XUV2172TT2400Data Logger

Cello 4S A remote telemetry outstation delivering a scalable and versatile solution for reducing operating and capital costs. Multiple site parameters are monitored, recorded and transmitted over 2G (SMS/GPRS), 3G, NB-IoT and LTE Cat M1 networks, providing a comprehensive multi-application solution for the Utilities and Industry. Key Features www.technolog.com • Future ready. Support for LTE Cat M1 and NB-IoT leverages low power network capability for greater energy efficiency • Flexible communication build options supporting either 2G only; 2G / 3G; or 2G / NB-IoT / LTE Cat M1 • Physical build options for up to two pressure and eight user programmable digital or analogue inputs • Two independent digital outputs configurable for external power control, alarm signalling or switching 12 Volt outputs for powering 4-20mA loops • Proven bidirectional Cello communication with automatic gap filling ensuring high level data reliability and supporting remote product configuration • Remote set-up, monitoring and control through locally deployed PMAC software or web based WaterCore platform • Models available to facilitate closed loop control of pressure reducing valves, pressure sustaining valves and variable speed pumps • Water temperature measurement • Advanced channel profile and threshold alarms • High frequency (100 Hz) pressure transient detection critical to extending asset life and network modelling • Low power design. Support for external battery packs and DC supply • Rugged, portable and waterproof to IP68 Technical Specifications +44(0)1629 823611 [email protected] www.technolog.com Technolog Limited, Ravenstor Road, Wirksworth, DE4 4FY, United Kingdom Copyright Technolog 2020 All rights reserved. Specifications subject to change without prior notice. 2099DS9000 Issue J & DMR n/a Configurable channel strategies : Voltage, event, tamper / status, count, frequency and encoder Digital: Pulses counted over, and recorded at, pre-set intervals. Tamper/status and event time supported Frequency input: Switch closures or logic pulses, maximum frequency 16 kHz, programmable sampling period Analogue: 0 - 2.5V, 0.01V resolution as standard, <1mV with 8 channel option Inputs Data Transmission Recording Alarm Dial-Out Environmental Mechanical Memory Supply Clock Modem Electrical Inputs 2i - Configurable for up to two digital or analogue inputs 1P - One internal or external pressure transducer 1P2i - Configurable for one internal or external pressure transducer and up to two digital or analogue inputs 2P2i - Configurable for up to two internal or external pressure transducerand up to two digital 1P7i - Configurable for one internal or external pressure transducer and up to seven digital or analogue inputs 8i - Configurable for up to eight digital or analogue inputs; supporting 12v flash powering Integral antenna: Optional external antenna – Support for 2G, 3G, NB-IoT and LTE Cat M1 frequencies (subject to build option) SIM: User replaceble SIM card Ty p e : 2G, 3G, NB-IoT and LTE Cat M1 networks (subject to build option) Interval: 1 min to 1 month at programmable date and time Size: 512K, allocable between channels as required (max 64K per channel) Ty p e : Crystal controlled calendar clock with leap year adjustment – Option to synchronise clock to local network at regular intervals – User replaceable Internal lithium battery pack, typical battery life > 5 years depending on mode of use – High capacity external lithium battery pack, user replaceable Interval: Programmable between 1 second and 1 hour Data storage: Rotating store or store until full – Four threshold and profile alarms, independently configurable on each channel – Option to update data on alarm and more frequently thereafter Operating ambient temperature: -20°C to +50°C Ingress protection classification: IP68 (submersion at 1m depth for 48 hours) Dimensions (mm): 149 x 146.5 (h) Weight: 0.750kg Pressure Sensors 1P, 1P2i, 2P2i & 1P7i options only Input range: 0 - 100 m, 0 - 200 m; 0 - 10 bar, 0 - 20 bar; 0 - 150 psi, 0 - 300 psi Programmable: +/- 0.5% or +/- 0.1% resolution F.S. – Supports average and statistical recording of pressure (min, max, mean, standard deviation) over logging interval Standard Build Options Standard Specification - Common to all Variants 1P7i & 8i options only: Two independent digital outputs for external power control and alarm signalling (0 & 3 volt levels, active low, 100k output impedance) or two individually switched 12 Volt outputs for powering 4-20mA loops Outputs

