Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
DOC023.53.90137 AN-ISE sc ammonium and nitrate combination sensor USER MANUAL 07/2010, Edition 1 © HACH Company, 2010. All rights reserved. Printed in Germany 3 Table of Contents Section 1 Specifications.....................................................................................................................5 1.1 Dimensions ........................................................................................................................................ 6 Section 2 General Information..........................................................................................................7 2.1 Safety information ............................................................................................................................... 7 2.1.1 Hazard information in these operating instructions.................................................................... 7 2.1.2 Precautionary labels .................................................................................................................. 7 2.2 General information about the probe .................................................................................................. 8 2.3 Theory of operation............................................................................................................................. 9 Section 3 Installation.........................................................................................................................11 3.1 Unpack the probe ............................................................................................................................. 11 3.2 Unpacking the sensor cartridge ........................................................................................................ 12 3.2.1 Assembling the storage container including sensor cartridge.................................................. 13 3.2.2 Removing the cartridge from the transport container............................................................... 14 3.3 Probe assembly ................................................................................................................................ 15 3.4 Installation of the cleaning unit (optional) ......................................................................................... 17 3.5 Installation of the probe in the sample flow....................................................................................... 18 3.5.1 Position of the probe on the mount .......................................................................................... 19 3.5.2 Probe installation example....................................................................................................... 19 3.6 Connect the probe to the sc controller (non-hazardous location) with screw fittings ........................ 20 Section 4 Operation...........................................................................................................................21 4.1 How to use an sc controller .............................................................................................................. 21 4.2 Sensor setup..................................................................................................................................... 21 4.3 Sensor data logger ........................................................................................................................... 21 4.4 Sensor diagnostics menu ................................................................................................................. 21 4.5 Sensor setup menu........................................................................................................................... 22 4.6 Calibration/Matrix correction ............................................................................................................. 25 4.6.1 Sensor code calibration ........................................................................................................... 26 4.6.2 Matrix correction via LINK2SC................................................................................................. 26 4.6.3 Matrix correction overview ....................................................................................................... 26 4.6.4 Performing the matrix correction.............................................................................................. 27 4.6.4.1 MATRIX 1 correction (1 point matrix correction) ............................................................. 27 4.6.4.2 Value correction 1 ........................................................................................................... 28 4.6.4.3 Value correction 2 ........................................................................................................... 29 4.6.4.4 MATRIX 2 correction (2 point matrix correction) ............................................................. 30 Section 5 Maintenance.....................................................................................................................31 5.1 Maintenance schedule ...................................................................................................................... 