XVV-RASPBEE2Generic Zigbee Gateway

dresden elektronik ingenieurtechnik gmbh 02|2020 RaspBee II – ZigBee USB Gateway User Manual The universal Zigbee USB gateway  Unites Zigbee devices of many vendors  A cloud free solution  strong signal range via power-amplifier  works with popular Home Automation Systems Technical specification Name Description Rated voltage DC 5,0 V Transmission power 10 mW Signal range 200 m in free line of sight Radio frequency 2.4 GHz Radio standard IEEE 820.15.4 / Zigbee Flash memory 256 kByte RTC battery type 337/SR416SW Battery life At least 2 years* Storage temperature -20 °C bis 55 °C Operating temperature -20 °C bis 55 °C Operating systems Raspbian, Docker Dimensions 30 mm × 18 mm × 10 mm *By keeping the Raspberry Pi powered at all times, the battery life can increase up to 8 years. dresden elektronik ingenieurtechnik gmbh Tel: +49 351 31850-0 Fax: -10 Kontakt Enno-Heidebroek-Str. 12 [email protected] 01237 Dresden | Germany www.dresden-elektronik.de © 2019 dresden elektronik ingenieurtechnik gmbh. Alle Rechte vorbehalten. Alle Warenzeichen, eingetragene Warenzeichen und Produktnamen sind das Eigentum der jeweils Berechtigten. Für die Aktualität, Vollständigkeit und Richtigkeit der enthaltenen Informationen können wir keine Garantie übernehmen. Technische Änderungen vorbehalten. Content The universal Zigbee USB gateway ........................................................................................................ 1 Technical specification ......................................................................................................................... 1 Installation ............................................................................................................................................ 2 Supported platforms ......................................................................................................................... 2 Connection ........................................................................................................................................... 2 Raspbian .............................................................................................................................................. 3 Supported Raspberry Pi models and distributions ........................................................................... 3 Installation ........................................................................................................................................ 3 Docker .................................................................................................................................................. 5 Supported host systems ................................................................................................................... 5 Installation ........................................................................................................................................ 5 Radio certification ................................................................................................................................ 6 United States (FCC) ......................................................................................................................... 6 Innovation, Science and Economic Development (ISED) Canada .................................................. 7 European Union (RED) .................................................................................................................... 8 Ordering Information ............................................................................................................................ 8 Installation The deCONZ application is a tool to configure, control and monitor Zigbee networks with the RaspBee II. The following sections describe the installation steps of deCONZ for various platforms. Supported platforms  Raspbian  Docker Connection 1. Insert the battery of type 337/SR416SW as shown in the battery slot. 2. The RaspBee II must be placed on the Raspberry Pi header as follows: dresden elektronik ingenieurtechnik gmbh Tel: +49 351 31850-0 Fax: -10 Kontakt Enno-Heidebroek-Str. 12 [email protected] 01237 Dresden | Germany www.dresden-elektronik.de © 2019 dresden elektronik ingenieurtechnik gmbh. Alle Rechte vorbehalten. Alle Warenzeichen, eingetragene Warenzeichen und Produktnamen sind das Eigentum der jeweils Berechtigten. Für die Aktualität, Vollständigkeit und Richtigkeit der enthaltenen Informationen können wir keine Garantie übernehmen. Technische Änderungen vorbehalten. Important: The RaspBee II must not be placed in an offset position, as this will damage the module! Raspbian Supported Raspberry Pi models and distributions  Raspberry Pi 1, 2B, 3B, 3B+ and 4B  Raspbian Jessie  Raspbian Stretch  Raspbian Buster Note The following steps describe the manual installation of deCONZ. Alternatively a preinstalled SD-card image can be used. Installation 1. Configure user access rights of the serial interface sudo raspi-config Interfacing Options → Serial o Would you like a login shell accessible over serial? → No o Would you like the serial port hardware to be enabled? → Yes Note: Changes to access rights only become active after a restart. 2. Import Phoscon public key 3. wget -O - http://phoscon.de/apt/deconz.pub.key | \ sudo apt-key add - 4. Configure the APT repository for deCONZ Stable sudo sh -c "echo 'deb http://phoscon.de/apt/deconz \ $(lsb_release -cs) main' > \ /etc/apt/sources.list.d/deconz.list" dresden elektronik ingenieurtechnik gmbh Tel: +49 351 31850-0 Fax: -10 Kontakt Enno-Heidebroek-Str. 12 [email protected] 01237 Dresden | Germany www.dresden-elektronik.de © 2019 dresden elektronik ingenieurtechnik gmbh. Alle Rechte vorbehalten. Alle Warenzeichen, eingetragene Warenzeichen und Produktnamen sind das Eigentum der jeweils Berechtigten. Für die Aktualität, Vollständigkeit und Richtigkeit der enthaltenen Informationen können wir keine Garantie übernehmen. Technische…

