Y35-9820011Keyboard

NUMBER SLIDE Mini Keyboard with Retractable Number Pad The Number Slide’s retractable number pad slides out when you need it and away when you’re finished. This feature delivers important ergonomic advantages over conventional keyboards. Number Slide reduces the distance you need to reach to operate your mouse, which allows you to adopt a more comfortable posture. The mouse can be positioned in front of the left or right shoulder (depending on your dominant hand), which facilitates a better posture in the arm and shoulder when using your mouse. Being so compact, Number Slide frees up more space at your workstation so you can bring work closer to your midline but does not compromise on functionality. ERGONOMICS x WIRED VERSION 1. Insert USB cable into a spare USB port on your computer 2. There are two auxiliary USB ports on the rear of the keyboard for use with peripherals Warning lights a. Number lock (Number Lock key found on slide out number pad) b. Caps lock c. Scroll lock BLUETOOTH VERSION With built in rechargeable Li-ion battery To pair with a Windows® PC 1. Turn on Bluetooth via the Control Panel on your PC and search for devices 2. On the keyboard rear edge, slide the keyboard ON/OFF switch to the ON position 3. Press the ‘CONNECT’ button on the rear edge. The power light should flash until pairing is complete 4. On your PC control panel, select Posturite KB Number Slide 5. To un-pair at any time, simply delete from the list of Bluetooth items USB ports (Wired version) PowerConnect (Bluetooth pairing) (a) Tab - pull gently to slide out number pad (b) (c) To pair with an Apple® Mac Please note on Mac the number keys are permanently active, so Number Lock will not operate. 1. Select ‘Bluetooth’ from the System Preferences menu on your Mac 2. On the keyboard rear edge, slide the keyboard ON/OFF switch to the ON position 3. Press the ‘CONNECT’ button on the rear edge of the keyboard. The power light should flash until pairing is complete 4. On your Mac’s Bluetooth window find ‘Posturite KB Number Slide’ and click ‘Pair’ 5. To un-pair at any time, simply delete from the list of Bluetooth items To pair with an Apple® iPad or iPhone 1. Make sure Bluetooth is turned on on your iOS device and keyboard is on 2. Press the ‘CONNECT’ button on the rear edge. The power light should flash until pairing is complete 3. In the Bluetooth section on the iPad, select the ‘Posturite KB Number Slide’ 4. You’ll be asked to type a pairing code on the keyboard - if it’s entered successfully, your keyboard will be paired with the iOS device 5. Note that when you are using the Bluetooth keyboard, the normal iOS keyboard does not appear - turn off to return to using the onscreen keyboard Warning lights a. Number lock (Number Lock key found on slide out number pad) b. Caps lock c. Power light - Charge Number Slide when light flashes or remains on Charging When voltage is low, the battery light will flash. This means that your keyboard needs charging. 1. Insert the USB end into a USB port directly into your computer (do not use a multi-port hub) and the micro USB end into the back of your Bluetooth Number Slide Keyboard 2. While charging the red LED light will remain on 3. When charged the red LED light turn off (Approx 2 hours) Sleep function After 5 minutes of inactivity the battery will enter a power-saving sleep mode. Press any key to wake up the keyboard. For up to date support please visit www.posturite.co.uk/numberslide Specifications Bluetooth Li-ion rechargeable battery. Bluetooth version: 3.0 Operating distance: 10m System model: GFSSK 2.4G Working voltage: 3-5V Working current: 1.5mA Battery: 300mA/h Charging voltage: 4.2V Charging current: 180mA Charging time: Approx. 2 hours ™ ™ © 2015 Posturite Ltd. All Rights Reserved. Posturite, the logo design, are registered trademarks of Posturite Ltd. Posturite Ltd, The Mill, Berwick, East Sussex BN26 6SZ, UK +44 (0)845 345 0010 www.posturite.co.uk GFSK 2.4G FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC STATEMENT This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (…

Text truncated - open the document above for the full version.

Posturite LTD The Mill, Berwick, East Sussex, BN26 6SZ,UK Berwick United Kingdom 2015-9 -0 9 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: Y35-9820011 Product Name: Keyboard Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 9/09/2015 By: Petrides R J Signature Printed Title: Manager On behalf of : Posturite LTD Telephone: 0845 345 0010

Differences Declaration To whom concern, We company Posturite LTD hereby declares: The product model(s) 9820013 is identical in the same PCB layout, interior structure and electrical circuits with the model 9820011 which tested in Global Unit Technology Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Date: 2015-9- 09

Posturite LTD The Mill, Berwick, East Sussex, BN26 6SZ,UK Berwick United Kingdom DATE :2015-9 -0 9 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank.Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Posturite LTD and The Mill, Berwick, East Sussex, BN26 6SZ,UK Berwick United Kingdom Dated this / Day of 9/09/2015 / Agency agreement expiration date: 9/09/2016 By: Petrides R J Signature Printed Title: Manager On behalf of : Posturite LTD Telephone: 0845 345 0010

Label Location

FCC ID: Y35-9820011 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) --- 3m So pt = (EXd) 2 /30 x gt Field strength = 95.86dBuV/m @3m Ant gain =2dBi, so Ant numeric gain= 1.58 So pt={ [10 (95.86/20) /10 6 x 3] 2 /30x1.58 }x1000 mW = 0.730mW So (0.730mW /5mm)x √2.402 = 0.226<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15080166301 FCC REPORT Applicant: Posturite LTD Address of Applicant: The Mill, Berwick, East Sussex, BN26 6SZ,UK Berwick United Kingdom Equipment Under Test (EUT) Product Name: Keyboard Model No.: 9820011, 9820013 Trade Mark: Posturite FCC ID: Y35-9820011 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: August 27, 2015 Date of Test: August 28-September 02, 2015 Date of report issued: September 06, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Robinson Lo Report No.: GTSE15080166301 2Version Version No.DateDescription 00September 06, 2015Original Prepared By: Date: September 06, 2015 Project Engineer Check By:Date: September 06, 2015 Reviewer Global United Technology Services Co., Ltd.Project No.: GTSE150801663RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 30 Report No.: GTSE15080166301 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................25 Global United Technology Services Co., Ltd.Project No.: GTSE150801663RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industr…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emissions