31 5.2 Clean the sensor............................................................................................................................... 31 5.2.1 Polish the chloride electrode.................................................................................................... 31 4 Table of Contents 5.3 Replace the sensor cartridge ............................................................................................................32 5.4 Storage..............................................................................................................................................34 Section 6 Troubleshooting...............................................................................................................35 6.1 Error messages ......…
Text truncated - open the document above for the full version.
Product Service GmbH FCC ID:YCB-LXG440 IC: 5879A-LXG440
Product Service GmbH FCC ID: YCB-LXG440 IC: 5879A-LXG440
Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 EUROFINS PRODUCT SERVICE GMBH RF-EXPOSURE A SSESSMENT FCC 47 CFR 2.1091 IC RSS-102 Measurement probe for water analysis LXG440 FCC ID: YCB-LXG440 IC: 5879A-LXG440 REPORT NUMBER: G0M-1107-1261-C-2 Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 2 of 13 TABLE OF CONTENTS 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 5 1.4 Application details 5 1.5 Acronyms and abbreviations 5 1.6 Reference standards 6 1.7 Test item 7 1.8 Referenced documents 7 1.9 Additional information 7 2 Exposure Assessment 8 2.1 Device Types 8 2.2 Exposure Categories 8 2.3 MPE Limits 9 2.4 Transmission modes 12 2.5 Field strength measurement 12 2.6 Test equipment utilized 12 2.7 Exposure assessment 13 Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 13 1.2 Testing laboratory EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 660 DA KKS ACCREDITED TESTING LABORATORY DA KKS-REGISTRATION NUMBER: D-PL-12092-01-01 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 Test location, where different: Name : ./. Street : ./. Town : ./. Country : ./. Telephone : ./. Fax : ./. Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 13 1.3 Details of approval holder Name : HACH LANGE GmbH Street : Königsweg 10 Town : 14163 Berlin Country : Germany Telephone : +49 30 80986.231 Fax : +49 30 80986.283 Contact : Herr Florian Eckelmann Telephone : +49 30 80986.231 Manufacturer: (if applicable) Name : HACH LANGE GmbH Street : Königsweg 10 Town : 14163 Berlin Country : Germany 1.4 Application details Date of receipt of application : 20.07.2011 Date of receipt of test item : 20.07.2011 Date of assessment : 20.07.2011 1.5 Acronyms and abbreviations EUT : Equipment under Test TX : Transmission RX : Reception RBW : Measurement Resolution Bandwidth Pol : Measurement Polarization N/A : Not applicable Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 13 1.6 Reference standards Technical standards : FCC 47 CFR 1.1310 FCC 47 CFR 2.1091 FCC 47 CFR 2.1093 OET Bulletin 65 : ” Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Elec tromagnetic Fields” 1997 RSS-102 Issue 4 : “Radio Frequency (RF) Exposure Com pliance of Radiocommunication Apparatus (All Frequency Bands)”, 2010 Safety Code 6: “Limits of Human Exposure to Radiofre quency Electromagnetic Energy in the Frequency Range from 3 kHz to 300 GHz”, 2009 IEEE C95.3 : “IEEE Recommended Practice for Measure ments and Computations of Radio Frequency Electro magnetic Fields With Respect to Human Exposure to Such Fields, 100 kHz–300 GHz”, 2002 Health Canada : “Technical Guide for Interpretation and Compliance Assessment of Health Canada’s Radiofre quency Exposure Guidelines”, 2009 Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 13 1.7 Test item Description of test item : Measurement probe for water analysis Type identification : LXG440 Serial Number : 1386813 (old DC/DC-Converter Traco) 1386816 (new DC/DC-Converter Peak) Hardware version : XMF785-E Software version : DD 0.7 / AC 0.11 Radiation sources included : 125kHz RFID Equipment type : End product Exposure Category : Uncontrolled / General public Device type : Mobile 1.8 Referenced documents None 1.9 Additional information Two models have been tested and assessed. The model with serial number S/N:1386813 uses the old DC/DC-Converter Traco and the model with serial number S/N: 1386816 uses the new DC/DC- Converter Peak. Test Report No.: G0M-1107-1261-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 13 2 Exposure Assessment 2.1 Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re- located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is nor- mally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating struc- ture(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) 2.2 Exposure Categories Occupational / Controlled Exposure In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leav- ing the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF …
Text truncated - open the document above for the full version.
Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 EUROFINS PRODUCT SERVICE GMBH TEST-REPORT FCC 47 CFR PART 15 SUBPART C IC RSS 210 ISSUE 8 Measurement probe for water analysis LXG440 FCC ID: YCB-LXG440 IC: 5879A-LXG440 TEST REPORT NUMBER: G0M-1107-1261-P-15 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 5 1.4 Application details 5 1.5 Acronyms and abbreviations 5 1.6 Test standards 6 1.7 Test item 6 1.8 Additional information 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Test equipment utilized 8 2.4 Sample emission level calculation 9 2.5 Test results 10 3 Informational Transmitter parameters 11 3.1 Occupied Bandwidth 11 4 Transmitter parameters 12 4.1 Radiated Emissions 12 5 Receiver parameters 16 5.1 Receiver spurious emissions 16 6 Power Line parameters 18 6.1 AC power line conducted emissions 18 Annex A Photos 19 Annex B Transmitter occupied bandwidth 24 Annex C AC Power line Conducted Emissions 26 Annex D Fundamental emissions 30 Annex E Transmitter radiated emissions 3 3 Page 2 of 41 Page 3 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D-15526 Reichenwalde b. Berlin Germany Telephone :+49 33631 888 00 Telefax :+49 33631 888 660 DA KKS ACCREDITED TESTING LABORATORY DA KKS-REGISTRATION NUMBER: D-PL-12092-01-01 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 Test location, where different: Name : ./. Street : ./. Town : ./. Country : ./. Telephone : ./. Fax : ./. Page 4 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.3 Details of approval holder Name : HACH LANGE GmbH Street : Königsweg 10 Town : 14163 Berlin Country : Germany Telephone : +49 30 80986.231 Fax : +49 30 80986.283 Contact : Herr Florian Eckelmann Telephone : +49 30 80986.231 Manufacturer: (if applicable) Name : HACH LANGE GmbH Street : Königsweg 10 Town : 14163 Berlin Country : Germany 1.4 Application details Date of receipt of application : 20.07.2011 Date of receipt of test item : 20.07.2011 Date of test : 20.07.2011 1.5 Acronyms and abbreviations EUT : Equipment under Test TX : Transmission RX : Reception RBW : Measurement Resolution Bandwidth Pol : Measurement Polarization e.r.p. : Effective radiated power e.i.r.p. : Equivalent isotropic radiated power T nom : Nominal Temperature T min : Minimum Temperature T max : Maximum Temperature V nom : Nominal Supply Voltage V min : Minimum Supply Voltage V max : Maximum Supply Voltage VDC : DC voltage N/A : Not applicable IC : Industry Canada Page 5 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.6 Test standards Technical standard : FCC 47 CFR PART 15 SUBPART C IC RSS 210 ISSUE 8 1.7 Test item Description of test item : Measurement probe for water analysis Type identification : LXG440 Serial number : 1386813 (old DC/DC-Converter Traco) 1386816 (new DC/DC-Converter Peak) Hardware version : XMF785-E Software version : DD 0.7 / AC 0.11 Equipment type : End product Technical data Radio type : Transceiver Radio technology : 125kHz RFID Frequency range : 125 kHz +/- 875Hz Assigned frequency band : Non-specific Tested frequencies : F 1 125kHz Antenna type(s) : integral Antenna model(s) : ZDA486 (internal HACH LANGE Part Number) Number of antennas : 1 Antenna gain(s) : Unspecified Power supply : 12VDC (power supplied from controller device) Duty cycle(s) : Unspecified Spreading technique : None Modulation(s) : OOK Device classification : Mobile Device (Human Body distance > 20 cm) 1.8 Additional information Two models have been tested. Model with serial number S/N:1386813 uses the old DC/DC- Converter Traco and the model with serial number S/N: 1386816 uses the new DC/DC-Converter Peak. Page 6 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests performed. 2.2 Test environment Temperature : 22 ... 26°C Relative humidity content : 20 ... 75% Air pressure : 86 ... 103kPa Extreme conditions parameters: V nom : 12VDC V min : N/A V max : N/A T nom : 25°C Other parameter: None Page 7 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.3 Test equipment utilized Measurement Equipment List No.: Measurement device: Type: Manufacturer: Last Cal. Next Cal. ETS 0086 Semi-anechoic chamber AC1 Frankonia 09.12.2010 09.12.2012 ETS 0253 Spectrum Analyzer FSIQ26 Rohde & Schwarz 04.11.2010 04.11.2012 ETS 0030 Biconical Antenna HK 116 Rohde & Schwarz 10.02.2011 20.02.2012 ETS 0295 LPD Antenna HL 223 Rohde & Schwarz 09.02.2011 09.02.2012 ETS 0018 Horn Antenna BBHA 9120D Schwarzbeck 26.08.2010 26.08.2011 ETS 0432 Amplifier-Matrix 02.06.2010 02.06.2012 ETS 0496 Spectrum Analyzer FSP30 Rohde & Schwarz 26.08.2010 26.08.2011 ETS 0288 LISN ESH2-Z5 Rohde & Schwarz 07.09.2010 07.09.2012 Page 8 of 41 Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.4 S…
Text truncated - open the document above for the full version.
Test Report No.: G0M-1107-1261-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TEST SETUP RADIATED EMISSIONS TEST SETUP CONDUCTED EMISSIONS Page 20 of 37
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.125 MHz - 0.125 MHz | - |

RFID Module
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
The LOC 100 RFID Tag read/write device can be used to write the operator ID and location ID to a RFID label on a sampling bottle together with the time and date. This information (sample ID) can then be read by an RFID-compatible photometer
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