Declaration of Conformity: Cello 4S - 2172 Document no. 2172DC9000 Rev. B Sheet 1 of 5 DMRs: 8610 Signed for & on behalf of: Technolog Limited, Ravenstor Road, Wirksworth, Matlock, Derbyshire, DE4 4FY (UK). Tel.: +44 (0) 1629 823611 Fax.: +44 (0) 1629 824283 Email: [email protected] Copyright Technolog Limited 2020 All rights reserved. Specifications subject to change without prior notice 1. Certificate & EU Declaration of Conformity Model / series: Cello 4S (2172) Product type: Equipment designation: General purpose data logger c/w wireless communications Technolog works order no(s): Customer order no(s): Product serial no(s): Product batch no(s): The object of this declaration conforms with the requirements of Technolog generated build information 2099TP3000 manufacturing data pack – Rev.:__ Q.A. representative signature: Q.A. representative name (print): Herewith we declare that the object of the declaration as described above is in conformity with the relevant European Union harmonisation legislation as listed below. Alterations or repair of said object without prior consultation and the written agreement of Technolog, will invalidate this declaration with regards to that product. This declaration does not extend to any system in which said object is incorporated. This declaration of conformity is issued under the sole responsibility of the manufacturer. Applied European Council Directive(s): 94/62/EC - on packaging and packaging waste. 97/23/EC - on the approximation of the laws of the Member States concerning pressure equipment (‘PED’). 1999/519/EC - on the limitation of exposure of the general public to electromagnetic fields (0Hz to 300GHz) 2006/66/EC - on batteries and accumulators and waste batteries and accumulators and repealing Directive 91/157/EC. 2011/65/EU - on the restriction of the use of certain hazardous substances in electrical & electronic equipment (recast) (‘RoHS2’). 2012/19/EU - on waste electrical & electronic equipment (recast) (‘WEEE2’). 2014/35/EU - on the harmonisation of the laws of the Member States relating to the making available on the market of electrical equipment designed for use within certain voltage limits (recast). 2014/53/EU - on the harmonisation of the laws of the Member States relating to the making available on the market of radio equipment and repealing Directive 1999/5/EC (‘RED’). Declaration of Conformity: Cello 4S - 2172 Document no. 2172DC9000 Rev. B Sheet 2 of 5 DMRs: 8610 Signed for & on behalf of: Technolog Limited, Ravenstor Road, Wirksworth, Matlock, Derbyshire, DE4 4FY (UK). Tel.: +44 (0) 1629 823611 Fax.: +44 (0) 1629 824283 Email: [email protected] Copyright Technolog Limited 2020 All rights reserved. Specifications subject to change without prior notice Referred harmonised standards and / or other technical specifications used in relation to which conformity is declared: All variants EN 60529: 1992 EN 62311: 2008 IEC 61010-1: Ed. 3 2G / 3G variants ETSI EN 301 511 v12.5.1 ETSI EN 301 908-1 v11.1.1 ETSI EN 301 489-1 v2.2.0 EN 301 489-52 v1.1.0 (draft) LTE (Cat M1 / NB1) / 2G variants ANSI C63.4: 2014 ANSI C63.26: 2015 ETSI EN 301 489-1 v2.2.3 ETSI EN 301 489-52 v1.1.0 EN 50665: 2017 ETSI EN 301 908-1 v13.1.1 ETSI EN 301 511: v12.5.1 FCC 47 CFR Part 2: 2020 FCC 47 CFR Part 15B: 2020 FCC 47 CFR Part 22: 2020 FCC 47 CFR Part 24: 2020 FCC 47 CFR Part 27: 2020 IEEE C95.3: 2002 Basis of self-attestation: Quality Management System meeting the requirements of Annexes IV and VII of European Directives 94/9/EC (until April 19 th 2016) and 2014/34/EU (from April 20 th 2016), ISO / IEC 80079-34 and ISO 9001. Third party approval(s): All variants IECEE CB safety approvals against the requirements of IEC 61010-1: Ed. 3: Element Materials Technology certificate: GB-EMT-0814. Ingress protection rating IP68 (1m / 48 hours) against the requirements of EN 60529: 1992 (Inc. amendments 1 & 2): Sira Certification certificate 58D33130. 2G / 3G variants República Argentina Comisión Nacional de Comunicaciones, contiene módulo CNC ID: H-24515 Malaysia "SIRIM QAS International" in-country certificate of conformity 'E098519' (certification of communications product) – standards SKMM WTS GSM-MT 1.01: 2007, SKMM WTS IMT-MT rev. 1.01: 2007 Republic of the Philippines 'National Telecommunications Commission (NTC)' in-country type approval certificate 'ESD-CPE-2003596' (customer premises equipment) Socialist Republic of Vietnam "Ministry of Information and Communication" in- country VNTA type approval certificate C0337311219AA04A2 – complies with QCVN 12:2015/BTTTT; QCVN 15:2015/BTTTT LTE (Cat M1 / NB1) / 2G variants US Equipment Authorisation FCC ID: XUV2172TT2400 Equipment marking: Not applicable Special conditions for safe use; Use of any battery pack other than those supplied by the manufacturer for the application will invalidate applicable warranties. Installation guidelines: Installation shall be carried out in accordance with the applicable code of practice by competent, and suitably trained, personnel. Declaration of Conformity: Cello 4S - 2172 Document no. 2172DC9000 Rev. B Sheet 3 of 5 DMRs: 8610 Signed for & on behalf of: Technolog Limited, Ravenstor Road, Wirksworth, Matlock, Derbyshire, DE4 4FY (UK). Tel.: +44 (0) 1629 823611 Fax.: +44 (0) 1629 824283 Email: [email protected] Copyright Technolog Limited 2020 All rights reserved. Specifications subject to change without prior notice 2. Essential Health & Safety Requirements Installation; Installation is to be carried out in accordance with the applicable code of practice by competent, and suitably trained, personnel. Intended area under the expected operating conditions The equipment may be operated in ambient temperatures in the range -20°C to +50°C and should not be used outside this range. The equipment is designed for use indoors and outdoors having an ingress protection rating of IP68, submersible to 1 metre for 24 hours. Use If the equipment is likely to come into contact wi…

Text truncated - open the document above for the full version.

