Y44-X170GOLASER SCANNER

38mm15mm 28mm 4mm 标签文字部分颜色为RAL7011 FCC ID: Y44-X170GO

Guangdong Dongdian Testing Service Co., Ltd. Report No.: DDT-RE26031615-2E05 TRF No.: RT-4-E-02-601 FCC SAR Test Report Ver.1.1 Page 1 of 29 FCC SAR TEST REPORT Applicant : STONEX SRL Address of Applicant : via dei Mille 4, 20900 Monza-MB, Italy Manufacturer : STONEX SRL Address of Manufacturer : via dei Mille 4, 20900 Monza-MB, Italy Equipment under Test : LASER SCANNER Model No. : X170GO FCC ID : Y44-X170GO Test Standard(s) : Test Standard Used: IEEE Std. 1528-2013, IEC/IEEE 62209-1528:2020 FCC Rules and Regulations: 47 CFR § 2.1093 KDB447498 D02 v02r01, KDB447498 D04 v01, KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 248227 D01 v02r02 Report No. : DDT-RE26031615-2E05 Issue Date : 2026/05/18 Issue By : Guangdong Dongdian Testing Service Co., Ltd. Address of Laboratory : Unit 2, Building 1, No. 17, Zongbu 2nd Road, Songshan Lake Park, Dongguan, Guangdong, China, 523808 Guangdong Dongdian Testing Service Co., Ltd. Report No.: DDT-RE26031615-2E05 TRF No.: RT-4-E-02-601 FCC SAR Test Report Ver.1.1 Page 2 of 29 Table of Contents 1.General test information .....................................................................................................6 1.1.Description of EUT .............................................................................................................6 1.2.Accessories of EUT ............................................................................................................6 1.3.Assistant equipment used for test ......................................................................................6 1.4.Block diagram of EUT configuration for test .......................................................................7 1.5.Test environment conditions...............................................................................................7 1.6.Test laboratory....................................................................................................................7 2.Summary of test results ......................................................................................................8 2.1.Report SAR results .............................................................................................................8 2.2.RF exposure limits ..............................................................................................................8 3.SAR measurements system configuration .........................................................................9 3.1.The SAR measurement system..........................................................................................9 3.2.Isotropic E-field probe EX3DV4 ........................................................................................10 3.3.SAM twin phantom ...........................................................................................................10 3.4.ELI phantom .....................................................................................................................11 3.5.Data acquisition electronics (DAE) ...................................................................................11 3.6.Device holder for transmitters...........................................................................................12 4.Measurement procedure ..................................................................................................13 4.1.Scanning procedure .........................................................................................................13 5.Description of test position ...............................................................................................17 5.1.Body-worn accessory configurations ................................................................................17 5.2.Extremity exposure configurations ...................................................................................18 5.3.Head exposure configurations ..........................................................................................18 6.RF exposure conditions ....................................................................................................19 6.1.EUT Test sides .................................................................................................................19 6.2.Standalone SAR test exclusion considerations ................................................................19 7.SAR system verification procedure ..................................................................................20 7.1.Tissue simulate liquid .......................................................................................................20 7.1.1.Target dielectric properties of head tissue-equivalent material ........................................20 7.1.2.Measurement for tissue simulate liquid ............................................................................20 7.2.SAR system validation......................................................................................................22 7.2.1.Justification for extended SAR dipole calibrations............................................................22 7.2.2.Validation test setup photograph ......................................................................................23 7.2.3.Summary system validation results ..................................................................................24 7.2.4.Detailed system validation results ....................................................................................24 8.Equipment list ...................................................................................................................25 Guangdong Dongdian Testing Service Co., Ltd. Report No.: DDT-RE26031615-2E05 TRF No.: RT-4-E-02-601 FCC SAR Test Report Ver.1.1 Page 3 of 29 9.Measurement uncertainty .................................................................................................26 10.Measurement of Body SAR data ........................................................................…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 1 of 3 Appendix A System Validation Plots Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 2 of 3 Table of Contents 1. D2450V2-SN: 904 Validation Plot ..................................................................................... 3 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 3 of 3 1. D2450V2-SN: 904 Validation Plot

Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 1 of 3 Appendix B Highest Test Plots Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 2 of 3 Table of Contents 1. 2.4G Body-worn 0mm SAR .................................................................................................... 3 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 3 of 3 1. 2.4G Body-worn 0mm SAR

Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 1 of 30 Appendix C Calibration Certification Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 2 of 30 Table of Contents 1. D2450V2-SN: 904 Calibration certification ............................................................................. 3 2. D5GHzV2-SN: 1148 Calibration certification .......................................................................... 9 3. DAE4-SN: 1366 Calibration certification............................................................................... 19 4. EX3DV4-SN: 3906 Calibration certification .......................................................................... 22 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 3 of 30 1. D2450V2-SN: 904 Calibration certification Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 4 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 5 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 6 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 7 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 8 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 9 of 30 2. D5GHzV2-SN: 1148 Calibration certification Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 10 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 11 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 12 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 13 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 14 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 15 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 16 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 17 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 18 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 19 of 30 3. DAE4-SN: 1366 Calibration certification Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 20 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 21 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 22 of 30 4. EX3DV4-SN: 3906 Calibration certification Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 23 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 24 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 25 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 26 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 27 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 28 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 29 of 30 Guangdong Dongdian Testing ServiceCo.,Ltd. Report No.: DDT-RE26031615-2E05 Page 30 of 30

