XUX-CON-M800-USA1MC627 Timekeeping System

ChronoTrack Systems, Inc. ChronoTrack User Manual Table of Contents Issued: January 2010 ChronoTrack Systems, Inc. 111 East Diamond Avenue Evansville, Indiana 47711 U.S.A. 812‐423‐7800 Main 314‐406‐7243 Sales 812‐759‐7877 Support 812‐423‐7801 Fax www.chronotrack.com ChronoTrack User Manual ChronoTrack Systems, Inc. ChronoTrack User Manual Table of Contents Issued: January 2010 1‐2 © Copyright 2010 ChronoTrack Systems, Inc. All rights reserved. “ChronoTrack”, “D-Tag”, and “D-Tag Interrogator” are trademarks of ChronoTrack Systems, Inc. “Windows” is a registered trademark of Microsoft Corporation in the United States and other countries. All other trademarks used herein are property of their respective owners. ChronoTrack Systems, Inc. makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. ChronoTrack Systems shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of ChronoTrack Systems. ChronoTrack Systems shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and is subject to change without notice. ChronoTrack Systems, Inc. ChronoTrack User Manual Table of Contents Issued: January 2010 1‐3 1 Table of Contents 1 Table of Contents ............................................................................................................................................. 1-3 2 Introduction ....................................................................................................................................................... 2-1 2.1 About This Guide .................................................................................................................................... 2-1 2.2 ChronoTrack System Overview .............................................................................................................. 2-1 3 Gator Setup and Configuration ......................................................................................................................... 3-1 3.1 Possible Gator Configurations ................................................................................................................ 3-1 3.2 Positioning and Linking Gators ............................................................................................................... 3-3 3.3 Connecting Antennas .............................................................................................................................. 3-4 3.4 Creating a “Dead Zone” .......................................................................................................................... 3-4 4 Controller Setup ................................................................................................................................................ 4-1 4.1 The Controller Interface .......................................................................................................................... 4-1 4.1.1 Status Indicator LEDs ......................................................................................................................... 4-2 4.2 Powering ON ........................................................................................................................................... 4-3 4.3 Pre-Event Configuration .......................................................................................................................... 4-3 4.4 Charging ................................................................................................................................................. 4-3 5 Using BoxScore ................................................................................................................................................ 5-1 5.1 The Main Screen ..................................................................................................................................... 5-1 5.1.1 Creating a Gun Start Timestamp and File Markers ............................................................................ 5-1 5.2 Configure Menu ...................................................................................................................................... 5-2 5.2.1 Network Configuration ........................................................................................................................ 5-2 5.2.1.1 Setting the Server Address ........................................................................................................................ 5-2 5.2.1.2 Advanced Network Configuration ............................................................................................................ 5-3 5.2.2 Powering ON/OFF Internal Components ............................................................................................ 5-3 5.2.3 Point Configuration ............................................................................................................................. 5-3 5.2.3.1 Point Configuration Data Input ................................................................................................................. 5-4 5.2.4 Copying Files to USB ......................................................................................................................... 5-5 5.2.4.1 File Copy Status Messages ....................................................................................................................... 5-5 5.2.5 Setup Wizard ..................................................................................................................…

Text truncated - open the document above for the full version.

Impinj, Inc. 701 N. 34 th Street, Suite 300 Seattle, WA 98103 Tel (206) 517-5300 Fax (206) 517-5262 www.impinj.com 25 October 2009 CKC Certification Services, LLC 4933 Sierra Pines Drive Mariposa, CA 95338 This letter is your authorization to obtain and use application materials (including test reports) currently filed with the FCC pertaining to the Impinj IPJ-R1000 RFID reader product (FCC ID TWYIPJR1000) solely for new product filings associated with ChronoTrack Systems. Items previously identified to the FCC or marked as confidential may not be released to ChronoTrack Systems or any other third party, except as required by law for the purpose of certification. Sincerely, William Ashley VP Reader Engineering Impinj, Inc.

