XYO-LM190Wi-Fi Halow Module

V1.4 Page 1 of 8 ATEL 900MHz Wi-Fi Halow Module —LM190 V1.4 Confidential Material: This document contains information that is proprietary and confidential, reading and copying this document is prohibited without permission from Asiatelco Technologies Co. V1.4 Page 2 of 8 1 Introduction LM190 is 900MHz Wi-Fi Halow IEEE 802.11ah Module, based on Morsemicro MM6108CQ chipset. Key function as below 1） Based on Morsemicro chipset MM6108CQ, 2） Supports 802.1ah 3） Support USA market（frequency range 902MHz~928MHz 4) Support SDIO/SPI, GPIOs interfaces 5) MIMO 1*1 Product model definition: Product Band DC Power Chipset LM190 902MHz~928MHz 3.3V and 5.0V Morsemicro MM6108CQ V1.4 Page 3 of 8 2 Spec overview Item Description Network Wi-Fi Halow Support Frequency Range 902MHz~928MHz Platform Morsemicro MM6108CQ Dimension Type LGA Dimension Same with current GM02S module Connector LGA Weight <30g Color Blue Hardware info CPU Morsemicro MM6108CQ Power supply 3.0V~3.6V， Type-3.3V USB Not Support SDIO Support RF connector PCB PAD Memory Integrate MM6108CQ chipset DDR NA NOR flash NA NAND NA USIM Not Support Working Current <750mA Idle current <15mA（TBD） V1.4 Page 4 of 8 3 Silkscreen 3.1 PCB Silkscreen & Color Item Requirement PCB Blue PCB version Required PCB ATTN Required Other No 3.2 Label Item Requirement Label color White Label Dimension 25*20*0.1mm（TBD） Company Required ,“ATEL” TYPE Required ,“LM190” IMEI Required , SN Required , Certification No Made in China Required , Other No 4 Hardware requirement 4.1 Basic Wireless performance Wi-Fi Halow Support WLAN Protocol IEEE 802.11ah Frequency Range 902MHz~928MHz Platform Morsemicro MM6108CQ Bandwidth 1, 2,4,8MHz Modulation OFDM, BPSK, QPSK, 16QAM, 64QAM Encryption Mode AES, SHA-256, SHA-384, SHA-512, WPA3 Working mode AP/STA V1.4 Page 5 of 8 Throughput Max throughput 8MHz BW（MCS7） 32.5Mbps 4.2 Power supply Voltage Range 3.3V and 5.0V 3.3V range:3.0V ～ 3.6V 5.0V range:4.2V~5.5V Safety information: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2)This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. V1.4 Page 6 of 8 —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. FCC Statement Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ⚫ Reorient or relocate the receiving antenna. ⚫ Increase the separation between the equipment and receiver. ⚫ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ⚫ Consult the dealer or an experienced radio/TV technician for help The device must not be co-located or operating in conjunction with any other antenna or transmitter. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Does not comply with the use restrictions of the product: Portable devices used close with human’s body (within 20cm), Like Cell phone, Notebook etc. Integration instructions for host product manufacturers according to KDB 996369 D03 V1.4 Page 7 of 8 OEM Manual v01 2.2 List of applicable FCC rules FCC Part 15 Subpart C 15.247 & 15.209 2.3 Specific operational use conditions The module can be used for mobile applications with a maximum 1.27dBi antenna. The host manufacturer installing this module into their product must ensure that the final compos it product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, User Manual_LM190_0917.pdf including the transmitter operation. The host manufacturer has to be aware not to provide …

Text truncated - open the document above for the full version.

(Asiatelco Technologies Co.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-5-2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: XYO-LM190 [Asiatelco Technologies Co.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Asiatelco Technologies Co.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Ella Chen (Asiatelco Technologies Co.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-05-2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: XYO-LM190 [Asiatelco Technologies Co.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Ella Chen

[Asiatelco Technologies Co.] [#289 Bisheng Road, Building-8, 3F, Zhang jiang Hi-Tech Park, Pudong, Shanghai 201204, China] Date: [2025/12/12] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: [XYO-LM190] FRN: 0032571200 US Agent – Attestation Statement / Part 2.911(d)(7) [Asiatelco Technologies Co.] certifies, that as of [2025/12/12], we have designated Asiatelco Technologies Inc.to accept service of process on our behalf for FCC ID: [XYO-LM190]. [Asiatelco Technologies Inc.], accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. Asiatelco Technologies Inc., accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Asiatelco Technologies Co.] for FCC ID: [XYO-LM190]. Designated Agent Information: Company Name: Asiatelco Technologies Inc. FRN: 0029986338 Address: 4611 Teller Avenue, Suite 110, Newport Beach, CA 92660, USA Contact Person: Ella Chen Telephone: (949)398-6408 Email: [email protected] Sincerely, Company: [Asiatelco Technologies Co.] Designated Agent: Asiatelco Technologies Inc. Company Representative: [Ella Chen] Designated Agent Representative: Ella Chen Signature: Signature:

Asiatelco Technologies Co. Declaration of the Modular Approval Applicant / Grantee Asiatelco Technologies Co. FCC ID: XYO-LM190 Model: LM190 The single module transmitter has been evaluated then tested meeting the requirements under Part 15C Section 212 as below: Modular approval requirement EUT Condition Comply (a) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio elements of the modular transmitter have their own shielding. YES (b) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. The modular has buffered data inputs, it is integrated in chip. Please see schematic.pdf YES (c)The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to LM190. Please see schematic.pdf YES (d) The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Device uses a micro-strip trace on the host’s printed circuit board to an antenna connector on the host circuit board. YES (e)The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted LM190 was tested in a stand‐alone configuration via a PCMCIA extender. Please see spurious set‐up YES Asiatelco Technologies Co. requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)) must not be in side another device during testing. (f)The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. The label position of LM190 is clearly indicated. If the FCC ID of the module cannot be seen when it is installed, then the host label must include the text: Contains FCC ID:XYO- LM190,Please see the label.pdf YES (g) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization requirements, which are based on the intended use/configurations. LM190 is compliant with all applicable FCC rules. Detail instructions are given in the User Manual. YES (h)The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. LM190 is approved to comply with the applicable RF exposure requirement, please see the MPE evaluation with 20cm as the distance restriction. YES Printed Name of Signee: Ella Chen Company: Asiatelco Technologies Co. Asiatelco Technologies Co. Phone: +86-21-51688806 Email: [email protected]

Asiatelco Technologies Co. Request for Confidentiality Date: December 5, 2025 Subject: Confidentiality Request for: FCC ID: XYO-LM190 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Schematics Short Term Permanent FCC SW SECURITY DESCRIPTION Short Term Permanent Tune Up Information Short Term Permanent Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Asiatelco Technologies Co. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of _______days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TCB in the event information regarding the product or the product is made available to the public. TCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, Signature: Printed Name of Signee: Ella Chen Company: Asiatelco Technologies Co. Phone: +86-21-51688806 Email: [email protected] Asiatelco Technologies Co. Job title: Certification Manager

Asiatelco Technologies Co. POWER OF ATTORNEY DATE: 2025-12-5 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize Eurofins TA Technology (Shanghai) Co., Ltd / Freda Shou on our behalf, to apply to FCC on our equipment for FCC ID: XYO-LM190. Any and all acts carried out by Eurofins TA Technology (Shanghai) Co., Ltd / Freda Shou on our behalf shall have the same effect as acts of our own. Sincerely, Signature： Printed Name of Signee: Ella Chen Company: Asiatelco Technologies Co. Phone: +86-21-51688806 Email: [email protected] Job title: Certification Manager

EUT Appearance Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 1 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance EUT Appearance Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 2 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Antenna EUT Appearance Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 3 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Picture 1: Constituents of EUT

Internal photo FCC ID: XYO-LM190 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 1 of 1 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo

Prepared by: Liu Wei Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 EMC TEST REPORT Applicant Asiatelco Technologies Co. FCC ID XYO-LM190 Product Wi-Fi Halow Module Brand ATEL Model LM190 Report No. EFTA25090219-IE-01-E1 Issue Date December 5, 2025 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC Code CFR47 Part15B (2024)/ ANSI C63.4-2014. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Test Report Report No.: EFTA25090219-IE-01-E1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 2 of 23 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ................................................................................................................................. 4 1.1 Notes of the Test Report ............................................................................................................ 4 1.2 Test Facility ................................................................................................................................ 4 1.3 Testing Location......................................................................................................................... 4 2 General Description of Equipment Under Test ................................................................................. 5 2.1 Applicant and Manufacturer Information ................................................................................... 5 2.2 General Information ................................................................................................................... 5 2.3 Applied Standards ..................................................................................................................... 6 2.4 Test Mode .................................................................................................................................. 7 3 Test Case Results ............................................................................................................................. 8 3.1 Radiated Emission ..................................................................................................................... 8 3.2 Conducted Emission ................................................................................................................ 15 4 Uncertainty Measurement ............................................................................................................... 20 5 Main Test Instruments ..................................................................................................................... 21 6 The EUT Appearance ...................................................................................................................... 22 7 Test Setup Photos ........................................................................................................................... 23 Test Report Report No.: EFTA25090219-IE-01-E1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 3 of 23 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Summary of measurement results Number Test Case Clause in FCC Rules Conclusion 1 Radiated Emission FCC Part15.109, ANSI C63.4-2014 PASS 2 Conducted Emission FCC Part15.107, ANSI C63.4-2014 PASS Date of Testing: September 24, 2025 ~ October 16, 2025 Date of Sample Received: September 12, 2025 Note: All indications of Pass/Fail in this report are opinions expressed by Eurofins TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. Test Report Report No.: EFTA25090219-IE-01-E1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 4 of 23 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2 Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. A2LA (Certificate Number: 3857.01) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform measurement. 1.3 Testing Location Company: Eurofins TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: https://www.eurofins.com/electrical-and-electronics E-mail: [email protected] Test Report Report No.: EFTA25090219-IE-01-E1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 5 of 23 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 2 General Description of Equipment Under Test 2.1 Applicant and Manufacturer Information Applicant Asiatelco Technologies Co. Applicant address #289 B…

Text truncated - open the document above for the full version.

EMC Test Setup Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-031E Page 1 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Part 15B EMC Test Setup Antenna 1 30MHz-1GHz 1GHz-18GHz EMC Test Setup Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-031E Page 2 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Antenna 2 30MHz-1GHz 1GHz-18GHz Picture 1: Radiated Emission Test Setup EMC Test Setup Report No.: EFTA25090219-IE-01 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-031E Page 3 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Antenna 1 Antenna 2 Picture 2: Conducted Emissions Test Setup
