YC5AC508-01style type radio receiver

SHENZHEN A-OK TECHNOLOGY GRAND DEVELOPMENT CO, LTD Electronic limit switch tubular motor operation manual 1 Program Switch power off over 10’s, power on motor again, press UP&DOWN together and hold on until motor have a shake, then release hand, motor is in the condition of program. Within the new 3’s, press PROGRAM button on transmitter back body for 1’s, motor have a shake again, means program complete. 2. Change direction After complete program, if press UP or DOWN, the motor running direction is in the opposite direction, need to change the direction now. Press STOP for 2’s, motor have a shake, change direction complete; (This operation will be valid only before set UP&DWON limit position; If you want to change direction again, delete all codes, program again and then operate step2) 3. Set UP limit position Press UP&DOWN together, motor up running, when arrive to the exact position, press STOP button, then use UP or DOWN button to micro adjustment limit position, when motor arrive to the exact position, press STOP for 2’s, motor have a shake, this UP limit position is memorized. 4. Set DOWN limit position Press PROGRAM on transmitter back for 1’s, motor have a shake, then press UP&DOWN together, motor down running, when arrive to the exact position, press STOP button, then use UP or DOWN button to micro adjustment limit position, when motor arrive to the exact position, press STOP for 2’s, motor have a shake, this DOWN limit position is memorized. 5. Micro adjustment UP/DOWN limit position If you want to change UP or DOWN limit position, after motor arrived to UP or DOWN limit position, press UP&DOWN together for 5’s, motor have a shake, and now motor is in the condition of bit adjustment mode, press UP or DOWN bit by bit, when motor arrived desired position, press STOP for 2’s, motor have a shake again, means micro adjustment new position complete. 6. Delete code Switch power on motor over 10’s, then switch power on and press UP&DWON together quickly, motor have a shake, then motor is in the condition of PROGRAM/DELETE mode, within 3’s press PROGRAM button on the transmitter back body for 7’s, motor have a shake again, delete all codes complete. Specifications： A. Working voltage（ AC230V ±10% 50/60Hz，AC115V±10% 50/60Hz, DC12V, DC24V） B. Built-in side receiver C. Precious adjustment limit position D. Memory position when power supply recover E. Auto redress slip position F. Stop once block G. Sensor short circuit and open circuit protection H. Step operation before set limit position Add new transmitter memory operation： Use the memorized transmitter, press STOP for 5’s, motor have a shake, motor is in the condition of micro adjustment mode, within 3’s press PROGRAM on new transmitter back body, motor have a new shake, program complete. SHENZHEN A-OK TECHNOLOGY GRAND DEVELOPMENT CO, LTD Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: - Reorient the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

DATE：20/04/2010 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint _ SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD ，5/F,Block 4, Anhua Industrial Zone.,No.8 TaiRan Rd.CheGongMiao,FuTian District, Shenzhen,CHINA.，Hanson Chueng_,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with _ Shenzhen A-OK Technology Grand Development Co., LTD _3rd Fl,34 East Bldg, Chentian Industry District, Xi’xiang Town, Ban’an Zone, Shenzhen City, Guangdong, China . Dated this 20/04/2010 Agency agreement expiration date: Usually Give 8 - 12 Months By: Zhiwen Tang Signature Printed Title: General Manager On behalf of : Shenzhen A-OK Technology Grand Development Co., LTD Telephone: 0755-27582809

DATE： 25/06/2010 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:__YC5AC 508-01_ Product Name: Style Type Radio Receiver Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this June 25, 2010 By: Zhiwen Tang Signature Printed Title: General Manager On behalf of : Shenzhen A-OK Technology Grand Development Co., LTD Telephone: 0755-27582809

Shenzhen A-OK Technology Grand Development Co., LTD FCC ID: YC5AC508-01 Model: AC508 This device complies with part 15 of the FCC rule s. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location

ISO/IEC17025 Accredited Lab. Report No: FCC 1003314 File reference No: 2010-06-03 Applicant: Shenzhen A-OK Technology Grand Development Co.,LTD Product: Style type radio receiver Brand Name: N/A Model No: AC508 Test Standards: FCC Part 15 Subpart B: 2008 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: June 03, 2010 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD East 5/Block 4, Anhua Industrial Zone, No.8, Tairan Rd. Chegongmiao, FuTian District, Shenzhen, CHINA. Tel (755) 83448688 Fax (755) 83442996 Report No: 1003314 Page 2 of 20 Date: 2010-06-03 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co., Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co., Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co., Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co., Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205A-01 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-01. Report No: 1003314 Page 3 of 20 Date: 2010-06-03 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co., Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co., Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co., Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co., Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT ............................................................................................4 1.4 Test Uncertainty................................................................................................ 4 1.5 Submitted Sample............................................................................................. 4 1.6 Test Duration.................................................................................................. 4 2.0 List of Measurement Equipment........................................................................ 5 2.1 Conducted Emission Test..................................................................................... 5 2.2 Radiated electromagnetic disturbance test................................................................. 5 3.0 Technical Details............................................................................................. 5 3.1 Investigations Requested..................................................................................... 5 3.2 Test Standards.................................................................................................. 5 4.0 Power line Conducted Emission Test..................................................................... 6 5.0 Radiated Disturbance Test................................................................................... 9 6.0 FCC ID Label ....................................................................................................... 15 7.0 Photo of testing........................................................................................................................... 16 Report No: 1003314 Page 4 of 20 Date: 2010-06…

Text truncated - open the document above for the full version.

Conducted test View—