Guangdong Dongdian Testing ServiceCo.,Ltd. Page 1 of 11 Appendix E Dipole Antenna self-calibration Guangdong Dongdian Testing ServiceCo.,Ltd. Page 2 of 11 Table of Contents 1. Calibration Date ...................................................................................................................... 3 2. Calibration Items ..................................................................................................................... 3 3. Standards ................................................................................................................................ 7 4. Laboratory ............................................................................................................................... 7 5. Calibration Results .................................................................................................................. 7 6. Appendix ................................................................................................................................. 8 Guangdong Dongdian Testing ServiceCo.,Ltd. Page 3 of 11 1. Calibration Date Calibration Date Feb.23,2026, Due to Feb.22,2027 2. Calibration Items Dipole Antenna self-calibration 1、 Calibration Method Immediate re-calibration is required for the following conditions. 1) According to KDB 865664 D01, When the most recent return-loss result, measured at least annually, deviates by more than 20% from the previous measurement (i.e. value in dB  0.2) or not meeting the required 20 dB minimum return-loss requirement. 2) When the most recent measurement of the real or imaginary parts of the impedance, measured at least annually, deviates by more than 5 Ω from the previous measurement. 3）When the measured SAR deviates from the calibrated SAR value by more than 10% due to changes in physical, mechanical, electrical or other relevant dipole conditions; i.e., the error is not introduced by incorrect measurement procedures or other issues relating to the SAR measurement system. 2、 Calibration Purpose Demonstrate that SAR target, the impedance and return loss of the dipole remain stable as required 3、 Test The Product Manufacturer Speag Name 1900MHz Dipole antenna Model number D1900V2 Environment temperature 22.5°C Look pictures As shown in figure 1 Manufacturer Speag Name 2450MHz Dipole antenna Model number D2450V2 Environment temperature 22.5°C Look pictures As shown in figure 2 Guangdong Dongdian Testing ServiceCo.,Ltd. Page 4 of 11 Manufacturer Speag Name 5GHz Dipole antenna Model numbe D5GHZV2 Environment temperature 22.5°C Look pictures As shown in figure 3 Guangdong Dongdian Testing ServiceCo.,Ltd. Page 5 of 11 Figure 1 Test signal source Figure 2 Test signal source Guangdong Dongdian Testing ServiceCo.,Ltd. Page 6 of 11 Figure 3 Test signal source Guangdong Dongdian Testing ServiceCo.,Ltd. Page 7 of 11 3. Standards This antenna calibration is conducted according to KDB 865664 D01 4. Laboratory The following personnel participated in this laboratory: Table 1： Participate in the measurement laboratory Laboratory Name Temp°C Test person Guangdong Dongdian Testing Service Co., Ltd. 22.5°C Johnson Huang 5. Calibration Results The quality control test results are shown in Table 2 and Table 3, and the detailed test data is in the Appendix. Table 2 Calibrated Antenna Target Return loss Test Return loss Deviation Result 1900 -25.239 -28.615 -13.38% Pass 2450 -29.342 -27.398 6.63% Pass 5200 -22.307 -24.392 -9.35% Pass 5300 -24.020 -22.804 5.06% Pass 5500 -25.127 -27.433 -9.18% Pass 5600 -23.627 -25.494 -7.90% Pass 5800 -22.061 -22.015 0.21% Pass Table 3 Calibrated Antenna Target Impedance （Real） Target Impedance （Imaginary） Test Impedance （Real） Test Impedance （Imaginary） Deviation （Real） Ω Deviation （Imaginary） Ω Result 1900 51.139 5.4224 48.982 3.5296 -2.157 -1.8928 Pass 2450 52.591 2.3537 49.150 4.1479 -3.441 1.7942 Pass 5200 49.512 -7.6366 47.671 -5.4209 -1.841 2.2157 Pass 5300 48.960 -6.1547 45.870 -5.5950 -3.09 0.5597 Pass 5500 53.939 -4.2094 54.184 -1.4493 0.245 2.7601 Pass 5600 56.654 -2.2552 54.407 -3.3729 -2.247 -1.1177 Pass 5800 57.008 -4.7182 57.485 -4.0893 0.477 0.6289 Pass Guangdong Dongdian Testing ServiceCo.,Ltd. Page 8 of 11 6. Appendix Guangdong Dongdian Testing ServiceCo.,Ltd. Page 9 of 11 Guangdong Dongdian Testing ServiceCo.,Ltd. Page 10 of 11 Guangdong Dongdian Testing ServiceCo.,Ltd. Page 11 of 11 END

