Y6MNCOM6Motorcycle helmet communication system with BT transceiver

Firmware Version: 3.1x v.04 EN USER INSTRUCTIONS AND SAFETY Congratulations on your purchase of an N-Com product. N-Com B1 was made using the most advanced technologies and the best materials. Long-running tests and thorough system development have allowed the highest audio quality to be achieved. For additional information about B1, and to download high- definition instructions as well as the latest Firmware version, visit the website www.n-com.it REFERENCE STANDARDS The products of the N-Com line are in compliance with standards as per the table below: B1 The Bluetooth system complies with the main safety requirements and other applicable provisions of Directive 99/5/CE, Directive 2002/95/CE, Directive 2002/96/CE Battery charger Directive 2006/95, 2004/108, 2002/95/CE, 2002/96/CE, 2009/125/CE Battery Directive 2006/66 The Declarations of Compliance can be downloaded from the website www.n- com.it (Download section). FccID: Y6MNCOM6 N21550 Bluetooth is a registered trademark property of Bluetooth SIG, Inc. B1 3 Contents 1. WARNINGS AND SAFETY......................................................4 1.1.Road safety..........................................................................4 1.2.Switching on the system in safe environments...........................4 1.3.Interferences.......................................................................4 1.4.Appropriate use....................................................................4 1.5.Qualified personnel...............................................................5 1.6.Accessories and batteries.......................................................5 1.7.Disposal..............................................................................6 2. CONTENT OF THE PACKAGING..............................................6 3. INSTALLATION....................................................................7 3.1.Removing the B1 system from the helmet................................10 4. SYSTEM CHARACTERISTICS...............................................11 4.1.Basic functions....................................................................11 4.2.N-Com Wizard.....................................................................11 5. PAIRING UP BLUETOOTH DEVICES.....................................11 5.1.Affiliation reset function........................................................12 6. MOBILE PHONE FUNCTIONS...............................................12 7. GPS SATELLITE NAVIGATOR FUNCTIONS............................13 8. BLUETOOTH A2DP MUSIC PLAYER......................................13 9. AUDIO DEVICES WITH CABLE CONNECTION.......................14 10. RIDER-PASSENGER INTERCOM MODE.................................14 10.1.Intercom affiliation.............................................................14 10.2.Intercom function...............................................................14 11. BATTERY...........................................................................15 11.1.Battery discharged signal.....................................................15 11.2.Recharging the system........................................................15 12. SUMMARY TABLE OF CONTROLS.........................................16 13. LIMITED WARRANTY..........................................................17 13.1.Warranty coverage.............................................................17 13.2.Exclusions and limitations of the coverage..............................17 13.3.Validity of this limited warranty............................................17 13.4.Procedure for the forwarding of claims...................................18 13.5.Product identification..........................................................18 14. WARRANTY REGISTRATION FORM......................................19 4 1. WARNINGS AND SAFETY Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-Com B1. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and the like. Caution: Installation of the N-Com B1 system results in a weight increase of approximately 100g, which is added to the weight of the helmet and of the other accessories. Warning: The electronic components of the N-Com system mounted inside the helmet are not waterproof. Consequently, make sure the inside of the helmet, including the comfort padding, does not get wet in order to avoid damage to the system. If it does, remove the N-Com system and the helmet comfort padding and let it air dry. Disconnect the battery connector and let it dry as well. 1.1. Road safety Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should always be engaged in actually riding the vehicle. Any operation to the N-Com system must be carried out with the vehicle stopped. Specifically:  Set your cell phone on automatic answer (see the cell phone instructions to do this).  If your cell phone is not equipped with this function, first stop your vehicle in a safe area, in compliance with Traffic Regulations and then answer the call.  Do not make any calls while riding. Stop your vehicle in a safe place in compliance with Traffic Regulations, and then make the call.  Adjust the volume so that it does not cause a disturbance or distraction while riding and at the same time allows you to distinctively hear background noises.  Do not operate your cell phone or other devices connected to N-Com while riding your motorcycle.  In all cases, obey the Traffic Regulations and remember that riding the motorcycle has absolute priority over any other maneuver. 1.2. Switching on the system in safe environments  When using the N-Com system, comply with all limitations and instructions related to the use of cell phones.  Do not turn on your cell phone or the N-Com system whenever the…

Text truncated - open the document above for the full version.

