 15 5.3.2 Measurement Procedure ······························································· 15 5.3.3 Test Results ·············································································· 16 Table 3: Frequency Tolerance····················································································· 16 5.4 AC POWER LINE CONDUCTED EMISSIONS ···································· 18 5.4.1 Regulation ················································································ 18 5.4.2 Measurement Procedure ······························································· 18 5.4.3 Test Results ·············································································· 19 Table 4: Measured Values of the Conducted Emissions······················································· 19 Figure 3: Plot of the Conducted Emissions ···································································· 21 SK TECH CO., LTD. Page 3 of 23 SKTRFC-101118-013 FCC ID: XTNTP9000 1. GENERAL These tests were performed using the test procedure outlined in ANSI C63.4-2003 for intentional radiators, and in accordance with the limits set forth in FCC Part 15.225. The EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards. We attest to the accuracy of data. All measurements reported herein were performed by SK TECH CO., LTD. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. TEST SITE SK TECH Co., Ltd. 2.1 Location #820-2, Wolmoon-ri, Wabu-up, Namyangju-si, Kyunggi-do, 472-905 South Korea (FCC Registered Test Site Number: 90752) (OPEN AREA TEST SITE INDUSTRY CANADA NUMBER: IC 5429A) This laboratory is recognized as a Conformity Assessment Body (CAB) for CAB's Designation Number: KR0007 by FCC, is accredited by NVLAP for NVLAP Lab. Code: 200220-0. SK TECH CO., LTD. Page 4 of 23 SKTRFC-101118-013 FCC ID: XTNTP9000 2.2 List of Test and Measurement Instruments No. Description ManufacturerModel No.Serial No. Calibrated until Used 1 Spectrum Analyzer Agilent E4405B US40520856 2011.05 2 Spectrum Analyzer Agilent E4440A MY46186322 2011.05 3 EMC Spectrum Analyzer Agilent E7405A US40240203 2011.03 4 EMI Test Receiver Rohde&Schwarz ESIB40 100277 2011.03 5 EMI Test Receiver Rohde&Schwarz ESHS10 862970/019 2011.07 6 Artificial Mains Network Rohde&Schwarz ESH3-Z5 836679/018 2011.07 7 Pre-amplifier HP 8447F 3113A05153 2011.07 8 Pre-amplifier MITEQ AFS44 1116321 2010.12 9 Pre-amplifier MITEQ AFS44 1116322 2011.07 10 Power Meter Agilent E4417A MY45100426 2011.07 11 Power Meter Agilent E4418B US39402176 2011.07 12 Power Sensor Agilent E9327A MY44420696 2011.07 13 Power Sensor Agilent 8482A MY41094094 2011.07 14 Attenuator (10dB) HP 8491B 38067 2011.07 15 Attenuator (20dB) Weinschel 44 AH6967 2011.07 16 High Pass Filter W…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 3 SKTRFC-101118-013 FCC ID: XTNTP9000 Test set up photos <Radiated Emissions - Front View> <Radiated Emissions - Rear View> SK TECH CO., LTD. Page 2 of 3 SKTRFC-101118-013 FCC ID: XTNTP9000 <Radiated Emissions - below 30 MHz> <Radiated Emissions - below 1 GHz> SK TECH CO., LTD. Page 3 of 3 SKTRFC-101118-013 FCC ID: XTNTP9000 <AC Power Line Conducted Emissions - Front View> <AC Power Line Conducted Emissions - Rear View>