公司地址：深圳市龙岗区宝龙街道沙背坜鸿永利工业区H栋 BuildingH,Hong Yongli Industrial Zone, ShabeiLi, BaoLong Sub-district,Longgang District, Shenzhen City TEL:0755-28700870FAX：0755-28483275 第 1 页 共 3 页 规 格 书 客户名称： 客户料号：Dual-frequency black soft built-in antenna 科信料号： 规格描述：双频黑色软内置/1.13线L=200MM(1代端子) 制作日期：2023年05月05日 出厂确认： 部 门 审 核 批 准 射 频 部 刘 景 雄 李 斌 结构部谢东展李斌 品 质 部 王 飞 李 斌 客 户 确 认 ： 检 查 审 核 批 准 Shenzhen Kexin Wireless Technology Co., Ltd. 公司地址：深圳市龙岗区宝龙街道沙背坜鸿永利工业区H栋 BuildingH,Hong Yongli Industrial Zone, ShabeiLi, BaoLong Sub-district,Longgang District, Shenzhen City TEL:0755-28700870FAX：0755-28483275 第 2 页 共 3 页 1.产品图片 photo： 2．电气性能测试报告Electrical PerformanceTest Report：VSWR： 公司地址：深圳市龙岗区宝龙街道沙背坜鸿永利工业区H栋 BuildingH,Hong Yongli Industrial Zone, ShabeiLi, BaoLong Sub-district,Longgang District, Shenzhen City TEL:0755-28700870FAX：0755-28483275 第 3 页 共 3 页 3． 产品性能参数 Product performance parameters： 电 性 能 指 标 E l e c t r i c a l S p e c i f i c a t i o n s 频 率 范 围 F r e q u e n c y R a n g e ( M H z ) 2 4 0 0 - 2 5 0 0 / 5 1 5 0 - 5 8 5 0 输 入 阻 抗 I n p u t I m p e n d e n c e ( Ω ) 5 0 电 压 驻 波 比 V . S . W . R ≤ 2 . 0 （ 未 匹 配 设 备 ， 仅 供 参 考 ） 增 益 G a i n ( d B i ) 3 . 0 ± 0 . 5 （ 未 匹 配 设 备 ， 仅 供 参 考 ） 极 化 形 式 P o l a r i z a t i o n T y p e 垂 直 V e r t i c a l 最大功率 Maximumpower(W) 10W 垂 直 面 波 瓣 角 度 V e r t i c a l l o b e A n g l e （ E ） 4 5 ~ 6 0 ° 水 平 面 波 瓣 角 度 W a t e r p l a n e l o b e A n g l e （ H ） 3 6 0 ° 机 械 指 标 M e c h a n i c a l S p e c i f i c a t i o n s 天 线 材 质 M a t e r i a l F P C 连 接 器 型 号 C o n n e c t T y p e I P E X ( 1 代 ) 天 线 尺 寸 S i z e 5 0 * 1 4 * 0 . 3 M M 工 作 温 度 O p e r a t i n g T e m p - 2 0 ~ + 6 5 ̊ C 储 存 温 度 S t o r a g e T e m p - 3 0 ~ + 7 5 ̊ C Frequency ID1234567891011121314151617181920212223242526272829303132333435363738394041424344454647 Frequency (MHz)2400.02410.02420.02430.02440.02450.02460.02470.02480.02490.02500.05150.05170.05190.05210.05230.05250.05270.05290.05310.05330.05350.05370.05390.05410.05430.05450.05470.05490.05510.05530.05550.05570.05590.05610.05630.05650.05670.05690.05710.05730.05750.05770.05790.05810.05830.05850.0 Efficiency (dBi)-3.99-3.91-3.85-3.86-3.83-3.76-3.80-3.74-3.55-3.40-3.10-4.38-4.61-4.74-4.68-4.59-4.50-4.32-4.31-4.47-4.44-4.33-4.25-3.80-3.61-3.75-3.78-3.89-3.87-3.48-3.30-3.23-3.26-3.44-3.63-3.66-3.55-3.46-3.39-3.36-3.49-3.67-3.74-3.91-3.99-3.93-3.95 Gain (dBi)1.101.060.990.900.901.031.091.261.641.872.07-0.08-0.21-0.35-0.29-0.13-0.160.290.440.390.350.380.460.941.271.451.641.521.471.711.772.082.442.472.392.242.192.192.322.492.562.492.281.761.501.401.39 Efficiency (%)39.8840.6641.2441.1541.4142.1041.7342.2944.1145.6848.9636.4834.5833.5634.0734.7735.4937.0237.0735.7335.9436.8637.6141.6643.5942.1841.8640.7940.9844.8246.7647.5047.2345.3243.3443.0444.2045.1245.8446.1044.8242.9342.2440.6839.8940.4540.27 Directivity (dB)5.094.974.834.754.734.784.885.005.195.275.174.304.404.394.384.464.344.604.754.864.794.714.704.754.875.205.425.415.345.195.075.315.695.916.025.905.745.655.705.856.046.166.025.675.505.335.34 Peak Gain Position (Theta)57.0057.0057.0057.0058.0058.0059.0059.0059.0059.0060.0096.0096.00139.00103.00104.00105.00139.00139.00139.00139.00133.00105.00105.00140.00139.00139.00138.00134.00134.00146.00145.00141.00141.00141.00142.00146.00145.00145.00144.00144.00145.00145.00144.00140.00139.00140.00 Peak Gain Position (Phi)214.00214.00214.00214.00215.00216.00216.00186.00184.00186.00187.00211.00217.00131.00120.00116.00114.00136.00138.00140.00141.00181.00117.00119.00140.00145.00147.00151.00186.00188.00103.00105.00143.00143.00144.00142.00103.00102.00102.00106.00107.00103.00101.00100.00152.00155.00150.00 Efficiency ThetaPol (%)30.6731.3431.8531.8332.1232.6632.3132.6433.9135.0037.3632.3230.7229.7730.1530.8331.5232.9533.0531.9032.1433.0433.7737.3038.9437.6637.4036.4336.5239.8441.3541.9141.7140.1038.3137.9738.9439.7740.4540.6639.4437.8037.2335.9335.3235.9135.85 Efficiency PhiPol (%)9.219.339.399.319.299.449.439.6510.2010.6811.604.163.863.793.913.943.964.074.023.823.803.813.854.354.654.524.464.364.464.995.415.605.535.225.025.075.255.355.395.445.385.135.014.754.574.544.42 Upper Hem. Efficiency (%)20.8121.2121.7022.1622.9424.0524.5625.4826.7827.7129.3913.3712.5911.8511.6011.6711.6811.9311.9311.5111.2611.0810.8011.4811.7511.3711.3510.8410.5011.1811.6411.9512.0111.5911.2111.2711.7712.2812.7113.1213.2313.1513.3413.3313.4313.9414.02 Lower Hem. Efficiency (%)19.0719.4619.5418.9918.4818.0517.1716.8217.3317.9719.5723.1121.9921.7122.4623.1123.8025.0925.1424.2124.6925.7826.8230.1831.8430.8130.5129.9530.4833.6435.1235.5635.2233.7332.1331.7732.4232.8433.1432.9831.5829.7928.8927.3526.4726.5126.25 VER7 T90(H)圆度15.6414.9114.4014.2414.9316.2317.3817.5216.4113.8711.525.174.474.104.434.835.415.886.025.675.305.466.307.708.759.348.838.018.109.4411.1711.4411.2110.7210.239.6110.0711.0211.4411.1011.5311.339.728.858.538.398.06 Gain 15deg (dBi) E1(XZ)波瓣宽度35.0035.0036.0035.0035.0033.0031.0031.0030.0030.0030.0022.0025.0024.0024.0025.0025.0025.0025.0024.0023.0023.0023.0024.0025.0024.0023.0023.0022.0022.0023.0023.0023.0022.0021.0022.0022.0023.0022.0021.0020.0021.0021.0020.0020.0020.0020.00 E1(XZ)前后比4.764.624.454.304.224.354.685.125.545.845.973.053.133.563.853.653.273.002.943.113.373.633.593.313.032.822.832.953.133.142.992.882.722.612.562.542.652.853.213.533.603.503.373.413.764.164.61 E2(YZ)波瓣宽度26.0026.0028.0028.0028.0028.0027.0027.0028.0031.0037.0021.0022.0022.0021.0019.0018.0025.0024.0024.0026.0026.0019.0019.0025.0024.0024.0024.0023.0022.0022.0023.0022.0021.0021.0020.0020.0021.0021.0020.0020.0019.0019.0020.0019.0019.0020.00 E2(YZ)前后比2.452.312.152.021.992.192.472.772.963.022.941.741.751.471.341.401.241.161.100.990.870.710.790.620.570.610.560.410.320.280.300.390.490.500.450.420.460.540.680.800.790.710.750.871.061.191.30 最大增益处轴比(P)1.