Firmware Version: 1.xx v.04 EN USER INSTRUCTIONS AND SAFETY Click to buy NOW! P D F - X C h a n g e V i e w e r w w w . d o c u - t r a c k . c o m Click to buy NOW! P D F - X C h a n g e V i e w e r w w w . d o c u - t r a c k . c o m Congratulations on your purchase of an N-Com product. N-Com B1 was made using the most advanced technologies and the best materials. Long-running tests and thorough system development have allowed the highest audio quality to be achieved. For additional information about B1, and to download high-definition instructions as well as the latest Firmware version, visit the website www.n-com.it REFERENCE STANDARDS The products of the N-Com line are in compliance with standards as per the table below: B1 The Bluetooth system complies with the main safety requirements and other applicable provisions of Directive 99/5/CE, Directive 2002/95/CE, Directive 2002/96/CE Battery charger Directive 2006/95, 2004/108, 2002/95/CE, 2002/96/CE, 2009/125/CE Battery Directive 2006/66 The Declarations of Compliance can be downloaded from the website www.n-com.it (Download section). FccID: Y6MNCOM6 N21550 Bluetooth is a registered trademark property of Bluetooth SIG, Inc. FOR USA MARKET ONLY: SPECIAL WARNING This device complies with part 15 of the FCC and Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna  Increase the separation between the equipment or devices  Connect the equipment to an outlet other than the receiver’s  Consult a dealer or an experienced radio/TV technician for assistance FccID: Y6MNCOM5 N21550 Click to buy NOW! P D F - X C h a n g e V i e w e r w w w . d o c u - t r a c k . c o m Click to buy NOW! P D F - X C h a n g e V i e w e r w w w . d o c u - t r a c k . c o m B1 3 Contents 1. WARNINGS AND SAFETY......................................................4 1.1.Road safety..........................................................................4 1.2.Switching on the system in safe environments...........................4 1.3.Interferences.......................................................................4 1.4.Appropriate use....................................................................4 1.5.Qualified personnel...............................................................5 1.6.Accessories and batteries.......................................................5 1.7.Disposal..............................................................................6 2. CONTENT OF THE PACKAGING..............................................6 3. INSTALLATION....................................................................7 3.1.Removing the B1 system from the helmet................................10 4. SYSTEM CHARACTERISTICS...............................................11 4.1.Basic functions....................................................................11 4.2.N-Com Wizard.....................................................................11 5. PAIRING UP BLUETOOTH DEVICES.....................................11 5.1.Affiliation reset function........................................................12 6. MOBILE PHONE FUNCTIONS...............................................12 7. GPS SATELLITE NAVIGATOR FUNCTIONS............................13 8. BLUETOOTH A2DP MUSIC PLAYER......................................13 9. AUDIO DEVICES WITH CABLE CONNECTION.......................14 10. RIDER-PASSENGER INTERCOM MODE.................................14 10.1.Intercom affiliation.............................................................14 10.2.Intercom function...............................................................14 11. BATTERY...........................................................................15 11.1.Battery discharged signal.....................................................15 11.2.Recharging the system........................................................15 12. SUMMARY TABLE OF CONTROLS.........................................16 13. LIMITED WARRANTY..........................................................17 13.1.Warranty coverage.............................................................17 13.2.Exclusions and limitations of the coverage..............................17 13.3.Validity of this limited warranty............................................17 13.4.Procedure for the forwarding of claims...................................18 13.5.Product identification..........................................................18 14. WARRANTY REGISTRATION FORM......................................19 Click to buy NOW! P D F - X C h a n g e V i e w e r w w w . d o c u - t r a c k . c o m Click to buy NOW! P D F - X C h a n …

Text truncated - open the document above for the full version.

Nolangroup S.p.a. Via G.Terzi di Sant’Agata,2 24030 Brembate di Sopra (BG) Italy Commercial Power of Attorney Ron Angel Wholesale Pty Ltd Ph 03 9464 3366 33 Macquarie Dve THOMASTOWN VIC 3074 Australia Commercial Power of Attorney for the type approval / registration of the N-Com B1 v04 in several countries. The company 7 layers AG, 40880 Ratingen, Germany, has been contracted by Redox s.r.l. to obtain „Radio Type Approval“ for the following electronic components: N-Com B1 v04 7 layers is authorized to make use of all test reports, issued by 7 layers and/or test reports issued by other national and international laboratories, for the purpose of the type approval process for the product listed above. Unless future correspondence from Redox s.r.l. directs otherwise, please extend your full cooperation to 7 layers regarding matters to the above mentioned products for the period beginning 01/10/2012 through 01/12/2012. Thank you. _____ Grant Sammut - national manager _____ (Name and function of person signing) __Thomastown_____ , ___16/10/12____ , _______________________ (place) (date) (signature)