Text truncated - open the document above for the full version.

dresden elektronik dresden elehronik ingenieurlechnik gmbh . Enno-Heidebroek-Str. '12 . D-01237 Dresden Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1t10t2020 To whom it may concern We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC lD: XW-RASPBEE2 inctuding the signing of ail documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1gBB,21 u.S.c. 862. Sincerely I P",lr- Signature Andreas Palm Department Manager Wireless Products dresden elektronik ingenieurtechnik gmbh t=F | 'lrs' t.- dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Str. 1 2 01237 Dresden Tel.: 0351 - 31 85 00 Fax: 0351 - 3 18 50 10 info@d resden-elektronik.de www. d resden-elektro n ik. de Seite 1 von 1

dresden eleklronik ingenieurlechßik gmbh . Enno-Heidebroek-Str. 12 . D-01237 Dresden Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1t10t2020 Request for Permanent Confidentiality Gompany name: dresden elektronik ingenieurtechnik gmbh FGG ID: XW-RASPBEE2 FCC Part 15 Gertification Gentlemen, ln accordance with CFR 47 S 0.457 and CFR 47 S 0.459 dresden elektronik ingenieurtechnik gmbh hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which dresden elektronik ingenieurtechnik gmbh considers to be proprietary, confidential and a custom design and othenrvise would not release to the general public. Since the design is a basis from which future technological products will evolve, dresden elektronik ingenieurtechnik gmbh considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature Andreas Palm Department Manager Wireless Prod ucts dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Str. 1 2 01237 Dresden, Germany dresden elektronik t--il: l_ P^l* dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Str. 1 2 01237 Dresden Tel.: 0351 - 31 85 00 Fax: 0351 - 3 18 50 10 info@d resden-elektron ik.de www.d resden-elektronik.de Seite 1 von 1

dresden elektronik Modular Approval Request Letter Date: 2020-02-21 FCC ID: XW-RASPBEE2 Type of Equipment: Limited Sinqle Modular The following requirements according to FCC Par|15.212 are met: i RF shielding The radio portion has no own shielding (see external photos). ii Buffered modulation/data inputs, has been integrated in the chipset iia Power supply regulation, is integrated iv Antenna requirements section 15.203, 15.204 b and 15.204 c The module comes with one permanently attached antennas. The spurious emission requirements are fulfilled (see attached test report). v Stand alone test configuration Please referring to test set up configuration photo vi Labelling The module has its own label. The instruction for labelling rules for the host device has been stated in the users manual vii Gompliance on specific rule or operating requirements The required FCC rules have been fulfilled and all instructions for maintaining compliance have been clearly stated in the user manual viii RF Exposure, RF exposure requirements are fulfilled for mobile configuration with minimum distance 20 cm. The installation of the module is restricted to minimum distance 20 cm, which is clearly stated in the installation instruction of the user manual. For applications with smaller distances OEM integrators need SAR evaluation and an own FCC lD. Andreas Palm Department Manager Wireless Products dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Str. 1 2 01237 Dresden, Germany .,.{l$.- \\il!')] dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Str. 1 2 01237 Dresden Tel.: 0351 - 31 85 00 Fax:0351 -3 18 50 10 [email protected] www. dresden-elektronik.de Seite 1 von I

