InfinID Technologies, Inc. V-TAG RFID Tag and USB Gateway v1.0 February 3, 2011 v1.0 2 V-TAG Manual Table of Contents 1.0 System Overview ...................................................................................3 2.0 Getting Started .......................................................................................4 3.0 Viewing Sensor Readings ......................................................................5 Appendix A FCC Compliance Statement ....................................................9 v1.0 3 V-TAG Manual 1.0 System Overview The V-TAG is a RFID tag with a set of sensors for temperature, light level, acceleration and battery level. In contrast to other systems where each tag is polled by a central gateway, the V-TAG tag relays messages from other V-TAG tags which aids with tag read range and communications reliability. See Figure 1. Figure 1 V-TAG System Overview v1.0 4 V-TAG Manual 2.0 Getting Started To start using your V-TAG RFID tags, insert a battery into each tag. The LED light on the tag should blink once every 20 seconds indicating normal operation. To start using your V-TAG USB Gateway, attach the gateway to a USB port on a PC running Windows XP, Vista or Windows 7. Select “OK” when the operating system asks to use the Internet to locate drivers. Install the InfinID Technologies, Inc. AssetWorx! asset tracking software on your PC by running setup.exe and following the prompts. v1.0 5 V-TAG Manual 3.0 Viewing Sensor Readings To associate a V-TAG tag with an asset, simply enter the V-TAG ID printed on the tag label into the VTAG ID field for the asset as shown: v1.0 6 V-TAG Manual To view sensor readings for the asset, choose the sensors tab for the asset: v1.0 7 V-TAG Manual To view historical sensor readings for the asset, click on the “Plot” button for the asset: v1.0 8 V-TAG Manual To set thresholds for the asset, click on the thresholds button for the asset: v1.0 9 V-TAG Manual Appendix A FCC Compliance Statement FCC NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of the manufacturer could void the user’s authority to operate the equipment. To satisfy RF exposure requirements, this device and its antennas must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

Correspondence by Project Project Number: Correspondence NumberMemo Y8FVT100D1-1 1) Please provide a block diagram for the entire device. The block diagram submitted only gives information for the RF portion of the device. Response: The block diagram for the rest of the device has been uploaded 2) Please provide a corrected sample label. The label submitted shows an incorrect FCC ID and it does not have the required two part statement. Response: The label has been revised to show the correct information. Also, the owners manual has been revised to show the 2-part statement since the device is small enough to exclude the 2 part statement. 3) Please provide corrected schematics. The schematics provided show a different RF chip then is shown in the internal photos. Response: The revised schematics have been uploaded

Ref Lvl 102 dB  V Ref Lvl 102 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB A IN1 UnitdB  V P0 TDS SWT 100 ms Center 2.405 GHz10 ms/ 1MA1VIEW 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] -0.72 dB 1.603206 ms 1 [T1] 39.90 dB  V 15.631263 ms 1 [T1] -0.72 dB 1.603206 ms D1 99.64 dB  V D2 54 dB  V Date: 7. NOV.2012 05:18:32 Plot Showing the Pulse only comes one for less than 10 mS per 100 mS period.

Report Number: B21107D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for V-TAG MODEL: VT100-1 Prepared for INFINID TECHNOLOGIES, INC. 1 WEST MOUNTAIN STREET, SUITE 12 PASADENA, CALIFORNIA 91103 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: NOVEMBER 30, 2012 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 16 2 2 2 13 31 66 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B21107D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B21107D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos Test Setup Diagram Antenna and Amplifier Factors Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURETITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site Report Number: B21107D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: V-TAG Model: VT100-1 S/N: N/A Product Description:See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: InfinID Technologies, Inc. 1 West Mountain Street, Suite 12 Pasadena, California 91103 Test Date(s): November 7, 2012 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B21107D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report V-TAG Model: VT100-1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the V-TAG, Model: VT100-1 (EUT). The Emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subp…