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Nolangroup s.p.a. Address : via Terzi di S.Agata 2 City: 24030 Brembate di sopra Country: Italy To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: Y6MNCOM6 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: This information should never get into the possession of competitors, which would be harmful for our business. Planned Release Date STC: 180 days (notes 2, 3, 4, 5) Date: 19 Oct. 12 Name and signature of applicant: Patrick Lomax Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

N-Com B1 v04 – Label - Labels on the product Located on the surface of the plastic Box containing the battery. Labels on the packaging Located on the external pack of the Bluetooth device Labels on the instructions leaflet: see page no. 3

Final Report on B1 v.04 FCC ID:Y6MNCOM6 MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C Report Reference: October 11, 2012 Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 1 Administrative Data 1.1 Project Data Patrick Lomax Project Responsible: 2012/10/11 Date Of Test Report: 2012/08/19 Date of first test: 2012/10/08 Date of last test: 1.2 Applicant Data Company Name: Nolangroup s.p.a. via Terzi di S.Agata 2 Street: 24030 Brembate di sopra City: Italy Country: Contact Person: Mr. Claudio Corollo +39 035 602 285 Phone: +39 035 602 261 Fax: [email protected] E-Mail: 1.3 Test Laboratory Data The following list shows all places and laboratories involved for test result generation: 7 layers DE Company Name : 7 layers AG Street : Borsigstrasse 11 City : 40880 Ratingen Country : Germany Contact Person : Mr. Michael Albert Phone : +49 2102 749 201 Fax : +49 2102 749 444 E Mail : [email protected] Laboratory Details Accreditation InfoLab IDIdentificationResponsible DAkkS-Registration no. D-PL-12140-01-01Conducted Emissions Lab 1Mr. Robert Machulec Mr. Andreas Petz DAkkS-Registration no. D-PL-12140-01-01Radiated Emissions Lab 2Mr. Robert Machulec Mr. Andreas Petz DAkkS-Registration no. D-PL-12140-01-01 Regulatory Bluetooth RF Test Solution Lab 3Mr. Jimmy Chatheril Mr. Sören Berentzen Page 2 of 83 Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 2.2 Detailed Description of OUT Samples Sample : BA01 OUT Identifier B1 v.04 Sample Description Wi-N4 Radiated Serial No. #1 HW Status 1.00 SW Status 1.00 Parameter List: ValueParameter Description Parameter for Scope FCC_v2 Antenna Gain 0 (dBi) Frequency_high 2480 (MHz) Frequency_low 2402 (MHz) Frequency_mid 2441 (MHz) Sample : BB01 OUT Identifier B1 v.04 Sample Description Wi-N4 Conducted Serial No. #2 HW Status 100 SW Status 1.00 Parameter List: ValueParameter Description Parameter for Scope FCC_v2 Antenna Gain 0 (dBi) Frequency_high 2480 (MHz) Frequency_low 2402 (MHz) Frequency_mid 2441 (MHz) Page 4 of 83 Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 2.3 OUT Features Features for OUT: B1 v.04 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 AC The OUT is powered by or connected to AC Mains BT EUT supports Bluetooth data rate of 1 Mbps with GFSK modulation in the band 2400 MHz - 2483.5 MHz EDR2 EUT supports Bluetooth using data rate of 2 Mbps with PI/4 DQPSK modulation in the band 2400 MHz - 2483.5 MHz EDR3 EUT supports Bluetooth using data rate of 3 Mbps with 8DPSK modulation in the band 2400 MHz - 2483.5 MHz Iant Integral Antenna: permanent fixed antenna, which may be built-in, designed as an indispensable part of the equipment TantC temporary antenna connector, which may be only built-in for testing, designed as an example part of the equipment 2.4 Auxiliary Equipment AE No.Serial No.SW StatusHW StatusDescriptionType Designation AE 01USB Cable AE 06 Cherry RS 6000 USB ON G 0000273 2P28Keyboard 1 AE 02LG L1740BQ509WANF1W607TFT 1 AE 05Logitech M-BB48LZC90505478Mouse AE 04 Toshiba PA3378E- 3AC3 AC Adapter 1 AE 03Toshiba TECRA M9TECRA M987060248H Laptop 1 2.5 Operating Mode(s) Ref.-No.Description 01Windows computer using a Redox program to continuously transmit data via USB. Page 5 of 83 Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 2.6 Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No. List of OUT samplesList of auxiliary equipment PC_BA01 (Wi-N4) AE 01USB CableBA01Wi-N4 Radiated Sample: AE 06Keyboard 1 AE 02TFT 1 AE 05Mouse AE 04AC Adapter 1 AE 03Laptop 1 S_BB01 BB01Wi-N4 Conducted Sample: S01_BA01 (Wi-N4) BA01Wi-N4 Radiated Sample: 3 Results 3.1 General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied standard. In cases where 'Declaration' is printed, the required documents are available in the manufacturers product documentation. In cases where 'not applicable' is printed, the test case requirements are not relevant to the specific equipment implementation. Documentation of tested devices: Interpretation of the test results: The laboratory environmental conditions are recorded and available in the Interlab system for each performed test. Note: 3.2 List of the Applicable Body (Body for Scope: FCC_v2) DesignationDescription Subpart C - Intentional Radiators; 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. FCC47CFRChIPART15c247RADIO FREQUENCY DEVICES Page 6 of 83 Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 3.3 List of Test Specification Test Specification: FCC part 2 and 15 Version10-1-11 Edition Title:PART 2 - GENERAL RULES AND REGULATIONS PART 15 - RADIO FREQUENCY DEVICES Page 7 of 83 Reference: MDE_REDOX_1202_FCCb According to Title 47 CFR chapter I part 15 subpart C 3.4 Summary Test Case Identifier / Name SetupDate of TestResultTest (condition)Ref. Lab 1…

