YC7-5006802.11b/g SDIO Module

Whitney 802.11b/g SDIO Module Operators Guide Clarity Design, Inc. Page 1 of 2 June 30, 2010 Whitney 802.11b/g SDIO Module Operators Guide FCC ID: YC7-5006 IC: 8962A-5006 1 Overview The Whitney 802.11b/g SDIO Module is normally inserted into an available SD card slot that is controlled by an SD Slot host controller. 2 Operation Turn the module on or off: The module will be turned on and off under the control of the SD slot host controller. Initialization of the module: The module will be initialized and configured by the SD slot host controller once it is inserted into an SD card slot. The module will connect to an 802.11 b/g compatible device after configuration assuming there one is available for connection. 3 FCC Part 15 Information to User This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. Whitney 802.11b/g SDIO Module Operators Guide Clarity Design, Inc. Page 2 of 2 June 30, 2010 • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 4 Industry Canada Statement This Class B digital apparatus complies with Canadian ICES-003 and RSS210. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. 5 RF Exposure Limits To comply with FCC regulations for the Module, the following rules must be obeyed during and after installation. Keep the antenna of the Module at a safe distance from your head and body while in use. Maintain a distance of at least 20 cm (8 inches) between the transmitter’s antenna and any person while in use. The device is designed for use in applications that observe the 20 cm separation distance. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Integrators must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

Whitney 802.11b/g SDIO Module FCC/IC ID Label and Location The FCC/IC ID label is shown below. The information is printed on the back cover of the module as shown in the picture below. The size of the information is 1.4 inches X 0.75 inches. FCC ID: YC7‐5006 IC: 8962A‐5006

FCC ID: YC7-5006 IC: 8962A-5006

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to isotropicR = distance to the center of radiation of the antenna 0.02924 Maximum peak output power at antenna input terminal: 19.35 (dBm) Maximum p eak out p ut p ower at antenna in p ut terminal: 86.10 ( mW ) 2 4 R PG S π = Maximum peak output power at antenna input terminal: 86.10 (mW) Antenna gain(typical): 4.4 (dBi) Maximum antenna gain: 2.754 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.000 (mW/cm^2) Power density at prediction frequency: 0.0472 (mW/cm^2) Power density at prediction frequency: 0.472 (W/m^2) Margin of Compliance: -13.26 (dB) 2 4 R PG S π =

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Phone (858) 755-5525 Fax (858) 452-1810 FCC Part 15 Subpart C, 15.247 : 08/07/2010 CERTIFICATION TEST REPORT Report Number: 2010 05149324 FCC Project Number: 43699 Nex Number: 149324 Applicant: C LARITY DESIGN 13029 DANIELSON STREET SUITE 100 Poway, CA 92064 Equipment Under Test (EUT): WIFI SD CARD Model: 5006 FCC ID: YC7-5006 IC: 8962A-5006 In Accordance With: FCC Part 15 Subpart C, 15.247 IC RSS-210 Issue 7 June 2007 IC RSS-Gen Issue 2 June 2007 Tested By: Nemko USA Inc. 11696 Sorrento Valley Road, Suite F San Diego, CA 92121 Authorized By: Alan Laudani, EMC/RF Test Engineer Date: May 7, 2010 Total Number of Pages: 83 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 FCC ID: YC7-5006 Report Number: 2010 05149324 FCC IC: 8962A-5006 Specification: FCC Part 15 Subpart C, 15.247 Page 2 of 83 Section1: Summary of Test Results General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15; Subpart C and IC RSS-210. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC and IC. The assessment summary is as follows: Apparatus Assessed: WiFi SD Card Model: 5006 Specification: FCC Part 15 Subpart C, 15.247 IC RSS-210 Issue 7 June 2007 Date Received in Laboratory: April 30, 2010 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 FCC ID: YC7-5006 Report Number: 2010 05149324 FCC IC: 8962A-5006 Specification: FCC Part 15 Subpart C, 15.247 Page 3 of 83 1.1 Report Release History REVISION DATE COMMENTS - May 7, 2010 Prepared By: Ferdinand Custodio - May 7, 2010 Initial Release: Alan Laudani Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko USA Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. TESTED BY: ___________________________________ Date: May 7, 2010 Ferdinand Custodio, EMC Test Engineer Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 FCC ID: YC7-5006 Report Number: 2010 05149324 FCC IC: 8962A-5006 Specification: FCC Part 15 Subpart C, 15.247 Page 4 of 83 TABLE OF CONTENTS Section1: Summary of Test Results ............................................................................ 2 1.1 Report Release History ..................................................................................... 3 Section 2: Equipment Under Test ................................................................................ 5 2.1 Product Identification ........................................................................................ 5 2.2 Samples Submitted for Assessment ................................................................. 5 2.3 Theory of Operation .......................................................................................... 6 2.4 Technical Specifications of the EUT ................................................................. 6 Section 3: Test Conditions ........................................................................................... 7 3.1 Specifications .................................................................................................... 7 3.2 Deviations From Laboratory Test Procedures ................................................... 7 3.3 Test Environment .............................................................................................. 7 3.4 Test Equipment ................................................................................................. 8 Section 4: Observations ............................................................................................... 9 4.1 Modifications Performed During Assessment ................................................... 9 4.2 Record Of Technical Judgements ..................................................................... 9 4.3 EUT Parameters Affecting Compliance ............................................................ 9 4.4 Test Deleted ...................................................................................................... 9 4.5 Additional Observations .................................................................................... 9 Section 5: Results Summary ...................................................................................... 10 5.1 Test Results .................................................................................................... 10 Appendix A: Test Results ........................................................................................... 11 Section 15.207(a) – Power Line Conducted Emissions................................................. 11 Section 15.215(c) – 20 dB Bandwidth ........................................................................... 20 Section 15.247(a)(2) – Minimum 6dB RF Bandwidth .................................................... 28 Section 15.247(b)(1) – Peak Output Power ................................................................... 35 Section 15.247(d) – Band-edge Compliance of RF Conducted …

Text truncated - open the document above for the full version.

FCC ID: YC7-5006 IC: 8962A-5006
