YB9R-2049MHZRemote Controller for Toy

AUTO RACING 1:20 R/C SAFETY FIRST! Read these instructions carefully before using this product and keep it in a safe place for future reference. We advise the use of this product whilst under the guidance of an adult. This toy is for children of 5 years and above. Do not use this toy on the road and keep away from animals and young children. Do not attempt to modify this product in any way or lift it from the ground whilst in movement. Keep moving parts of this product away from hair, clothes and hands. Handle it with care at all times and only when the motor is off. INSTRUCTIONS OF USE Operating multiple vehicles with the same frequency in close proximity will Cause interference and poor performance. For the best performance we advise use on flat, clean surfaces. Hold the transmitter antenna up for best performance. Eusure that the ON/OFF power switch of verhicle is in the ON position while playing. FUNCTIONS Full Functions: Forwards, Backwards, Backwards Right, Forward Right, Backwards Left, Forward Left and Stop. BATTERIES REQUIRED: No. 2 * 1.5V AA batteries for the transmitter (not included). No. 3 * 1.5V AAA batteries for the vehicle (not included). BATTERY INSTALLATION A-TRANSMITTER 1. Open the battery door with a screwdriver and install No. 2 * 1.5V AA batteries as shown in the polarity diagram (+/-) inside the compartment 2. Replace the battery door and screw it is well tighten ensuring that it closes securely. 3. Insert the antenna in the small hole located on the top of the remote control unit. Screw it until it is well tighten by turning clockwise. B-VEHICLE 1. Ensure that the ON/OFF power switch is in the OFF position; 2. Open the battery door with a screwdriver and take out the individual battery box from batery compartment. 3. Remove the battery lid from battery box according to the arrow symbol as shown on battey door. 4. Insert No. 3 * 1.5V AAA batteries as shown in the polarity diagram (+/-) inside the battery box. 5. Replace the battery lid to battery box ensuring that it closes securely. 6. Replace the battery door and screw it is well tighten ensuring that it closes securely. CLEANING Clean the vehicle with a damp cloth and dry. Do not submerge this item in water or in any other liquid. Do not expose this toy to direct sunlight or to any other heat source. WARNING! Improper use of the batteries may lead to overheating, battery leakage, explosion and damage or injury.please read the following instructions carefully. • Non-rechargeable batteries are not to be recharged. • Rechargeable batteries are to be removed from the product before being charged. • Rechargeable batteries are only to be charged under adult supervision. • Do not mix old and new batteries. • Do not mix Alkaline, Standard(Carbon-Zinc), or Rechargeable(nickel- cadmium) batteries. • Do not mix different makes or types batteries together. • Only batteries of the same or equivalent type as recommended are to be used. • Batteries are to be inserted with the correct polarity (+/-), As shown in the battery compartment. • Exhausted batteries are to be removed from the product, And dispose of them in the appropriate container. • The supply terminals are not to be short-circuited. • Remove the batteries from the toy when not in use for an extended period of time. • Do not dispose of this product and batteries in a fire. Allow them to leak or explode. • Keep these instructions for future reference. NOTE: The manufacturer is not responsible for the possible interferences from radio or Tv owing to non-permitted modifications on this appliance. MADE IN CHINA IMPORTED BY: Mac Due S.p.A. Società Uninominale Via Raffaello Sanzio, 19 - 20058, Villasanta - MB - ITALY Phone no. +39 039 2058.1 - Fax no.+39 039 2058.204 www.motoramaclub.com Mac Due ITEM: KD0725A/KD0709A/KD0726A – Code 496141 Frequency: 27MHz & 49MHz WARNING! Not suitable for children under 3 years of age because small parts can be swallowed. Please retain these particulars for future reference. Right is reserved to effect changes in colours and technical details. Remove all packaging before giving toy to child.

External Photo Front View of the product Rear View of the product Battery compartment Battery Cover

Internal Photo Inner Circuit Top View Inner Circuit Bottom View Internal View of the product Internal View of the product Antenna

TEST REPORT N°: (5211)078-0202 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 2 of 14 Location of the test laboratory Radiated and Conducted emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2003. An Open Area Test Site and Full Anechoic Chamber (FCC Listed Site, Registration No. 642151) are set up for investigation and located at : BUREAU VERITAS HONG KONG LIMITED, EMC CENTRE No. 2106-2107, 21/F., Westin Centre, 26 Hung To Road, Kwun Tong, Kowloon, Hong Kong List of measuring equipment Radiated Emission EQUIPMENT MANUFACTURER MODEL NO. SERIAL NO. CALIBRATION DUE EMI TEST RECEIVER R&S ESCI 100379 06-SEP-2011 LOOP ANTENNA ETS-LINDGREN 6502 00102266 17-MAY-2011 BILOG ANTENNA SCHAFFNER CBL6112D 25229 02-AUG-2011 OPEN AREA TEST SITE BVCPS N/A N/A 05-JUL-2011 ANECHOIC CHAMBER ALBATROSS M-CDC 80374004499B 26-OCT-2011 COAXIAL CABLE SUHNER N/A N/A 19-SEP-2011 Remarks:- N/A : Not Applicable or Not Available The measurement instrumentation uncertainty would be taking into consideration on each of the test result TEST REPORT N°: (5211)078-0202 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 3 of 14 Equipment Under Test [EUT] Description of Sample: Model Name: 1:20 Aston martin B/O Model Number: KD0725A Additional Model Name: 1:20 lamborghini B/O / 1:20 corvette B/O Additional Model Number: KD0709A / KD0726A Additional Model Information: Declare the Circuit, PCB layout and Electrical parts of the products are identical to the basic model. Except the shape and colour of shell. Rating: 3Vd.c (“AA” size battery x 2) Description of EUT Operation: The Equipment Under Test (EUT) is a MAC DUE INTERNATIONAL LTD. of Radio Control toy. It is a 2 sticks and operating at 49.86MHz transmitter. The EUT continues to transmit while sticks are being pushed or pulled, Modulation by IC, and type is pulse modulation. The transmitter has different control: 1. Left stick – control forward and backward 2. Right stick – control left and right Antenna Requirement (Section 15.203) The EUT is use of a screw-on type antenna. The antenna consists of 43cm long metal antenna. The antenna connector is custom-made and not be able to found in the market. It also cannot be replaced with other antenna other then the one bundled inside the package. The requirements of S15.203 are met. There are no deviations or exceptions to the specifications. Photo of Antenna TEST REPORT N°: (5211)078-0202 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure…

Text truncated - open the document above for the full version.

Test Set Up Photo