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.50 仰角10度最差(大)轴比(P)1.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501.501…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF: RT-4-E-005Page 1 of 122 RADIO TEST REPORT Applicant : STONEX SRL Address of Applicant : via dei Mille 4, 20900 Monza-MB, Italy Manufacturer : STONEX SRL Address of Manufacturer : via dei Mille 4, 20900 Monza-MB, Italy Equipment under Test : LASER SCANNER Model No. : X170GO FCC ID : Y44-X170GO Test Standard(s) : FCC Rules and Regulations Part 15 Subpart C, ANSI C63.10-2020, RSS-247 Issue 4 July 24, 2025, RSS-Gen Issue 5, Apr. 2018, Amendment 2 (February 2021), ANSI C63.10-2020+Cor.1-2023+C63.10a- 2024+Errata to C63.10a-2024 Report No. : DDT-RE26031615-2E02 Issue Date : 2026/05/19 Issue By : Guangdong Dongdian Testing Service Co., Ltd. Unit 2, Building 1, No. 17, Zongbu 2nd Road, Songshan Lake Park, Dongguan, Guangdong, China, 523808 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF: RT-4-E-005Page 2 of 122 Table of Contents 1.Summary of Test Results .............................................................................................7 2.General Test Information..............................................................................................8 2.1.Description of EUT .......................................................................................................8 2.2.Accessories of EUT......................................................................................................8 2.3.Block diagram of EUT configuration for test.................................................................9 2.4.Decision of final test mode ...........................................................................................9 2.5.Deviations of test standard.........................................................................................10 2.6.Test environment conditions ......................................................................................10 2.7.Test laboratory ...........................................................................................................10 2.8.Measurement uncertainty...........................................................................................11 3.Equipment Used During Conductive Test ..................................................................12 4.6dB Bandwidth ...........................................................................................................13 4.1.Block diagram of test setup ........................................................................................13 4.2.Limits ..........................................................................................................................13 4.3.Test procedure ...........................................................................................................13 4.4.Test result...................................................................................................................14 4.5.Test graphs ................................................................................................................15 5.99% Bandwidth ..........................................................................................................21 5.1.Block diagram of test setup ........................................................................................21 5.2.Limits ..........................................................................................................................21 5.3.Test procedure ...........................................................................................................21 5.4.Test result...................................................................................................................22 5.5.Test graphs ................................................................................................................23 6.Conducted Output Power ...........................................................................................29 6.1.Block diagram of test setup ........................................................................................29 6.2.Limits ..........................................................................................................................29 6.3.Test procedure ...........................................................................................................29 6.4.Test result