Bottom View: Front View: Left Hand Side View: Right Hand Side View: Inside View: Rear View: Top View:

Left Hand Side View: Right Hand Side View:

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuv-sud.co.uk TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Andy Lawson Senior Engineer Authorised Signatory 01 Sept 2020 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15B. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Matthew Dawkins 01 Sept 2020 FCC Accreditation 90987 Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15B: 2019 for the tests detailed in section 1.3. FCC Test Report Technolog Ltd Remote Telemetry Outstation, Model: Cello 4S In accordance with FCC 47 CFR Part 15B Prepared for: Technolog Ltd Ravenstor Road Wirksworth DE4 4FY United Kingdom FCC ID: XUV-2172TT2400 COMMERCIAL-IN-CONFIDENCE Document 75948801-02 Issue 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2020 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75948801-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 26 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Declaration of Build Status ............................................................................................................4 1.5 Product Information .......................................................................................................................7 1.6 Deviations from the Standard ........................................................................................................7 1.7 EUT Modification Record ..............................................................................................................8 1.8 Test Location .................................................................................................................................8 2 Test Details ..................................................................................................................................9 2.1 Radiated Disturbance ....................................................................................................................9 3 Measurement Uncertainty ....................................................................................................... 26 Document 75948801-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 26 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 01 Sept 2020 Table 1 1.2 Introduction Applicant Technolog Ltd Manufacturer Technolog Ltd Model Number(s) Cello 4S Serial Number(s) 20201793756-F4 and 20201793755.92 Hardware Version(s) 2172TT2400B Software Version(s) 4.47 Number of Samples Tested 2 Test Specification/Issue/Date FCC 47 CFR Part 15B: 2019 Order Number Date PO-020235 09-April-2020 Date of Receipt of EUT 28-April-2020 and 30-April-2020 Start of Test 01-May-2020 Finish of Test 01-May-2020 Name of Engineer(s) Matthew Dawkins Related Document(s) ANSI C63.4: 2014 Document 75948801-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 26 1.3 Brief Summary of Results A brief summary of the tests carried out in accordance with FCC 47 CFR Part 15B is shown below. Section Specification Clause Test Description Result Comments/Base Standard Configuration and Mode: Battery Powered - Internal Battery - Idle 2.1 15.109 Radiated Disturbance Pass ANSI C63.4: 2014 Configuration and Mode: Battery Powered - External Battery - Idle 2.1 15.109 Radiated Disturbance Pass ANSI C63.4: 2014 Table 2 Document 75948801-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 26 1.4 Declaration of Build Status Equipment Description Technical Description: (Please provide a brief description of the intended use of the equipment) Data logger for monitoring pressure and flow in a mains water distribution network. The logger sends data periodically via SMS or a data connection with a server. Manufacturer: Technolog Ltd Model: Cello 4S Part Number: 2172CG3517 Hardware Version: 2172TT2400B Software Version: 4.47 FCC ID (if applicable) XUV-2172TT2400 IC ID (if applicable) Not Applicable Intentional Radiators Technology GSM 850 LTE FDD Band 12 Cat-M1 LTE FDD Band 4 Cat-M1 LTE FDD Band 12 NB-IoT LTE FDD Band 4 NB-IoT Frequen…

Text truncated - open the document above for the full version.

Technolog Cello 4S LTE XUV2172TT2400 – Test Setup Photos FCC CFR 47 Part 22: Internal Antenna 30 MHz to 1 GHz: External Antenna 30 MHz to 1 GHz Internal Antenna 1 GHz to 10 GHz: External Antenna 1 GHz to 10 GHz: FCC CFR 47 Part 15B (Cello 4S c/w ME910C1-WW module): Internal Battery - 30 MHz to 1 GHz: Internal Battery - 1 GHz to 13 GHz: External Battery – 30 MHz to 1 GHz: External Battery 1 GHz to 13 GHz: FCC CFR 47 Part 27 and Part 2: Internal Antenna 30 MHz to 1 GHz: External Antenna 30 MHz to 1 GHz: Internal Antenna 1 GHz to 8 GHz: External Antenna 1 GHz to 8 GHz: Internal Antenna 8 GHz to 18 GHz: External Antenna – 8 GHz to 18 GHz: FCC CFR 47 Part 24 and Part 2 (PCS 1900 – Cello 4S LTE c/w ME910G1-WW module): 30 MHz to 1 GHz – x orientation: 30 MHz to 1 GHz – Y Orientation: 30 MHz to 1 GHz – Z Orientation: 1 GHz to 18 GHz – X Orientation: 1 GHz to 18 GHz – Y Orientation: 1 GHz to 18 GHz – Z Orientation: 18 GHz to 20 GHz – X Orientation: 18 GHz to 20 GHz – X Orientation: 18 GHz to 20 GHz – X Orientation:
