Y7ZDL7101TRemote Control

1." LOW, MED, HI" buttons: These three buttons are used to set the fan speed as follows: " "= Low speed " "= Medium speed " "= High speed 2. " " button: This button turns the fan off. 3. " " button: This button will make forward or reverse the fan. 4. Th e "UP LIGHT" "DOWN LIGHT" button turns the light ON orOFF . Press and release the button to turn the light ON or OFF Remote Control User Manual FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. IC Caution: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1)This device may not cause interference; and (2)This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux apparei ls radio exemp ts de licence. L 'exploitation est autorisée aux deux c onditions s uivant es: (1)l' appareil ne doit pas p roduire de brouillage, et (2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même s i le brouillage est susceptible d'en compromettre le fonctionnement. Th e device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restricti on. L'appa reil a été évalué pour répondre aux exigences générales d'exposition RF. L'appareil peut être utilisé dans des conditions d'exposition portables sans restriction.

(S.Q.M CO., LTD.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: Y7ZDL7101T Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Jones Lin) Rev 11/20/07

(S.Q.M CO., LTD.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: Y7ZDL7101T To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Jones Lin)

External Photos

Label & label location Model: DL-7101T FCC ID: Y7ZDL7101T IC: 10874A-DL7101T

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E FCC Part 15C Test Report FCC ID: Y7ZDL7101T Product Name: Remote Control Trademark: N/A Model Name : DL-7101T Prepared For : S.Q.M CO., LTD. Address : No.1599 GUANGXING RD.TAIPING CITY TAICHUNG COUNTY 41149 Taiwan Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Mar. 30, 2020 – Apr. 10, 2020 Date of Report : Apr. 10, 2020 Report No.: BCTC2003001986E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 30 VERIFICATION OF COMPLIANCE Applicant’s name ........ S.Q.M CO., LTD. Address ....................... . No.1599 GUANGXING RD.TAIPING CITY TAICHUNG COUNTY 41149 Taiwan Manufacture's Name .. . S.Q.M CO., LTD. Address ....................... . No.1599 GUANGXING RD.TAIPING CITY TAICHUNG COUNTY 41149 Taiwan Product description Product name ................ Remote Control Trademark: N/A Model Name: DL-7101T Test Standards: FCC Part15.231 ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ....................................... Pass Prepared by(Engineer): Kelsey Tan Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 30 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 12 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 TEST SETUP 15 3.2.4 EUT OPERATING CONDITIONS 16 3.2.5 TEST RESULTS 17 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . CALCULATION OF AVERAGE FACTOR 24 6 . DWELL TIME 26 6.1 DEVIATION FROM STANDARD 26 6.2 TEST SETUP 26 6.3 EUT OPERATION CONDITIONS 26 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 30 Table of Contents Page 6.4 TEST RESULTS 27 7 . ANTENNA REQUIREMENT 28 7.1 STANDARD REQUIREMENT 28 7.2 EUT ANTENNA 28 8 . EUT TEST PHOTO 29 9 . EUT PHOTO 30 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 30 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.209,15.231b Fundamental &Radiated Spurious Emission Measurement PASS 15.231c Occupy Bandwidth PASS 15.231a Dwell time PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 30 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add.: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.38dB 5 Conducted output power uncertainty Above 1G U=1.576dB 6 Conducted output power uncertainty below 1G U=1.28dB 7 humidity uncertainty U=5.3% 8 Temperature uncertainty U=0.59°C Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 7 of 30 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Remote Control Trade Name N/A Model Name DL-7101T Serial Model N/A Model Difference N/A Product Description Operation Frequency: 303.875MHz Modulation Type: ASK Antenna Type: Internal antenna Antenna Gain: 3dBi Ratings DC 12V Connecting I/O Port(s) Please refer to the User's Manual Hardware version IT-099-V5 Software version SV01 Serial number N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003001986E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 8 of 30 2.2 DESCRIPTION OF TEST MODES For All Emission Final Test Mode Description Mode 1 TX Mode Note: (1) Fully…
