YCNA6000LLenovo Mobile Phone

Read this guide carefully before using your smartphone. Quick Start Guide v1.0 Lenovo A6000-l Type: CMOS Pixels: 8.0 megapixels (back) + 2.0 megapixels (front) Processor: Qualcomm MSM8916, Quad Core, 1.2GHz Size: 5.0 inches Screen: multi-touch Resolution: 1280 × 720 pixels LCD type: IPS Model: Lenovo A6000-l System: Android Battery: 2300 mAh Height: 140.9 mm (5.547 inches) Width: 70.55 mm (2.778 inches) Depth: 8.2 mm (0.323 inch) Weight: 129.6 g (0.286 lb) Model and system Depending on the measuring method, the dimensions and weight might vary slightly. In some countries, LTE is not supported. To know if your smartphone works with LTE networks in your country, contact your carrier. Display Battery Processor Dimensions and weight Camera Wireless Communication Technical specifications Bluetooth 4.0; WLAN 802.11 b/g/n; LTE, WCDMA, GSM; GPS 654 Microphone Flashlight Micro USB connector SpeakerOn/Off button Volume buttons Home key 7 10 13 8 11 9 12 Front-facing camera Headset connector Rear-facing camera 12 Receiver 3 Back key Menu key First glance You must insert the SIM card provided by your carrier to use cellular services. Set up your smartphone as shown. Step 1. Open the back cover. Step 2. Insert the SIM card and the memory card. Step 3. Install the battery. a. Align the battery connectors on the battery with the pins in the battery compartment. b. Push the battery down into place. Step 4. Install the back cover. Always turn off your smartphone first before you insert or remove a SIM card. Insert or remove a SIM card with your smartphone on may damage your SIM card or smartphone permanently. a b SIM SIM Preparing your smartphone Turning on or turning off your smartphone Turn on: Press and hold the On/Off button until the Lenovo logo appears. Tur n of f : Press and hold the On/Off button for a few seconds, then tap Power off. Reboot : Press and hold the On/Off button for a few seconds, then tap Reboot . Your smartphone has a rechargeable battery. For more information about battery safety, see the “Rechargeable battery notice” in the Important Product Information Guide shipped with your smartphone. Low battery powerFully chargedCharging 2 1 Charge the battery as shown. Method 1. Method 2. Connect your smartphone to a power outlet using the cable and USB power adapter that come with your smartphone. Connect your smartphone to a computer using the cable that comes with your smartphone. Charging the battery FCC statement FCC statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communi- cations. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAR information statement Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is XXX W/Kg and when worn on the body, as described in this user guide, is XXX W/Kg (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). The maximum scaled SAR in hotspot mode is XXX W/KG, While there may be differe…

Text truncated - open the document above for the full version.