Text truncated - open the document above for the full version.

Final Report on B1 v.04 FCC ID:Y6MNCOM6 MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B Report Reference: October 11, 2012 Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B 2.2 Detailed Description of OUT Samples Sample : BA01 OUT Identifier B1 v.04 Sample Description Wi-N4 Radiated Serial No. #1 HW Status 1.00 SW Status 1.00 Parameter List: ValueParameter Description Parameter for Scope FCC_v2 Antenna Gain 0 (dBi) Frequency_high 2480 (MHz) Frequency_low 2402 (MHz) Frequency_mid 2441 (MHz) Sample : ACDC01 OUT Identifier ACDC Adaptor (AK00G-0500040VU) Sample Description AK00G-0500040VU Serial No. #1 2.3 OUT Features Features for OUT: B1 v.04 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 AC The OUT is powered by or connected to AC Mains BT EUT supports Bluetooth data rate of 1 Mbps with GFSK modulation in the band 2400 MHz - 2483.5 MHz EDR2 EUT supports Bluetooth using data rate of 2 Mbps with PI/4 DQPSK modulation in the band 2400 MHz - 2483.5 MHz EDR3 EUT supports Bluetooth using data rate of 3 Mbps with 8DPSK modulation in the band 2400 MHz - 2483.5 MHz Iant Integral Antenna: permanent fixed antenna, which may be built-in, designed as an indispensable part of the equipment TantC temporary antenna connector, which may be only built-in for testing, designed as an example part of the equipment Page 4 of 24 Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B 2.4 Auxiliary Equipment AE No.Serial No.SW StatusHW StatusDescriptionType Designation AE 01USB Cable AE 06 Cherry RS 6000 USB ON G 0000273 2P28Keyboard 1 AE 02LG L1740BQ509WANF1W607TFT 1 AE 05Logitech M-BB48LZC90505478Mouse AE 04 Toshiba PA3378E- 3AC3 AC Adapter 1 AE 03Toshiba TECRA M9TECRA M987060248H Laptop 1 2.5 Operating Mode(s) Ref.-No.Description 01Windows computer using a Redox program to continuously transmit data via USB. 2.6 Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No. List of OUT samplesList of auxiliary equipment ACDC_BA01 (Wi-N4) ACDC01AK00G-0500040VU Sample: BA01Wi-N4 Radiated Sample: PC_BA01 (Wi-N4) AE 01USB CableBA01Wi-N4 Radiated Sample: AE 06Keyboard 1 AE 02TFT 1 AE 05Mouse AE 04AC Adapter 1 AE 03Laptop 1 Page 5 of 24 Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B 3 Results 3.1 General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied standard. In cases where 'Declaration' is printed, the required documents are available in the manufacturers product documentation. In cases where 'not applicable' is printed, the test case requirements are not relevant to the specific equipment implementation. Documentation of tested devices: Interpretation of the test results: The laboratory environmental conditions are recorded and available in the Interlab system for each performed test. Note: 3.2 List of the Applicable Body (Body for Scope: FCC_v2) DesignationDescription Part 15, Subpart B - Unintentional Radiators FCC47CFRChIPART15bRADIO FREQUENCY DEVICES 3.3 List of Test Specification Test Specification: FCC part 2 and 15 Version10-1-11 Edition Title:PART 2 - GENERAL RULES AND REGULATIONS PART 15 - RADIO FREQUENCY DEVICES Page 6 of 24 Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B 