average.....................................................................................................30 7.Power Spectral Density ..............................................................................................31 7.1.Block diagram of test setup ........................................................................................31 7.2.Limits ..........................................................................................................................31 7.3.Test procedure ...........................................................................................................31 7.4.Test result...................................................................................................................32 7.5.Test graphs ................................................................................................................33 8.Band Edge Compliance (Conducted Method)............................................................39 8.1.Block diagram of test setup ........................................................................................39 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF: RT-4-E-005Page 3 of 122 8.2.Limits ..........................................................................................................................39 8.3.Test procedure ...........................................................................................................39 8.4.Test result...................................................................................................................40 8.5.Test graphs .....…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF:RT-4-E-005Page 61 of 122 11AX20SISO_Ant1_2462_0~Reference 11AX20SISO_Ant1_2462_30~1000 11AX20SISO_Ant1_2462_1000~26500 A Att30dB * Offset19.9dB LVL Ref30dBm Center2.462GHzSpan30MHz3MHz/ 3DB RBW100kHz SWT15ms * VBW300kHz * 1PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP10of10 1 Marker1[T1] 0.00dBm 2.460701923GHz Date: 27.MAR.2026 12:07:22 A Att20dB * * 3DB RBW100kHz * VBW300kHz SWT125msRef20dBm Offset19.9dB LVL Start30MHzStop1GHz97MHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP10of10 1 Marker1[T1] -49.11dBm 888.062000000MHz D1-30dBm Date: 27.MAR.2026 12:07:31 Att20dB * A * 3DB RBW100kHz SWT2.6s * VBW300kHz Ref20dBm Offset19.9dB LVL Start1GHzStop26.5GHz2.55GHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP8of10 1 Marker1[T1] -5.31dBm 2.462000000GHz 2 Marker2[T1] -44.25dBm 24.792350000GHz D1-30dBm Date: 27.MAR.2026 12:07:54 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF:RT-4-E-005Page 62 of 122 11AX40SISO_Ant1_2422_0~Reference 11AX40SISO_Ant1_2422_30~1000 11AX40SISO_Ant1_2422_1000~26500 A Att30dB * Offset19.7dB LVL Ref30dBm Center2.422GHzSpan60MHz6MHz/ 3DB RBW100kHz SWT10ms * VBW300kHz * 1PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP10of10 1 Marker1[T1] -7.24dBm 2.419500000GHz Date: 27.MAR.2026 13:52:56 A Att20dB * * 3DB RBW100kHz * VBW300kHz SWT125msRef20dBm Offset19.7dB LVL Start30MHzStop1GHz97MHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP10of10 1 Marker1[T1] -49.66dBm 37.889333333MHz D1-37.24dBm Date: 27.MAR.2026 13:53:05 Att20dB * A * 3DB RBW100kHz SWT2.6s * VBW300kHz Ref20dBm Offset19.7dB LVL Start1GHzStop26.5GHz2.55GHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP8of10 1 Marker1[T1] -11.36dBm 2.419500000GHz 2 Marker2[T1] -44.65dBm 24.828050000GHz D1-37.24dBm Date: 27.MAR.2026 13:53:28 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF:RT-4-E-005Page 63 of 122 11AX40SISO_Ant1_2437_0~Reference 11AX40SISO_Ant1_2437_30~1000 11AX40SISO_Ant1_2437_1000~26500 A Att30dB * Offset19.9dB LVL Ref30dBm Center2.437GHzSpan60MHz6MHz/ 3DB RBW100kHz SWT10ms * VBW300kHz * 1PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP10of10 1 Marker1[T1] -6.00dBm 2.434500000GHz Date: 27.MAR.2026 14:16:11 A Att20dB * * 3DB RBW100kHz * VBW300kHz SWT125msRef20dBm Offset19.9dB LVL Start30MHzStop1GHz97MHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP10of10 1 Marker1[T1] -49.33dBm 463.105000000MHz D1-36dBm Date: 27.MAR.2026 14:16:20 Att20dB * A * 3DB RBW100kHz SWT2.6s * VBW300kHz Ref20dBm Offset19.9dB LVL Start1GHzStop26.5GHz2.55GHz/ 1PK VIEW -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP8of10 1 Marker1[T1] -10.75dBm 2.433950000GHz 2 Marker2[T1] -45.12dBm 24.382650000GHz D1-36dBm Date: 27.MAR.2026 14:16:43 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE26031615-2E02 TRF:RT-4-E-005Page 64 of 122 11AX40SISO_Ant1_2452_0~Reference 11AX40SISO_Ant1_2452_30~1000 11AX40SISO_Ant1_2452_1000~26500 A Att30dB * Offset20dB LVL Ref30dBm Center2.452GHzSpan60MHz6MHz/ 3DB RBW100kHz SWT10ms * VBW300kHz * 1PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP10of10 1 Marker1[T1] -7.36dBm 2.448153846GHz Date: 27.MAR.2026 14…

Text truncated - open the document above for the full version.