G0M-1910-8555 FCC ID: XVV-RASPBEE2 IC: 8720A-RASPBEE2

Page No. : 12 Label Sample Exhibit Subject: Label Sample Date: 2020-01-10 FCC ID: XVV-RASPBEE2 Company name: dresden elektronik ingenieurtechnik gmbh Company Address: Enno-Heidebroek-Str. 12, 01237 Dresden, Germany

Page No. : 12 Label Location Exhibit Subject: Label Location Date: 2020-01-10 FCC ID: XVV-RASPBEE2 Company name: dresden elektronik ingenieurtechnik gmbh Company Address: Enno-Heidebroek-Str. 12, 01237 Dresden, Germany

G0M-1910-8555 FCC ID: XVV-RASPBEE2 IC: 8720A-RASPBEE2

Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 29 EMC TEST REPORT FCC 47 CFR Part 15B, ISED ICES-003 Issue 6 Report Reference No G0M-1910-8555-EF0115B-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant dresden elektronik ingenieurtechnik gmbh Address Enno-Heidebroek-Straße 12 01237 Dresden GERMANY Test Specification Standard(s) 47 CFR Part 15 Subpart B ISED ICES-003 Issue 6 ANSI C63.4:2014 Non-Standard Test Method None Equipment under Test (EUT): Product Description Zigbee Radio Module for Raspberry Pi Model(s) RaspBee II Additional Model(s) None Brand Name(s) None Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Test Result PASSED Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 29 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada T NOM Nominal operating temperature V NOM Nominal supply voltage Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 29 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-02-26 Initial Release Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 29 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Equipment Ports ............................................................................................................................................ 7 1.2 Equipment Photos ......................................................................................................................................... 8 1.3 Support Equipment ...................................................................................................................................... 10 1.4 Operational Modes ...................................................................................................................................... 10 1.5 EUT Configuration ....................................................................................................................................... 10 1.6 Sample emission level calculation ............................................................................................................... 11 2 Result Summary ............................................................................................................................... 12 2.1 Test Conditions and Results - Radiated emissions acc. to ANSI C63.4 ...................................................... 13 2.2 Test Conditions and Results - Conducted emissions acc. to ANSI C63.4 ................................................... 26 Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 29 1 Equipment (Test Item) Under Test Description Zigbee Radio Module for Raspberry Pi Model RaspBee II Additional Model(s) None Brand Name(s) None Serial Number(s) unspecified Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Class Class B Equipment type Table top Highest internal frequency [MHz] 2483.5 Supply Voltage V NOM 5 V DC (external power supply) AC/DC-Adaptor None Manufacturer dresden elektronik ingenieurtechnik gmbh Enno-Heidebroek-Straße 12 01237 Dresden GERMANY Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 29 1.1 Equipment Ports Name Type Attributes Comment POWER DC Count: Direction: Service only: 1 In No - UART IO Count: Direction: Service only: 1 IO No - I2C IO Count: Direction: Service only: 1 IO No - Description: AC AC mains power input/output port DC DC power input/output port BAT DC power input port connected to external battery IO Input/Output port TP Telecommunication port NE Non-electrical port Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 29 1.2 Equipment Photos EUT TOP SIDE EUT BOTTOM SIDE Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 29 EUT INSERTED IN EVALUATION BOARD Test Report No.: G0M-1910-8555-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 29 1.3 Support Equipment Product Type Device Manufacturer Model Comment AE Raspberry Pi Raspberry Pi Foundation Raspberry Pi 3 Host for EUT AE Conbee De - Companion device, ZigBee USB dongle MON Laptop Lenovo T450 - AE AC/DC-Adaptor 1 Lenovo ADLX45NDC3A - AE AC/DC-Adaptor 2 SAMSUNG ETA-U90EWE - Description: AE Auxiliary Equipment SIM Simulator MON Monitoring Equipment CBL Connecting Cable Comment: 1.4 Operational Modes Mode # Description 1 ZigBee Tx (EUT sends/receives permanent data packages to/from companion device via ZigBee connection) Comment: 1.5 EUT Configuration Configuration # Description 1 EUT is inserted in Raspberry Pi. EUT get power from Raspberry Pi. Raspberry Pi is powered up and powered with 5 V DC via USB connection from Laptop. Laptop is powered via AC/DC-Adaptor 1 with 120 V / 60 Hz external power supply. Conbee is connected with Laptop EUT sends permanent data packages to Conbee via ZigBee connection. Laptop is used for monitoring the sends and receives data packages. 