3.4 Summary Test Case Identifier / Name SetupDate of TestResultTest (condition)Ref. Lab 15b.1 Conducted Emissions (AC Power Line) §15.107 15b.1; Mode = transmit2012/09/14PC_BA01Lab 1Passed operating mode: 01 2012/08/09ACDC_BA01Lab 1Passed 15b.2 Spurious Radiated Emissions §15.109 15b.2; Mode = transmit2012/09/14PC_BA01Lab 2Passed operating mode: 01 2012/08/09ACDC_BA01Lab 2Passed Page 7 of 24 Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B 3.5 Detailed Results 3.5.1 15b.1 Conducted Emissions (AC Power Line) §15.107 Test1: 15b.1; Mode = transmit Result: Passed Setup No.: ACDC_BA01 Date of Test: 2012/08/09 7:12 Body: FCC47CFRChIPART15bRADIO FREQUENCY DEVICES Test Specification: FCC part 2 and 15 Page 8 of 24 Reference: MDE_REDOX_1202_FCCe According to: FCC 47 CFR Ch.1 Part 15 Subpart B Detailed Results: AC MAINS CONDUCTED EUT: (UH040BA01) Manufacturer: Redox Operating Condition: charging via ACDC(USB) charger Test Site: 7 layers Ratingen Operator: Giz Test Specification: ANSI C63.4; FCC 15.107 / 15.207 Comment: Start of Test: 10.08.2012 / 10:11:07 SCAN TABLE: "FCC Voltage" Short Description: FCC Voltage Start Stop Step Detector Meas. IF Transducer Frequency Frequency Width Time Bandw. 150.0 kHz 30.0 MHz 5.0 kHz MaxPeak 20.0 ms 9 kHz ESH3-Z5 Average 0 10 20 30 40 50 60 70 80 Level [dBμV] 150k 300k 500k 1M 2M 3M 5M 7M 10M 30M Frequency [Hz] MES Red_1203_005_pre PK MES Red_1203_005_pre AV LIM FCC 15b QP volt Voltage QP Limit LIM FCC 15b AV volt Voltage QP Limit Test2: 15b.1; Mode = transmit Result: Passed Setup No.: PC_BA01 Date of Test: 2012/09/14 8:36 Body: FCC47CFRChIPART15bRADIO FREQUENCY DEVICES Test Specification: FCC part 2 and 15 Page 9 o…

Text truncated - open the document above for the full version.

7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com InterLab  is a registered trademark of 7 layers AG Photo Report – Test Setup Photos Bluetooth transceiver N-Com B1 v03 Report Reference: MDE_REDOX_1201_FCC_c_Photo This report contains the setup photos for the reports referenced be MDE_REDOX_1202_FCCb (Part 15c) and MDE_REDOX_1202_FCCe (Part 15b) Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DGA-PL-192/99-02 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 2 of 7 1 Photo Report 1.1 Photos of test setups Photo 1: Test setup for radiated measurements (Enclosure, below 30 MHz) Part 15c Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 3 of 7 Photo 2: Test setup for radiated measurements (Enclosure, 30 MHz to 1 GHz), intentional transmission Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 4 of 7 Photo 3: Test setup for radiated measurements (Enclosure, above 1 GHz) Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 5 of 7 Photo 4: Test setup for radiated measurements (Enclosure, above 18 GHz) Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 6 of 7 Photo 5: Test setup for conducted measurements (AC Port (power line)), unintentional transmission, EUT + computer peripheral setup Test report Reference: MDE_REDOX_1201_FCC_c_Photo Page 7 of 7 Photo 7: Test setup for radiated measurements (Enclosure, 30 MHz to 1 GHz), unintentional transmission, EUT + computer peripheral setup