6 January 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: This letter is to comply with Section 0.457(d)(2)(i) and Section 0.459 pertaining to confidential material. We would like to formally request, on behalf of both our modular vendors and us (ChronoTrack Systems, LLC), that the following documents regarding this submission for FCC ID: XUX-CON-M800-USA1 be held permanently confidential: 1.) All Block Diagrams 2.) All Operational Descriptions 3.) All Schematics The above material contains trade secrets and/or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Daniel R. Howell Daniel R. Howell President ChronoTrack Systems, LLC Phone: 812-423-7800 Fax: 812-499-9199 E-Mail: [email protected]

30 December 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: XUX-CON-M800-USA1 Gentlemen: Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1.) All Internal Photos 2.) All External Photos 3.) All Manuals The above material contains trade secrets or technical data that if other companies with in the same industry were able to view, it would remove the edge on the market that this product provides our company. Sincerely, Daniel R. Howell Daniel R. Howell President ChronoTrack Systems, LLC Phone: 812-423-7800 Fax: 812-499-9199 E-Mail: [email protected]

ChronoTrack Mobile RFID Controller MODEL: Series 800 FCC ID : XUX-CON-M800-USA1 IC : 8688A-CONM800USA Contains FCC ID : N7NMC8775 Contains IC : 2417C-MC8775 ChronoTrack Systems LLC This device complies with Part 15 of FCC Rules. Operation isThis device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 14 Page 15

Page 1 CONSTRUCTION PHOTOS OF EUT Antenna 1 Page 2 Antenna 2 Page 3 Page 4 Antenna 3 Page 5 Antenna 4 Page 6 Page 7 Antenna 5 Page 8 Antenna 6 Page 9 Page 10 Antenna 7 Page 11 Antenna 8 Page 12 Page 13

Top Bottom Inside Top Inside Bottom PCB Top PCB Bottom PCB in Case

Side 1 Side 2

FCC ID: RUJ-Q802XKG Report No: SA951206L13 1 RF EXPOSURE REPORT REPORT NO.: SA951206L13 MODEL NO.: Q802XKG ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Qcom Technology Inc. ADDRESS: 7F, NO.178, MING CHUAN E. RD. SEC 3, TAIPEI TAIWAN R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: RUJ-Q802XKG Report No: SA951206L13 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: RUJ-Q802XKG Report No: SA951206L13 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: RUJ-Q802XKG Report No: SA951206L13 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 4.51dBi or 2.82488(numeric) and 2.51dBi or 1.782379(numeric) 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: Test Mode A: Antenna gain: 4.51dBi: For DSSS: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 39.994 0.022 1.0 6 2437 40.644 0.023 1.0 11 2462 31.989 0.018 1.0 For OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 25.293 0.014 1.0 6 2437 25.410 0.014 1.0 11 2462 25.177 0.014 1.0 Test Mode B: Antenna gain: 2.51dBi: For DSSS: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 39.994 0.014 1.0 6 2437 40.644 0.014 1.0 11 2462 31.989 0.011 1.0 For OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 25.293 0.009 1.0 6 2437 25.410 0.009 1.0 11 2462 25.177 0.009 1.0

