YBM-MSM2050MOTORCYCLE AND YACHT AUDIO SYSTEM

Using instruction 一， specification： Working frequency： 433.92MHz±150KHz Modulation mode： OOK Transmitting power： ＜10mW Working voltage： DC3V（2302纽扣电池） Working current： ＜8mA Encode mode： LX2260 1.2M 二， Using instruction: Push down the key M on the remote, the transmitted LED will light at the same time , the transmitted signal is D3. Push off the key, transmitting will tranmilated and the LED will light off. Push down the key+ on the remote, the transmitted LED will light at the same time , the transmitted signal is D1. Push off the key, transmitting will tranmilated and the LED will light off. Push down the key on the remote, the transmitted LED will light at the same time , the transmitted signal is D1. Push off the key, transmitting will tranmilated and the LED will light off. Push down the key - on the remote, the transmitted LED will light at the same time , the transmitted signal is D1. Push off the key, transmitting will tranmilated and the LED will light off. 三， Notation: Replace the battery if the remote distance becomes short or the LED light becomes dim. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Reference No: Report No: SZ100401B01-RP Page 1 / 3 Reference No: Report No: SZ100401B01-RP Page 2 / 3 Reference No: Report No: SZ100401B01-RP Page 3 / 3

Label Location

Reference No: Report No: SZ100401B01-RP Page 1 / 2 Reference No: Report No: SZ100401B01-RP Page 2 / 2

Reference No.: Report No.: SZ100401B01-RP FCC ID : YBM-MSM2050 Page 1 / 26 FCC TEST REPORT for MOTORCYCLE AND YACHT AUDIO SYSTEM MODEL: MSM-2050A,MSM-2050B,MSW-2050A,MSW-2050B Brand Name:ACTIWAY,WS Test Report Number: SZ100401B01-RP Issued for Shenzhen Actiway Electronics Co.,Ltd. Bdg 2,Longwu Industrial Zone,Shangtang Village,Minzhi,Baoan District,Shenzhen,P.R.C. Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China TEL: 86-755-28055000 FAX: 86-755-28055221 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test results in the report only apply to the tested sample. Reference No.: Report No.: SZ100401B01-RP FCC ID : YBM-MSM2050 Page 2 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 April 14, 2010 Initial Issue ALL Clinton Kao Reference No.: Report No.: SZ100401B01-RP FCC ID : YBM-MSM2050 Page 3 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ................................................................................................. 4 2 EUT DESCRIPTION....................................................................................................... 5 3 TEST METHODOLOGY................................................................................................. 6 3.1. DESCRIPTION OF TEST MODES ...................................................................................... 6 4 TEST METHODOLOGY................................................................................................. 7 4.1. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 7 5 SETUP OF EQUIPMENT UNDER TEST ....................................................................... 8 5.1. DESCRIPTION OF SUPPORT UNITS................................................................................. 8 5.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 8 6 FACILITIES AND ACCREDITATIONS .......................................................................... 9 6.1. FACILITIES .......................................................................................................................... 9 6.2. ACCREDITATIONS ............................................................................................................. 9 6.3. MEASUREMENT UNCERTAINTY....................................................................................... 9 7 FCC PART 15.231 REQUIREMENTS ......................................................................... 10 7.1. 20 DB BANDWIDTH .......................................................................................................... 10 7.2. LIMIT OF TRANSMISSION TIME ...................................................................................... 12 7.3. DUTY CYCLE .................................................................................................................... 14 7.4. POWER LINE CONDUCTED EMISSIONS MEASUREMENT........................................... 17 7.5. RADIATED EMISSIONS .................................................................................................... 20 Reference No.: Report No.: SZ100401B01-RP FCC ID : YBM-MSM2050 Page 4 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product: MOTORCYCLE AND YACHT AUDIO SYSTEM Model: MSM-2050A,MSM-2050B,MSW-2050A,MSW-2050B Brand: ACTIWAY,MS Tested: April 01~14, 2010 Applicant: Shenzhen Actiway Electronics Co.,Ltd. Bdg 2,Longwu Industrial Zone,Shangtang Village,Minzhi,Baoan District,Shenzhen,P.R.C. Manufacturer: Shenzhen Actiway Electronics Co.,Ltd. Bdg 2,Longwu Industrial Zone,Shangtang Village,Minzhi,Baoan District,Shenzhen,P.R.C. APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and Part 15.231. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Clinton Kao Manager Compliance Certification Service Inc. Sunday Hu Assistant manager Compliance Certification Service Inc. Reference No.: Report No.: SZ100401B01-RP FCC ID : YBM-MSM2050 Page 5 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product MOTORCYCLE AND YACHT AUDIO SYSTEM Trade Name ACTIWAY Model Number MSM-2050A,MSM-2050B,MSW-2050A,MSW-2050B Model Discrepancy The electrical circuit designs of the above models are identical, only their item no.’s and outer decoration are different. Serial Number SZ100401B01-RP Power Supply DC3V powered by the battery Frequency Range 433.92MHz Modulation Technique OOK Number of Channels 1 Channel Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. Remark: This s…