2 E…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1910-8555-TFC247ZB-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 126 RADIO REPORT FCC 47 CFR Part 15C ISED Canada RSS-247 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No G0M-1910-8555-TFC247ZB-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant dresden elektronik ingenieurtechnik gmbh Address Enno-Heidebroek-Straße 12 01237 Dresden GERMANY Test Specification According to FCC/ISED rules Standard 47 CFR Part 15C RSS-247, Issue 2, 2017-02 RSS-Gen, Issue 5, Amendment 1, 2019-03 Non-Standard Test Method None Equipment under Test (EUT): Product Description Zigbee Radio Module for Raspberry Pi Model(s) RaspBee II Additional Model(s) None Brand Name(s) None Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Test Result PASSED Test Report No.: G0M-1910-8555-TFC247ZB-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 126 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-02-26 Initial Release Test Report No.: G0M-1910-8555-TFC247ZB-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 126 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description DSSS Direct Sequence Spread Spectrum EUT Equipment Under Test FCC Federal Communications Commission IEEE 802.15.4 MAC and PHY Layer for Wireless Personal Area Networks ISED Innovation, Science and Economic Development Canada O-QPSK Offset-Quadrature Phase Shift Keying QPSK Quadrature Phase Shift Keying RBW Resolution bandwidth RMS Root mean square VBW Video bandwidth V NOM Nominal supply voltage Test Report No.: G0M-1910-8555-TFC247ZB-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 126 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Photos – Equipment ...................................................................................................................................... 7 1.2 Photos – Test Setup ...................................................................................................................................... 9 1.3 Support Equipment ...................................................................................................................................... 12 1.4 Test mode duty cycle .................................................................................................................................. 13 1.5 Test Modes ................................................................................................................................................. 15 1.6 Test Frequencies ......................................................................................................................................... 16 1.7 Sample emission level calculation ............................................................................................................... 17 2 Result Summary ............................................................................................................................... 18 3 Test Conditions and Results .......................................................................................................... 19 3.1 Test Conditions and Results - Occupied bandwidth .................................................................................... 19 3.2 Test Conditions and Results - 6 dB bandwidth ............................................................................................ 28 3.3 Test Conditions and Results - Maximum peak conducted output power ..................................................... 38 3.4 Test Conditions and Results - Power spectral density ................................................................................ 40 3.5 Test Conditions and Results - AC powerline conducted emissions ............................................................. 50 3.6 Test Conditions and Results - Band-edge compliance ................................................................................ 52 3.7 Test Conditions and Results - Conducted spurious emissions .................................................................... 60 3.8 Test Conditions and Results - Transmitter radiated emissions ................................................................... 70 3.9 Test Conditions and Results - Receiver radiated emissions ....................................................................... 75 ANNEX A Transmitter spurious emissions ....................................................................................................... 78 ANNEX B Receiver spurious emissions ......................................................................................................... 117 Test Report No.: G0M-1910-8555-TFC247ZB-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 126 1 Equipment (Test Item) Under Test Description Zigbee Radio Module for Raspberry Pi Model RaspBee II Additional Model(s) None Brand Name(s) None Serial Number(s) None Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 PMN RaspBee II HVIN RaspBee II FVIN N/A HMN N/A FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Equipment type Radio Module Radio type Transceiver Assigned frequency bands 2400 - 2483.5 MHz Radio technology IEEE 802.15.4 Modulation O-QPSK Number of antenna ports 1 Antenna Type Integrated Model PCB antenna Manufacturer dresden elektronik Gain -0.26 dBi (antenna pattern measurement) Supply Voltage V NOM 5.0 VDC Operating Temperature T …

Text truncated - open the document above for the full version.

Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 14 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1091 ISED RSS-102 Maximum permissible exposure Report Reference No G0M-1910-8555-TFC091MP-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant dresden elektronik ingenieurtechnik gmbh Address Enno-Heidebroek-Straße 12 01237 Dresden GERMANY Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1091 ISED RSS-102 Non-Standard Test Method None Equipment under Test (EUT): Product Description Zigbee Radio Module for Raspberry Pi Model(s) RaspBee II Additional Model(s) None Brand Name(s) None Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Test Result PASSED Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 14 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-01-30 Initial Release Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 14 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power EUT Equipment Under Test MPE Maximum Permissible Exposure Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 14 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Power density radiation sources.................................................................................................................... 8 1.3 Field strength radiation sources .................................................................................................................... 8 1.4 Concurrent Sources ...................................................................................................................................... 8 2 Result Summary ................................................................................................................................. 9 3 RF-Exposure classification ............................................................................................................ 10 4 RF-Exposure limits .......................................................................................................................... 11 5 RF-Exposure Evaluation ................................................................................................................. 12 6 Single Source Evaluation Results - FCC ...................................................................................... 13 7 Single Source Evaluation Results - ISED ..................................................................................... 14 Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 14 1 Equipment (Test Item) Under Test Description Zigbee Radio Module for Raspberry Pi Model RaspBee II Additional Model(s) None Brand Name(s) None Serial Number(s) Not specified (Test Sample ID 26334) Hardware Version(s) 5 770 19 00.150.00 Software Version(s) 0 PMN RaspBee II HVIN RaspBee II FVIN N/A HMN N/A FCC-ID XVV-RASPBEE2 IC 8720A-RASPBEE2 Equipment type End Product Environment General public Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 14 1.1 Reference Documents Document Type Document No. Issued by Date Test Report (Radio) – FCC 47 CFR Part 15C + ISED RSS-247, Issue 2, February 2017 – IEEE 802.15.4 G0M-1910-8555- TFC247ZB-V01 Eurofins Product Service GmbH 2020-01-06 Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 14 1.2 Power density radiation sources Mode Operating Frequency [MHz] Maximum conducted power [dBm] Maximum radiated power [dBm EIRP] Maximum duty cycle [%] Maximum antenna gain [dBi] Maximum antenna diameter [cm] IEEE 802.15.4 (2.4 GHz) – Data rate = 250 kbps 2405 8.991 8.731 100 -0.26 N/A IEEE 802.15.4 (2.4 GHz) – Data rate = 2000 kbps 2405 9.061 8.801 100 -0.26 N/A Comment: None. 1.3 Field strength radiation sources None. 1.4 Concurrent Sources No concurrent radiation sources. Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 14 2 Result Summary FCC MPE Evaluation - Single radiation sources Product Standard Reference Requirement Reference Method Mode Distance [m] Verdict 47 CFR 2.1091 Maximum permissible exposure FCC KDB 447498 IEEE 802.15.4 (2.4 GHz) – Data rate = 250 kbps 0.20 PASS 47 CFR 2.1091 Maximum permissible exposure FCC KDB 447498 IEEE 802.15.4 (2.4 GHz) – Data rate = 2000 kbps 0.20 PASS Comment: None. ISED MPE Evaluation - Single radiation sources Product Standard Reference Requirement Reference Method Mode Distance [m] Verdict ISED RSS-102 Maximum permissible exposure ISED RSS-102 IEEE 802.15.4 (2.4 GHz) – Data rate = 250 kbps 0.20 PASS ISED RSS-102 Maximum permissible exposure ISED RSS-102 IEEE 802.15.4 (2.4 GHz) – Data rate = 2000 kbps 0.20 PASS Comment: None. Test Report No.: G0M-1910-8555-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 14 3 RF-Exposure classification RF-Exposure Categories Fixed A fixed device is defined as a dev…

Text truncated - open the document above for the full version.

G0M-1910-8555 FCC ID: XVV-RASPBEE2 IC: 8720A-RASPBEE2