Page 1 of 22 Report No.:FC09-177 TESTING CERT #803.01, 803.02, 803.05, 803.06 CHRONOTRACK SYSTEMS TEST REPORT FOR THE TIMEKEEPING SYSTEM, CHRONOTRACK MC627 FCC PART 15 SUBPART B SECTIONS 15.107 AND 15.109 CLASS A TESTING DATE OF ISSUE: OCTOBER 26, 2009 PREPARED FOR: ChronoTrack Systems 111 East Diamond Ave. Evansville, IN 47711 PREPARED BY: Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 W.O. No.: 89917 Date of test:October 12 - 14, 2009 Report No.: FC09-177 This report contains a total of 22 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. The results in this report apply only to the items tested, as identified herein. Page 2 of 22 Report No.:FC09-177 TABLE OF CONTENTS Administrative Information .............................................................................................3 Approvals .........................................................................................................................4 Site File Registration Numbers ........................................................................................4 Summary of Results .........................................................................................................4 Conditions During Testing ...............................................................................................4 Equipment Under Test (EUT) Description ......................................................................5 Equipment Under Test .....................................................................................................5 Peripheral Devices ...........................................................................................................5 Measurement Uncertainties .............................................................................................6 Report of Emissions Measurements.................................................................................6 Testing Parameters ...............................................................................................6 Conducted Emissions ...........................................................................................8 Radiated Emissions ..............................................................................................15 Page 3 of 22 Report No.:FC09-177 ADMINISTRATIVE INFORMATION DATE OF TEST: October 12 - 14, 2009 DATE OF RECEIPT: October 12, 2009 REPRESENTATIVE: Daniel Howell MANUFACTURER: ChronoTrack Systems 111 East Diamond Ave. Evansville, IN 47711 TEST LOCATION: CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 TEST METHOD: ANSI C63.4 (2003) PURPOSE OF TEST: To perform testing of the Timekeeping System, ChronoTrack MC627 with the requirements for FCC Part 15 Subpart B Sections 15.107 and 15.109 Class A devices. Page 4 of 22 Report No.:FC09-177 APPROVALS QUALITY ASSURANCE: TEST PERSONNEL: Steve Behm, Director of Engineering Services Chuck Kendall, Senior EMC Engineer / Senior EMC Consultant Mike Wilkinson, Senior EMC Engineer/Lab Manager Greg Johnson, EMC Engineer SITE FILE REGISTRATION NUMBERS Location Japan Canada FCC Mariposa A R-563, C-578 & T-1492 3082A-2 90477 SUMMARY OF RESULTS Test Specification Results Conducted Emissions FCC Part 15 Subpart B Section 15.107 Class A Pass Radiated Emissions FCC Part 15 Subpart B Section 15.109 Class A Pass CONDITIONS DURING TESTING No modifications to the EUT were necessary during testing. Page 5 of 22 Report No.:FC09-177 EQUIPMENT UNDER TEST (EUT) DESCRIPTION The EUT tested is a ChronoTrack Timekeeping System. EQUIPMENT UNDER TEST Timekeeping System Manuf: ChronoTrack Systems Model: ChronoTrack MC627 Serial: 2017-115 PERIPHERAL DEVICES The EUT was tested with the following peripheral device(s): Tablet PC Manuf: XPlor Technologies Model: iX104 Serial: 914G001018G7350138EM00 AC/DC power supply Manuf: Delta Electronics, Inc. Model: SADP-65KB D Serial: 92W0725009590 Threshold Antenna Manuf: Impinj Model: IPJ-A0310-EU1 Serial: 005107 Threshold Antenna Manuf: Impinj Model: IPJ-A0310-EU1 Serial: 005109 GPRS Stub Antenna Manuf: Wilson Model: Unknown qtr wave antenna Serial: NA Page 6 of 22 Report No.:FC09-177 MEASUREMENT UNCERTAINTIES Uncertainty Value Parameter 4.73 dB Radiated Emissions 3.34 dB Mains Conducted Emissions 3.30 dB Disturbance Power The reported measurement uncertainties are calculated based on the worst case of all laboratory environments from CKC Laboratories, Inc. test sites. Only those parameters which require estimation of measurement uncertainty are reported. The reported worst case measurement uncertainty is less than the maximum values derived in CISPR 16-4-2. Reported uncertainties represent expanded uncertainties expressed at approximately the 95% confidence level using a coverage factor of k=2. Compliance is deemed to occur provided measurements are below the specified limits. REPORT OF EMISSIONS MEASUREMENTS TESTING PARAMETERS The cables were routed consistent with the typical application by varying the configuration of the test sample. Interface cables were connected to the available ports of the test unit. The effect of varying the position of the cables was investigated to find the configuration that produced maximum emissions. Cables were of the type and length specified in the individual requirements. The length of cable that produced maximum emissions was selected. The equipment under test (EUT) was set up in a manner that represented its normal use, as shown in the setup photographs. Any special conditions required for the EUT to operate normally are identified in the comments that accompany the emissions tables. The emissions data was taken with a spectrum analyzer or receiver. Incorporating the applicable correction factors for distance, antenna, cable loss and amplifier gain, the data was reduced as shown in the table below. The corrected data was then compared to the applicable emission limits. P…
