InfinID Technologies, Inc. V-TAG RFID Tag and USB Gateway v1.0 February 3, 2011 v1.0 2 V-TAG Manual Table of Contents 1.0 System Overview .................................................................................. 3 2.0 Getting Started....................................................................................... 4 3.0 Viewing Sensor Readings ..................................................................... 5 Appendix A FCC Compliance Statement ................................................... 9 v1.0 3 V-TAG Manual 1.0 System Overview The V-TAG is a RFID tag with a set of sensors for temperature, humidity, shock and battery level. In contrast to other systems where each tag is polled by a central gateway, the V-TAG tag relays messages from other V-TAG tags which aids with tag read range and communications reliability. See Figure 1. Figure 1 V-TAG System Overview v1.0 4 V-TAG Manual 2.0 Getting Started To start using your V-TAG RFID tags, insert a battery into each tag. The LED light on the tag should blink once every 20 seconds indicating normal operation. To start using your V-TAG USB Gateway, attach the gateway to a USB port on a PC running Windows XP, Vista or Windows 7. Select “OK” when the operating system asks to use the Internet to locate drivers. Install the InfinID Technologies, Inc. AssetWorx! asset tracking software on your PC by running setup.exe and following the prompts. v1.0 5 V-TAG Manual 3.0 Viewing Sensor Readings To associate a V-TAG tag with an asset, simply enter the V-TAG ID printed on the tag label into the VTAG ID field for the asset as shown: v1.0 6 V-TAG Manual To view sensor readings for the asset, choose the sensors tab for the asset: v1.0 7 V-TAG Manual To view historical sensor readings for the asset, click on the “Plot” button for the asset: v1.0 8 V-TAG Manual To set thresholds for the asset, click on the thresholds button for the asset: v1.0 9 V-TAG Manual Appendix A FCC Compliance Statement FCC NOTICE This equipment has been tested and found to comply with the limits for a class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of the manufacturer could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

RFID & UID Software Solutions for Defense www.lnfinlDTech.com One West Mountain Street, Suite 12 Pasadena, CA 91 103 (626) 793-2019 T (626) 798-2019 F rl lnfinlD))l Technologies Inc ?/ March 16,2011 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for InfinID Technologies, Inc. 1 West Mountain St., Suite 12, Pasadena, CA 91103 for a period of one yeat, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following InfinID Technologies, Inc. product: RFID Tag and RFID Tag Gateway under FCC Docket Number 20180 and General Docket Number 80-284 oursuant to Part 15 of FCC Rules and Regulations. Please_ also accept this letter as an attestation that neither InfinID Technologies, Inc. nor a-ny of its officers, directors, or persons holding 5Yo or more of the outstanding stock or shares, voting ornon-voting, have been denied federal benefits under section 5301 of the Anli-Drug-Abg1e act of 1988,21 U.S.C. 853(a). In addition, InfinID Technologies, Inc. will notify the Federal Communications Commissionif, at any time, the situation changes causing InfinID Technologies, Inc. to be denied federal benefits. If you have any further questions or need me a call at (626) 7932019 x239. Sincerely, \i.\i frr, -i\ ffiL; i' :d:* {.; Barry Ambrose Systems Engineer additional information. please feel free to sive

One West Mountain Street, Suite 12 RFID &UID Software Solutions for Defense Pasadena, CA 91103 (626) 793-2019 T www.lnfinIDTech.com (626) 798-2019 F February 3, 2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, InfinID Technologies, Inc. would like to declare that the application being submitted for the device with FCC ID: Y8FVTlOO 1, has not been submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at (626) 793-2019 x239. Sincerely, ~asr~~~r'D~ Barry Ambrose Systems Engineer •

RFID & UID Software Solutions for Defense www.lnfinIDTech.com One West Mountain Street, Suite 12 Pasadena, CA 91103 (626) 793-2019 T (626) 798-2019 F t~!tlJe!!») February 3, 2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, InfinID Technologies, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This I:equest is made under the provisions of Section 0.457 (d) ofthe Commission's Rules,and Section 552 (b)(4) of the Freedom ofInformation Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at 626-793-2019 x206 Sincerely, ~,"-t -1\\'(\~{'v SR- Barry Ambrose Systems Engineer •

Correspondence by Project Project Number: Correspondence NumberMemo Y8FVT1001-1 1. The block diagram only gives information for the RF portion. Please provide a block diagram of the entire device. Response: The revised block diagram has been uploaded. 2) The schematic shows U2 populated, however it is not shown in the internal photos. Please provide a revised schematic. Response: The Revised Schematic has been uploaded 3) Please describe the type of modulation that is used in the device. Response: Please see the modulation exhibit uploaded. 4) Please provide the duty cycle plots used to calculate the correction factor used for the average measurements. Response: They duty cycle plot has been uploaded. 5) The FCC label does not meet have the two part statement. Please provide a corrected label. Response: The EUT is smaller than a person's palm. Please see the revised FCC ID Exhibit. 6) The Anti-Drug Abuse and Letter of Authority were not signed by the correct person. Please provide a corrected letter. Response: The Anti-Drug Abuse and Letter of Authority have been revised to be signed by the correct person.

Report Number: B10104D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 17 FCC PART 15 SUBPART B and C TEST REPORT for V-TAG MODEL: VT100-1 Prepared for INFINID TECHNOLOGIES, INC. 1 WEST MOUNTAIN STREET, SUITE 12 PASADENA, CALIFORNIA 91103 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JANUARY 12, 2011 REPORT APPENDICES TOTAL BODY A B C D E PAGES 17 2 2 2 13 26 62 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B10104D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Facility Environmental Characteristics 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.1.3 RF Emissions Test Results 16 8. CONCLUSIONS 17 Report Number: B10104D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos • Test Setup Diagram • Antenna and Amplifier Factors • Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B10104D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 17 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: V-TAG Model: VT100-1 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: InfinID Technologies, Inc. 1 West Mountain Street, Suite 12 Pasadena, California 91103 Test Date(s): January 3 and 4, 2011 Test Specifications: EMI requirements CFR Title 47, Part 15, Subpart B Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter, Receive, and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Highest reading in relation to spec limit: 42.25 dBuV @ 4810 MHz (*U = 5.34 dB) *U = Expanded Uncertainty with a coverage factor of k=2 Report Number: B10104D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 17 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the V-TAG, Model: VT100-1. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by …

Text truncated - open the document above for the full version.

Ref Lvl 92 dB
V Ref Lvl 92 dB
V RBW 3 MHz VBW 3 MHz RF Att 10 dB A IN1 Unit dB
V P0 TDS SWT 100 ms Center 2.405 GHz10 ms/ 2MA2VIEW D15 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T2] -1.34 dB 1.002004 ms 1 [T2] 44.29 dB
V 50.300601 ms 1 [T2] -1.34 dB 1.002004 ms D1 54 dB
V Date: 30.DEC.2010 15:05:45 Plot Showing the Pulse only comes one for less than 10 mS per 100 mS period.
